Emerson Rosemount 702DX22 User manual

Reference Manual
00809-0200-4702, Rev CA
February 2013
Rosemount 702 Wireless Discrete Transmitter

i
Reference Manual
00809-0200-4702, Rev CA
Title Page
February 2013
Rosemount 702 Wireless
Discrete Transmitter
Read this manual before working with the product. For personal and system safety, and for
optimum product performance, make sure to thoroughly understand the contents before
installing, using, or maintaining this product.
The United States has two toll-free assistance numbers and one international number.
Customer Central
1 800 999 9307 (7:00 a.m. to 7:00 p.m. CST)
National Response Center
1 800 654 7768 (24 hours a day)
Equipment service needs
International
1 952 906 8888
The products described in this document are NOT designed for nuclear-qualified
applications.
Using non-nuclear qualified products in applications that require nuclear-qualified
hardware or products may cause inaccurate readings.
For information on Rosemount nuclear-qualified products, contact an Emerson Process
Management Sales Representative.

ii
Reference Manual
00809-0200-4702, Rev CA
Title Page
February 2013
The power module with the wireless unit contains two “C” size primary lithium/thionyl chloride
batteries. Each battery contains approximately 2.5 grams of lithium, for a total of 5 grams in
each pack. Under normal conditions, the battery materials are self-contained and are not
reactive as long as the batteries and the pack integrity are maintained. Care should be taken to
prevent thermal, electrical, or mechanical damage. Contacts should be protected to prevent
premature discharge.
Battery hazards remain when cells are discharged.
Power modules should be stored in a clean and dry area. For maximum battery life, storage
temperature should not exceed 30 °C.
The power module has surface resistivity greater than one gigaohm and must be properly
installed in the wireless device enclosure. Care must be taken during transportation to and from
the point of installation to prevent electrostatic charge build-up.
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance with
the appropriate local, national, and international standards, codes, and practices. Please
review the approvals section of the 702 Reference Manual for any restrictions associated
with a safe installation.
Before connecting a Field Communicator in an explosive atmosphere, ensure the
instruments are installed in accordance with intrinsically safe or non-incendive field
wiring practices
Process leaks may cause harm or result in death:
Install and tighten process connectors before applying pressure
Electrical shock can result in death or serious injury:
Avoid contact with the leads and terminals. High voltage that may be present on leads
can cause electrical shock
The 702 transmitter and all other wireless devices should be installed only after the Smart
Wireless Gateway has been installed and is functioning properly. Wireless devices should
also be powered up in order of proximity from the Smart Wireless Gateway, beginning with
the closest. This will result in a simpler and faster network installation.
Shipping considerations for wireless products:
The unit was shipped to you without the power module installed. Please remove the power
module prior to shipping.
Each power module contains two “C” size primary lithium batteries. Primary lithium
batteries are regulated in transportation by the U. S. Department of Transportation, and are
also covered by IATA (International Air Transport Association), ICAO (International Civil
Aviation Organization), and ARD (European Ground Transportation of Dangerous Goods). It
is the responsibility of the shipper to ensure compliance with these or any other local
requirements. Please consult current regulations and requirements before shipping.

iii
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents
1Section 1: Introduction
1.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 Using this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.3 Models covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.3.1 Rosemount 702DX22 Wireless Discrete Transmitter . . . . . . . . . . . . . . . . . .3
1.3.2 Rosemount 702DX61 Wireless Discrete Transmitter for liquid hydrocarbon
leak detection3
1.3.3 Rosemount 702DX32 Wireless Discrete Transmitter . . . . . . . . . . . . . . . . . .3
1.3.4 Rosemount 702DX42 Wireless Discrete Transmitter . . . . . . . . . . . . . . . . . .3
1.4 Transmitter overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.4.1 Functions of the transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.4.2 Wireless Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.4.3 Choosing an Installation Location and Position. . . . . . . . . . . . . . . . . . . . . . . .5
1.4.4 Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.4.5 Verifying Operating Atmosphere. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.5 Service Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1.6 Product Recycling/Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2Section 2: Configuration: Models 702DX22 and 702DX61
2.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.1.2 Connecting the switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2 Configuring the Device Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.3 Configuring on the bench with a Field Communicator . . . . . . . . . . . . . . . . . . . . . .10
2.4 Configuring the Device Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.4.1 Configuring Transmitter with Dry Contact Inputs, Measurement Option Code
22 (702DX22)11
2.4.2 Configuring Transmitter with Liquid Hydrocarbon Detection, Measurement
Option Code 61(702DX61)12
2.5 HART menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.5.1 Dry contact inputs, measurement option code 22 (702DX22) . . . . . . . . .13
2.5.2 Liquid Hydrocarbon Detection, Measurement Option Code 61(702DX61)14
2.5.3 Fast Key Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.6 Remove Power Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Contents

iv
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents
3Section 3: Mounting, Wiring Switches, and Sensors: Models
702DX22 and 702DX61
3.1 Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.2 Installing the transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.2.1 Installing the Transmitter in a Direct Mount Configuration . . . . . . . . . . . .19
3.2.2 Installing the Transmitter in a Remote Mount. . . . . . . . . . . Configuration21
3.3 Wiring Switches and Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.3.1 Wireless Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.3.2 Wiring Switches and Sensors with Liquid Hydrocarbon Detection, Measure-
ment Option Code 61(702DX61)24
3.4 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.5 Grounding the Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
4Section 4: Commissioning: Models 702DX22 and 702DX61
4.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.2 Configuring the transmitter to communicate with the wireless network . . . . . .30
4.3 Using AMS Wireless Configurator to configure the transmitter . . . . . . . . . . . . . .30
4.4 Using a field communicator to change the network ID and join key . . . . . . . . . .30
4.5 Verifying operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
4.5.1 AMS Wireless Configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
5Section 5: Operation and Maintenance: Models 702DX22 and
702DX61
5.1 Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
5.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
5.2 Discrete Input from Switches and Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
5.2.1 Dry Contact Inputs, Measurement Option Code 22 (702DX22) . . . . . . . .36
5.2.2 Wireless output specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
5.2.3 Liquid Hydrocarbon Detection, Measurement Option Code 61 (702DX61)39
5.3 Interpreting LCD Screen Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
5.3.1 Startup Screen Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
5.3.2 Diagnostic Button Screen Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
5.3.3 Network Connection Status Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
5.3.4 Device Diagnostic Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
5.4 Replacing the power module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

v
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents
6Section 6: Configuration: Models 702DX32 and 702DX42
6.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
6.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
6.1.2 Ensuring proper switch connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
6.2 Discrete channel configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
6.3 Device network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
6.3.1 Configuring the Transmitter with Dry Contact Inputs, Measurement Option
Code 32, 42 (702DX32, 702DX42)58
6.4 HART Menu Tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
6.4.1 Measurement Option Code 32, 42 (702DX32, 702DX42) . . . . . . . . . . . . .59
6.4.2 Measurement Option Code 32, 42 (702DX32, 702DX42) . . . . . . . . . . . . .60
6.4.3 Measurement Option Code 32, 42 (702DX32, 702DX42) . . . . . . . . . . . . .61
6.4.4 Fast Key Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
6.5 Removing the power module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
7Section 7: Mounting, Wiring Switches, and Output Circuits:
Models 702DX32 and 702DX42
7.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
7.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
7.2 Installing the transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
7.2.1 Installing the Rosemount 702 Transmitter in a direct mount . . . . . . . . . .64
7.2.2 Installing the 702 Transmitter in a Remote Mount. . . . . . . . . . . . . . . . . . . .66
7.3 Wiring switches and sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
7.3.1 Dry Contact Inputs, Measurement Option Code 32, 42 (702DX32, 702DX42)
67
7.3.2 Dry contact switch inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
7.3.3 Output Circuits, measurement option code 42 (702DX42) . . . . . . . . . . . .69
7.3.4 Safety shower and eye wash monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
7.4 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
7.5 Grounding the Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
8Section 8: Commissioning: Models 702DX32 and 702DX42
8.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
8.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
8.2 Configuring the transmitter to communicate with the wireless network . . . . . .78
8.3 Using a field communicator to change the network ID and join key . . . . . . . . . .78
8.4 Verifying operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
8.4.1 AMS Wireless Configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

vi
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents
9Section 9: Operation and Maintenance: Models 702DX32 and
702DX42
9.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
9.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
9.2 Discrete Input from Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
9.2.1 Dry Contact Inputs, Measurement Option Code 32, 42 (702DX32, 702DX42)
84
9.2.2 Wireless Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
9.2.3 Momentary Discrete Inputs, measurement option code 32 and 42 (702DX32,
702DX42)87
9.3 Discrete output circuits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
9.4 Modbus and OPC mapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
9.5 Interpreting the LCD screen messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
9.5.1 Startup screen sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
9.5.2 Diagnostic button screen sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
9.5.3 Network connection status screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
9.5.4 Device diagnostic screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
9.6 Replacing the power module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
AAppendix A: Specifications and Reference Data
A.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
A.1.1 Functional specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
A.1.2 Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
A.1.3 Performance specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
A.2 Dimensional drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
A.3 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
A.3.1 Wireless Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
A.3.2 Other Options (Include with selected model number) . . . . . . . . . . . . . . 113
BAppendix B: Product Certifications
B.0.1 Approved manufacturing locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
B.0.2 European Union Directive Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
B.0.3 Telecommunication compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
B.0.4 FCC and IC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
B.0.5 Ordinary Location Certification for FM Approvals. . . . . . . . . . . . . . . . . . . 115
B.0.6 Hazardous Locations Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

vii
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents
CAppendix C: High Gain Remote Antenna Option
C.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
C.1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
C.2 Functional specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
C.3 Installation Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
C.4 Transient / Lightning Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
C.5 Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
C.6 Installing the High Gain Remote Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
DAppendix D: Installation Instructions and Drawings for Safety
Shower Monitoring

viii
Reference Manual
00809-0200-4702, Rev CA
Table of Contents
February 2013
Table of Contents

1
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
Section 1 Introduction
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1
Using this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1
Models covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Transmitter overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Service Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Product Recycling/Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 8
1.1 Safety messages
Instructions and procedures in this section may require special precautions to ensure the safety
of the personnel performing the operations. Information that potentially raises safety issues is
indicated by a warning symbol ( ). Please refer to the following safety messages before
performing an operation preceded by this symbol.
1.1.1 Warnings
1.2 Using this manual
The sections in this manual provide information on installing, operating, and maintaining the
Rosemount 702 Wireless Discrete Transmitter. Section 2 through Section 5 are for the
Rosemount 702DX22 and Rosemount 702DX61 models. The Rosemount 702DX22 is the legacy
702 transmitter that has discrete input function only. The Rosemount 702DX61 is a special
version for liquid hydrocarbon leak detection with Tyco®TraceTek®sensors. Section 6 through
Section 9 are for the Rosemount 702DX32 and Rosemount 702DX42 models. The Rosemount
702DX32 has all of the functionality of the 702DX22, with the addition of momentary discrete
input sensing and counting. The 702DX42 adds the capability of discrete output switching.
Failure to follow these installation guidelines could result in death or serious injury:
Only qualified personnel should perform the installation
Explosions could result in death or serious injury.
Before connecting a Field Communicator in an explosive atmosphere, make sure that
the instruments are installed in accordance with intrinsically safe or non-incendive
field wiring practices
Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications
Process leaks could result in death or serious injury.
Do not remove the switch while in operation
Install and tighten switches before applying pressure
Electrical shock could cause death or serious injury.
Use extreme caution when making contact with the leads and terminals

2
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
The manual sections are organized as follows:
Section 2: Configuration: Models 702DX22 and 702DX61 contains information on the
configuration of the Rosemount 702 transmitter so that it can be added to the wireless network.
This configuration can be done using the AMS Suite™ Wireless Configurator or a Field
Communicator. Field Communicator menu trees are here.
Section 3: Mounting, Wiring Switches, and Sensors: Models 702DX22 and 702DX61 contains
information on the mounting of the transmitter and wiring of switches and sensor to the
transmitter.
Section 4: Commissioning: Models 702DX22 and 702DX61 contains information for the
commissioning of the transmitter onto the wireless network, and how to verify that the
transmitter has successfully joined.
Section 5: Operation and Maintenance: Models 702DX22 and 702DX61 provides detailed
information on operation of the Rosemount 702 transmitter with various switch and sensor con-
figurations. LCD display messages are shown. Power module replacement is described.
Section 6: Configuration: Models 702DX32 and 702DX42 contains information on the
configuration of the Rosemount 702 transmitter so that it can be added to the wireless network.
This configuration can be done using the AMS Suite Wireless Configurator or a Field
Communicator. Field Communicator menu trees are here.
Section 7: Mounting, Wiring Switches, and Output Circuits: Models 702DX32 and 702DX42
contains information on the mounting of the transmitter and wiring of switches and sensor to
the transmitter.
Section 8: Commissioning: Models 702DX32 and 702DX42 contains information for the
commissioning of the transmitter onto the wireless network, and how to verify that the
transmitter has successfully joined.
Section 9: Operation and Maintenance: Models 702DX32 and 702DX42 provides detailed
information on operation of the 702 transmitter with various switch and sensor configurations.
Also described are: Momentary discrete input detection and counting, discrete output switch
function, and variable reporting and mapping. LCD display messages are shown. Power module
replacement is described.
Appendix A: Specifications and Reference Data supplies functional, physical and performance
specifications; as well as ordering information.
Appendix B: Product Certifications contains telecommunication compliance information,
ordinary location certification, hazardous locations certificates and intrinsic safety installation
drawings.
Model Number Functionality Manual Sections
702DX22 Two channel discrete input 1, 2, 3, 4, 5
702DX61 One channel for Tyco TraceTek liquid hydrocarbon leak
detection 1, 2, 3, 4, 5
702DX32 Two channel discrete input with momentary input detection
and counting 1, 6, 7, 8, 9
702DX42 Two channel discrete input or discrete output, with
momentary input detection and counting 1, 6, 7, 8, 9

3
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
Appendix C: High Gain Remote Antenna Option describes the high gain remote antenna, its
specifications and installation.
1.3 Models covered
The following Rosemount 702 Wireless Discrete Transmitters are covered by this manual:
1.3.1 Rosemount 702DX22 Wireless Discrete Transmitter
Two input channels,
Discrete input only
1.3.2 Rosemount 702DX61 Wireless Discrete Transmitter for
liquid hydrocarbon leak detection
Detects hydrocarbon leaks using Tyco TraceTek sensor
Color coded terminal block for easy wiring of Tyco sensors
Compatible with Tyco TT5000 TraceTek fuel sensing cable
Compatible with Tyco TT-FSS TraceTek Fast Fuel Sensor
1.3.3 Rosemount 702DX32 Wireless Discrete Transmitter
Two discrete input channels
Momentary input detection and counting
1.3.4 Rosemount 702DX42 Wireless Discrete Transmitter
Two channels
Each channel configurable to discrete input or discrete output
Momentary input detection and counting
Discrete output switch function
1.4 Transmitter overview
Features of the Rosemount 702 Wireless Discrete Transmitter include:
An installation-ready solution that provides a variety of mounting options, transmitter
configurations, and switches
Flexibility to meet your most demanding applications
Wireless output with >99% data reliability delivers rich HART®data, protected by
industry leading security
Single or dual switch input with logic for limit contact and opposing contact
applications
The integral LCD conveniently displays the primary switch input and diagnostics of the
transmitter
Simple and easy installation practices currently being used for robust installations

4
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
1.4.1 Functions of the transmitter
Switches produce either an open or closed signal. By using simple HART configuration, the 702
transmitter converts the switch signal to a wireless-enabled signal.
1.4.2 Wireless Considerations
Power Up Sequence
The Smart Wireless Gateway should be installed and functioning properly before any wireless
field devices are powered. Install the Black Power Module, SmartPower™Solutions model
number 701PBKKF (part number 00753-9220-0001) into the 702 transmitter to power the
device. Wireless devices should also be powered up in order of proximity from the Gateway,
beginning with the closest. This will result in a simpler and faster network installation. Enable
Active Advertising on the Gateway to ensure that new devices join the network faster. For more
information see the Smart Wireless Gateway Manual (Document Number 00809-0200-4420).
Antenna Position
The antenna should be positioned vertically, either straight up or straight down, and it should be
approximately 3 ft. (1 m) from any large structure, building, or conductive surface to allow for
clear communication to other devices.
Figure 1-1. Antenna Position
Preparing (or sealing) the conduit entries
Upon installation, ensure that each conduit entry is either sealed with a conduit plug with
appropriate thread sealant, or has an installed conduit fitting or cable gland with appropriate
thread sealant.

5
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
Figure 1-2. Locating Conduit Entries
Connecting the Field Communicator to the Power Module
The Power Module needs to be connected for the Field Communicator to interface with the 702
transmitter.
Figure 1-3. Field Communicator Connections
1.4.3 Choosing an Installation Location and Position
Choosing an Installation Location and Position
When choosing an installation location and position, take into account access to the
transmitter. For best performance, the antenna should be vertical with space between objects in
a parallel metal plane, such as a pipe or metal framework, as the pipes or framework may
adversely affect the antenna’s performance.
Conduit Entry
Conduit Entry
COMM
P/N00753-9200-0020
1
2
3
4

6
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
1.4.4 Electrical
Caring for the Power Module
The Rosemount 702 Wireless Discrete Transmitter is self-powered. The included Black Power
Module contains two “C” size primary lithium/thionyl chloride batteries. Each battery contains
approximately 2.5 grams of lithium, for a total of 5 grams in each pack. Under normal
conditions, the battery materials are self-contained and are not reactive as long as the batteries
and the power module are maintained. Care should be taken to prevent thermal, electrical, or
mechanical damage. Contacts should be protected to prevent premature discharge.
Use caution when handling the power module, it may be damaged if dropped from heights in
excess of 20 feet (6.10 m).
Making Switch Connections
Make switch connections through the cable entry in the side of the connection head. Be sure to
provide adequate clearance for cover removal.
1.4.5 Verifying Operating Atmosphere
Verify that the operating atmosphere of the transmitter is consistent with the appropriate
hazardous locations certifications.
Isolating the transmitter from sources of heat
The transmitter will operate within specifications for ambient temperatures between -40 and
185 °F (-40 and 85 °C). Heat from the process is transferred from the switch to the transmitter
housing. If the expected process temperature is near or beyond specification limits, consider
using an extension, or remote mount the transmitter to thermally isolate it from the process.
Figure 1-4 provides an example of the relationship between the transmitter housing
temperature rise and the extension length.
Figure 1-4. Rosemount 702 Transmitter Connection Head Temperature Rise vs. Extension
Length
Housing Temperature Rise, Above
Ambient °C (°F)
3 4 5 6 7 8 9
0
60 (108)
50 (90)
40 (72)
30 (54)
20 (36)
10 (18)
4.2
55
Extension Length (in.)
815 °C (1500 °F) Process Temperature
540 °C (1000 °F) Process Temperature
250 °C (482 °F) Process Temperature

7
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
Example
The transmitter specification limit is 185 °F (85 °C). If the ambient temperature is 131 °F (55 °C)
and the maximum process temperature to be measured is 1500 °F(815 °C), the maximum
permissible connection head temperature rise is the transmitter specification limit minus the
ambient temperature (moves 185 °F to 131 °F [85 to 55 °C]), or 86 °F (30 °C).
In this case, an extension of 5-in. (0.13 m) meets t his requirement, but 6-in. (0.15 m) provides
an additional margin of protection, thereby reducing risk of ambient thermal damage.
Temperature Limits
1.5 Service Support
To expedite the return process outside of North America, contact your Emerson Process
Management representative,
Within the United States, call the Emerson Process Management Response Center toll-free
number 1 800 654 7768. The center, which is available 24 hours a day, will assist you with any
needed information or materials.
The center will ask for product model and serial numbers, and will provide a Return Material
Authorization (RMA) number. The center will also ask for the process material to which the
product was last exposed.
Operating Limit Storage Limit
With LCD Display -4 to 175 °F
-20 to 80 °C -40 to 185 °F -40 to 85 °C
Without LCD Display -40 to 185 °F
-40 to 85 °C -40 to 185 °F -40 to 85 °C
Individuals who handle products exposed to a hazardous substance can avoid injury if they
are informed of, and understand, the hazard. If the product being returned was exposed to
a hazardous substance as defined by OSHA, a copy of the required Material Safety Data
Sheet (MSDS) for each hazardous substance identified must be included with the returned
goods.

8
Reference Manual
00809-0200-4702, Rev CA
Section 1: Introduction
February 2013
Introduction
Shipping Wireless Products (Lithium Batteries):
The unit was shipped with the Power Module not installed. Please remove the Power Module
from the unit before shipping.
Primary lithium batteries (charged or discharged) are regulated during transportation by the
U.S. Department of Transportation. They are also covered by IATA (International Air Transport
Association), ICAO (International Civil Aviation Organization), and ARD (European Ground
Transportation of Dangerous Goods). It is the responsibility of the shipper to ensure compliance
with these or any other local requirements. Consult current regulations and requirements
before shipping.
1.6 Product Recycling/Disposal
Recycling of equipment and packaging should be taken into consideration. The product and
packaging should be disposed of in accordance with local and national legislation.

9
Reference Manual
00809-0200-4702, Rev CA
Section 2: Configuration: Models 702DX22 and 702DX61
February 2013
Configuration: Models 702DX22 and 702DX61
Section 2 Configuration: Models
702DX22 and 702DX61
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 9
Configuring the Device Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 10
Configuring the Device Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 11
HART menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page13
Remove Power Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 15
2.1 Safety messages
Instructions and procedures in this section may require special precautions to ensure the safety
of the personnel performing the operations. Information that potentially raises safety issues is
indicated by a warning symbol ( ). Please refer to the following safety messages before
performing an operation preceded by this symbol.
2.1.1 Warnings
Failure to follow these installation guidelines could result in death or serious injury:
Only qualified personnel should perform the installation
Explosions could result in death or serious injury.
Before connecting a Field Communicator in an explosive atmosphere, make sure that
the instruments are installed in accordance with intrinsically safe or non-incendive
field wiring practices
Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications
Process leaks could result in death or serious injury.
Do not remove the switch while in operation
Install and tighten switches before applying pressure
Electrical shock could cause death or serious injury.
Use extreme caution when making contact with the leads and terminals

10
Reference Manual
00809-0200-4702, Rev CA
Section 2: Configuration: Models 702DX22 and 702DX61
February 2013
Configuration: Models 702DX22 and 702DX61
2.1.2 Connecting the switches
The 702 transmitter is compatible with a number of simple switches. When ordered in the
optional configuration for Liquid Hydrocarbon Detection, option code 61, the 702 transmitter is
compatible with Tyco®TraceTek®Fast Fuel Sensors and TraceTek sensing cable. Figure 2-1 on
page 11 shows the correct input connections to the switch terminals on the transmitter. To
ensure a proper switch connection, anchor the switch lead wires into the appropriate
compression terminals and tighten the screws.
Wiring the transmitter
If the switch is installed in a high-voltage environment and a fault condition or installation error
occurs, the sensor leads and transmitter terminals could carry lethal voltage. Use extreme
caution when making contact with the leads and terminals.
Use the following steps to wire the sensor and power supply to the transmitter:
1. Remove the transmitter enclosure cover (if applicable).
2. Attach the sensor leads according to the wiring diagram Figure 3-3 on page 4.
3. Connect the Black Power Module.
4. Verify the connection by viewing the LCD.
5. Replace the cover and tighten (if applicable).
2.2 Configuring the Device Sensor
Remove the power module-side housing cover to expose the terminal block and HART
communication terminals, then connect the power module to power the unit for configuration.
The 702 transmitter will receive any HART communication from a handheld Field
Communicator, or AMS Wireless Configurator.
2.3 Configuring on the bench with a Field
Communicator
When using a Field Communicator, any configuration changes must be sent to the transmitter
using the Send key (F2). AMS Wireless Configurator configuration changes are implemented
when the Apply button is clicked.
Configuring on the Bench with AMS Wireless Configurator
AMS Wireless Configurator is capable of connecting to devices directly, using a HART modem,
or with the Gateway. When configuring on the bench with a HART modem, double click the
device icon, then choose the Configure/Setup tab (or right click and select Configure/Setup).
Configure the device settings using the Direct Connection menu. When configuring with the
Gateway, double click the device icon then choose the Configure/Setup tab (or right click and
select Configure/Setup). Configure the device settings using the Wireless Connection menu. To
check or change sensor configuration using a Field Communicator, enter the following Fast Key
Sequence: 2, 2, 2.
