Emerson Rosemount Analytical X-STREAM Enhanced... How to use

www.EmersonProcess.com
Short Form Manual
HASXEE-SFM-HS
05/2017
Gas Analyzers
X-STREAM Enhanced Series
Short Form Manual

ESSENTIAL INSTRUCTIONS
READ THIS PAGE BEFORE PROCEEDING!
Emerson Process Management (Rosemount Analytical) designs, manufactures and
tests its products to meet many national and international standards. Because these
instruments are sophisticated technical products, you MUST properly install, use, and
maintain them to ensure they continue to operate within their normal specications.
The following instructions MUST be adhered to and integrated into your safety program
when installing, using and maintaining Emerson Process Management (Rosemount
Analytical) products. Failure to follow the proper instructions may cause any one of the
following situations to occur: Loss of life; personal injury; property damage; damage to
this instrument; and warranty invalidation.
• Read all instructions prior to installing, operating, and servicing the product.
• If you do not understand any of the instructions, contact your Emerson Process
Management (Rosemount Analytical) representative for clarication.
• Follow all warnings, cautions, and instructions marked on and supplied with the
product.
• Inform and educate your personnel in the proper installation, operation, and
maintenance of the product.
• Install your equipment as specied in the Installation Instructions of the
appropriate Instruction Manual and per applicable local and national codes.
Connect all products to the proper electrical and pressure sources.
• To ensure proper performance, use qualied personnel to install, operate, update,
program, and maintain the product.
• When replacement parts are required, ensure that qualied people use replacement
parts specied by Emerson Process Management (Rosemount Analytical).
Unauthorized parts and procedures can affect the product’s performance, place the
safe operation of your process at risk, and VOID YOUR WARRANTY. Look-alike
substitutions may result in re, electrical hazards, or improper operation.
• Ensure that all equipment doors are closed and protective covers are in place,
except when maintenance is being performed by qualied persons, to prevent
electrical shock and personal injury.
The information contained in this document is subject to change without notice.
8th edition 05/2017
Emerson Process Management GmbH & Co. OHG
Rosemount Analytical
Process Gas Analyzer Center of Excellence
Industriestrasse 1
63594 Hasselroth, Germany
T [phone]
F [phone]
www.RosemountAnalytical.com

Emerson Process Management GmbH & Co. OHG TOC-1
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
TOC Table of contents
Table of ConTenTs
Introduction S-1
Denitions S-1
Terms Used in This Instruction Manual ......................................... S-2
Symbols Used on and Inside the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . S-3
Symbols Used in This Manual ................................................ S-4
Safety Instructions S-5
Intended Use Statement..................................................... S-5
General Safety Notice / Residual Risk .......................................... S-5
Additional Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . S-5
Authorized Personnel ....................................................... S-6
Disposal of Batteries........................................................ S-6
Installing and Connecting This Analyzer......................................... S-7
Operating and Maintaining This Analyzer........................................ S-7
Chapter 1 Technical Description 1-1
1.1 Overview .............................................................1-2
1.1.1 Housings ............................................................1-2
1.1.2 The Front Panel.......................................................1-2
1.1.3 Interfaces............................................................1-3
1.2 Comparison of the Various X-STREAM Analyzer Model .........................1-4
1.3 X-STREAM XEGK: ½ 19 Inch Table-Top Unit .................................1-6
1.4 X-STREAM XEGP: 19 Inch Table-Top or Rackmount Design .....................1-8
1.5 X-STREAM XEXF: Field Housing With Single (XEF) or Dual (XDF) Compartment ...1-10
1.5.1 XEXF Field Housings for Installation in Hazardous Areas (Ex-Zones) ............1-13
1.6 Measurement Specications ...........................................1-14
Chapter 2 Installation 2-1
2.1 Scope of Supply........................................................2-1
2.2 Introduction ...........................................................2-2
2.3 Technical Data .........................................................2-3
2.3.1 Common Technical Data ................................................2-3
2.3.2 Specic Technical Data .................................................2-4
2.4 Gas Conditioning .....................................................2-5
2.5 Gas Connections .......................................................2-7
2.6 Electrical Connections ...................................................2-9
2.6.1 X-STREAM XEGK, X-STREAM XEGP ....................................2-11
2.6.2 X-STREAM XEXF ....................................................2-16
2.7 Notes on Wiring Signal Inputs and Outputs ..................................2-24
2.7.1 Electrical Shielding of Cables ...........................................2-24

Emerson Process Management GmbH & Co. OHGTOC-2
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Table of Contents
2.7.2 Wiring Inductive Loads ................................................2-26
2.7.3 Driving High-Current Loads.............................................2-26
2.7.4 Driving Multiple Loads .................................................2-27
Chapter 3 Startup 3-1
3.1 Introduction ...........................................................3-1
3.2 Performing a Leak Test ..................................................3-2
3.3 Symbols and Typographical Conventions ....................................3-3
3.4 Front Panel Elements ...................................................3-4
3.4.1 Display..............................................................3-4
3.4.2 Status Line and Text Message Line........................................3-4
3.4.3 Keys 3-5
3.5 Software..............................................................3-7
3.5.1 Access Levels & Codes................................................3-10
3.5.2 Special Messages ....................................................3-11
3.6 Powering Up .........................................................3-11
3.6.1 Boot Sequence ......................................................3-11
3.6.2 Measurement Display .................................................3-11
3.7 Language Settings .....................................................3-13
3.8 Checking the Settings ..................................................3-14
3.8.1 Installed Options .....................................................3-15
3.8.2 Conguring the Display ................................................3-16
3.8.3 Calibration Setup.....................................................3-17
3.8.4 Setting the Analog Outputs .............................................3-19
3.8.5 Setting Concentration Alarms ...........................................3-24
3.8.6 Backup the Settings ..................................................3-25
3.9 Web Browser .........................................................3-27
3.9.1 Connection Via Network ...............................................3-27
3.9.2 Connection to Single Computer .........................................3-28
Chapter 4 Maintenance 4-1
4.1 Perform a Calibration ....................................................4-1
4.1.1 Preparing Calibrations..................................................4-3
4.1.1.1 Manual Zero Calibration...............................................4-5
4.1.1.2 Manual Span Calibration ..............................................4-7
Chapter 5 Dismounting and Disposal 5-1
5.1 Dismounting and Diposal of the Analyzer ....................................5-1
Appendix A-1
A.1 Block Diagram ........................................................ A-2
A.2 Assignment of Terminals and Sockets ..................................... A-17
A.2.1 Tabletop & Rack Mount Analyzers....................................... A-17
A.2.2 Field Housings...................................................... A-18

Emerson Process Management GmbH & Co. OHG TOC-3
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
TOC Table of contents
Index of fIgures
Fig. 1-1: X-STREAM XE Front Panel (here the X-STREAM XEGP) ..................1-3
Fig. 1-2: X-STREAM XEGK .................................................1-7
Fig. 1-3: X-STREAM XEGP - Details ..........................................1-9
Fig. 1-4: X-STREAM XEF / XDF- Front Views ..................................1-11
Fig. 1-5: X-STREAM XEF - Side and Bottom View...............................1-12
Fig. 1-6: X-STREAM XEF - Power Supply and Signal Terminals ....................1-12
Fig. 2-1: X-STREAM XE Analyzers - Scope of Supply .............................2-1
Fig. 2-3: Installation in Bypass Mode ..........................................2-8
Fig. 2-2: Labelling of Gas Connectors (example) .................................2-8
Fig. 2-4: X-STREAM XEGK - Rear Panel......................................2-11
Fig. 2-5: X-STREAM XEGP - Rear View ......................................2-12
Fig. 2-6: X-STREAM XEGP - Dimensions .....................................2-13
Fig. 2-7: Socket X1 - Analog Outputs & Digital Outputs 1-4 .......................2-14
Fig. 2-8: Power Supply Connectors ..........................................2-15
Fig. 2-9: X-STREAM XEF - Dimensions for Installation...........................2-16
Fig. 2-10: X-STREAM XDF - Dimensions for Installation ..........................2-17
Fig. 2-11: X-STREAM XEXF Field Housings - Arrangement of Terminals, Cable Glands and
Gas Connectors ..................................................2-18
Fig. 2-12: Terminal Block X1 - Analog Signals and Relay Outputs 1-4 (XSTA) ..........2-21
Fig. 2-13: Power Supply Connections .........................................2-22
Fig. 2-14: Shielded Signal Cable, Shielding Connected At Both Ends. ................2-24
Fig. 2-15: Shielded Signal Cable, Shielding Connected At One end. ..................2-24
Fig. 2-16: Signal Cable With Double Shielding, Shieldings Connected AtAlternate Ends. .2-25
Fig. 2-17: Shield Connector Terminal With Cable.................................2-25
Fig. 2-18: Suppressor Diode for Inductive Loads. ................................2-26
Fig. 2-19: Driving High-Current Loads .........................................2-26
Fig. 2-20: Loads in Series...................................................2-27
Fig. 2-21: Loads in Parallel ..................................................2-27
Fig. 3-1: Leak Testing With U-Turn Manometer ..................................3-2
Fig. 3-2: X-STREAM XE Front Panel ..........................................3-4
Fig. 3-3: Arrangement of Concentration Thresholds..............................3-24
Fig. 3-4: Ethernet Connectors...............................................3-27
Fig. 3-5: Web Browser Logon Screen.........................................3-29
Fig. 3-6: Web Browser Measurements Screen..................................3-29

Emerson Process Management GmbH & Co. OHGTOC-4
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Index of Tables
Tab. 1-1: Gas Components and Measuring Ranges, Examples ......................1-14
Tab. 1-2: IR, UV, VIS, TCD - Standard and Enhanced Measurement Performance
Specications ....................................................1-15
Tab. 1-3: Trace Moisture - Standard Measurement Performance Specications .........1-15
Tab. 1-4: Oxygen - Standard and Enhanced Measurement Performance Specications ...1-16
Tab. 1-5: H2S - Standard Measurement Performance Specications ..................1-16
Tab. 1-6: Special Performance Specications for Gas Purity Measurements (Low Ranges)1-17
Tab. 1-7: Special Performance Specications for Gas Purity Measurements (Suppressed
Ranges) ........................................................1-18
Tab. 3-1: Analog Output Signals ..............................................3-20
Tab. 3-2: Analog Output Signals Settings and Operational Modes ....................3-22

Emerson Process Management GmbH & Co. OHG S-1
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
This short form manual provides information on installation and startup of the
X-STREAM®Enhanced Series gas analyzers. For comprehensive instructions see the
X-STREAM Enhanced Series instruction manual.
This manual covers several X-STREAM Enhanced analyzer models and so may contain
information about congurations and/or options not applicable to your analyzer.
The installation and operation of units for use in explosive (hazardous) environments is
not covered in this manual.
Analyzers intended to be used in such environments are supplied with further instruction
manuals, which should be consulted in addition to this.
INTRODUCTION
The following denitions apply to WARNINGS, CAUTIONS and NOTES found throughout
this publication.
DEFINITIONS
NOTE!
Highlights an essential operating procedure, condition or statement.
HIGHLIGHTS AN OPERATION OR MAINTENANCE PROCEDURE,
PRACTICE, CONDITION, STATEMENT, ETC.
If not strictly observed, could result in injury, death, or long-term health
hazards of personnel.
HIGHLIGHTS AN OPERATION OR MAINTENANCE PROCEDURE,
PRACTICE, CONDITION, STATEMENT, ETC.
If not strictly observed, could result in damage to or destruction of
equipment, or loss of effectiveness.

Emerson Process Management GmbH & Co. OHGS-2
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
TERMS USED IN THIS INSTRUCTION MANUAL
Lower Explosion Limit (LEL)
Volume ratio of ammable gas in air below
which an explosive gas atmosphere will not
be formed: the mixture of gas and air lacks
sufcient fuel (gas) to burn.
Upper Explosion Limit (UEL)
Volume ratio of ammable gas in air above
which an explosive gas atmosphere will not
be formed: the mixture of gas and air is too
rich in fuel (decient in oxygen) to burn.
Flammable Gas(es)
Gases and gas mixtures are assigned to be
ammable if they might become ignitable
when in a mixture with air.
Explosive Gas(es)
Flammable Gases and gas mixtures in a mix-
ture with air within the explosive limits.
Infallible Containment
This term is derived from the standards of
explosion protection especially from the re-
quirements for pressurized housings: thus an
infallible containment can be characterized
by no intended leakage out of the gas paths
enabling gas to enter the inner compartment
of the analyzer housing.
NAMUR
NAMUR is an international user association of
automation technology in process industries.
This organisation has issued experience re-
ports and working documents, called recom-
mendations (NE) and worksheets (NA).
Protection Class IP66 / NEMA 4X
Both terms are used to specify conditions for
equipment to be installed outdoor.
IP stands for Ingress Protection, the rst num-
ber species protection against solid objects
(6. = dust tight) while the second number
species the degree of protection against
liquids (.6 = heavy seas).
NEMA stands for National Electrical Manu-
facturers Association. 4X species a degree
of protection to personnel against incidental
contact with the enclosed equipment; to pro-
vide a degree of protection against falling dirt,
rain, sleet, snow, windblown dust, splashing
water, and hose-directed water; and that will
be undamaged by the external formation of
ice on the enclosure

Emerson Process Management GmbH & Co. OHG S-3
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
SYMBOLS USED ON AND INSIDE THE EQUIPMENT
This symbol at the instrument ... ... means
dangerous voltages may be accessible. Remov-
ing covers is permitted only, if the instrument is
disconnected from power - and even in this case
by qualied personnel only!
hot surfaces may be accessible. Removing
covers by qualied personnel is permitted only,
if the instrument is disconnected from power.
Nevertheless several surfaces may remain hot
for a limited time.
more detailled information available: see in-
struction manual before proceeding!
more detailled information available: see in-
struction manual before proceeding!
Wherever one or more of the following symbols appear on or inside the instrument, be careful
and read the instructions given in the accompanying manuals!
Strictly observe the given warnings, instructions and information to minimize hazards!

Emerson Process Management GmbH & Co. OHGS-4
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SYMBOLS USED IN THIS MANUAL
Where one or more of the following symbols appear within this manual, carefully read the relat-
ed information and instructions!
Strictly observe the given warnings, instructions and information to minimize hazards!
This symbol used in the manual ... ... means
dangerous voltages may be exposed
hot surfaces may be exposed
possible danger of explosion
toxic substances may be present
substances harmful to health may be present
indicates notes relating to heavy instruments
electrical components may be destroyed by
electrostatic discharges
units must be disconnected from the power
source
indicates special instructions or information for
operation at low temperatures.
indicates basic conditions or procedures are
being described.
This symbol may also indicate information import-
ant for achieving accurate measurements.

Emerson Process Management GmbH & Co. OHG S-5
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
INTENDED USE STATEMENT
X-STREAM series gas analyzers are intended to be used as analyzers for industrial pur-
poses. They must not be used in medical, diagnostic or life support applications nor as
safety devices.
Using X-STREAM Enhanced Series analyzers as safety devices, requiring redundant design
or SIL classication, is also not permitted. They must not be used to measure explosive
gas mixtures.
No independent agency certications or approvals are to be implied as covering such
applications!
SAFETY INSTRUCTIONS
ADDITIONAL LITERATURE
This manual deals with instructions on how to safely install and startup X-STREAM X2
series analyzers, intended to be operated in general purpose (safe) areas, only.
DO NOT use this manual for instruments to be installed in hazardous areas!
For comprehensive information on operating and maintain/service the instrument in a
safe manner it is MANDATORY to read all additional instruction manuals, if not provided
as printed version, see the accompanying USB stick for an electronic version (PDF)!
The following additional instruction manuals are available or referenced within this manual:
HASXEE-IM-HS X-STREAM Enhanced Series instruction manual
HASICx-IM-H Infallible containment instruction manual
Contact your local service center or sales ofce when missing documents.
SAVE ALL INSTRUCTIONS FOR FUTURE USE!
GENERAL SAFETY NOTICE / RESIDUAL RISK
If this equipment is used in a manner not specied in these instructions, protective sys-
tems may be impaired.
Despite of incoming goods inspections, production control, routine tests and application
of state-of-the-art measuring and test methods, an element of risk remains when operating
a gas analyzer!
Even when operated as intended and observing all applicable safety instructions some
residual risks remain, including, but not limited to, the following:
• An interruption of the protective earth line, e.g. in an extension cable, may result in risk
to the user.
• Live parts are accessible when operating the instrument with doors open or covers
removed.
• The emission of gases hazardous to health may even be possible when all gas connec-
tions have been correctly made.
Avoid exposure to the dangers of these residual risks by taking particular care when in-
stalling, operating, maintaining and servicing the analyzer.

Emerson Process Management GmbH & Co. OHGS-6
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Safety Instructions
DISPOSAL OF BATTERIES
• This instrument contains a Li battery (button cell) of type CR 2032.
• The battery is soldered and usually does not need to be replaced during the instru-
ment´s lifetime.
• At the end of lifetime, the instrument must be disposed in compliance with the wast
regulations. The disposal specialist then has to disassemble the instrument and
dispose the battery in compliance with the regulations.
AUTHORIZED PERSONNEL
In-depth specialist knowledge is an absolutely necessary condition for working with and
on the analyzer.
Authorized personnel for installing, operating, servicing and maintaining the analyzer are
instructed and trained qualied personnel of the operating company and the manufacturer.
It is the responsibility of the operating company to
• train staff,
• observe safety regulations,
• follow the instruction manual.
Operators must
• have been trained,
• have read and understood all relevant sections of the instruction manual before
commencing work,
• know the safety mechanisms and regulations.
To avoid personal injury and loss of property, do not install, operate, maintain or service
this instrument before reading and understanding this instruction manual and receiving
appropriate training.

Emerson Process Management GmbH & Co. OHG S-7
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
Safety Instructions
INSTALLING AND CONNECTING THIS ANALYZER
The following notices should be carefollowed to ensure compliance with the low voltage directive
(Europe) and other applicable regulations.
1. Suitable grounding connections should be made at all connectors provided for this purpose.
2. All safety covers and grounding connections must be properly reinstated after maintenance
work or troubleshooting.
3. A fuse should be provided at the installation site which will completely disconnect the unit
in case of failure. Installing an isolating switch may also be benecial. In either case, these
components must be constructed to conform to recognised norms.
OPERATING AND MAINTAINING THIS ANALYZER
On leaving our factory, this instrument con-
formed to all applicable safety directives.
In order to preserve this state of affairs, the
operator must take care to follow all the in-
structions and notes given in this manual and
on the unit.
Before switching on the unit, ensure that the
local nominal mains voltage corresponds to
the factory-set operational voltage of this unit.
Any interruption of the protective earth con-
nections, whether inside or outside of the unit,
may result in exposure to the risk of electricity.
Deliberately disconnected the protective earth
is therefore strictly forbidden.
Removing covers may expose components
conducting electric current. Connectors may
also be energised. The unit should therefore
be disconnected from the power supply before
any kind of maintenance, repair or calibration
work requiring access to the inside of the unit.
Only trained personnel who are aware of
the risk involved may work on an open and
energized unit.
Fuses may only be replaced by fuses of an
identical type and with identical ratings. It is
forbidden to use repair fuses or to bypass
fuses.
Take note of all applicable regulations when
using this unit with an autotransformer or a
variable transformer.
Substances hazardous to health may escape
from the unit’s gas outlet. This may require
additional steps to be taken to guarantee the
safety of operating staff.

Emerson Process Management GmbH & Co. OHGS-8
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Safety Instructions
EXPLOSION HAZARD
The units described in this manual may not be used in explosive atmospheres
without additional safety measures.
ELECTRICAL SHOCK HAZARD
Do not operate without covers secure.
Do not open while energized.
Installation requires access to live parts which can cause death or serious
injury.
For safety and proper performace this instrument must be connected to a
properly grounded three-wire source of power.
TOXIC GASES
This unit’s exhaust may contain toxic gases such as (but not limited to)
e.g. sulfur dioxide. These gases can cause serious injuries.
Avoid inhaling exhaust gases.
Connect the exhaust pipe to a suitable ue and inspect the pipes regularly
for leaks.
All connections must be airtight to avoid leaks; X-STREAM Enhanced
series instruction manual on how performing a leak test.

Emerson Process Management GmbH & Co. OHG S-9
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
Safety Instructions
HEAVY INSTRUMENT
The models intended for outside and wall mounted use (X-STREAM XEF and
XDF) weigh between 25 kg (57 lb) and 45 kg (99 lb), depending on version
and options installed.
Two people and/or lifting equipment is required to lift and carry these units.
Take care to use anchors and bolts specied to be used for the weight of
the units!
Take care the wall or stand the unit is intended to be installed at is solid
and stable to support the weight!
HIGH TEMPERATURES
Hot parts may be exposed when working on photometers and/or
heated components in the unit.
CRUSHING HAZARD
Take care of crushing hazard when closing the front door of analyzer eld
housings!
Keep out of the closing area between enclosure cover and base!
OPERATION AT LOW TEMPERATURES
When operating an instrument at temperatures below 0 °C (32 °F), do
NOT apply gas nor operate the internal pump before the warmup time has
elapsed!
Violation may result in condensation inside the gas paths or damaged
pump diaphragm!

Emerson Process Management GmbH & Co. OHGS-10
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Safety Instructions
GASES AND PREPARATION OF GASES
GASES HAZARDOUS TO HEALTH
Follow the safety precautions for all gases (sample and span gases) and
gas cylinders.
Before opening the gas lines, they must be purged with air or neutral gas (N2)
to avoid hazards from escaping toxic, ammable, explosive or hazardous
gases.
FLAMMABLE OR EXPLOSIVE GASES
The analyzers are not suitable to measure explosive gases. When supplying
ammable gases with concentrations of more than 25 % of the lower
explosion limit, we RECOMMEND implementing one or more additional
safety measures:
• purging the unit with inert gas
• stainless steel internal pipes
• ame arrestors on gas inlets and outlets
• infallible measuring cells.

Emerson Process Management GmbH & Co. OHG S-11
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
SSafety Instructions
Safety Instructions
POWER SUPPLY
CONNECTING UNITS FOR PERMANENT INSTALLATION
Only qualied personnel following all applicable and legal regulations may
install the unit and connect it to power and signal cables. Failure to comply
may invalidate the unit’s warranty and cause exposure to the risk of damage,
injury or death.
This unit may only be installed by qualied personnel familiar with the
possible risks.
Working on units equipped with screw-type terminals for electrical
connections may require the exposure of energized components.
Wall-mounted units have no power switch and are operational when
connected to a power supply. The operating company is therefore required
to have a power switch or circuit breaker (as per IEC 60947-1/-3) available
on the premises. This must be installed near the unit, easily accessible to
operators and labelled as a power cut-off for the analyzer.
HAZARD FROM WRONG SUPPLY VOLTAGE
Ensure that the local power voltage where the unit is to be installed,
corresponds to the unit’s nominal voltage as given on the name plate label.
ADDITIONAL NOTES FOR UNITS WITH SCREW-TYPE TERMINALS
Cables for external data processing must be double-insulated against mains
power.
If this is not possible, cables must be laid in such a way as to guarantee
a clearance of at least 5 mm from power cables. This clearance must be
permanently secured (e.g. with cable ties).

Emerson Process Management GmbH & Co. OHGS-12
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
General Operating Notes
GENERAL OPERATING NOTES
• The unit must be installed in a clean and dry area, protected from strong vibrations and frost .
• The unit must not be exposed to direct sunlight and sources of heat. Admissible ambient
temperatures (see technical details) must be adhered to.
• Gas inlets and outlets must not be interchanged. All gases must be conditioned, before sup-
plied to the unit. When using this unit with corrosive sample gases, ensure that these gases
do not contain components harmful to the gas lines.
• Admissible gas pressure for sample and test gases is 1500 hPa.
• Exhaust lines must be laid inclined downwards, depressurized, protected from frost and
according to applicable regulations.
• If it is necessary to disconnect the gas lines, the unit’s gas connectors must be sealed with
PVC caps to avoid polluting the internal gas lines with condensate, dust, etc.
• To ensure electromagnetic compatibility (EMC), only shielded cables (supplied by us on re-
quest, or of equivalent standard) may be used. The customer must ensure that the shielding
is correctly tted. Shielding and terminal housing must be electrically connected; submin-D
plugs and sockets must be screwed to the unit.
• When using optional external adapters (submin-D to screw-type terminals), protection against
electromagnetic interference is not ensured (CE compliance pursuant to EMC guidelines).
In this case the customer or operating company functions as a system builder and must
therefore ensure and declare compliance with EMC guidelines.
HAZARD TO LIFE AND EXPLOSION HAZARD BY EXHAUST GASES
Exhaust gases may contain hydrocarbons and other toxic gases such as
carbon monoxide.
Faulty gas connections may lead to explosion and death.
Ensure that all gas connections are connected as labelled and airtight.

Emerson Process Management GmbH & Co. OHG 1-1
1Techn. Description
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
Chapter 1
Technical Description
The following are the main features of the
Emerson Process Management X-STREAM
Enhanced (hereinafter also referred to as
"X-STREAM XE") gas analyzers in brief:
• compact design with easily accessible
internal components
• customizable for a wide range of appli-
cations: different housings are available
while internal construction remains largely
identical
• a highly integrated mainboard contains
all interfaces and basic functions for the
operation of the unit
• multilingual microprocessor-controlled
user interface with liquid crystal (LCD) to
indicate measurement value and status
messages
• units for outdoor use are optionally sup-
plied with an impact tested front panel
• widerange power supply unit for worldwide
use without modication (1⁄219in units with
internal or external PSUs)
X-STREAM Enhanced gas analyzers can
measure up to ve different gas components
using many combinations of the following
analyzing techniques:
IR = non-dispersive infrared analysis
UV = ultraviolet analysis
pO2= paramagnetic oxygen analysis
eO2= electrochemical oxygen analysis
tO2 = trace oxygen analysis
TCD = thermal conductivity analysis
tH2O = trace moisture measurement
Modied resistant measuring cells are avail-
able for use with corrosive gases and/or
gases containing solvents.
Special congurations for the analysis of am-
mable gases are also available.
EXPLOSION HAZARD
X-STREAM XE analyzers MUST NOT be used in explosive environments
(hazardous areas) without additional safety features.
This instruction manual does NOT describe the special conditions necessary
to operate gas analyzers in hazardous areas.
Please refer to the separate instruction manual, supplied with units for use
in hazardous areas.

Emerson Process Management GmbH & Co. OHG1-2
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
1.1 Overview
All X-STREAM XE gas analyzers feature
an easy-to-use LCD graphic user interface,
which displays measurement values, status
and error messages, and menus for the input
of parameters.
Measurement and status information are vi-
sualized with plain text and symbols.
The symbols are designed to indicate the dif-
ferent status “Failure”, “Function check”, “Out
of specication” and “Maintenance request” as
specied by the NE 107 standard. For further
information, X-STREAM Enhanced Se-
ries instruction manual.
The analyzer software is operated by means
of only six keys.
For ease of use, the operator can select one of
three languages for the display: By default any
analyzer is congured with English and Ger-
man language sets, while a third can option-
ally be added. Currently available: French,
Italian, Portuguese and Spanish.
1.1.1 Housings
The displays of outdoor versions are protected
with an impact tested glass panel, to withstand
even harsher conditions and to provide a higher
IP protection class of up to IP66 / NEMA Type
4X.
1.1 Overview
1.1.2 The Front Panel
Different housings allow X-STREAM analyz-
ers to be tailored to many different applica-
tions:
• Tabletop units in 1⁄219in modular design,
with IP 20 protection class. Can be in-
stalled into a rack or used as a table top
instrument. Optionally featuring a handle
enabling mobile measurements at differ-
ent sampling points.
• Tabletop and rack mountable units in 19in
modular design, with IP 20 protection
class.
• Stainless steel wall mountable eld hous-
ing XEXF with IP 66 / NEMA 4X protection
class enables outdoor use (operating tem-
perature -20°C to +50°C [-4 °F to 122 °F]).
• Cast aluminium wall mountable eld hous-
ing with IP 66 / NEMA 4X protection class
for outdoor use (operating temperature
-20 °C to +50 °C [-4 °F to 122 °F]). Spe-
cially designed to meet hazardous area
certications, but also suitable for non-
hazardous locations with requirements for
robust designed equipment.
