Emerson Rosemount Ultrasonic 3107 User manual

Quick Start Guide
00825-0200-4840, Rev BB
July 2016
Rosemount Ultrasonic
3107 Level and 3108 Flow Transmitters

July 2016
2
Quick Start Guide
NOTICE
This installation guide provides basic guidelines for the Rosemount 3107 and
Rosemount 3108. It does not provide instructions for detailed configuration, diagnostics,
maintenance, service, troubleshooting, or installations. Refer to the Rosemount 3107 and 3108
Reference Manual for more instructions. Manuals are available electronically on
EmersonProcess/Rosemount.com.
Failure to follow these installation guidelines could result in death or serious injury
The Rosemount 3107 and Rosemount 3108 are ultrasonic transmitters. They must be
installed, connected, commissioned, operated, and maintained by suitably qualified
personnel only, observing any national and local requirements that may apply
Use the equipment only as specified. Failure to do so may impair the protection provided by
the equipment
Explosions could result in death or serious injury
Installation of the transmitters in a hazardous environment must be in accordance with the
appropriate local, national, and international standards, codes, and practices. Please review
the Product Certifications section for any restrictions associated with a safe installation
Before connecting a Field Communicator in an explosive atmosphere, ensure the instruments
are installed in accordance with intrinsically safe or non-incendive field wiring practices
Verify that the operating atmosphere of the transmitter is consistent with the appropriate
hazardous locations certifications
External surface may be hot
Care must be taken to avoid possible burns
Process leaks could result in death or serious injury
Install and tighten process connectors before applying pressure
Do not attempt to loosen or remove process connectors while the transmitter is in service
Electrical shock could cause death or serious injury
Make sure that the transmitter is not powered when making connections
If the liquid level switch is installed in a high voltage environment and a fault condition or
installation error occurs, high voltage may be present on leads and terminals

Quick Start Guide
3
July 2016
Overview of the Rosemount 3107 and 3108
The Rosemount 3107 and 3108 are sealed 4–20 mA loop-powered liquid level
transmitters, specifically designed for use in waste water and effluent treatment plant
on aqueous applications.
These rugged UPVC transmitters are certified Intrinsically Safe for use in Zone 0 areas,
and factory fitted with up to 165 ft. (50 m) of two-core cable for simple low cost
installation in sumps, wet-wells and over open channel flow structures.
The transmitter may be mounted in a hazardous area if powered from a protected
power supply. They can be connected directly to a plant control system, or used with a
Rosemount 3490 Series Control Unit for programmable control functionality.
Theory of operation
Each transmitter is designed to be mounted above a liquid, and uses ultrasonic pulses
to continuously measure the distance to the liquid surface. The
microprocessor-controlled electronics calculates distance to the liquid level from the
time delay between the transmitting and receiving of signals.
When programmed with the bottom reference of the application – usually the bottom
of a tank – the transmitter will calculate the liquid depth (level), and output the level
(Figure 1) as a 4–20 mA signal and a digital HART®signal.
The 3107 and the 3108 can also calculate contents (volume) or open channel flow, and
then output the result as a 4–20 mA signal and a digital HART signal.
Programming is achieved by remote communication using HART.
Figure 1. Typical application
A. Rosemount 3108 Flow Transmitter E. Pump
B. Rosemount 3490 Series Control Unit F. Transmitter Bottom Reference
C. 4–20 mA signal output G. 4–20 mA and HART signal input
D. Relay
B
A
G
EE
20mA
4mA
C
F
D
D

July 2016
4
Quick Start Guide
Components of the transmitter
The transmitter has a housing containing advanced electronics to generate ultrasonic
pulses, process the resultant signals, and provide a 4–20mA and HART output.
There is a factory-fitted cable for the signal output and connecting an external power
supply. The 3108 has a factory-fitted Remote Temperature Sensor.
Figure 2. Transmitter components
A. Mounting bracket D. UPVC wetted parts
B. Two-core cable E. Remote temperature sensor (3108 only)
C. 1-in. mounting thread
Considerations before you install
Install the transmitter where it is protected from ultraviolet radiation to prevent long
term degradation of the plastics used in its construction e.g. shrouded from direct
sunlight.
Note
See also “Product Certifications” on page 21 for special conditions for safe use.
General
Installation must be carried out by suitably trained personnel in accordance with
the applicable code of practice.
If the equipment is likely to come into contact with aggressive substances, it is the
responsibility of the user to take suitable precautions that prevent it from being
adversely affected, thus ensuring that the type of protection is not compromised.
Aggressive Substances are acidic liquids or gases that may attack metals or
solvents that may affect polymeric materials.
Suitable Precautions are regular checks as part of routine inspections, or
establishing, from the material's datasheet, that it is resistant to specific
chemicals.
The equipment should only be cleaned with a damp cloth; do not use solvents.
D
C
E
B
A
D

Quick Start Guide
5
July 2016
The transmitter is Double Insulated, and therefore Protective Earthing is not
required. However, the cable screen should be connected (see Figure 9 on
page 10).
Note that if the equipment is used in a manner not specified by the manufacturer,
the protection afforded by the equipment may be impaired.
This transmitter is classified Type A in accordance with the European EMC directive
2004/108/EC. To ensure electro-magnetic compatibility, in any member state, it
should not be installed in a residential area.
Note
It is not advisable to mount the transmitter in close proximity to a source of
electrical noise such as a variable-speed drive, or other high-powered electrical
device.
Environmental
The Rosemount 3107 and 3108 ultrasonic transmitters are Intrinsically Safe (IS)
approved for hazardous area installations.
The 3107 is designed for open or closed tank installation. It is weatherproof and
protected against the ingress of dust
The 3108 is designed for open channel flow measurement. It is weatherproof and
protected against the ingress of dust
Avoid installing the 3107 and 3108 near heat sources
Figure 3. Environmental considerations
Installation
Mount the transmitter above the liquid using the 1-in. thread provided, but no
closer than 13.8 in. (0,35 m) to the surface. The transmitter does not detect any
liquid surface closer than 12 in. (0,3 m) to the transmitter face
The transmitter should be mounted vertically to ensure a good echo from the liquid
surface. The beam half angle of the transmitter is 6 degrees (Figure 5 on page 7)
OKOK OK

July 2016
6
Quick Start Guide
Obstructions in the tank, or well, may generate echoes which can be confused with
the real liquid surface echo. Obstructions within the beam angle generate strong
false echoes. Wherever possible, the transmitter should be positioned to avoid
false echoes.
To avoid detecting unwanted objects in the tank or well, it is advisable to maintain
a distance of at least 1.3 in. from the center line of the transmitter for every foot
(11 cm per meter) range to the obstruction. (See Figure 5 on page 7).
No false echoes are generated if the transmitter is located near the side of the tank
or well and the wall is smooth and free of protrusions. However, there will still be a
reduction in the echo size. It is recommended that the transmitter be mounted no
closer than 12 in. (0,3 m) to the wall to avoid a large reduction in the echo size
If the transmitter is mounted in an enclosed tank with a domed top, avoid
mounting the transmitter in the center of the tank roof because this could act as a
parabolic reflector and create unwanted echoes
Avoid applications where heavy condensation could form on the transmitter face
If the transmitter is mounted in a stand-off or nozzle, the transmitter face should
protrude at least 0.2 in. (5 mm) into the tank
If the transmitter is used in environments where direct sunlight can cause high
surface temperatures on exposed instruments, a sun-shade is recommended
Mounting the transmitter above the liquid surface
A 1 in. thread is provided to mount the transmitter (Figure 4). The thread form is either
BSPP (G1) or NPT, and is marked below the mounting thread.
Mounting bracket
The transmitter is supplied with a purpose made 316 Stainless Steel mounting bracket
(Figure 4) which should be used to mount the transmitter over the liquid surface.
The bracket is designed to fit over the threaded neck of the transmitter and is retained
by a locknut
Use a chain or wire through the hole provided in the bracket, which is shaped to
ensure that the transmitter will hang perpendicular to the liquid surface.
Never suspend the transmitter by the cable. Check that the material of the chain or
wire is corrosion resistant to the liquids and any vapors present.
The bracket may be bolted to a suitable cross member above the liquid surface. Ensure
the transmitter is perpendicular to the surface to maximise the return echo size.
Figure 4. Mounting bracket
A. 1-in. mounting thread
A

Quick Start Guide
7
July 2016
Note
To help with alignment, the echo size (signal strength) can be indicated on the
Rosemount 3490 Series Control Unit or a Field Communicator.
Flange mounting
The instrument (accessory) flanges supplied by Emerson are manufactured from PVC
and are a full face design. Care must be taken when installing to a raised face mating
flange on the tank or vessel to prevent distortion of the PVC flange by over-tightening
the bolts. See Product Data Sheet for a list of all accessories and their part numbers.
Figure 5. Flange mounting
A. Transmitter is mounted vertically (maximum deviation of 3°).
B. 6° beam half angle.
C. 1.3 in./ft. (11 cm/m). Minimum of 12 in. (0.3 m).
Mounting from a conduit
The 3107 and the 3108 can be mounted from a conduit using the optional adaptor
accessory. See Product Data Sheet for a list of all accessories and their part numbers.
A
C
B

July 2016
8
Quick Start Guide
Open channel flow installations
Mount an ultrasonic transmitter over an area of clear liquid. Avoid mounting the
transmitter directly over any inlet stream. Never suspend the transmitter by the cable.
The positioning is critical, and should be the correct distance upstream from the flow
structure as stated in the relevant standard for your country. For example, in the ISO
standards, the distance should be four to five times the maximum height of the water
(Hmax) for a thin plate weir, or three to four times Hmax for a flume. For optimum
accuracy, position the transmitter’s front face at a height equal to the sum of the
maximum flow depth plus the transmitter deadband of 12.2 in. (300 mm) plus an
extra 2 in. (50 mm).
It is important that the bottom reference of the transmitter should be related to the
datum of the primary measuring device (Figure 7).
When setting the bottom reference on a ‘V’- notch weir, it is important the true invert
is used (Figure 8 on page 9) and not the meniscus level.
Figure 6. Choosing the height position above a flow
A. Transmitter front face
B. Hmax
C. Transmitter bottom reference = Hmax + 12.2 in. (300 mm) + 2 in. (50 mm)
Figure 7. Bottom reference of a flume or weir
A. Transmitter bottom reference C. Approach channel
B. Primary element (e.g. flume, weir) invert D. Flow
A
B
C
A
D
CB

Quick Start Guide
9
July 2016
Note
The transmitter should be free from a situation where it is likely to 'drown'
(refer to the relevant standard for further information)
Figure 8. Bottom reference of a ‘V’ notch weir
A. Transmitter bottom reference (i.e. true invert)
B. Meniscus level
The Rosemount 3108 transmitter has a factory fitted remote temperature sensor.
The temperature sensor is enclosed in a M8 x 1.5 threaded stainless steel body, and
can be installed in a suitable plastic conduit box and clamped in place using a suitable
compression type cable gland.
Open weir chamber
Mount the remote temperature sensor so that it is representative of the mean air
temperature in the chamber and is in a shaded area away from direct sunlight and
solar radiation.
Enclosed or partially covered flume chamber
Mount the remote temperature sensor in the approach channel, in a shaded area away
from direct sunlight and solar radiation. The temperature sensor should be positioned
in the weir chamber or flume approach channel so the average air temperature can be
accurately measured. The temperature sensor must be protected at all times from
direct sunlight and any radiated heat.
In extreme high temperatures, for the best accuracy and stability of level
measurement reading, the transmitter should be shrouded to prevent the incidence
of direct sunlight and solar radiation. If the flow structure permits, mount the
transmitter within the flow channel or chamber.
Note
For some installations, the use of a calibration device is mandatory. Emerson offers
the Rosemount Head Verification Device (HVD) for this purpose.
See Quick Installation Guide for more information.
BA

July 2016
10
Quick Start Guide
Connecting the transmitter
Note
To comply with the CSA requirements, the transmitters must be powered from a
Rosemount 3490 Series Control Unit, or a class 2 or separate extra-low voltage (SELV)
source.
Other devices may reset if connecting the transmitter to a multi-drop system while the
loop is powered. De-energize loop to avoid devices being reset.
The 3107 and 3108 are two-wire, loop-powered transmitters accepting external
power supplies as follows:
12 to 40 Vdc in a non-hazardous area
12 to 30 Vdc in a hazardous area
Each transmitter is supplied with a factory-fitted PVC sheathed, two-core, shielded
cable for communications and external power supply connections. There are no cable
conduit entries and no covers to remove. The cable may be cut to length on site or
may be extended using a junction box and suitable extension cable.
Installation in a non-hazardous area
1. Make sure that the power supply is disconnected.
2. Connect the cable wires (Figure 9), taking note of the required voltage of
12 to 40 Vdc for non-hazardous applications.
Installation in a hazardous area
When used with a Rosemount 3490 Series Control Unit, no additional safety barriers
are required. If powering the transmitter from any other source, ensure a suitable
Intrinsically Safe barrier is fitted in the non-hazardous (safe) area.
To connect the transmitter:
1. Make sure that the power supply is disconnected.
2. Connect the cable wires (Figure 9), taking note of the restricted voltage of
12 to 30 Vdc for hazardous applications.
Figure 9. Wiring
A. Remote Temperature Sensor (3108 Only)
B. Black: 0 Vdc
C. Red: 12 to 40 Vdc (non-hazardous area), 12 to 30 Vdc from protective barrier (hazardous area)
D. Non-hazardous Area: Connect Cable Screen To Standard Ground (Earth) or
Hazardous Area: Connect Cable Screen To I.S. Ground (Earth)
B
C
D
A

Quick Start Guide
11
July 2016
Configuration
The transmitter can be configured and verified using a Field Communicator or a
Rosemount 3490 Series Control Unit.
The parameters in this section are for a sufficient for a basic level, contents (volume),
or open channel flow application. For a more advanced application, refer to the
Rosemount 3107 and 3108 Reference Manual.
Transmitter base units
When the transmitter is shipped from the factory, the default factory setting for Base
Units is “metric” or “imperial ft” depending on the model order code.
Note
Keep a record of your programmed settings. Changing the base units will reset
parameters to their default factory settings in the appropriate units.
Field Communicator and AMS
To view or change the transmitter base units:
1. From the Home screen,
select 3: Service Tools.
2. Select 4: Maintenance.
3. Select 3: Utilities.
4. Select 3: Set Base Units.
5. Select new base units.
Note
When on-screen messages appear, take action if needed and press “OK”.
Rosemount 3490 Series Control Unit
To view or change the transmitter base units:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select SYSTEM, and then select Base Units.
4. Select new base units.
Note
To get the same base units on the control unit, switch the power off and then on
again. The control unit prompts for the transmitter’s Bottom Reference value in
the new base units.
Set Base Units (ft)
m
ft
in
ft
ENTER
ABORT
(Field Communicator screen)
Base Units
Esc=Quit =Edit
metric
(Rosemount 3491 screen)

July 2016
12
Quick Start Guide
Transmitter bottom reference
This is the transmitter’s Bottom Reference setting. It is the distance measured
vertically along the ultrasonic beam path from the User Preferred Sensor Reference
Point (UPSRP) to the Zero Level of a tank or an open channel (Figure 10 on page 13).
The zero level establishes where the transmitter starts to measure the process value. It
is not necessary to have the 4 mA output start at the zero level, and the 4 mA starting
pointing can be any liquid height above or below this zero level.
Note
This parameter is important for calibrating and configuring the transmitter.
Field Communicator or AMS
To view or change the bottom reference:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 1: Basic Setup.
4. Select 2: Bottom Reference P010.
5. Input the new bottom reference,
and press “ENTER” to save it.
6. Press “SEND” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the bottom reference:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select DUTY, and then select Bottom Ref.
4. Follow the on-screen instructions to input
and save the new setting.
Bottom Reference P010
40.000 ft
40.000 ft
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
lFN
(Field Communicator screen)
Bottom Ref. P010
40.000ft
Esc=Quit =Edit
(Rosemount 3491 screen)

Quick Start Guide
13
July 2016
Figure 10. Tank geometry
The process value (e.g. liquid level) is indicated in the HART Primary Variable (D900),
which drives the 4–20 mA output signal.
Parameter Fast Key 3490 Series Menu Navigation
Lower Blanking (P063) 2, 2, 5, 6 SETUP,[Tag], ENGINEERING, Lower Blanking
Upper Blanking (P023) 2, 2, 5, 5 SETUP,[Tag], ENGINEERING, Upper Blanking
Distance Offset (P060) 2, 2, 2, 2 SETUP,[Tag], DUTY, Distance Offset
Level Offset (P069) 2, 2, 2, 4 SETUP,[Tag], DUTY, Level Offset
20mA Point1
1. Configure this parameter if not communicating HART variables (PV, SV, TV, and FV) to a Host.
2, 2, 1, 3 SETUP, [Tag], OUTPUT, CURRENT, Upper Range Val.
4mA Point12, 2, 1, 4 SETUP, [Tag], OUTPUT, CURRENT, Lower Range Val.
Primary Variable (D900) 1, 2, 1 MONITOR,[Tag], READINGS, VARIABLES, Primary Variable
Level SV (D901) 1, 2, 2 MONITOR,[Tag], READINGS, VARIABLES, Level SV
Distance TV (D902) 3, 2, 1, 3 MONITOR,[Tag], READINGS, VARIABLES, Distance TV
Distance (D910) 3, 1, 2, 1, 1 MONITOR,[Tag], DIAGNOSTICS, Distance
Abbreviations:
TRP= Tank Reference Point. SRP = Sensor Reference Point. UPSRP = User Preferred SRP
4–20mA/HART
Rosemount
3107 or 3108
Rosemount
3490 Series
control unit
SRP
Zero
level
Bottom
reference
(P010)
Lower
blanking
(P063)
Upper
blanking
(P023)
Distance (D910)
Level SV (D901)
Distance TV
(D902)
Level
offset
(P069)
Distance offset
(P060)
TRP
UPSRP
20mA point
4mA point
Liquid Level

July 2016
14
Quick Start Guide
Transmitter primary variable units (P012)
This selects alternative display units for the HART Primary Variable (PV), which are
then reported to a HART Master Device such as a Rosemount 3490 Series Control Unit.
Note
Selecting alternative display units does not automatically re-scale the PV value.
Use the parameter Transmitter Scale Factor (page 16) to manually re-scale the
value (or base units) into appropriate units.
Field Communicator or AMS
To view or change the PV Units:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 3: Profiling.
4. Select 1: Primary Variable Units P012.
5. Select new units, and then press “Enter” to
save the selection.
6. Press “SEND” to update the transmitter.
Note
If the HART PV has no units, select and confirm the “None”, “Unknown”, or
“Not Used” option as appropriate for the HART Master Device (host).
Rosemount 3490 Series Control Unit
To view or change the PV Units:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select UNITS, and then select PV Units.
4. Follow the on-screen instructions to select
and confirm the new setting. If the HART PV
has no units, select and confirm the “None”
option.
Transmitter tank shape / non-linear profile (P011)
This selects the shape of a tank or an open channel, and establishes the linear or
non-linear relationship between the live liquid level (height) and the process value
(PV) derived from that level. The transmitter is pre-programmed with popular profiles
that are mathematical formulas to convert a linear level reading to a flow or
volumetric process value (PV). The Current Output is then driven by the flow or
volumetric PV.
Note
Select “Linear” if the process value (PV) is a level measurement.
Primary Variable Units P012
ft
Cum
Cum/h
Cum/s
ft
gal/min
Impgal
Impgal/d
ft
ENTER
ESC
(Field Communicator screen)
PV Units P012
ft
Esc=Quit =Edit
(Rosemount 3491 screen)

Quick Start Guide
15
July 2016
Field Communicator or AMS
To change the tank shape / non linear profile:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 3: Profiling.
4. Select 2: Set Non-Linear Profile.
5. Select a new profile, and then press “Enter”
to save the selection.
6. Press “SEND” to update the transmitter.
7. The selected profile can be viewed at
Fast Key sequence 2, 2, 3, 3.
Note
When on-screen messages appear, take action if needed and press “OK”.
Rosemount 3490 Series Control Unit
To change the tank shape / non linear profile:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select DUTY, and then select Tank Shape.
4. Follow the on-screen instructions to select
and save the new setting.
Select Non-Linear Profile: (Linear)
Linear
Special Plotted
Horizontal Cylinder Flat
Spherical
Horizontal Cylinder Domed
Flume/weir (3/2)
V notch (5/2)
Linear
ENTER
ABORT
(Field Communicator screen)
Tank Shape P011
Linear
Esc=Quit =Edit
(Rosemount 3491 screen)

July 2016
16
Quick Start Guide
Transmitter scale factor / K-factor (P013)
Level measurement
When the process value (PV) is a level measurement in meters, feet, or inches, this
parameter converts the level measurement into alternative units before being output.
Enter a value of 1.0 if alternative units are not required.
Volume measurement
When the PV is a volume measurement from a standard non-linear-shaped tank e.g.
cylinder or sphere, use this parameter to enter the volume of the ideal shaped tank
(Figure 11).
When the PV is a volume measurement from a regular-shaped tank e.g. square or
rectangular, use this parameter to enter the volume change per unit of the base unit.
When the PV is a volume measurement from an irregular-shaped tank, use this
parameter to enter the maximum volume relating to the Profile Height (page 17).
See also the Special Plot section on page 19 for defining the irregular-shaped tank.
Figure 11. Volume from a cylinder/sphere
A. Rosemount 3107 or 3108
B. Rosemount 3490 Series Control Unit
C. 4–20mA/HART
D. Bottom Reference (P010)
E. Profile Height (P014)
Open channel measurement
When the PV is the flow rate in a standard open channel, use this parameter to enter
the scale factor (‘k’ term) in a flow rate calculation. See page 14 for selecting a flow
profile.
When the PV is the flow rate in an irregular-shaped open channel, use this parameter to
enter the maximum flow rate. See also the Special Plot section on page 19 for defining
the irregular-shaped channel.
P013 = Full Volume of Ideal Cylindrical or
Spherical Tank of Constant Diameter P014
C
A
E
B
D

Quick Start Guide
17
July 2016
Field Communicator or AMS
To view or change the scale factor / k-factor:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 3: Profiling.
4. Select 4: Scale Factor P013 or
4: k-factor P013, depending on the
Non-Linear Profile selected.
5. Input the factor, and press “ENTER” to save it.
6. Press “SEND” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the scale factor / k-factor:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select DUTY, and then select PV Scale Factor.
4. Follow the on-screen instructions to edit and save the new setting.
Note
Some flow profiles automatically populate this parameter, and do not allow
editing.
Profile height / Power factor (P014)
Level measurement
This is not used for level measurements. It does not appear on the Field Communicator
unless required for volume or flow measurements.
Volume measurement
When the process value (PV) is a volume measurement from a standard
non-linear-shaped tank e.g. an ideal horizontal cylinder or a sphere, use this parameter
to enter the diameter (see Figure 11 on page 16).
When the PV is a volume measurement from a regular-shaped tank e.g. square or
rectangular, this parameter is not used.
When the PV is a volume measurement from an irregular-shaped tank, use this
parameter to enter the maximum height. See also the Special Plot section on page 19
for defining the irregular-shaped tank.
Open channel measurement
When the PV) is a flow rate in a standard open channel, this parameter is used as the
power factor (‘pwr’ term) in a flow rate calculation. See page 14 for selecting a flow
profile.
When the PV is the flow rate in an irregular-shaped open channel, use this parameter to
enter the maximum height. See also the Special Plot section on page 19 for defining
the irregular-shaped channel.
Scale Factor P013
1
1
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
lFN
(Field Communicator screen)
PV Scale Factr P013
1.000
Esc=Quit =Edit
(Rosemount 3491 screen)

July 2016
18
Quick Start Guide
Field Communicator or AMS
To view or change the diameter, maximum
height, or power factor:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 3: Profiling.
4. Select 5: Non-Linear Profile Height P014 or
5:Power Factor P014, depending on the
Non-Linear Profile selected.
5. Input a new value, and press “ENTER” to save it.
6. Press “SEND” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the diameter, maximum
height, or power factor:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select DUTY.
4. Select Profile Height.
5. Follow the on-screen instructions to edit and save the new setting.
(Press the Enter ( ) key if prompted to change the mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
Note
Some flow profiles automatically populate this parameter, and do not allow
editing.
Non-Linear Profile Height P014
1 ft
1
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
lFN
(Field Communicator screen)
Profile Height P014
1.0000ft
Esc=Quit =Edit
(Rosemount 3491 screen)

Quick Start Guide
19
July 2016
Profile points 1 to 10 (P030 to P039)
These parameters are used to define an irregular-shaped profile for calculating the
process value (PV) from a live level reading. See Figure n on page 18 for an example of
how these parameters are used.
Field Communicator or AMS
To view or change the profile point:
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 3: Profiling.
4. Select 6: Plot Non-Linear Profile Points.
5. Select a profile point
e.g. 1: Profile Point1 P030.
6. Input a new value, and then select “ENTER” to save it.
7. Press “SEND” to update the transmitter.
Note
The profile point parameters are only accessible on a Field Communicator
if they are required for a selected profile. The points can be changed only if the
“Special Plotted” profile has been selected.
Rosemount 3490 Series Control Unit
To view or change the profile point:
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3107”).
3. Select DUTY, and then NLP CURVE.
4. Select a profile point e.g. “Profile Pt. 1”.
5. Follow the on-screen instructions to edit and save the new setting.
(Press the Enter ( ) key if prompted to change the mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
Procedure for P011=“Special Plot”
1. Draw the graph of Process Value (PV) versus Liquid Height, and note the maximum
points (Figure n).
2. Enter the maximum volume or flow into PV Scale Factor (P013) (page 16).
3. Enter the maximum liquid height into Profile Height (P014) (page 17).
4. Use parameters Profile Point 1 to 10 (P030 to P039) (page 19) to enter the Y-axis
percentages that relate to the X-axis fixed percentages and produce the curve.
In the example, 60% of the maximum height (on the X-axis) relates to a percentage of
the maximum PV on the Y-axis. The related percentage on the Y-axis, say 55%, is
entered into parameter Profile Point 6 (P035).
The transmitter interpolates linearly between the plotted points to give an accurate
curve fit, which will determine the output process value (PV) from the live level
(height) measurement.
Profile Point1 P030
10.000%
10.000%
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
7
4
1
7
4
1
i
k
o
lFN
(Field Communicator screen)
Profile Pt. 1
10.000%
Esc=Quit =Edit
(Rosemount 3491 screen)

July 2016
20
Quick Start Guide
Figure 12. Volume or flow from 2-stage weir
Rectangular
weir
V-notch
weir
4–20mA/HART
Rosemount
3107 or 3108
Profile
height
(P014)
Bottom reference
(P010)
Rosemount
3490 Series
control unit
Y
X
0,0
P039 = Maximum process value (PV)
Maximum height (P014)
(Entered percentages relating
output PV to maximum PV)
(Fixed percentages relating height to maximum height)
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
P030
P031
P032
P033
P035
P036
P037
P038
P039
P034
P013 = Maximum volume or flow
