Emerson IE Series User manual

Surge Protective Devices
IE Series

IE Series
Page: B

Page: C
IE Series
Safety Information
Important Information
Read these instructions carefully and look at the equipment to become
familiar with the device before trying to install, operate, service or maintain it.
The following special messages may appear throughout thisbulletin or on the
equipment to warn of potential hazards or to call attention to information that
clarifies or simplifies a procedure.
The addition of either symbol to a “Danger”or “Warning” safety label
indicates that an electrical hazard exists which will result inpersonal
injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messagesthat follow this
symbol to avoid possible injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderateinjury.
NOTICE
NOTICE is used to address practices not related to physical injury. The safety
alert symbol shall not be used with this signal word.
Please Note
Electrical equipment should be installed, operated, serviced, and maintained only
by qualified personnel. No responsibility is assumed by Appleton Grp LLC d/b/a
Appleton Group for any consequences arising out of the use of this material.
A qualified person is one who has skills and knowledge related to the
construction, installation, and operation of electrical equipment andhas received
safety training to recognize and avoid the hazards involved.

Page: 1
IE Series
Introduction
The IE Series offers high frequency noise lter capabilities with surge protection for loads up to 20 A of
continuous current. This product is a DIN or ange mounted device that helps to protect industrial
critical loads.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E,
NOM-029-STPS or CSA Z462.
• This equipment must only be installed and serviced by qualied electrical personnel.
• Turn o󰀨 all power supplying this equipment before working on or inside equipment.
• Always use a properly rated voltage sensing device to conrm power is o󰀨.
• Replace all devices, doors and covers before turning on power to this equipment.
• This equipment must be e󰀨ectively grounded per all applicable codes. Use an equipment-grounding conductor to
connect this equipment to the power system ground.
• Do not supply more than 24VDC / 24VAC and no more than a current of 2A to contacts.
• Conrm that the Surge Protective Device voltage rating on the module or nameplate label is not less than the
operating voltage.
Failure to follow these instructions will result in death or serious injury.
WARNING: This product can expose you to chemicals including DINP, which is known to the
State of California to cause cancer, and DIDP which is known to the State of California to cause
birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov.
NOTICE
LOSS OF SURGE SUPPRESSION
• Make certain the Surge Protective Device is disconnected from the circuit it is protecting before conducting high
potential insulation testing.
Failure to follow these instructions can result in equipment damage.

IE Series
Page: 2
Installation
1. Turn off all power supplying this equipment before working on or inside equipment.
2. Conrm that the unit has the same voltage rating and conguration as the power system voltage and
power system voltage to which it will be connected.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Conrm that the Surge Protective Device voltage rating on the module or nameplate label is not less than the
operating voltage.
Failure to follow these instructions will result in death or serious injury.
3. Install the unit and cables as close as possible to the protected equipment and secure.
4. Connect the supply cables to the line side of the device.
5. Complete the circuit by connecting cables from the load of the device to the protected equipment.
Note: A dry contact connection is available.
6. Check that all connections are secure. Remove all tools and discarded hardware from the unit.
7. Replace the barrier, cover/door and/or trim to the equipment.
8. Equipment may be re-energized after all the above steps are complete.
Table 1: Ratings
Service Voltage MCOV Continuous
Current
Normal
Discharge
Current
Fusing Circuit
Breaker Size Certification Catalog Numbers
120 V, 50/60 Hz,
1-phase
2 wire + ground
150 V
(L–N)
3 A
3 kA 25 A Class CC
Fuse
UL1449 /
UL1283 CSA
C22.2 No.
269.5
IE103
5 A IE105
10 A IE110
20 A IE120
240 V, 50/60 Hz,
1-phase
2 wire + ground
275 V
(L–N)
3 A IE203
5 A IE205
10 A IE210
20 A IE220

Page: 3
IE Series
Description Catalog Number
IE1XX IE2XX
Input Voltage 120 V (0–150 VRMS) 240 V (0–275 VRMS)
Line Frequency 47–63 Hz
Response Time < 0.5 ns normal mode; < 5 ns common mode
Enclosure Fully enclosed polycarbonate housing
Connection/Mounting Type DIN rail or Panel mount
Status Indication Green LED “OK”, Form C contact, 5 A @ 125 VAC or 5 A @ 100 VDC
Dimensions H x W x D 4.88 x 2.56 x 4.56in. (124 x 65 x 116mm)
Operating Temperature -40°C to +50°C at full load; derate linearly to 60% at +70°C
Operating Humidity 0% to 95% Non-condensing
Peak Surge Current Capability
Per Phase 19,500 A
Line to Neutral 13,000 A
Line to Ground 6,500 A
Neutral to Ground 6,500 A
Load Surge Current Rating
10 ms 5 x Nominal
1 s 3 x Nominal
10 s 2 x Nominal
Nominal Discharge Current Rating 3 kA
Short Circuit Current Rating (SCCR) 5kA
Maximum Continuous Operating Voltage (MCOV) 150V L-N, L-G, N-G 320 L-L
Frequent Response
Normal Mode (forward-reverse) 100 kHz to 50 MHz -90 dB Max
Common Mode (forward-reverse) 5 kHz to 50 MHz -60 dB Max
Transient Reduction (IEEE C62.41)*
*All Voltage congurations are single phase, 2 wire + ground
Typical Category A Ringwave (6 kV, 200 A, 100 kHz) < 60 V peak
Typical Category B Ringwave (6 kV, 500 A, 100 kHz) < 100 V peak
Standards Certication cRUus: UL 1449, CSA 22.2 No. 269, UL 1283, CSA 22.2 No. 8 (recognized component), CE
Warranty 5 year limited warranty
Voltage, Current and Power Configurations
Catalog Number Load Current Wire Size Range
(AWG)
Required
Torque (lb-in.)
Fuse/Circuit Breaker Ampacity
Suggest Max
Single-Phase Models (120 VAC)
IE103 3.0 A
12 - 14 12.1 lb-in. (1.37 N•m)
3.0 A 3.75 A
IE105 5.0 A 5.0 A 6.25 A
IE110 10.0 A 10.0 A 12.5 A
IE120 20.0 A 20.0 A 25.0 A
Single-Phase Models (240 VAC)
IE203 3.0 A
12 - 14 12.1 lb-in. (1.37 N•m)
3.0 A 3.75 A
IE205 5.0 A 5.0 A 6.25 A
IE210 10.0 A 10.0 A 12.5 A
IE220 20.0 A 20.0 A 25.0 A

IE Series
Page: 4
Table 2: General Specifications1
Mounting Power
Connection
Wiring
(Copper
Wire)
Terminal
Torque
Operating / Storage
Temperature
Catalog
Numbers
DIN rail or
surface mount
Line / Neutral /
Ground
18–12 AWG
4 lb-in.
(0.45
N•m)
+32 °F to +77 °F (0 °C to +25 °C)
IE103
IE105
IE110
IE120
14–10 AWG 7 lb-in.
(0.45
N•m)
IE203
IE205
12–10 AWG IE210
IE220
1 Contains no serviceable parts.
Figure 1: DIN Rail Installation and Removal
Figure 2: DIN Clips
Note: DIN-Rail clips can be positioned for vertical or horizontal installation.

Page: 5
IE Series
Figure 3: Connections and Wiring
LINE INPUT
FROM SOURCE
RELAY
CONTACTS
TO REMOTE
INDICATION
IF NEEDED
TO LOAD OR
EQUPMENT
TO PROTECT
NO COM NC
LINE LOAD
GND
L/L1
N/L2
GND
L/L1
N/L2
GND
Diagnostic Operation
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E,
CSA Z462, or NOM-029-STPS.
Failure to follow these instructions will result in death or serious injury.
Indicator Status ON =
The device is installed correctly and the line side has power.
Indicator Status OFF =
Check connections, verify that the line voltage is at the point of connection; if all is correct,
then replace the device.
Dry Contact Terminal Power OFF Power ON
N/O Normally Open Open Closed
COM Common Common Common
N/C Normally Closed Closed Open

IE Series
Page: 6
Dimensions (in. / [mm]) and weights (lb. / kg.)
3.83
[97.2]
3.06
[77.7]
4.06
[103.1]
3.83 in.
[97.2 mm]
3.06 in.
[77.7 mm]
4.06 in.
[103.1 mm]
Catalog
Numbers
Weights
(lb./kg.)
IE103 0.94 lb. (0.42 kg)
IE105 0.95 lb. (0.43 kg)
IE110 1.2 lb. (0.58 kg)
IE120 1.4 lb. (0.64 kg)
IE203 0.94 lb. (0.42 kg)
IE205 0.95 lb. (0.43 kg)
IE210 1.2 lb. (0.58 kg)
IE220 1.4 lb. (0.64 kg)

Page: 7
IE Series
Technical Support
Website: www.solahd.com
Technical Support E-Mail: [e-mail]
Toll-Free: [phone]
USA: [phone]
Warranty
Please refer to the “Terms & Conditions of Sale” document.
