Rosemount 848T Wireless Temperature
Transmitter

December 2014
2
Quick Start Guide
NOTICE
This guide provides basic guidelines for the Rosemount 848T. It does not provide instructions
for detailed configuration, diagnostics, maintenance, service, troubleshooting, or installations.
Refer to the Rosemount 848T reference manual (document number 00809-0100-4848) for
more instruction. The manual and this guide are also available electronically on
www.rosemount.com.
Explosions could result in death or serious injury.
Installation of this transmitter in an explosive environment must be in accordance with the
appropriate local, national, and international standards, codes, and practices. Review the
Product Certifications section for any restrictions associated with a safe installation.
Before connecting a Field Communicator in an explosive atmosphere, ensure the instruments
are installed in accordance with intrinsically safe or non-incendive field wiring practices.
Electrical shock can result in death or serious injury.
Avoid contact with the leads and terminals. High voltage that may be present on leads can
cause electrical shock. This device complies with Part 15 of the FCC Rules. Operation is subject
to the following conditions. This device may not cause harmful interference. This device must
accept any interference received, including interference that may cause undesired operation.
This device must be installed to ensure a minimum antenna separation distance of 20 cm
from all persons.
The power module may be replaced in a hazardous area. The power module has surface
resistivity greater than one gigaohm and must be properly installed in the wireless device
enclosure. Care must be taken during transportation to and from the point of installation to
prevent electrostatic charge build-up.
NOTICE
Shipping considerations for wireless products:
The unit was shipped to you without the power module installed. Remove the power module
prior to shipping the unit.
Each power module contains two “C” size primary lithium batteries. Primary lithium batteries
are regulated in transportation by the U.S. Department of Transportation, and are also covered
by IATA (International Air Transport Association), ICAO (International Civil Aviation
Organization), and ARD (European Ground Transportation of Dangerous Goods). It is the
responsibility of the shipper to ensure compliance with these or any other local requirements.
Please consult current regulations and requirements before shipping.
Contents
Wireless Considerations. . . . . . . . . . . . . . . . . 3
Physical installation . . . . . . . . . . . . . . . . . . . . . 5
Verify operation . . . . . . . . . . . . . . . . . . . . . . . . 8
Reference Information . . . . . . . . . . . . . . . . .10
Product Certifications. . . . . . . . . . . . . . . . . .12

Quick Start Guide
3
December 2014
Wireless Considerations
Power up sequence
The power module should not be installed on any wireless device until the Smart
Wireless Gateway (“Gateway”) is installed and functioning properly. Wireless
devices should also be powered up in order of proximity from the Gateway,
beginning with the closest. This will result in a simpler and faster network
installation. Enable Active Advertising on the Gateway to ensure that new devices
join the network faster. For more information see the Smart Wireless Gateway
Manual (Doc. No. 00809-0200-4420).
Antenna position
The antenna should be positioned vertically and it should be approximately 3 ft.
(1 m) from any large structure, building, or conductive surface to allow for clear
communication to other devices.
Figure 1. Antenna Position
Conduit plug
The temporary orange plugs should be replaced with the included conduit plugs
using approved thread sealant.

December 2014
4
Quick Start Guide
Figure 2. Conduit Plug
Field Communicator connections
The power module needs to be connected for the Field Communicator to
interface with the Rosemount 848T Wireless.
Figure 3. Connection Diagram
A. Maintenance Port
A

Quick Start Guide
5
December 2014
Step 1: Physical installation
Initial configuration
If the device was ordered with a factory configured Network ID and Join Key, it
should join the network with no user input. If unsure, the Network ID and the Join
Key may be manually entered to match the Gateway’s.
The Network ID and Join Key may be obtained from the Gateway on the
Setup>Network>Settings page on the web server (see Figure below).
The Network ID and Join Key may be changed in the wireless device by using the
following Fast Key sequence.
Sensor configuration
Sensor inputs can be configured for different sensor types. To verify or change the
sensor configuration with a Field Communicator, use the following Fast Key
sequence.
Remote mount
The Rosemount 848T Wireless is designed to be installed only in the Remote
Mount configuration where the sensor is mounted separate from the 848T
housing, then connected to the 848T via conduit.
1. Install the sensor according to standard installation practices. Be sure to use
thread sealant on all connections.
Function Key sequence Menu items
Wireless 2,1,1 Join Device to Network
Function Key sequence Menu items
Sensor Configuration 2,1,3 Configure Sensors

December 2014
6
Quick Start Guide
2. To reduce sensor wiring length, mount the Rosemount 848T Wireless
transmitter central to all of the measurements. When installing the 848T
wireless, the conduit entries need to be facing downward. If using the
mounting bracket (Option Code B6), mount to a 2-in. pipe.
3. Run wiring (and conduit, if necessary) from the sensor to the 848T. For an
easier installation, use the outside conduit entries as shown below. Any
unused conduit entries should be sealed with approved sealant using the
included threaded conduit plugs.
A. Conduit Entry
B. Conduit Plug
4. Pull the wiring through the threaded conduit entry of the 848T.
5. Attach the sensor wiring to the terminals as indicated on the wiring diagram.
Note that Terminal screw 5 is for attaching the shield wire of the sensor to the
device. See 848T Wireless Reference Manual (Document No.
00809-0100-4848) for more information.
B
A
AA

Quick Start Guide
7
December 2014
6. To connect the power module, remove the plastic plug from the receptacle.
A. Plastic Plug
7. After initial installation, close the housing cover securely. Always ensure a
proper seal by installing the electronics housing cover so that metal touches
metal, but do not over tighten.
8. Position the antenna vertically. The antenna should be approximately three
feet (1 m) from any large structures or buildings to allow clear communication
to other devices.
Installing the optional voltage adapter
The Rosemount 848T Wireless voltage adapter allows voltage measurement from
0-10 volts. Each adapter accommodates 2 voltage inputs, and can be installed
interchangeably on inputs 1 & 2 or 3 & 4.
To install voltage adapter:
1. Open terminal screws 2 and 3 on BOTH inputs. Note that the screws are
captive and should NOT be completely removed by using excess force.
A

December 2014
8
Quick Start Guide
2. Angle adapter and slide spade lugs into terminals 2 and 3 on the left side, as
shown in the figure below. Ensure that the positive and negative polarity
indicators match on the adapter and the terminal block.
3. Lower right side of adapter into terminals 2 and 3 on the right side and center
the adapter.
4. Tighten all terminal screws to lock divider in place.
Step 2: Verify operation
Operation can be verified using one of three methods: Field Communicator, the
Smart Wireless Gateway’s integrated web interface, or via AMS®Wireless
Configurator.
Field Communicator
For HART communication, an 848T Wireless DD is required. For connecting with a
Field Communicator, refer to Figure 3 on page 4.
Smart Wireless Gateway
In the Gateway’s integrated web interface, navigate to the Explorer page. This
page shows whether the device has joined the network and if it is communicating
properly.
Note
It may take several minutes for the device to join the network.
Note
If the device joins the network and immediately has an alarm present, it is likely due to sensor
configuration. Check the sensor wiring (see “Rosemount 848T Terminal Diagram” on page 10) and
the sensor configuration (see “848T Fast Key Sequence for Field Communicator” on page 10).
Function Key sequence Menu items
Communications 3,3
Join Status, Communications Status, Join
Mode, Number of Advertisements Heard,
Number of Available Neighbors, Number
of Join Attempts

Quick Start Guide
9
December 2014
Figure 4. Smart Wireless Gateway Explorer Page
AMS Wireless Configurator
When the device has joined the network, it will appear in the Device Manager as
illustrated below.
Figure 5. AMS Wireless Configurator Explorer Page

December 2014
10
Quick Start Guide
Reference Information
Figure 6. Rosemount 848T Terminal Diagram
Figure 7. Sensor Wiring Diagrams
Table 1. 848T Fast Key Sequence for Field Communicator
Function Key sequence Menu items
Device Information 1, 1, 13 Manufacturer, Model, Final Assembly Number, Universal, Field Device, Software, Hardware, Descriptor, Message, Date,
Model Number SI Unit Control, Country, Device ID
Guided Setup 2, 1 Join Device to Network, Configure Update Rate, Configure
Sensor, Calibrate Sensors, Configure Alerts
Manual Setup 2, 2 Wireless, Sensor 1, Sensor 2, Sensor 3, Sensor 4, Device
Temperature, Device Information, Other
Wireless 2, 2, 1 Network ID, Join Device to Network, Configure Update Rate,
Configure Broadcast Power Level, Power Mode, Power Source
Sensor Calibration 3, 4, 1-4
Sensor 1-4, Current Upper Trim, Current Lower Trim, Lower
Sensor Trim, Upper Sensor Trim, Recall Factory Trim, RTD 2
Wire Offset
+-
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
2-wire RTD,
Ohm
4-wire RTD,
Ohm
3-wire RTD,
Ohm
Thermocouple, millivolt

Quick Start Guide
11
December 2014
Wiring 0-10 volts inputs on the voltage adapter
Wiring voltage 0-10 volt inputs using the adapter follows the same procedure as
mV inputs and thermocouples.
Figure below shows how to connect the voltage leads.
Adapter requirements
1. The adapter is only designed to be used with the 1000 mV sensor type, found
on device revisions 3 and above. If it is ordered pre-installed from the factory,
this will be the default sensor type. If the adapter is ordered as a spare part, the
user must configure the inputs to this sensor type. The user is responsible for
converting the 0-1000 mV transmitter output into a 0-10 volt scale. The
formula to do this is as follows:
2. If input type S004 ((1) dual channel voltage adapter) is ordered, it will be
factory installed on channels 1 and 2. However, if the adapter is required to be
installed on channels 3 and 4, the procedure to do so is a simple process.
Confirm that channels 3 and 4 are configured for 1000 mV sensor input. After
confirmation, remove the adapter from channels 1 and 2 and follow the steps
provided in the 'Installing the Optional Voltage Adapter' section of this guide
to install it on channels 3 and 4.
3. In order to ensure the device remains within the accuracy specifications, the
effect of source impedance must be checked.
Loaded to unloaded, the impedance ratio cannot exceed 0.1%. For detailed
instructions on how to verify this, refer to Section 5 of the User’s Manual.
Transmitter output (in mV)
100
----------------------------------------------------------------- Actual reading (in V)=

December 2014
12
Quick Start Guide
Product Certifications
Approved Manufacturing Locations
Rosemount Inc. – Chanhassen, Minnesota, USA
Emerson Process Management GmbH & Co. - Germany
Emerson Process Management Asia Pacific Private Limited - Singapore
Telecommunication Compliance
All wireless devices require certification to ensure that they adhere to regulations
regarding the use of the RF spectrum. Nearly every country requires this type of
product certification. Emerson is working with governmental agencies around
the world to supply fully compliant products and remove the risk of violating
country directives or laws governing wireless device usage.
FCC and IC
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions: This device may not cause harmful interference. This device
must accept any interference received, including interference that may cause
undesired operation.
This device must be installed to ensure a minimum antenna separation distance
of 20 cm from all persons.
Ordinary Location Certification for FM
As standard, the transmitter has been examined and tested to determine that the
design meets basic electrical, mechanical, and fire protection requirements by
FM, a nationally recognized testing laboratory (NRTL), as accredited by the
Federal Occupational Safety and Health Administration (OSHA).
Hazardous Locations Certificates
North America
Factory Mutual (FM) approvals
N5 FM Class 1, Division 2, and Dust
Certificate: 3034378
Applicable Standards: Class 3600:1998, Class 3610:2010, Class 3810:2005,NEMA 250:
1997,ANSI/ISA-60079-0:2009, ANSI/ISA-60079-11:2009.
Non-Incendive for Class I, Division 2, Groups A, B, C, and D.
Dust Ignition-proof for Class II, Division 1, Groups E, F, and G.
Ambient Temperature Limits T4 (Tamb = -50 °C to 70 °C)
Non-incendive when installed in accordance with Rosemount drawing 00849-1000.
For use with Rosemount power module P/N 753-9220-0001 only.
Enclosure Type 4X / IP66

Quick Start Guide
13
December 2014
I5 FM Intrinsic Safety and Non-Incendive
Certificate: 3034378
Applicable Standards: Class 3600:1998, Class 3610:2010, Class 3810:2005,NEMA 250:
1997,ANSI/ISA-60079-0:2009, ANSI/ISA-60079-11:2009.
Intrinsically Safe for Class I, Division 1, Groups A, B, C, and D.
Non-incendive for Class I, Division 2, Groups A, B, C, and D.
Intrinsically Safe Zone Marking: Zone 0, AEx ia llC
Temperature Codes T4 (Tamb = -50 °C to 70 °C)
Intrinsically Safe and non-incendive when installed in accordance with Rosemount
drawing 00849-1000.
Enclosure Type 4X / IP66
Sensor Terminal Output Parameter Limits
Canadian Standards Association (CSA)
I6 CSA Intrinsic Safety
Certificate: 1261865
Applicable Standards: C22.2 25:1966, C22.2 30:1986, C22.2 94:1991, C22.2 142:1987,
C22.2 157:1992, C22.2 213:1987, CAN/CSA C22.2 0:2001, ANSI/ISA 12.27.01-2003,
C22.2 60529:2005
Intrinsically Safe for Class I, Division 1, Groups A, B, C, and D.
Non-incendive for Class I, Division 2, Groups A, B, C, and D.
Temp Code T3C
Enclosure Type 4X / IP66
For use with Rosemount power module P/N 753-9220-0001 only.
Intrinsically Safe and non-incendive when installed in accordance with Rosemount
drawing 00849-1016.
Sensor Terminal Output Parameter Limits
Uo= 6.6 Vdc
Io= 3.2 mA
Po= 5.1 mW
Co= 22 uF
Lo= 1 H
Uo= 6.6 Vdc
Io= 3.2 mA
Po= 20.4 mW
Co= 22 uF
Lo= 1 H

December 2014
14
Quick Start Guide
N6 CSA Dust Ignition-proof and Non-Incendive
Certificate: 1261865
Applicable Standards: C22.2 25:1966, C22.2 30:1986, C22.2 94:1991, C22.2 142:1987,
C22.2 157:1992, C22.2 213:1987, CAN/CSA C22.2 0:2001, ANSI/ISA 12.27.01-2003,
C22.2 60529:2005
Non-Incendive for Class I, Division 2, Groups A, B, C, and D.
Enclosure Type 4X / IP66.
For use with Rosemount power module P/N 753-9220-0001 only.
Non-incendive when installed per Rosemount drawing 00849-1016.
Europe
I1 ATEX Intrinsic Safety
Certificate No.: Baseefa09ATEX0022X II 1G
Applicable Standards: EN 60079-0:2009, EN-60079-1:2009, EN 60079-11:2007
Ex ia IIC T5/T4 Ga
Special Condition for Safe Use (X):
1. The surface resistivity of the antenna is greater than one GΩ. To avoid electrostatic
charge build-up, it must not be rubbed or cleaned with solvents or a dry cloth.
IECEx
I7 IECEx Intrinsic Safety
Certificate: IECEx BAS 09.0004X
Applicable Standards: IEC 60079-0:2009, IEC 60079-1:2009, IEC 60079-11:2007
Ex ia IIC T5/T4 Ga
Special Condition for Safe Use (X):
1. The surface resistivity of the antenna is greater than one GΩ. To avoid electrostatic
charge build-up, it must not be rubbed or cleaned with solvents or a dry cloth.
Uo= 6.6 V
Io= 3.2 mA
Po= 5.3 mW
Co= 22 uF
Lo= 1 H
Uo= 6.6 V
Io= 3.2 mA
Po= 5.3 mW
Co= 22 uF
Lo= 1 H

Quick Start Guide
15
December 2014
Figure 8. Rosemount 848T Wireless Declaration of Conformity

December 2014
16
Quick Start Guide

Quick Start Guide
17
December 2014

Emerson Process Management
Rosemount Inc.
8200 Market Boulevard
Chanhassen, MN 55317 USA
www.rosemount.com
T (USA) [phone]
T (International) [phone]
F [phone]
Emerson Process Management Latin
America
Multipark Office Center
Turrubares Building, 3rd & 4th floor
Guachipelin de Escazu, Costa Rica
T+(506) 2505-6962
[e-mail]
Emerson Process Management
Asia Pacific Private Limited
1 Pandan Crescent
Singapore 128461
T (65) 6777 8211
F (65) 6777 0947
[e-mail]
Emerson Process Management
Flow B. V.
Neonstraat 1
6718 WX Ede
The Netherlands
T [phone]
F [phone]
Emerson FZE
P.O. Box 17033
Jebel Ali Free Zone
Dubai UAE
T [phone]
F [phone]
FlowCustomerCare.ME[email protected]om
© 2014 Rosemount Inc. All rights reserved. All marks property of owner.
AMS and the Emerson logo are trademarks and service marks of Emerson Electric Co.
Rosemount and the Rosemount logotype are registered trademarks of Rosemount
Inc.
WirelessHART is a registered trademark of the HART Communication Foundation.
Quick Start Guide
00825-0100-4848, Rev DA
December 2014
?00825-0100-4848I?
