Micro Motion®Series 3000 electronics combine transmitter functions and

PLC capabilities in one instrument. Series 3000 models feature MVD™

technology, providing high-speed DSP capabilities and a broad range of

specialty applications.

Large operator interface for easy setup & control

• 128 x 128 pixel display enhances view of process

• Easy to read menus and advanced help system

Transmitter and discrete control from a single instrument

• Functions as an advanced process transmitter or as a discrete

batch controller, with 8 I/O channels for maximum adaptability

•HART

®and Modbus®support expand communications options

Wide variety of applications

• Concentration & net flow measurement

• Custody transfer with batch control

• Patented meter verification application

Micro Motion®Series 3000 Transmitters and Discrete Controllers

Versatile

field-mount

transmitter

Frequency-input

discrete controller

Compact

control-room

transmitter

1700

2700

2400S

1500

2500

3300

3350

3500

3700

Product Data Sheet

PS-00291, Rev. B

May 2007

Compact integral

transmitter

Integrated control

and measurement

platform

2Micro Motion®Series 3000 Transmitters and Discrete Controllers

Micro Motion transmitters and controllers

Micro Motion transmitters and controllers fit a wide variety of application needs. The table below can help

determine which Micro Motion products are right for your process. For more detailed product information,

consult the appropriate Product Data Sheet or contact your local Micro Motion representative.

1500 1700 2400S 2500 2700 3300 3350 3500 3700

Mass / volume flow

Net mass / volume flow

Temperature

Density

Concentration

2-line

Multi-line

4–20 mA

10 kHz pulse

Discrete

HART®

Modbus®

FOUNDATION fieldbus™

PROFIBUS-PA

PROFIBUS-DP

DeviceNet®

10 kHz pulse

Discrete

4-wire Coriolis sensor

9-wire Coriolis sensor

Integral – Field

Remote – Field

Remote – Control room

Batch controller

Custody transfer

Filling & dosing

Meter verification

C1D1

C1D2

Zone 1

Zone 2

Output variables

Local display

Outputs

Inputs

Mounting

Application type

Hazardous approvals

Micro Motion®Series 3000 Transmitters and Discrete Controllers 3

Series 3000 transmitters and discrete controllers

MVD technology. MVD technology makes your

Micro Motion meter work smarter. Front-end digital

processing dramatically reduces signal noise and

gives you faster response time compared to analog

devices.

Only MVD technology allows you to:

• Measure multiple variables

• Install easily with a standard 4-wire signal cable

• Identify and resolve problems easily with built-in

smart diagnostics

• Choose transmitter capabilities based on your

application’s needs

• Upgrade transmitter functionality as needed

Series 3000 transmitters and controllers with MVD

technology. Model 3500 and 3700 transmitters

deliver process measurement and discrete control

based on direct input from a Micro Motion Coriolis

meter. Model 3300 and 3350 controllers provide

discrete control based on a frequency input from a

remote transmitter. Series 3000 models are

available with specialty applications, such as batch

control, enhanced density measurement, petroleum

measurement, custody transfer, and meter

verification.

Configuration, operation, and maintenance are all

accomplished using the innovative Series 3000 user

interface. The interface features a large, easy-to-

use backlit display with big, tactile-feedback push

buttons. Other user interfaces (such as hand-held

communication devices) are not required, but can

be used. Modbus and HART communication allow

configuration devices such as ProLink II, AMS, and

HART Communicators to be used with the

Series 3000, and the Series 3000 can be integrated

into a PlantWeb network.

Contents

Housings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Interface/display. . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electrical connections . . . . . . . . . . . . . . . . . . . . . . 5

Input signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Output signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Environmental specifications. . . . . . . . . . . . . . . . . 8

Power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Hazardous area classifications . . . . . . . . . . . . . . . 9

Model 3100 accessory . . . . . . . . . . . . . . . . . . . . 10

Model 3500/3700 liquid flow performance . . . . . 10

Model 3500/3700 density

performance (liquid only). . . . . . . . . . . . . . . . . . . 11

Model 3500/3700 gas flow performance. . . . . . . 11

Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Ordering information . . . . . . . . . . . . . . . . . . . . . . 16

4Micro Motion®Series 3000 Transmitters and Discrete Controllers

Housings

Applications

Rack-mount 19-inch (486.2 mm) rack-mount housing meets DIN standard 41494 and IEC 297-3

Front panel is rated IP40

Panel-mount Front panel with bezel is rated NEMA 4X (IP65)

Field-mount Compartment with threaded cover contains electronics

Terminal compartment contains:

• Non-intrinsically safe compartment with input/output and power supply terminals

• Intrinsically safe compartment with interface/display, sensor terminals (Model 3700 only), and

optional input and output terminals

Mounting bracket and interface/display rotate to allow mounting in four different orientations

Rated NEMA 4X (IP67)

Process monitor/totalizer Process monitoring and totalizing for multiple variables, including mass flow, volume flow, density,

and temperature.

Discrete batch control • Configuration of up to six preset batch recipes

• One-stage or two-stage batch control

• End-of-batch warning and batch-overrun alarms

• Configuration by quantity or by percent of target for primary valve closure, secondary valve

opening and closure, end warning, and batch overrun

• Configuration for target lockout, or for target adjustment during batch operation

• Automatic overshoot compensation

Meter verification Provides in-situ assessment of a Micro Motion Coriolis meter, determining whether the meter has

been affected by erosion, corrosion, or other influences affecting meter calibration. No secondary

references are required to perform this operation.

Enhanced density Enhanced density measurement for a number of applications, including:

• %HFCS, °Brix, °Plato, °Balling,

• °Baumé at SG60/60

• Density at reference temperature

• Specific gravity

• Concentration derived from reference density

• Concentration derived from specific gravity

Custody transfer • Physical and software security

• Security-alarm posting

• Mass or volume totalizer that can be configured by the user

• Custom formatting of receipt tickets

• Audit trail of configuration changes

• Multidrop printing capability

Petroleum measurement (API) Provides API process variables, such as API volume flow and API average density.

Micro Motion®Series 3000 Transmitters and Discrete Controllers 5

Interface/display

Electrical connections

Display

Models 3300 and 3500 Backlit LCD, 128 × 128 pixel, bit map

Adjustable contrast

Non-glare, chemical-resistant acrylic lens

Models 3350 and 3700 Backlit LCD, 128 × 128 pixel, bit map

Adjustable contrast

Non-glare tempered glass lens

Suitable for hazardous area installation

Keypad membrane switch Large push buttons with tactile feedback

Software-defined function keys

Chemical-resistant polyester

Input and output connections

Rack-mount Type D connectors per DIN standard 41612 (IEC 603-2)

Available as solder tails (standard) or screw terminals (optional)

Screw terminals accept 24 AWG (0.25 mm2) to 16 AWG (1.5 mm2) wires

Panel-mount Screw terminals (standard) or I/O cable with remote DIN rail-mount screw

terminals (optional)

Remote terminals attach to any of four rail types. I/O cable is available in lengths of 2, 5, and 10

feet (0.6, 1.5, and 3 meters)

Screw terminals accept 24 AWG (0.25 mm2) to 16 AWG (1.5 mm2) wires

Field-mount Two color-coded wiring compartments:

• Compartment with intrinsically safe terminals has two 3/4-inch NPT or M20 × 1.5 conduit

openings

• Compartment with non-intrinsically safe terminals has three 3/4-inch NPT or M20 × 1.5

conduit openings

Screw terminals accept 22 AWG (0.34 mm2) to 16 AWG (1.5 mm2) wires

Power connection

Rack-mount Screw terminals are fixed to rack chassis

Ground makes first and breaks last

Screw terminals accept 18 AWG (0.75 mm2) to 14 AWG (2.5 mm2) wires

Panel-mount Screw terminals accept 18 AWG (0.75 mm2) to 14 AWG (2.5 mm2) wires

Field-mount Screw terminals accept 18 AWG (0.75 mm2) to 12 AWG (4.0 mm2) wires

6Micro Motion®Series 3000 Transmitters and Discrete Controllers

Input signals

Output signals

Non-intrinsically safe input signals

One 2-wire

frequency/pulse input Frequency range 0–20,000 Hz

Minimum pulse width 25 μ-sec

Power Sourcing or sinking

Voltage 0–0.8 VDC low state

3–30 VDC high state

Current Nominal 5 mA pull-up

Two discrete

momentary inputs Pulse width 0.15 sec minimum

Voltage 0–0.8 VDC low state

3–30 VDC high state

Dry contacts

Intrinsically safe input signals

One 4-wire Coriolis sensor signal input with ground

Non-intrinsically safe output signals

Two active

4–20 mA outputs Isolated to ±50 VDC from all other outputs and earth ground

Maximum load limit of 1000 Ohms

Output is linear with process from 3.8 to 20.5 mA per NAMUR NE43 (June 1994)

Three discrete outputs Configurable for the application

Polarity Active high or active low, software selectable

Power Internal pull-up to 24 V

Voltage 24 VDC nominal

Current Sourcing at 5.6 mA when Vout = 3 VDC

Sinking up to 500 mA at 30 VDC maximum

One 2-wire

frequency/pulse output Scalable to 10,000 Hz

Output is linear with flow rate to 12,500 Hz

Pulse width 50% duty cycle above the crossover frequency(1)

(1) The crossover frequency depends on the configured value of the pulse width. At the minimum pulse width value of 0.543 ms, the

crossover frequency is 922 Hz. At the maximum pulse width value of 277 ms, the crossover frequency is 1.8 Hz.

Configurable between 0.543 ms and 277 ms

Polarity Active high or active low, software selectable

Power Active or passive, software selectable

Voltage 24 VDC nominal, active

30 VDC applied maximum, passive

Current Sourcing at 10 mA at 3 VDC, active

Sinking at 500 mA, active or passive

Micro Motion®Series 3000 Transmitters and Discrete Controllers 7

Output signals continued

Fault indication

When a fault is detected, outputs go to configured states. User can select upscale, downscale, internal zero, or none. Milliamp

outputs conform to NAMUR NE43 (June 1994).

Upscale Milliamp 21 to 24 mA, user configurable

Frequency 15,000 Hz

Downscale Milliamp 1 to 3.6 mA, user configurable

Frequency 0 Hz

Internal zero Drives the mA and frequency outputs for process variables to zero values

None Ignores fault conditions

Digital communications

RS-485 port One pair of terminals supports SP (service port) mode or RS-485 mode. On device power-up, the

user has 10 seconds to connect in SP mode. After 10 seconds, the terminals switch to RS-485

mode. The communication parameters in SP mode are:

Data rate 38,400 baud

Parity No parity

Stop bit One stop bit

Address 111

In RS-485 mode, the Series 3000 can communicate via Modbus RTU, Modbus ASCII, or HART(1)

protocols. The communication parameters are configurable with ProLink II software, Modbus, or

the display. The shipped default parameters are:

(1) Using HART, it is possible to configure basic transmitter functionality, and read/write batch setpoints and totals. Series 3000 batch

applications or enhanced density applications cannot be configured using HART. Using Modbus, all transmitter functionality, batch

commands, and batch applications can be controlled.

Data rate 9600 baud

Parity Odd

Stop bit One stop bit

The RS-485 port can also be configured as a printer port (see below).

HART Bell 202(1) The HART Bell 202 signal is superimposed on the primary mA output, and is available for host

system interface. The HART Bell 202 communication parameters are:

Frequency 1.2 and 2.2 KHz

Amplitude 0.8 mA peak-to-peak

Data rate 1200 baud

Resistance Loop requires 250 to 600 Ohms resistance

Printer port The RS-485 port can be configured as a printer port. When the RS-485 port is

configured as a printer port, it cannot be used for any other function.

Requires external RS-232 adapter (not included)

Bidirectional with Epson printer; send only with all other printers and when using a multidrop

configuration

8Micro Motion®Series 3000 Transmitters and Discrete Controllers

Environmental specifications

Power supply

EMI effects All Series 3000 devices Meet EMC directive 89/336/EEC per EN 61326 Industrial, and all Series

3000 devices conform to NAMUR NE21 (June 1997).

Ambient temperature effect On analog outputs ±0.005% of span per °C

Ambient temperature limits(1)

(1) If exposed to direct sunlight, the ambient temperature can be expected to rise by an additional 50 °F (10 °C).

Operating –4 to +140 °F –20 to +60 °C

Storage –40 to +158 °F –40 to +70 °C

Temperature accuracy Models 3500 and 3700 ±1.0 °C ±0.5% of reading in °C

Temperature repeatability Models 3500 and 3700 ±0.2 °C

Humidity limits 5 to 95% relative humidity, non-condensing at 140 °F (60 °C)

Vibration limits Per IEC 68-2-6, endurance sweep, 5 to 2000 Hz, 50 sweep cycles at 1.0 g

AC power supply

Model 3300 85 to 265 VAC

50/60 Hz, 15 VA

0.25 A maximum at 85 VAC, 0.12 A maximum at 265 VAC

IEC 127-3/4 fuse, 0.63 A time-delay

Complies with European low-voltage directive 2006/95/EC per IEC 61010-1

Installation (Overvoltage) Category II, Pollution Degree 2

Models 3350, 3500,

and 3700 85 to 265 VAC

50/60 Hz, 30 VA

0.33 A maximum at 85 VAC, 0.15 A maximum at 265 VAC

IEC 127-3/4 fuse, 0.63 A time-delay

Complies with European low-voltage directive 2006/95/EC per IEC 61010-1

Installation (Overvoltage) Category II, Pollution Degree 2

DC power supply

Model 3300 18 to 30 VDC

7 watts typical, 14 watts maximum

IEC 127-3/4 fuse, 1.6 A time-delay

Models 3350, 3500,

and 3700 18 to 30 VDC

18 watts typical, 25 watts maximum

IEC 127-3/4 fuse, 1.6 A time-delay

Micro Motion®Series 3000 Transmitters and Discrete Controllers 9

Hazardous area classifications

UL is a U.S.A. approvals agency. CSA is a Canadian approvals agency that provides approvals accepted in both the U.S.A.

(C-US) and Canada. ATEX is a European directive.

UL and CSA Model 3300 Class I, Div. 2, Groups A, B, C, and D when installed in a suitable

enclosure

Model 3350 Class I, Div. 2, Groups A, B, C, and D

Model 3500 Class I, Div. 2, Groups A, B, C, and D when installed in a suitable

enclosure

Provides non-incendive sensor outputs for use in Class I, Div. 2,

Groups A, B, C, and D, or intrinsically safe sensor outputs for use

in Class I, Div. 1, Groups C and D; Class II, Div. 1, Groups E, F,

and G

Model 3700 Class I, Div. 2, Groups A, B, C, and D

Provides non-incendive sensor outputs for use in Class I, Div. 2,

Groups A, B, C, and D, or intrinsically safe sensor outputs for use

in Class I, Div. 1, Groups C and D; Class II, Div. 1, Groups E, F,

and G

ATEX Model 3350 ATEX Zone 1

CE 0575 II 2G EEx de [ib] IIB/IIC T4

Model 3500 Safe area only. Can be connected to a sensor in ATEX Zone 1

area.

CE 0575 II (2)G [EEx ib] IIB/IIC

Model 3700 ATEX Zone 1

CE 0575 II 2G EEx de [ib] IIB/IIC T4

10 Micro Motion®Series 3000 Transmitters and Discrete Controllers

Model 3100 accessory

Model 3500/3700 liquid flow performance

Relays module Three relays

Solid state, SPST

Rated at 24–250 VAC, 40 mA to 5 A; or 0–70 VDC, 5 A

Energized by discrete outputs

NEMA 4X (IP65) enclosure (optional)

UL and CSA approvals Class I, Div. 2, Groups A, B, C, and D

ATEX approvals Suitable for installation in Zone 2, when properly installed in a suitable enclosure, complying with

ATEX Directive (94/9/EC) for Group II, Category 3G, according to CENELEC standard EN 50021

(1998) and marked as:

EEx n V II T4

KEMA 97 ATEX4940X

Ambient temperature –20 to +60 °C (–4 to +140 °F)

Additional installation-specific requirements are described in detail in the Series 3000 instruction

manual.

Sensor model

Mass flow accuracy(1)(2)

(1) Stated flow accuracy includes the combined effects of repeatability, linearity, and hysteresis.

(2) For the details of flow accuracy and repeatability specifications, refer to the product data sheet for each sensor family.

ELITE®±0.05% of rate

F-Series ±0.10% of rate

H-Series ±0.10% of rate

T-Series ±0.15% of rate

R-Series ±0.50% of rate

Volume flow accuracy(1)(2) ELITE ±0.05% of rate

F-Series ±0.15% of rate

H-Series ±0.15% of rate

T-Series ±0.25% of rate

R-Series ±0.50% of rate

Repeatability(2) ELITE ±0.025% of rate

F-Series ±0.05% of rate

H-Series ±0.05% of rate

T-Series ±0.05% of rate

R-Series ±0.25% of rate

Micro Motion®Series 3000 Transmitters and Discrete Controllers 11

Model 3500/3700 density performance (liquid only)

Model 3500/3700 gas flow performance

Weight

Sensor model g/cm3kg/m3

Accuracy(1)

(1) For the details of the density accuracy and repeatability specifications, refer to the product data sheet for each sensor family.

ELITE ±0.0002 ±0.2

F-Series ±0.001 ±1.0

H-Series ±0.001 ±1.0

T-Series ±0.002 ±2.0

R-Series Not rated for density

Repeatability(1) ELITE ±0.0001 ±0.1

F-Series ±0.0005 ±0.5

H-Series ±0.0005 ±0.5

T-Series ±0.0005 ±0.5

R-Series Not rated for density

Sensor model

Mass flow accuracy ELITE®±0.35% of rate

F-Series ±0.50% of rate

H-Series ±0.50% of rate

T-Series ±0.65% of rate

R-Series ±0.75% of rate

Repeatability ELITE ±0.20% of rate

F-Series ±0.25% of rate

H-Series ±0.25% of rate

T-Series ±0.25% of rate

R-Series ±0.50% of rate

Models 3300 and 3500 Maximum 3.5 lb (1.6 kg), excluding prepared cables

Models 3350 and 3700 19 lb (8.6 kg)

12 Micro Motion®Series 3000 Transmitters and Discrete Controllers

Dimensions

Rack-mount Model 3300/3500

Dimensions in inches

(mm)

25 HP (25 TE)

5.0 (127) 4× M2.5 × 11

5 1/16

(128.5)

28 HP (28 TE)

5 9/16 (142.2)

19″(486.2 mm) subrack conforms to

DIN 41494 Part 5, and IEC 297-3

Not included as part of Model 3300/3500

3 U

(3 HE)

4 13/16

(122.5)

(25.4) 6 11/16

(169.9)

7 11/32

(186.7)

7 29/32

(200.6)

8 33/64

(216.2)

Screw terminal connector (optional)

Rear rail for mounting connectors that

conform to DIN 41612 and IEC 603-2

Not included as part of Model 3300/3500

Approvals tag

Intrinsic safety shield

(Model 3500 only)

1 U = 1 HE = 1.750 inches (44.45 mm)

1 HP = 1 TE = 0.200 inches (5.08 mm)

Micro Motion®Series 3000 Transmitters and Discrete Controllers 13

Dimensions continued

Panel-mount Model 3300/3500 with screw-type connectors

Dimensions in inches

(mm)

Bezel

(152)

1/2

(12)

7 3/4

(197)

8 1/2

(216)

6 1/2

(165)

Frame

Panel

(152)

Approvals tag

4 1/2

(114)

6 11/16

(170)

Intrinsic safety barrier

(Model 3500 only)

14 Micro Motion®Series 3000 Transmitters and Discrete Controllers

Dimensions continued

Panel-mount Model 3300/3500 with optional I/O cable

Bezel

(152)

Frame

8 3/4

(222)

5 5/16

(135)

6 11/16

(170)

Minimum 4 1/4″

(108 mm) bend radius

Approvals tag

6 1/2

(165)

1/2

(12)

Dimensions in inches

(mm)

Panel

(152)

DIN-rail-mount

screw terminals detail

3 3/64

(77)

2 37/64

(66)

2 31/64

(63)

2 19/64

(59)

2 1/4

(57)

(229)

2 15/64

(57)

3 17/32

(90)

DIN rail type TS 32

DIN rail type TS 35 × 15

DIN rail type TS 15

DIN rail type TS 35 × 7.5

Micro Motion®Series 3000 Transmitters and Discrete Controllers 15

Dimensions continued

Field-mount Model 3350/3700

Dimensions in inches

(mm)

(305)

(279)

4× ø 5/16

(9)

(102)

2 13/16

(71)

Display/cover can be

rotated 90° or 180°

11 5/16

(288)

3 5/8

(92) 6

(152)

6 1/8

(156)

5 1/16″(129 mm)

Minimum clearance for removal

of circuit boards

8 11/16

(221) 15 1/2

(394)

2× 2 13/16

(71)

1 7/8

(48)

2× 15/16

(24)

Case ground

5× 3/4–14 NPT

or M20 × 1.5

female conduit opening

Mounting bracket can

be rotated 90°

10 3/8

(264)

7 1/2

(191)

5 3/4

(147)

9 3/16

(234)

4× M8 × 16 bolts are included

for attaching the mounting bracket to

the Model 3350 or 3700 transmitter

Approvals tag

Mounting surface

Conduit openings view

16 Micro Motion®Series 3000 Transmitters and Discrete Controllers

Ordering information — Model 3300

Model Product description

3300 Micro Motion Coriolis Discrete Controller; remote rack/panel-mount

Code Mounting options

RDINrack

P Panel-mount

Code Power supply options

1 85 to 265 VAC

2 18 to 30 VDC (recommended for 24 VDC users)

Code Communication gateway module

A No communication gateway module

Code Additional hardware modules

0 No additional hardware modules

1(1)

(1) Control Application code must be code D (Discrete Batch Controller).

Weights & Measures Custody Transfer (all other than OIML)

2 Weights & Measures Custody Transfer (OIML)

Code Sensor interface

0 No sensor interface

Code Terminals

A Solder pins (use with mounting code R only)

BScrewterminals

C Prepared cables; 2 foot (0.6 m) length (use with mounting code P only)

D Prepared cables; 5 foot (1.5 m) length (use with mounting code P only)

E Prepared cables; 10 foot (3 m) length (use with mounting code P only)

Code Relays and housings

1 No relays and housing

Code Approvals

M Micro Motion standard (no approval)

UUL

C CSA (Canada only)

A CSA C-US (U.S.A. and Canada)

Q(2)

(2) Available with Chinese (M) language option only.

General purpose with CMC (China only)

Continued on next page

Micro Motion®Series 3000 Transmitters and Discrete Controllers 17

Ordering information — Model 3300 continued

Code Language

A English local display Danish quick reference guide English manual

D English local display Dutch quick reference guide English manual

E English local display English quick reference guide English manual

F French local display French quick reference guide French manual

G German local display German quick reference guide German manual

H English local display Finnish quick reference guide English manual

I English local display Italian quick reference guide English manual

J Japanese local display Japanese quick reference guide English manual

M English local display Chinese quick reference guide English manual

N English local display Norwegian quick reference guide English manual

O English local display Polish quick reference guide English manual

P English local display Portuguese quick reference guide English manual

S English local display Spanish quick reference guide Spanish manual

W English local display Swedish quick reference guide English manual

B English local display Hungarian CE requirements document English manual and quick reference guide

C English local display Czech CE requirements document English manual and quick reference guide

K English local display Slovak CE requirements document English manual and quick reference guide

L English local display Latvian CE requirements document English manual and quick reference guide

T English local display Estonian CE requirements document English manual and quick reference guide

U English local display Greek CE requirements document English manual and quick reference guide

V English local display Lithuanian CE requirements document English manual and quick reference guide

Y English local display Slovenian CE requirements document English manual and quick reference guide

Code Control application software

Z Process monitor/totalizer (standard)

D Discrete batch controller

Code Measurement application software

Z No measurement application software

Code Specialty applications

Z No specialty applications

X ETO application

Typicalmodelnumber: 3300R1A00A1UEDZZ

18 Micro Motion®Series 3000 Transmitters and Discrete Controllers

Ordering information — Model 3350

Model Product description

3350 Micro Motion Coriolis Discrete Controller; remote field-mount

Code Mounting options

A Field-mount

Code Power supply options

1 85 to 265 VAC

2 18 to 30 VDC (recommended for 24 VDC users)

Code Communication gateway module

A No communication gateway module

Code Additional hardware modules

0 No additional hardware modules

1(1)

(1) Control Application code must be code D (Discrete Batch Controller).

Weights & Measures Custody Transfer (all other than OIML)

2 Weights & Measures Custody Transfer (OIML)

Code Sensor interface

0 No sensor interface

Code Conduit connections

A M20 without glands

B M20 with three increased safety glands

C M20 with five increased safety glands

D 3/4-inch NPT without conduit seals

Code Approvals

M Micro Motion standard (no approval)

UUL

C CSA (Canada only)

A CSA C-US (U.S.A. and Canada)

Z ATEX — Zone 1 Equipment Category 2

P(2)

(2) Available only with language option M (Chinese).

NEPSI — Safe area

Continued on next page

Micro Motion®Series 3000 Transmitters and Discrete Controllers 19

Ordering information — Model 3350 continued
