XWEB300D/500D PRO
(V.1.0)

INDEX
1. PRODUCT DISPOSAL (WEEE)................................................................................................5
2. THE RECIPIENTS OF THIS MANUAL.......................................................................................5
3. PACKAGE.............................................................................................................................6
4. TECHNICAL DATA.................................................................................................................7
5. INSTALLATION......................................................................................................................8
5.1 XWEB............................................................................................................................... 8
5.2 CONTROLLERS................................................................................................................. 10
5.3 CONFIGURATION FOR XC400/600/800/900 and XH200/300/400 SERIES .................................. 11
5.4 CONFIGURATION FOR XJA/XJP/XJM MODELS ....................................................................... 11
6. REMOTE CONNECTIVITY ..................................................................................................... 12
6.1 DESKTOP SOFTWARE REQUIREMENTS (PC).......................................................................... 12
6.2 SOFTWARE MOBILE REQUIREMENTS (SMARTPHONE/TABLET)................................................ 12
6.3 CROSSOVER CABLE INSTRUCTIONS ..................................................................................... 13
6.4 INTRANET CONNECTIVITY (“OR LAN CONNECTION”) AND VPN................................................ 14
6.5 INTERNET CONNECTIVITY ON PUBLIC IP .............................................................................. 15
6.6 WIFI CONNECTIVITY ......................................................................................................... 16
7. EMERGENCYPROCEDURE.................................................................................................. 17
8. OPERATIVE PROCEDURES.................................................................................................. 19
9. SYSTEM IDENTIFICATION.................................................................................................... 19
10. TRADEMARKS..................................................................................................................... 19
11. NOTE.................................................................................................................................. 20

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 3/20
CAUTION: TO PREVENT FLAMES FROM DEVELOPING OR ELECTRIC SHOCK,
AVOID ANY CONTACT BETWEEN THIS DEVICE AND RAIN OR WATER
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER IT DOES NOT
CONTAIN ANY PARTS THAT REQUIRE SERVICING BY
THE USER ALWAYS HAVE QUALIFIED STAFF
PERFORM THE PROCEDURES.
THE SYMBOL OF THE LIGHTNING BOLT INSIDE AN
EQUILATERAL TRIANGLE IS USED TO ALERT THE
USER OF THE POTENTIALLY DANGEROUS NON-
INSULATED ELECTRICAL VOLTAGES
THE SYMBOL OF THE EXCLAMATION MARK INSIDE
AN EQUILATERAL TRIANGLE IS USED TO WARN THE
USER THAT HE/SHE MUST PAY CLOSE ATTENTION
TO THE TOPIC COVERED IN THIS MANUAL
CAUTION
This device must be installed exclusively by service staff with suitable technical
training and experience,who are aware of the dangers that they are exposed to.
The operationsdescribed herein are set forth exclusivelyfor the service staff. The
user is not enabled to open the device.
CAUTION
Use only modems and usb-donglesofficially supported by this monitoring unit. Dixell
srl. cannot be held responsible for any type of damage resulting from the use of
unsupported devices.
CAUTION
Dixell srl reserves therightto amend thismanual withoutprior notice. The latest
available version can be downloaded fromthe internet site.
CAUTION
Immediatelyafter the powerfailure,no new data is recorded; all recorded data is
kept in non-volatile memory. The memory is electronic and no data is kept or
conveyed to other media such as paper. When the memoryis exhausted,the oldest
data is lost to store the most recent data. The product provides memory
consumption indications on the userinterface.The device does not have its own
power supply. The recording interval can be configured from a minimum of 30
seconds to a maximum of1 day. The duration of the recordings depends on the
interval and the number of points configured for each device in configuration. One
yearof data logging is guaranteed for 2 analog resources with an interval of 15
minutes, per configured device. Selecting other resources can affect storage
performance.
CAUTION
This is a Class A product. In a domestic environment, this productmay cause radio
interference in which case the user maybe required to take adequate measures
CAUTION
Dixell srl reserves therightto varythe composition of its products without prior
notice to the customer, ensuring the identical and unchanged features of the same

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 4/20
CAUTION
The product is not suitable forenvironments subject to mechanical vibrations and
does not withstand shocks. It must be installed in a dry and clean environment.
CAUTION
The customershall bearfull responsibilityand riskfor product configuration inorder
to achieve the results pertaining to installation and/or final equipment/system. Upon
the customer's request and following a specific agreement, Dixell s.r.l. maybe
present during the start-up ofthe final machine/application, as a consultant,
however, under no circumstancescanthe company be held responsible for the
correct operation of the final equipment/system.
CAUTION
Since Dixellproducts formpart of a very high level of technology, a
qualification/configuration/programming/commissioning stage is required to use
them as best as possible.Otherwise,these products maymalfunction and Dixell
cannot be held responsible. The product must notbe used in any way thatdiffers
from thatstipulated in the documentation

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 5/20
1. PRODUCT DISPOSAL (WEEE)
With reference to the DIRECTIVE 2012/19 / UE OFTHE EUROPEAN PARLIAMENTAND OF THE
COUNCIL of 4 July 2012 on Waste Electrical and Electronic Equipment (WEEE), and to the relevant national
implementation regulations, we inform you thatusers ofEEE in households:
➢there is an obligation not to dispose of WEEE as mixed urban waste and to separate waste collection of
WEEE;
➢Public orprivate collection systems required by local laws must be used for disposal. It is also possible,
at the end of its life,to return the equipment to the distributor in case of purchase of a newone.
➢This equipmentmay contain hazardous substances; improper use or incorrect disposal could have
negative effects on human health and the environment.
➢The symbol shown on the product or on the packaging indicates that the product must be treated
with separate waste.
➢In case of incorrect disposal,sanctions can be applied as established by the local laws on waste
disposal.
2. THE RECIPIENTS OF THIS MANUAL
The contents of thismanual are intended forprofessionalusers, such as XWEB installers. It may also be of
use to the administrator of the network that it is connected to.
The mechanical product drawings required for any form of intervention and the possible network
configurationsare all an integral partof this manual.

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 6/20
3. PACKAGE
Before opening the package make sure that the packaging is intact and that there is no sign of impact or
tampering. Before starting anyoperation, it is necessary to check that the XWEB boxcontains:
•1 XWEB Unit
•1 Installation Manual
•1 cross cable 1mt
•Removable female connector
•
XWEB300
- 2x2 ways (1 green and 1 black)
- 2x3 ways
XWEB500
- 2x2 ways (2 greene 1 black)
- 1x3 ways
- 1x7 ways
•1 Jumper 2 vie
If one of the following parts is damaged, promptly contact your dealer.
You may also receive a modem or a wifi dongle- which will not be included in the same package - as a
package option.When working with a modemconnection, always check that the type of modem you are
about to install is a Dixell approved model;as it cannot be held responsible for the malfunctioning of devices
not expressly approved by it.

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 7/20
4. TECHNICALDATA
Dimensions
175 x 110 x 41 mm
Mounting
DINrail mounting device
Degree of Protection
Indoor use, Open Type (NEMA - UL 50e)
IP20 (EN60529)
Power supply
100-240VAC ±10%
Power supply frequency
50/60 Hz
Overvoltage Category
I
Rated power
15VA Max
Rated Impulse Voltage
2500V
Type of Action
1B
PollutionDegree
2
Ambient Operating
Temperature
-10T60°C
Shippingand storage
temperature
-40T85°C
Field wiringterminal
identification, wire size and
torque value
The serial line cable can be of the two-wire type plus the shield, with a
minimum section of 0.5mm2 (eg BELDEN 8772).
Internal battery and RTC
accuracy
Rechargeable and non-removable lithium battery. 50ppmfor temperature
variation up to 60 ° C, 5ppmfor aging. The maximumdrift of the clock in a
yearis therefore 33 min peryear
Digital Inputs
Optoisolated with common at + 12Vdc (isolated), connectable via 2-way
terminal block. Presentonly forXWEB500D
Digital Outputs
AUX1-2-3 clean contacts for 24/120 / 240Vacmax 5A resistive loads.
AUX1 port ("Systema Alarm") in exchange;connectable via 3-way
terminal block; always present. AUX2 ('Alarm 1') and AUX3 ('Alarm 2')
ports thatcan be connected via a 2-way terminal block; presentonly for
XWEB500D.
"Pwr Ext Modem"clean contacts 12Vdcmax 250mA connectable via 2-
way terminal block;alwayspresent
RS485 Ports
RS485 port 1: optically isolated (always present)
RS485 port 2: optically isolated (onlyfor XWEB500D)
USB Ports
1 standard HOSTconnector type A port
Maximum deliverable current500 mA
Purpose of control
Operating control
Construction of control
Incorporated control, intended to be used in Class Ior Class II equipment
Approvals
CE, UL. The system consisting of this control and monitoring unitand
Dixell temperature meters compliantwith the EN13485 standard complies
with the EC regulation no. 37/2005 and in particularwith the EN12830
standard.Temperature recorders for the transport and storage and
distribution of chilled, frozen,deep-frozen and ice-creamproducts (UNI
EN 12830, S, A, 1, measurementrange corresponding to the class of
connected devices)
CAUTION
The terminal board for connecting the relays can be used to directly
drive high voltage loads (higher than 24V) but the voltages between
the different terminals cannot be mixed.

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 8/20
5. INSTALLATION
5.1 XWEB
For installation, the XWEBsystemmust notbe open in any way. If the boxis opened,the guarantee
becomes void. Installation cantake place in different ways depending on the modeland thetype of access to
the user interface that you wantto provide to the end user. The particularitiesof these types ofconnectivity
are described in this manual.
ATTENTION: in order to protect both yourself and the XWEB, the unitmust be switched on only when all the
electrical deviceshave already been connected.In order to avoid accidental switching on,insertthe power
cable only after connecting all the otherexternalunits.
TERMINAL BLOCK
26
27
Alarm Relay 1 (**)
1
2
PowerXWEB
28
29
Alarm Relay 2 (**)
33
34
External GSM modem power supply (*)
30
31
32
SystemAlarm Relay
* 30-31No Allarm
* 30-32 Alarm
USB port
6
7
Ingresso digitale (**)
COM port
14
15
16
RS485 A port
RJ45 port
17
18
19
RS485B port (**)
LED
Led
Colour
Description
Alarm
Red
RS485 alarm
Rec
Blue
Data recording
Power
Green
Systemturned on
Status
Green
Messages are being sent
System
Red
Systemalarm
Alarm2
Red
Alarm relay2 status(**)
Alarm1
Red
Alarm relay1 status(**)
(*)= 12Vdc - 250mA. Compatible modem TC35-KIT (MC55i by Siemens, CINTERION L30960N2700A100),
Gatetel GT-HE910-EUD, Gatetel GT-HE910-NAD
(**)= For XWEB 500DINonly

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 9/20
ATTENTION: the status of the System LED is linked to thatof the corresponding "Systemalarm"relay
ATTENTION: for XWEB300D the 'relaysystem' as AUXassumesthe following logic:
• at rest (XWEB off) contacts 30 and 32 are closed
• in the event of an alarm, it closes at 30-31
• when switched on, it closesfor a few seconds at 30-31. then if there are no alarms it returns to rest and
closesat 30-32.
ATTENTION: always use the power supply of the external modem from the XWEB itself to ensure the
correct sending of messages(for example SMS). In other words, use the cable supplied in the modem KIT
on terminals 33-34.
ATTENTION: the 'resetmodem' relay is energized for reset, in conditions of non-use every two minutes; and
before each activation of the service. It is necessaryto insert this relay in the power supply circuit of the
external modem to ensure the correct sending of messages(SMS).
ATTENTION: During the initial start-up phase, the STATUS, REC and ALARM LEDs FLASH at regular
intervals. This flashing IS NORMAL and highlights the regular progress of the ignition phase which can last
up to 5 minutes.
•Avoid direct passage between operators as much as possible (to avoid electrostatic
induction and subsequent discharges);
•If the electrical voltage supply differs from the required rating, this could seriously damage
the system;
•Connection errors (and connections that differ from the prescribed ones) can pose a danger
to operator safety and cause faults in the system and to the instruments that are connected
to it;
•Insert one or more easily accessible disconnecting devices to the exterior of the device to
separate the device from the power mains;
•Do not use the device in environments with flammable gases.
•Do not modify the device in any way.

1592028040 XWEB300D_500D_PRO STP GB r1.0 25.11.2020.doc XWEB PRO 10/20
5.2 CONTROLLERS
XWEB has at least one RS485 serial port, on which the line of the controller devices can be connected. If
there are more serials, more device linescan be served.
Most Dixell controllerdevices are equipped with an RS485 serialoutput and can be connected without the
need for any additional module or connection cable. To make sure of this possibility, check the
characteristics of the controller in its manual.
Some Dixell devices however, may not be direct, but it can be obtained via the small external Dixell
XJRS485 or DixellXJ485 converter.It converts the controller outputfrom "TTL" (five wires) to "485" (two
wires). If you need to use the TTL / 485 converter, please payattention in:
•Keep the TTL cable away from any source of electromagnetic disturbance
•Connect each XJ485 module to the instrumentwith the TTL cable supplied with the module itself
•Mark the polarityof output 485 which must be respected when connecting the instruments to the
network
Below is a list of operating tipsto obtain the best result in terms of instrument net work reliability, RS485
serial connection:
•The serial line cable can be of the two-wire type plus the shield, with a minimumsection of 0.5mm2
(eg BELDEN 8772). This cable isrecommended for its technical characteristics and formaintaining
the quality of the electrical signal;
•The serial line cable must reachall the instrumentstations: check the plant layout and the various
distances thatthe cable will have to travel;
•The serial line cable can reach a maximum length of 1 km
•Respect the polaritiesindicated on the instrument withthose ofthe cablesleading to the serial
•Keep the serial cable away from power cables and any possible source of electromagnetic
disturbance
•Do not connectthe shield of the serial cable to the earth of the electrical system
•Do not connect the “Gnd” terminal.
•Drawa map of the installation you are performing: itwill beusefulboth in case of problems and in
case of future changes; the serial line must reach all the stations where the instruments must be
controlled.
