INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
DIRECT-VENT
FIREPLACE STOVE MODELS:
DVP(20,30)MS(30,70)(N,P)-1
WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas
supplier, call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
�
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certied kit is used.
WARNING
Improper installation, adjustment, alteration ,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult a
qualied installer, service agency, or the gas
supplier.
GAS-FIRED
MH30033
Page 1

42603-4-0421Page 2
TABLE OF CONTENTS
SECTION PAGE
Important Safety Information......................................................................................................................................3
Safety Information For Users Of Propane Gas..........................................................................................................4
Requirements For Massachusetts .............................................................................................................................5
Introduction ................................................................................................................................................................6
Specications.............................................................................................................................................................7
Gas Supply ................................................................................................................................................................8
Clearances........................................................................................................................................................... 9-10
Venting Stove......................................................................................................................................................11-13
Termination Clearances ...........................................................................................................................................14
Vent Clearances.......................................................................................................................................................15
Vent System Identication........................................................................................................................................16
Framing And Finishing ....................................................................................................................................... 17-18
Horizontal Termination .............................................................................................................................................18
Vertical Termination............................................................................................................................................ 19-20
DVP20MS Log Identication....................................................................................................................................21
DVP20MS Log Placement ................................................................................................................................. 22-27
DCP30MS Log Identication....................................................................................................................................28
DVP30MS Log Placement ................................................................................................................................. 29-33
Operating Instructions..............................................................................................................................................34
Main Burner Flame Characteristics..........................................................................................................................35
Wiring.......................................................................................................................................................................36
Millivolt Lighting Instructions ....................................................................................................................................37
Millivolt Wiring..........................................................................................................................................................38
Millivolt Troubleshooting...........................................................................................................................................39
IP Operating Instructions .........................................................................................................................................40
IP Electronic System Wiring Diagram......................................................................................................................41
Intermittent Pilot Lighting Instructions......................................................................................................................42
Intermittent Control System Troubleshooting..................................................................................................... 43-45
Maintenance ...................................................................................................................................................... 46-47
Maintenance And Service ........................................................................................................................................48
DVP20MS Parts List .......................................................................................................................................... 49-50
DVP20MS Parts View..............................................................................................................................................51
DVP30MS Parts List .......................................................................................................................................... 52-53
DVP30MS Parts View..............................................................................................................................................54
CIB3-1 Optional Blower Installation Instructions - DVP30MS............................................................................ 55-57
CIB4-1 Optional Blower Installation Instructions - DVP20MS............................................................................ 58-60
Master Parts Distributor List.....................................................................................................................................61
How To Order Repair Parts......................................................................................................................................61
Quick Reference Guide...................................................................................................................................... 62-63
Appliance Service History.................................................................................................................................. 64-66
Warranty ..................................................................................................................................................................67

42603-4-0421 Page 3
DO NOT OPERATE THIS APPLIANCE WITHOUT GLASS FRONT PANEL INSTALLED
Before enclosing the vent pipe assembly, operate the appliance to ensure it is venting properly.
IMPORTANT SAFETY INFORMATION
WARNING
1. “Due to high temperatures, the appliance should be
located out of trafc and away from furniture and
draperies.”
2. “Children and adults should be alerted to the hazards
of high surface temperature and should stay away to
avoid burns or clothing ignition.”
3. “Young children should be carefully supervised when they
are in the same room as the appliance. Toddlers, young
children, and others may be susceptible to accidental
contact burns. A physical barrier is recommended if there
are at-risk individuals in the house. To restrict access to a
replace or stove, install an adjustable safety gate to keep
toddlers, young children, and other at-risk individuals out
of the room and away from hot surfaces.”
4. For appliances requiring a barrier, as determined under
Clause 5.15.4: “A barrier designed to reduce the risk of
burns from the hot viewing glass is provided with this
appliance and must be installed for the protection of
children and other at-risk individuals.”
5. “If the barrier becomes damaged, the barrier must
be replaced with the manufacturer’s barrier for this
appliance. ”
6. “Clothing or other ammable material should not be
placed on or near the appliance.”
7. “Any safety screen, guard, or barrier removed for
servicing an appliance must be replaced prior to
operating the appliance” (see Clause 4.1.6).
8. “Installation and repair should be done by a qualied
service person. The appliance should be inspected
before use and at least annually by a professional service
person. More frequent cleaning might be required due to
excessive lint from carpeting, bedding material, et cetera.
It is imperative that control compartments, burners, and
circulating air passageways of the appliance be kept
clean.”
9. The instructions for an appliance optionally for use
with glass doors (or equivalent) shall state that, “Only
doors certied with the appliance shall be used.”
10. The instructions for an appliance not intended for use
with glass doors (or equivalent) shall emphasize that
the appliance is not for use with glass doors.
11. Where applicable, provide a means by which the
consumer can identify the barrier, (such as graphic
representation, clear description, or reference marking).
WARNING
CARBON MONOXIDE POISONING HAZARD
Failure to follow the steps outlined below for each appliance
connected to the venting system being placed into operation
could result in carbon monoxide poisoning or death.
The following steps shall be followed for each appliance
connected to the venting system being placed into operation,
while all other appliances connected to the venting system
are not in operation:
1. Seal any unused openings in the venting system.
2. Inspect the venting system for proper size and horizontal
pitch, as required in the National Fuel Gas Code ANSI
Z223.1/NFPA 54 or the National Gas and Propane
Installation Code CSA B149.1 and these instructions.
Determine that there is no blockage or restriction,
leakage, corrosion and other deciencies which could
cause an unsafe condition.
3. As far as practical, close all building doors and
windows and all doors between the space in which
the appliance(s) connected to the venting system are
located and other spaces of the building.
4. Close replace dampers.
5. Turn on clothes dryers and any appliance not connected
to the venting system. Turn on any exhaust fans, such
as range hoods and bathroom exhausts, so they are
operating at maximum speed. Do not operate a summer
exhaust fan.
6. Follow the lighting instructions. Place the appliance
being inspected into operation. Adjust the thermostat
so appliance is operating continuously.
7. Test for spillage from draft hood equipped appliances
at the draft hood relief opening after 5 minutes of main
burner operation. Use the ame of a match or candle.
8. If improper venting is observed during any of the
above tests, the venting system must be corrected
in accordance with National Fuel Gas Code, ANSI
Z223.1/NFPA and/or National Gas and Propane
Installation Code, CSA B149.1.
9. After it has been determined that each appliance
connected to the venting system properly vents when
tested as outlined above, return doors, windows,
exhaust fans, replace dampers and any other gas-red
burning appliance to their previous conditions of use.

42603-4-0421Page 4
SAFETY INFORMATION FOR USERS OF PROPANE GAS
Propane is a ammable gas which can cause res and
explosions. In its natural state, propane is odorless and
colorless. You may not know all the following safety precau-
tions which can protect both you and your family from an ac-
cident. Read them carefully now, then review them point by
point with the members of your household. Someday when
there may not be a minute to lose, everyone's safety will
depend on knowing exactly what to do. If, after reading the
following information, you feel you still need more informa-
tion, please contact your gas supplier.
PROPANE GAS WARNING ODOR
If a gas leak happens, you should be able to smell the gas
because of the odorant put in the Propane Gas.
That's your signal to go into immediate action!
• Do not operate electric switches, light matches, use your
phone. Do not do anything that could ignite the gas.
• Get everyone out of the building, vehicle, trailer, or area. Do
that IMMEDIATELY.
• Close all gas tank or cylinder supply valves.
• Propane Gas is heavier than air and may settle in low areas
such as basements. When you have reason to suspect a gas
leak, keep out of basements and other low areas. Stay out
until reghters declare them to be safe.
• Use your neighbor's phone and call a trained Propane Gas
service person and the re department. Even though you may
not continue to smell gas, do not turn on the gas again. Do
not re-enter the building, vehicle, trailer, or area.
• Finally, let the service man and reghters check for escaped
gas. Have them air out the area before you return. Properly
trained Propane Gas service people should repair the leak,
then check and relight the gas appliance for you.
NO ODOR DETECTED - ODOR FADE
Some people cannot smell well. Some people cannot smell
the odor of the chemical put into the gas. You must nd
out if you can smell the odorant in propane. Smoking can
decrease your ability to smell. Being around an odor for a time
can affect your sensitivity or ability to detect that odor. Sometimes
other odors in the area mask the gas odor. People may not smell
the gas odor or their minds are on something else. Thinking
about smelling a gas odor can make it easier to smell.
The odorant in Propane Gas is colorless, and it can fade
under some circumstances. For example, if there is an under-
ground leak, the movement of the gas through soil can lter the
odorant. Odorants in Propane Gas also are subject to oxidation.
This fading can occur if there is rust inside the storage tank or in
iron gas pipes.
The odorant in escaped gas can adsorb or absorb onto or into
walls, masonry and other materials and fabrics in a room. That
will take some of the odorant out of the gas, reducing its odor
intensity.
Propane Gas may stratify in a closed area, and the odor intensity
could vary at different levels. Since it is heavier than air, there
may be more odor at lower levels. Always be sensitive to the
slightest gas odor. If you detect any odor, treat it as a serious
leak. Immediately go into action as instructed earlier.
SOME POINTS TO REMEMBER
• Learn to recognize the odor of Propane Gas. Your lo-
cal Propane Gas Dealer can give you a "Scratch and Sniff"
pamphlet. Use it to nd out what the propane odor smells like.
If you suspect that your Propane Gas has a weak or abnormal
odor, call your Propane Gas Dealer.
• If you are not qualied, do not light pilot lights, perform
service, or make adjustments to appliances on the Propane
Gas system. If you are qualied, consciously think about the
odor of Propane Gas prior to and while lighting pilot lights or
performing service or making adjustments.
• Sometimes a basement or a closed-up house has a musty
smell that can cover up the Propane Gas odor. Do not try to
light pilot lights, perform service, or make adjustments in an
area where the conditions are such that you may not detect
the odor if there has been a leak of Propane Gas.
• Odor fade, due to oxidation by rust or adsorption on walls
of new cylinders and tanks, is possible. Therefore, people
should be particularly alert and careful when new tanks or
cylinders are placed in service. Odor fade can occur in new
tanks, or reinstalled old tanks, if they are lled and allowed to
set too long before relling. Cylinders and tanks which have
been out of service for a time may develop internal rust which
will cause odor fade. If such conditions are suspected to ex-
ist, a periodic sniff test of the gas is advisable. If you have
any question about the gas odor, call your Propane Gas
Dealer. A periodic sniff test of the Propane Gas is a good
safety measure under any condition.
• If, at any time, you do not smell the Propane Gas odorant and
you think you should, assume you have a leak. Then take the
same immediate action recommended above for the occasion
when you do detect the odorized Propane Gas.
• If you experience a complete "gas out," (the container is un-
der no vapor pressure), turn the tank valve off immediately. If
the container valve is left on, the container may draw in some
air through openings such as pilot light orices. If this oc-
curs, some new internal rusting could occur. If the valve is left
open, then treat the container as a new tank. Always be sure
your container is under vapor pressure by turning it off at the
container before it goes completely empty or having it relled
before it is completely empty.

42603-4-0421 Page 5
REQUIREMENTS FOR MASSACHUSETTS
For all side wall horizontally vented gas fueled equipment installed
in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the
Commonwealth and where the side wall exhaust vent termination
is less than seven feet above nished grade in the area of the vent-
ing, including but not limited to decks and porches, the following
requirements shall be satised:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At
the time of installation of the side wall horizontal vented gas fu-
eled equipment, the installing plumber or gastter shall observe
that a hard wired carbon monoxide detector with an alarm and
battery back-up is installed on the oor level where the gas
equipment is to be installed. In addition, the installing plumber
or gastter shall observe that a battery operated or hard wired
carbon monoxide detector with an alarm is installed on each
additional level of the dwelling, building or structure served by
the side wall horizontal vented gas fueled equipment. It shall be
the responsibility of the property owner to secure the services
of qualied licensed professionals for the installation of hard
wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fu-
eled equipment is installed in a crawl space or an attic,
the hard wired carbon monoxide detector with alarm and
battery back-up may be installed on the next adjacent oor
level.
b. In the event that the requirements of this subdivision can
not be met at the time of completion of installation, the
owner shall have a period of thirty days to comply with
the above requirements; provided, however, that during
said thirty day period, a battery operated carbon monoxide
detector with an alarm shall be installed.
2. APPROVED CARBONMONOXIDE DETECTORS. Eachcarbon
monoxide detector as required in accordance with the above
provisions shall comply with NFPA 720 and be ANSI/UL 2034
listed and IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be per-
manently mounted to the exterior of the building at a minimum
height of eight feet above grade directly in line with the exhaust
vent terminal for the horizontally vented gas fueled heating ap-
pliance or equipment. The sign shall read, in print size no less
than one-half inch in size, “GAS VENT DIRECTLY BELOW.
KEEP CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side wall
horizontally vented gas fueled equipment shall not approve the
installation unless, upon inspection, the inspector observes
carbon monoxide detectors and signage installed in accordance
with the provisions of 248 CMR 5.08(2)(a) 1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from
248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled “Equip-
ment Not Required To Be Vented” in the most current
edition of NFPA 54 as adopted by the Board; and
2. Product Approved side wall horizontally vented gas
fueled equipment installed in a room or structure
separate from the dwelling, building or structure used
in whole or in part for residential purposes.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIP-
MENT VENTING SYSTEM NOT PROVIDED. When the
manufacturer of a Product Approved side wall horizontally
vented gas fueled equipment does not provide the parts
for venting the ue gases, but identies “special venting
systems”, the following requirements shall be satised by
the manufacturer:
1. The referenced “special venting system” instructions
shall be included with the appliance or equipment
installation instructions; and
2. The “special venting systems” shall be Product Ap-
proved by the Board, and the instructions for that
system shall include a parts list and detailed installa-
tion instruction.
(e) Acopy of all installation instructions for all ProductApproved
side wall horizontally vented gas fueled equipment, all
venting instructions, all parts lists for venting instructions,
and/or all venting design instructions shall remain with the
appliance or equipment at the completion of the installation.

42603-4-0421Page 6
Instructions to Installer
1. Installer must leave instruction manual with owner after
installation.
2. Installer must have owner ll out and mail warranty card supplied
with the stove.
3. Installer should show owner how to start and operate the stove.
This direct vent gas stove heater is designed to operate with all
combustion air being siphoned from the outside of the building
and all exhaust gases expelled to the outside of the building. The
information contained in this manual pertains to all models and gas
control systems unless otherwise noted.
WARNING
This unit is not for use with solid fuels.
NOTICE: During initial ring of this unit, its paint will bake out and
smoke will occur. To prevent triggering of smoke alarms, ventilate
the room in which the unit is installed.
NOTICE: Remove screw in valve cover. Screw is required to prevent
shipping damage.
Appliance must not be connected to a chimney ue that is servicing
a separate solid-fuel burning appliance.
Installation in Residential Garages
Gas utilization equipment in residential garages shall be installed
so that all burners and burner ignition devices are located not less
than 18" (457 mm) above the oor.
Such equipment shall be located, or protected, so it is not subject
to physical damage by a moving vehicle.
Appliance Certication
This stove is design certied in accordance with American National
Standard/CSAStandardANSI Z.21-88/CSA2.33 and by Underwriters
Laboratories as a Direct Vent Gas Fireplace Heater and shall be
installed according to these instructions.
Consult your local building code agency, prior to installation, to ensure
compliance with local codes-including permits and inspections.
The stove, when installed with blower, must be electrically grounded
in accordance with local codes or, in absence of local codes, with
the National Electric CodeANSI/NFPA70 or Canadian Electric code,
CSA C22.1, if an external electrical source is utilized.
These models may be installed in a bedroom or bed-sitting room
in the U.S.A. and Canada.
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization equipment
or accessories and repair and servicing of equipment shall be
performed only by a qualied agency. The term “qualied agency”
means any individual, rm, corporation or company which either in
person or through a representative is engaged in and is responsible for
(a) the installation or replacement of gas piping or (b) the connection,
installation, repair or servicing of equipment, who is experienced in
such work, familiar with all precautions required and has complied
with all the requirements of the authority having jurisdiction.
Commonwealth of Massachusetts: The installation must be
made by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.
The installation must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code ANSI Z223.1/NFPA
54* Natural Gas and Propane Installation Code, or CSA B149.1 in
Canada.*Available from the American National Standards Institute,
Inc. 11 West 42nd St., New York, N.Y. 10036.
WARNING
ANY CHANGE TO THIS STOVE OR ITS CONTROLS CAN
BE DANGEROUS.
Improper installation or use of the stove can cause serious
injury or death from re, burns, explosions, or carbon
monoxide poisoning.
Any alteration of the original design, installed other than as
shown in these instructions or use with a type of gas not
shown on the rating plate is the responsibility of the person
and company making the change.
Important
All correspondence should refer to complete Model Number, Serial
Number and type of gas.
High Altitude
When installing this unit at an elevation above 2000 feet (in the
United States) it may be necessary to decrease the input rating by
changing the existing burner orice to a smaller size. Generally,
input should be reduced 4 percent for each 1000 feet above sea
level. However, if the heating value of the gas has been reduced,
this general rule may not apply. Check with local gas utility for proper
orice size identication.
Canadian High Altitude
Altitude: 0-4500 feet (0-1370 m)
When installing this unit at an elevation above 4500 feet (in Canada),
check with local authorities.
Consult your local gas utility for assistance in determining the proper
orice for location.
Preparation
This direct vent gas stove and its components are tested and safe
when installed in accordance with this Installation Manual. Report
to your dealer any parts damaged in shipment, specically check
glass condition. Do not install unit with damaged, incomplete, or
substitute parts. Read all instructions before starting installation
and follow these instructions carefully during installation to insure
maximum benet and safety. Failure to follow them will void your
warranty and may present a re hazard.
The warranty will be voided by, and the warranter disclaims any
responsibility for the following actions:
• Installation of any damaged stove or vent system component.
• Modication of the stove or direct vent system.
•
Installation other than as instructed by Empire Comfort Systems, Inc.
• Improper positioning of the logs or glass door.
• Installation and/or use of any component part not manufactured
or approved by manufacturer.
INTRODUCTION

42603-4-0421 Page 7
SPECIFICATIONS
MODEL DVP20MS DVP30MS
Gas Type Natural Gas Propane Gas Natural Gas Propane Gas
Input BTU/HR (KW/H) Max 19,500 26,500
Input BTU/HR (KW/H) Min 13,500 18,000 21,000
Gas Inlet (Pipe) 3/8" 3/8"
Orice 2.15mm 55 39 1.55mm
Air Shutter Setting 1/8" Full Open 3/16" Full Open
Gas Supply Pressure Max 10.5" W.C. / 2.614 kPa 13.0" W.C. / 3.237 kPa 10.5" W.C. / 2.614 kPa 13.0" W.C. / 3.237 kPa
Gas Supply Pressure Min 4.5" W.C. / 1.121 kPa 11.0" W.C. / 2.739 kPa 4.5" W.C. / 1.121 kPa 11.0" W.C. / 2.739 kPa
Gas Supply Pressure Manifold 3.5" W.C. / .872 kPa 10.0" W.C. / 2.490 kPa 3.5" W.C. / .872 kPa 10.0" W.C. / 2.490 kPa
Height 23-3/8" 27-1/8"
Width 22-1/8" 27-1/8"
Depth 16-1/2" 16-1/2"
VENTING ACCESSORIES (SPECIAL VENT KITS - DURAVENT CAN BE PURCHASED FROM EMPIRE COMFORT SYSTEMS, INC.)
DVKHP45
Horizontal Termination Vent Kit - Includes SD46DVA08AB, SD46DVA09, SD46DVA24B, SD46DVADC, SD46DVAE45B, SD46DVAE90B, SD46DVAHC, SD46DVAWT3.
DVK45LP Horizontal 45 Deg Vent Kit (For Propane only) - includes SD09261B, SD46DVAE45B, SD58DVADC, SD58DVAHSCH, SD58DVAWTEC.
DVK45NAT Horizontal 45 Deg Vent Kit (For Natural only) - includes SD46DVA12B, SD46DVADC, SD46DVAE45B, SD46DVAHC, SD46DVAWT3.
DVKVP45 Horizontal 45 Deg Vent Kit - includes SD46DVA12B, SD46DVA17TAB, SD46DVADC, SD46DVAE45B, SD46DVAE90B, SD46DVAHC, SD46DVAWT3.
DVKVP Vertical Termination Kit - includes SD46DVA48B (2 ea), SD46DVADC, SD46DVAF6, SD46DVAFS, SD46DVASC, SD46DVAHC
NOTE: On horizontal applications, snorkel kits may be used. DVP20MS(LP,NAT) and DVP30MSNAT: SD-46DVASNK14 (14-inch pipe snorkel) DVP30MSLP: SD-46DVASNK36 (36-inch pipe snorkel)
ACCESSORIES
TMV Millivolt Wall Thermostat - Reed Switch
FRBC Battery Operated Remote Control
FRBTC2 Battery Operated Remote Control with Thermostat
FREC Electric Remote Control
FWS Wall Switch
FRBTPS 7-Day Programmable Remote
TRW Remote Wall Thermostat
CIB3 Automatic Blower (DVP30MS)
CIB4 Automatic Blower (DVP20MS)
RVKN Remote Variable Control kit - "IP" Natural Gas Valve units only (must also use RCK20 Valve Cover kit on DVP20 Stove, or RCK30 Valve Cover kit on DVP30 Stove)
RVKP Remote Variable Control kit - "IP" Propane Gas Valve units only (must also use RCK20 Valve Cover kit on DVP20 Stove, or RCK30 Valve Cover kit on DVP30 Stove)
RCK20 Valve Cover Kit - For use on DVP20 Stove when installing the RVKN or RVKP Remote Variable Control kit.
RCK30 Valve Cover Kit - For use on DVP30 Stove when installing the RVKN or RVKP Remote Variable Control kit.
CONVERSION KITS
Part Number Description Used On Valve Type
31051 Propane to Natural DVP20MS30 MV
31052 Natural to Propane DVP20MS30 MV
31053 Propane to Natural DVP20MS70 IP
31054 Natural to Propane DVP20MS70 IP
31057 Propane to Natural DVP30MS30 MV
31058 Natural to Propane DVP30MS30 MV
31059 Propane to Natural DVP30MS70 IP
31060 Natural to Propane DVP30MS70 IP

42603-4-0421Page 8
GAS SUPPLY
Consult the current National Fuel Gas Code, ANSI Z223.1 CAN/
CGA-B149 (.1 or .2) installation code.
RECOMMENDED GAS PIPE DIAMETER
Pipe
Length
Schedule 40 Pipe
Inside Diameter
Tubing, Type L
Outside Diameter
Natural Propane Natural Propane
0-10 feet
0-3 meters
1/2”
12.7 mm
3/8”
9.5 mm
1/2”
12.7 mm
3/8”
9.5 mm
10-40 feet
4-12 meters
1/2”
12.7 mm
1/2”
12.7 mm
5/8”
15.9 mm
1/2”
12.7 mm
40-100 feet
13-30 meters
1/2”
12.7 mm
1/2”
12.7 mm
3/4”
19 mm
1/2”
12.7 mm
100-150 feet
31-46 meters
3/4”
19 mm
1/2”
12.7 mm
7/8”
22.2 mm
3/4”
19 mm
NOTE: Never use plastic pipe. Check to conrm whether your local
codes allow copper tubing or galvanized.
NOTE: Since some municipalities have additional local codes, it
is always best to consult your local authority and installation code.
The use of the following gas connectors is recommended:
— ANS Z21.24Appliance Connectors of Corrugated Metal Tubing
and Fittings
— ANS Z21.45Assembled FlexibleAppliance Connectors of Other
Than All-Metal Construction
The above connectors may be used if acceptable by the authority
having jurisdiction. The Commonwealth of Massachusetts requires
that a exible appliance connector cannot exceed three feet in length.
Figure 1
Installing A New Main Gas Shut-Off Valve
Each appliance should have its own manual gas shut-off valve.
A manual main gas shut-off valve should be located in the vicinity
of the unit. Where none exists, or where its size or location is not
adequate, contact your local authorized installer for installation
or relocation.
Compounds used on threaded joints of gas piping shall be resistant
to the action of liqueed petroleum gases. The gas lines must be
checked for leaks by the installer. This should be done with a soap
solution watching for bubbles on all exposed connections, and if
unexposed, a pressure test should be made.
Never use an exposed ame to check for leaks. Appliance must
be disconnected from piping at inlet of control valve and pipe
capped or plugged for pressure test. Never pressure test with
appliance connected; control valve will sustain damage!
NOTE: The gas control is equipped with a captured screw type
pressure test point, therefore it is not necessary to provide a 1/8"
test point up stream of the control.
A gas valve and ground joint union should be installed in the gas
line upstream of the gas control to aid in servicing. It is required by
the National Fuel Gas Code that a drip line be installed near the gas
inlet. This should consist of a vertical length of pipe tee connected
into the gas line that is capped on the bottom in which condensation
and foreign particles may collect.
When using copper or ex connector use only approved ttings.
Always provide a union so that gas line can be easily disconnected
for burner servicing.
The appliance and it's individual shut off valve must be disconnected
from supply piping system during any pressure testing of that system
at test pressures in excess of 1/2 psig (3.5 kPa).
The appliance must be isolated from the gas supply piping system
by closing its individual manual shut off valve during any pressure
testing of the gas supply piping system at test pressures equal to
or less than 1/2 psig (3.5 kPa).
CAUTION
If one of the procedures results in pressures in excess of
1/2 psig (14" w.c.) (3.5 kPa) on the stove gas valve, it will
result in a hazardous condition.
Checking Manifold Pressure
Both Propane and Natural Gas valves have a built-in pressure
regulator in the gas valve. Natural Gas models will have a manifold
pressure of approximately 3.5" w.c. (.871 kPa) for maximum input or
1.7" w.c. (.423 kPa) for minimum input at the valve outlet with the inlet
pressure to the valve from a minimum of 5.0" w.c. (1.245 kPa) for the
purpose of input adjustment to a maximum of 10.5" w.c. (2.615 kPa).
Propane Gas models will have a manifold pressure approximately
10.0" w.c. (2.49 kPa) for maximum input or 5.9" w.c. (1.469 kPa)
for minimum input at the valve outlet with the inlet pressure to the
valve from a minimum of 11.0" w.c. (2.739 kPa) for the purpose of
input adjustment to a maximum of 13.0" w.c. (3.237 kPa).
A 1/8" (3 mm) N.P.T. plugged tapping, accessible for test gauge
connection, is located on the outlet side of the gas control.

42603-4-0421 Page 9
In selecting a location for installation, it is necessary to provide ad-
equate accessibility clearances for servicing and proper operation.
Locating and Venting the Direct Vent Stove
Clearances: When facing the front of the direct vent stove the
minimum clearances to combustible construction (material) are
the following:
Top of appliance (ceiling) 36" (914.4 mm)
Rear Wall 2" (50.8 mm)
Side Wall 6" (152.4 mm)
Heater Corners (45° angle) to Wall 4" (101.6 mm)
Floor 0" (0 mm)
Installation on Rugs and Tile
This appliance must be installed on a at, solid, continuous surface
(e.g. wood, metal, concrete). This may be the oor, or it may be
raised up on a platform to enhance its visual impact. The continu-
ous surface may be covered with carpeting, vinyl, wood ooring
or other combustible material.
6” (153mm)
TO SIDE WALL
6” (153mm)
TO SIDE WALL
6” (153mm) TO
COMBUSTIBLE
MATERIAL
6” (153mm) TO
COMBUSTIBLE
MATERIAL
36” (915mm) TO CEILING OR
HORIZONTAL PROJECTION
ABOVE APPLIANCE
36” (915mm) TO CEILING OR
HORIZONTAL PROJECTION
ABOVE APPLIANCE
Figure 2
CLEARANCES
6" (153mm) TO
SIDEWALL
NOTE: HEATER INSTALLED AT 45° ANGLE IN CORNERNOTE: HEATER INSTALLED AT 45° ANGLE IN CORNER
4” (102mm) HEATER CORNERS TO SIDE WALL
4” (102mm) HEATER CORNERS TO SIDE WALL
10” DVP20
(254mm)
10” DVP20
(254mm)
10” DVP20
(254mm)
10” DVP20
(254mm)
4”
(102mm)
4”
(102mm)
14” DVP30
(355mm)
14” DVP30
(355mm)
14” DVP30
(355mm)
14” DVP30
(355mm)
Figure 3
2” (51mm) TO COMBUSTIBLE MATERIAL2” (51mm) TO COMBUSTIBLE MATERIAL
Figure 4
2" (51mm) TO COMBUSTIBLE MATERIAL
36" (915mm) TO
CEILING OR
HORIZONTAL
PROJECTION
ABOVE APPLIANCE
6" (153mm) TO
COMBUSTIBLE
MATERIAL
NOTE: HEATER
INSTALLED
AT 45° ANGLE
IN CORNER
4"
(102mm)
4" (102mm) HEATER CORNERS TO SIDEWALL

42603-4-0421Page 10
Special Vent Systems
The following vent systems are acceptable for use with the
DVP(20,30)MS stoves:
• Empire Horizontal Round Termination Kits - DVVK-4RE,
DVVK-4REVS
• Empire Horizontal Round Flex Termination Kits - DVVK-
4FRE, DVVK-4FREVS
• Duravent® Pro 4" - 6 5/8"
• American Metal® 4" - 6 5/8"
• Selkirk Direct-Temp® 4" - 6 5/8"
• ICC Inc. Excel 4" - 6 5/8"
• MetalFab SureSeal® 4" - 6 5/8"
• BDM Manufacturing 4" - 6 5/8"
• Olympia VENTIS® 4" - 6 5/8"
NOTE: American Metal®, Selkirk Direct-Temp®, MetalFab
SureSeal®, BDM Manufacturing, and ICC Inc. Excel CAN NOT
be used in side wall horizontal vent installations in the Common-
wealth of Massachusetts.
CLEARANCES (CONT'D)
Figure 5

42603-4-0421 Page 11
VENTING STOVE
Special Venting Notes:
• DVP20CCNAT - can be terminated horizontally with kit DVK45NAT
maximum 18".
• DVP20CCLP - can be terminated horizontally with kit DVK45LP
maximum 18".
• DVP20CC(LP,NAT) - can use a 14" short snorkel or 36" tall snorkel.
• DVP30CC (NATURAL) - Can be vented horizontally straight
out the back of stove if a minimum 14” snorkel is used. Or,
if venting horizontally, a 12” vertical vent is required off the
back of the stove before turning with an elbow horizontally
out the wall. See page 12.
• DVP30CC (PROPANE) - Can be vented horizontally straight
out the back of the stove if a 36” snorkel is used. Or, if
venting horizontally, a 24” vertical vent is required off the
back of the stove before turning with an elbow horizontally
out the wall. See page 12.
CAUTION
Total vertical run MUST BE completed before starting horizontal
run. Horizontal chimney run must slope upward (away from
stove) 1/4" per foot and vent termination must be level.
Sidewall Venting
The maximum vertical and horizontal distances are 25 feet and 12
feet, respectively. Vertical dimensions are based on top of stove to
centerline of pipe. Horizontal dimensions are based on centerline
of pipe to termination.
Under no circumstances should combustible materials (including
siding) be closer than 3" from the top of the 6 5/8" pipe or closer
than 1" on the sides and bottom.
Cutting the Hole
After the appliance has been positioned in its permanent location,
the hole through the exterior wall of the house can be cut. This
hole needs to be 10" high x 9" wide for 4 x 6 pipe and 12-1/2 high
x 10-1/2 wide for 5 x 8 pipe with its center line determined by the
amount of vertical arise and horizontal run of the termination. When
locating the hole it must be noted that the bottom of the cap must
be 12" above the ground level, and top of the cap must be no less
than 18" below a combustible projection, and no closer than 9" to
any wall running parallel to vent termination.
CHAPEAU D’ÉVACUATIONCHAPEAU D’ÉVACUATION
229 mm (9 po) VERS MUR LATÉRAL229 mm (9 po) VERS MUR LATÉRAL
Figure 6
Co-Linear to Co-Axial Connection
A Co-Axial to Co-Linear appliance connector is approved for
installation in vertical venting applications. One can be purchased
through Empire Comfort Systems or Simpson Dealer (part number
46DVA-GCL).
(DVKI)
CHAPEAU D'ÉVACUATION
RACCORD ROND
COLINÉAIRE-COAXIAL
PRÊT-À-MONTER
DE TERMINAISON
DE CONDUIT
DE CHEMINÉE
TUYAU FLEXIBLE
PRISE D'AIR
ÉVACUATION
COAXIAL DROIT
RACCORD
COAXIAL-COLINÉAIRE
(SD46DVA-GCL)
COUDE DE 45°
(SD46DVA-E45B)
Figure 7
VENT CAP
9' (222MM TO SIDE WALL
VENT CAP
ROUND CO-LINEAR TO
CO-AXIAL CONNECTOR
CHIMNEY LINER
TERMINATION KIT
FLEX PIPE
CO-AXIAL TO
CO-LINEAR
CONNECTOR
(SD46DVA-GCL)
45° ELBOW
(SD46DVA-E45B)
STRAIGHT
CO-AXIAL
(DETERMINE
LENGTH NEEDED
& PURCHASE
SEPARATELY)
EXHAUST
INTAKE
VERTICAL
VENT KIT
(DVKI)

42603-4-0421Page 12
Venting Graph (Dimensions in Feet)
1. Determine the height of the center of the termination. Using this
dimension on the Venting Graph, locate the point it intersects
with the slanted graph line, or the right edge of the graph.
2. From the point of this intersection, draw a vertical line to the
bottom of the graph.
3. Adjust the indicated maximum dimension for additional elbows
if necessary.
4. Position the unit so that maximum horizontal run is not exceeded.
Venting Requirements:
• Minimum vertical rise from appliance outlet before any elbows =
12 inches (305mm) for DVP20MS(LP,NAT) and DVP30MSNAT
and 24 inches (610 mm) for DVP30MSLP.
• Maximum vertical rise from appliance outlet = 40 feet (12.19 m).
• Maximum vertical rise and horizontal run is a combined total
of 25 feet (7.62 m).
• Maximum elbows = two 90°, for the second elbow subtract 5
feet from a horizontal run.
VENTING STOVE (CONT'D)
A
"A" Dimension
DVP20MS 24" (610mm)
DVP30MS 27" (686mm)
Figure 8 - Snorkel Installation
VENTING APPLICATIONS INFORMATION
Model Venting Run
Description
DVP20
Propane
DVP20
Natural
DVP30
Propane
DVP30
Natural
DVKHP45
24" Vertical,
then 90
degree
elbow to
Horizontal
Termination
Yes Yes Yes Yes
DVK45LP
Straight out
back with
Horizontal
venting and
termination.
May require
additional
venting
with 18"
maximum
Horizontal
run allowed.
Yes No No No
DVK45NAT
Straight out
back with
Horizontal
venting and
termination.
May require
additional
venting
with 18"
maximum
Horizontal
run allowed.
No Yes No No
DVKVP45
12" Vertical,
then 90
degree
elbow to
Horizontal
Termination.
Includes
a 11"- 17"
slip vent
section.
Yes Yes No Yes
DVKVP45
Kit used
with a 14"
Snorkel on
outside of
building.
Yes Yes No Yes
DVKVP45
Kit used
with a 36"
Snorkel on
outside of
building.
Yes Yes Yes Yes
DVKVP 96" Vertical
Termination Yes Yes Ye s Yes

42603-4-0421 Page 13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
VENTING MUST
TERMINATE IN
THIS AREA
VERTICAL RISE ABOVE FIREPLACE IN FEET
24”
012345678910 11 12 13 14
36
37
38
39
40
HORIZONTAL RUN IN FEET
29
30
31
33
32
33
34
35
26
27
28
Figure 9a - DVP20MS Figure 9b - DVP30MS
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
VENTING MUST
TERMINATE IN
THIS AREA
VERTICAL RISE ABOVE FIREPLACE IN FEET
28”
012345678910 11 12 13 14
36
37
38
39
40
HORIZONTAL RUN IN FEET
29
30
31
33
32
33
34
35
26
27
28
LP
NAT
To Use the Vent Graph
EXAMPLE A:
If the vertical rise from the appliance outlet is 21 feet, the horizontal
run to the outer wall ange of the vent termination must not exceed
4 feet with one 90° elbow.
EXAMPLE B:
If the vertical rise from the appliance outlet is 14 feet, the horizontal
run to the outer wall ange of the vent termination must not exceed
11 feet with one 90° elbow.
VENTING STOVE (CONT'D)
SPECIAL NOTE: For each 45 degree elbow installed in the horizontal
run, the length of the horizontal run MUST be reduced by 18 inches
(457.2 mm). This does not apply if the 45 degree elbows are installed
on the vertical rise of the vent system.
Example: According to the chart the maximum horizontal run is 12
feet and if two 45 degree elbows are required in the horizontal run
it must be reduced to 9 feet.
The maximum number of 45 degree elbows permitted per side
wall installation is two. These elbows can be installed in either the
vertical rise or horizontal run.

42603-4-0421Page 14
Figure 10
RECESSED LOCATION
OUTSIDE CORNER
INSIDE CORNER
“A” = COMBUSTIBLE 9” (229mm)
= NONCOMBUSTIBLE 2” (51mm)
BALCONY
WITH PERPENDICULAR SIDE WALL
BALCONY
WITH NO SIDE WALL
“C”=CLEARANCE FROM CORNER
IN RECESSED LOCATION
COMBUSTIBLE 9” (229mm)
NONCOMBUSTIBLE 2” (51mm)
“D”=MINIMUM WIDTH FOR BACK WALL
OF A RECESSED LOCATION
COMBUSTIBLE 38” (965mm)
NONCOMBUSTIBLE 24” (610mm)
“E” = MAXIMUM DEPTH OF 48” (1219mm)
FOR RECESSED LOCATION
“G”=COMBUSTIBLE 9” (229mm)
= NONCOMBUSTIBLE 2” (51mm)
“H”=COMBUSTIBLE 18” (457mm)
= NONCOMBUSTIBLE 12” (305mm)
“I” = COMBUSTIBLE 18” (457mm)
= NONCOMBUSTIBLE 12” (305mm)
“F” = COMBUSTIBLE 6” (305mm)
= NONCOMBUSTIBLE 6” (305mm)
Vertical Sidewall Installations
Important! Minimum clearance between vent pipes and combustible
materials is one inch (25 mm) on, bottom and sides and three inches
(51 mm) on top.
Important! When vent termination exits through foundation less
than 20" below siding outcrop, the vent pipe must ush up with the
siding. 46-DVA-HC termination cap must also be used.
Information on Various Venting Routes and Components
Important: It is always best to locate the appliance in such a way
that minimizes the number of offsets and horizontal vent length.
Since it is very important that the venting system maintain its balance
between the combustion air intake and the ue gas exhaust, certain
limitations as to vent congurations apply and must be strictly
adhered to.
The graph showing the relationship between vertical and horizontal
side wall venting will help to determine the various vent lengths
allowable.
The horizontal vent run refers to the total length of vent pipe from
the vent elbow of the appliance to the face of the outer wall.
TERMINATION CLEARANCES
Termination clearance for buildings with combustible and noncombustible exteriors.

42603-4-0421 Page 15
Figure 11
VENT CLEARANCES
Canadian Installations1 US Installations2 Canadian Installations1 US Installations2
A= Clearance above grade,
veranda, porch, deck, or
balcony
12 in (30 cm) 12 in (30cm)
I= Clearance to service
regulator vent outlet 3 ft (91 cm) 6 ft
B= Clearance to window or
door that may be open
6 in (15 cm) for appli-
ances ≤ 10,000 Btuh
(3 kW), 12 in (30 cm)
for appliances > 10,000
Btuh (3 kW) and ≤
100,000 Btuh (30 kW),
36 in (91 cm) for appli-
ances > 100,000 Btuh
(30 kW)
6 in (15 cm) for appli-
ances ≤ 10,000 Btuh (3
kW), 9 in (23 cm) for ap-
pliances > 10,000 Btuh
(3 kW) and ≤ 50,000
Btuh (15 kW), 12 in
(30 cm) for appliances >
50,000 Btuh (15 kW)
J= Clearance to nonme-
chanical air supply
inlet to building or the
combustion air inlet to
any other appliance
6 in (15 cm) for appli-
ances ≤ 10,000 Btuh (3
kW), 12 in (30 cm) for
appliances > 10,000
Btuh (3 kW) and ≤
100,000 Btuh (30 kW),
36 in (91 cm) for appli-
ances > 100,000 Btuh
(30 kW)
6 in (15 cm) for appli-
ances ≤ 10,000 Btuh
(3 kW), 9 in (23 cm) for
appliances > 10,000 Btuh
(3 kW) and ≤ 50,000 Btuh
(15 kW), 12 in (30 cm) for
appliances > 50,000 Btuh
(15 kW)
C= Clearance to
permanently
closed window
12 in (30 cm) 12 in (30 cm)
K= Clearance to a
mechanical air
supply inlet
6 ft (1.83 m)
3 ft (91 cm) above if
within 10 ft (3 m) hori-
zontally
D= Vertical clearance
ventilated soft located
above the terminal within
a horizontal distance of
2 feet (61 cm) from the
center line of the terminal
24 in (61 cm) 24 in (61 cm)
L= Clearance above paved
sidewalk or paved
driveway located on
public property 7 ft (2.13 m) † 7 ft (2.13 m) †
E= Clearance to
unventilated
soft
12 in (30 cm) 12 in (30 cm)
M= Clearance under
veranda, porch
deck, or balcony
12 in (30 cm) ‡ 12 in (30 cm) ‡
F= Clearance to
outside corner 6 in (15 cm) 6 in (15 cm) 1 In accordance with the current CSA B149.1, Natural Gas and Propane Instal- lation Code
G= Clearance
inside corner 9 in (23 cm) 9 in (23 cm) 2 In Accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code
H= Clearance to each side
of center line extended
above meter/regulator
assembly
3 ft (91 cm) within a
height 15 ft (4.5 m)
above the meter/regula-
tor assembly
3 ft (91 cm)
† A vent shall not terminate directly above a sidewalk or paved driveway that is
located between two single family dwellings and serves both dwellings
ATTENTION: Vinyl Soft, Vinyl Ceiling, Vinyl Overhang
Disclaimer
Clearances are to heat resistant material (i.e. wood, metal). This
does not include vinyl. Empire Comfort Systems Inc. will not be held
responsible for heat damage caused from terminating under vinyl
overhangs, vinyl ceilings or vinyl ventilated/unventilated softs.
‡Permitted only if veranda,, porch, deck, or balcony is fully open on a minimum
of two sides beneath the oor.
*For clearances not specied in ANSI Z223.1/NFPA 54 or CSA B149.1, one of
the following shall be indicated:
Clearance in accordance with local installation codes and the requirements of the
gas supplier.

42603-4-0421Page 16
Installing Vent Components
Begin the vent system installation by installing the rst Simpson
Duravent component on the top of the appliance with a 45° elbow
and rotate the vent elbow to the desired position then add horizontal
and vertical pipe lengths and then a horizontal or vertical termination
kit. Elbows can be added where necessary. See Pages 11 through
15 for venting requirements.
Simpson Duravent vent system components lock into place by
sliding the concentric pipe section with four equally spaced interior
beads onto the appliance collar or previously installed component
end with four equally spaced indented sections. When the internal
beads of each starting 6 5/8 inch outer pipe line up, rotate pipe
section clockwise 90° (approximately 3 inches). The vent pipe is
now locked together.
Continue adding components per the pre-planned vent system
conguration. Be certain that each succeeding vent component
is securely tted and locked into the preceding component in the
vent system.
Figure 13
Figure 12
VENT SYSTEM IDENTIFICATION
PART NAME "A" "B" "C"
6" PIPE 6" (152 mm) 1-1/2" (38 mm) 4-1/2" (114 mm)
9" PIPE 9" (229 mm) 1-1/2" (38 mm) 7-1/2" (191 mm)
12" PIPE 12" (305 mm) 1-1/2" (38 mm) 10-1/2" (267 mm)
24" PIPE 24" (610 mm) 1-1/2" (38 mm) 22-1/2" (572 mm)
36" PIPE 36" (914 mm) 1-1/2" (38 mm) 34-1/2" (876 mm)
48" PIPE 48" (1.220 m) 1-1/2" (38 mm) 46-1/2" (1.18 m)
45° ELBOW 5-1/2" (140 mm) 1-1/2" (38 mm) ---
90° ELBOW 6-1/2" (165 mm) 1-1/2" (38 mm) 5" (127 mm)

42603-4-0421 Page 17
Installing Support Brackets
Ahorizontal pipe support MUSTBE used for each 3 feet of horizontal
run. The pipe supports should be placed around 6-5/8 inch diameter
pipe and nailed in place to framing members. There MUST BE a
2 inch clearance to combustibles above 6-5/8 inch diameter pipe and
elbows and 1 inch clearance on both sides and bottom of 6-5/8 inch
to combustibles on all horizontal pipe sections and elbows.
Vertical runs of this vent systems must be supported every 4 feet
above the appliance ue outlet by wall brackets attached to the
6-5/8 inch vent pipe and secured with nails or screws to structural
framing members.
48”
(1219mm)
PIPE STRAP
MINIMUM 1” (25.4mm)
CLEARANCE TO
COMBUSTIBLE
CONSTRUCTION WITH
DOUBLE WALL VENT PIPE
STUD WALL
Figure 14
Installing Firestops
Firestops are required for safety whenever the vent system passes
through an interior wall, an exterior wall, or a ceiling. These restops
act as a rebreak heat shield and as a means to insure that minimum
clearances are maintained to the vent system.
Horizontal runs in the vent system which pass through either interior
or exterior walls, require the use of wall restops on both sides of
the wall through which the vent passes.
Position the restops on both sides of the 9-1/8 inch x 11 inch hole
for 4 x 6 inch pipe and 10-1/2 x 10-1/2 inch hole for 5 x 8 inch pipe,
previously cut. Secure with nails or screws. Continue the vent run
through the restops. See Figure 15.
11”
(297 mm)
MIN.
9 1/8”
(232 mm)
MIN.
OUTSIDE THIMBLE ASSEMBLY
INSIDE THIMBLE ASSEMBLY
EXTERIOR
SHEAVING
Figure 15
Vertical runs of this system which pass through ceilings require the
use of one ceiling restop at the hole in each ceiling through which
the vent passes.
Position a plumb bob directly over the center of the vertical vent
component and mark the ceiling to establish the center point of the
vent. Drill a hole or drive a nail through this center point and check
the oor above for any obstructions such as wiring or plumbing
runs. Reposition the appliance and vent system, if necessary, to
accommodate ceiling joists and/or obstructions.
Cut a 9 inch x 9 inch hole through the ceiling, using the center point
previously marked. Frame the hole with framing lumber the same
size as the ceiling joists. See Figure 16. If the area above the ceiling
is NOT an attic, position and secure the ceiling restop (46DVA-FS)
on the ceiling side of the previously cut and framed hole. See Figure
17. If the area above the ceiling IS an attic, position and secure
the restop on top of the previously framed hole. See Figure 18.
NOTE: Remove insulation from the framed area in the attic before
installing the restop and/or vent stop and/or vent pipes.
Figure 16
FRAMING AND FINISHING

42603-4-0421Page 18
Figure 17
Figure 18
Attach and secure the termination to the last section of horizontal
venting by sliding cap over the last section of horizontal venting to
ensure proper location.
NOTE: Termination cap should pass through the wall restop from
the exterior of the building. Adjust the termination cap to
its nal exterior position on the building.
WARNING
Termination cap must be positioned so that the arrow is
pointing up.
Using the termination cap in the center of the square hole, attach
the termination cap with the four wood screws provided. Before
attachment of the termination, run a bead of silicone sealant rated
above 250°F on its outside edge too, so as to make a seal to that
exterior wall.
NOTE: Wood screws can and should be replaced with appropriate
fasteners for use on stucco, brick, concrete or other types
of siding.
CAUTION
If exterior walls are nished with siding (vinyl, aluminum, etc.),
it is necessary to install the vinyl siding shield (46DVA-VSS).
Vinyl siding shield (46DVA-VSS) will be installed between the vent
termination and the exterior wall. See Figure 19. This horizontal
vent termination bolts onto the at portion of the vinyl siding standoff,
so an air space will exist between the wall and the termination cap. Figure 19
HORIZONTAL TERMINATION
FRAMING AND FINISHING (CONT'D)

42603-4-0421 Page 19
Vertical Terminations
Locate and mark the center point of the venting pipe. Using a nail
on the underside of the roof and drive this nail through this center
point. Make the outline of the roof hole around this center point.
NOTE: Size of the roof hole dimensions depend on the pitch of the
roof. There must be a 1 inch clearance (25 mm) to the vertical pipe
sections. This clearance is to all combustible material.
Cover the opening of the vent pipe and cut and frame the roof hole.
Use framing lumber the same size as the roof rafters and install the
frame securely. Flashing anchored to frame must withstand high
winds. The storm collar is placed over this joint to make a watertight
seal. Non-hardening sealant should be used to completely seal this
ashing installation.
Determining Minimum Vent Height Above the Roof.
WARNING
Major U.S. building codes specify minimum chimney and/or
vent height above the roof top. These minimum heights are
necessary in the interest of safety. These specications are
summarized in Figure 20.
ROOF PITCH H (MINIMUM
FEET METER
FLAT TO 6/12 1.0 0.30
6/12 TO 7/12 1.25 0.36
OVER 7/12 TO 8/12 1.5 0.46
OVER 8/12 TO 9/12 2.0 0.61
OVER 9/12 TO 10/12 2.5 0.76
OVER 10/12 TO 11/12 3.25 0.99
OVER 11/12 TO 12/12 4.0 1.22
OVER 12/12 TO 14/12 5.0 1.52
OVER 14/12 TO 16/12 6.0 1.83
OVER 16/12 TO 18/12 7.0 2.13
OVER 18/12 TO 20/12 7.5 2.27
OVER 20/12 TO 21/12 8.0 2.44
Figure 20
Figure 21
Note that for steep roof pitches, the vent height must be increased.
In high wind conditions, nearby trees, adjoining roof lines, steep
pitched roofs, and other similar factors can result in poor draft, or
down-drafting. In these cases, increasing the vent height may solve
this problem.
When terminating the vent cap near an exterior wall or overhang,
maintain minimum clearances as shown in Figure 20.
General Maintenance
Conduct an inspection of the venting system semi-annually.
Recommended areas to inspect are as follows:
1. Check areas of the venting system which are exposed to
the elements for corrosion. These will appear as rust spots
or streaks and, in extreme cases, holes. These components
should immediately be replaced.
2. Remove the cap and shine a ashlight down the vent. Remove
any bird nests or other foreign material.
3. Check for evidence of excessive condensate, such as water
droplets forming in the inner liner and subsequently dripping
out at joints. Continue condensate can cause corrosion of caps,
pipe and ttings. It may be caused by having excessive lateral
runs, too many elbows and exterior portions of the system being
exposed to cold weather.
4. Inspect joints to verify that no pipe sections or ttings have been
disturbed and, consequently, loosened.Also, check mechanical
supports, such as wall straps or plumbers' tape for rigidity.
Venting terminal shall not be recessed into a wall or siding. A
removable panel or other means must be provided in the enclosure
for visual inspection of the ue connection.
Installing the Vent System in a Chase
A chase is a vertical box like structure built to enclose the gas
appliance and/or it's vent system. Vertical vent runs on the outside of
a building may be, but are not required to be installed inside a chase.
Figure 22
CAUTION
Treatment of restop spacers and construction of the chase
may vary with the type of building. These instructions are
not substitutes for the requirements of local building codes.
Therefore, your local building codes must be checked to
determine the requirements for these steps.
VERTICAL TERMINATION

42603-4-0421Page 20
Ahorizontal pipe support MUST BE used for each 3 feet of horizontal
run. The pipe supports should be placed around 6-5/8 inch diameter
pipe and nailed in place to framing members. There MUST BE a 2
inch clearance to combustibles above 6-5/8 inch diameter pipe and
elbows and 1 inch clearance on both sides and bottom of 6-5/8 inch
to combustibles on all horizontal pipe sections and elbows.
Vertical runs of this vent systems must be supported every 4 feet
above the appliance ue outlet by wall brackets attached to the
6-5/8 inch vent pipe and secured with nails or screws to structural
framing members.
NOTE: When installing this vent system in a chase, it is always good
building practice to insulate the chase as you would the outside walls
of your home. This is especially important for cold climate installations.
Upon completion of building your chase framing, install the vent
system by following the instructions in this manual. Remember to build
the chase large enough so that minimum clearance of combustible
materials (including insulation) to the vent system are maintained.
Vertical Through the Roof Applications
Your Gas Stove has been approved for
a) Vertical installations up to 40 feet of vent run
b) Two sets of 45 degree elbow offsets within these vertical
installations. From 0 to a maximum of 8 feet a vent pipe can be
used between elbows.
c) Wall straps must be used to support offset pipe every 4 feet.
This applications will require that you rst determine the roof pitch
and use the appropriate venting components.
Reassembly and Resealing Vent-Air Intake System
Attach vent pipe to appliance air drop with four 1/2" hex-head screws
in position, replace vertical and horizontal pipe lengths, elbows and
horizontal or vertical termination kit.
All vent system components lock into place by sliding the concentric
pipe section with four equally spaced interior beads onto the
appliance collar or previously installed component end with four
equally spaced indented sections. When the internal beads of each
starting 6 5/8 inch outer pipe line up, rotate pipe section clockwise
90° (approximately 3 inches). The vent pipe is now locked together.
Continue replacing components per the vent system conguration.
Be certain that each succeeding vent component is securely tted
and locked into the preceding component in the vent system.
Installing Support Brackets
Figure 23
VERTICAL TERMINATION (CONT'D)
