Empire Comfort Systems DVP36DP31 Series Quick start guide

Page 1
DIRECT VENT GAS FIREPLACE
HEATER
MILLIVOLT STANDING PILOT
DVP36DP31(N,P)-2
DIRECT IGNITION
DVP36DP51N-1
INTERMITTENT PILOT
DVP36DP71(N,P)-3
REMOTE RF
DVP36DP91(N,P)-3
UL FILE NO. MH30033
— Donotstoreorusegasolineorotherammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
anyphoneinyourbuilding.
 • Immediately call your gas supplier from a
neighbor’sphone.Followthegassupplier’s
instructions.
• If you cannot reach your gas supplier, call the
redepartment.
— Installationandservicemustbeperformedbya
qualiedinstaller,serviceagencyorthegassup-
plier.
INSTALLATION INSTRUCTIONS
AND
OWNER’SMANUAL
GAS-FIRED
EMPIRE
EMPIRE
Comfort Systems
WARNING:Ifnotinstalled,operatedandmaintained
inaccordancewiththemanufacturer’sinstructions,
thisproductcouldexposeyoutosubstancesinfuel
or from fuel combustion which can cause death or
serious illness.
This appliance may be installed in an aftermarket,
permanentlylocated,manufacturedhome(USAonly)
ormobilehome,wherenotprohibitedbystateorlocal
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertibleforusewithothergases,unlessacertied
kitisused.
Installer: Leavethismanualwiththeappliance.
Consumer: Retainthismanualforfuturereference.
WARNING:Iftheinformationintheseinstruc-
tionsarenotfollowedexactly,areorexplosion
mayresultcausingpropertydamage,personalin-
jury or loss of life.
Direct Vent Zero Clearance Gas
Fireplace Heater

31451-2-1013Page 2
Section Page
TABLE OF CONTENTS
IMPORTANT SAFETY INFORMATION..................................................................................................................................... 3
SAFETY INFORMATION FOR USERS OF LP GAS................................................................................................................. 4
REQUIREMENTS FOR MASSACHUSETTS............................................................................................................................ 5
INTRODUCTION....................................................................................................................................................................... 6
SPECIFICATIONS..................................................................................................................................................................... 7
VENT SYSTEM IDENTIFICATION............................................................................................................................................ 8
SPECIAL VENT SYSTEMS....................................................................................................................................................... 8
FIREPLACE DIMENSIONS....................................................................................................................................................... 9
CLEARANCES ........................................................................................................................................................................ 10
LOCATING FIREPLACE ..........................................................................................................................................................11
GAS SUPPLY .......................................................................................................................................................................... 12
INSTALLATION .................................................................................................................................................................. 13-16
VENTING FIREPLACE - TOP ............................................................................................................................................ 17-20
EXAMPLES - TOP VENT RUN ............................................................................................................................................... 21
REAR VENT CONVERSION................................................................................................................................................... 22
VENTING FIREPLACE - REAR .............................................................................................................................................. 23
EXAMPLES - REAR VENT RUN............................................................................................................................................. 24
VENT CLEARANCES.............................................................................................................................................................. 25
FRAMING AND FINISHING ............................................................................................................................................... 26-27
TERMINATION CLEARANCES............................................................................................................................................... 28
HORIZONTAL TERMINATION ................................................................................................................................................ 29
VERTICAL TERMINATION................................................................................................................................................. 30-31
DVVK-4FV DIRECT VENT TERMINATION KIT ................................................................................................................. 32-38
DVVK-4F FLEX VENT INSTRUCTIONS - TOP VENT ONLY ................................................................................................. 39
DVVK-4RE VENT KIT INSTALLATION INSTRUCTIONS .................................................................................................. 40-42
PROPANE/LP GAS CONVERSION ........................................................................................................................................ 43
LOG PLACEMENT (4 LOG SET)............................................................................................................................................ 44
MILLIVOLT SYSTEM OPERATING INSTRUCTIONS........................................................................................................ 45-46
MILLIVOLT SYSTEM STANDING PILOT WIRING DIAGRAM................................................................................................ 47
MILLIVOLT SYSTEM STANDING PILOT LIGHTING INSTRUCTIONS .................................................................................. 48
MILLIVOLT SYSTEM STANDING PILOT TROUBLESHOOTING........................................................................................... 49
DIRECT IGNITION LIGHTING INSTRUCTIONS .................................................................................................................... 50
DIRECT IGNITION WIRING DIAGRAM.................................................................................................................................. 51
OPTIONAL REMOTE CONTROL............................................................................................................................................ 51
INITIAL START UP GAS LINE PURGE................................................................................................................................... 52
DIRECT IGNITION TROUBLESHOOTING ............................................................................................................................. 52
PROPANE/LP GAS CONVERSION ........................................................................................................................................ 53
IPI ELECTRONIC SYSTEM OPERATING INSTRUCTIONS .................................................................................................. 54
IPI ELECTRONIC SYSTEM WIRING DIAGRAM.................................................................................................................... 55
INTERMITTENT PILOT LIGHTING INSTRUCTIONS............................................................................................................. 56
INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING .............................................................................. 57-59
RF OPERATING INSTRUCTIONS.......................................................................................................................................... 60
RF MAINTENANCE INSTRUCTIONS..................................................................................................................................... 61
RF WIRING DIAGRAM............................................................................................................................................................ 62
RF STANDING PILOT LIGHTING INSTRUCTIONS ............................................................................................................... 63
MAINTENANCE AND SERVICE ........................................................................................................................................ 64-65
PARTS VIEW........................................................................................................................................................................... 66
PARTS LIST ....................................................................................................................................................................... 67-68
MASTER PARTS DISTRIBUTOR LIST................................................................................................................................... 69
HOW TO ORDER REPAIR PARTS ......................................................................................................................................... 69
FBB4 VARIABLE SPEED BLOWER INSTALLATION ........................................................................................................ 70-71
JUNCTION BOX WIRING INSTALLATION INSTRUCTIONS ................................................................................................. 72
BRICK LINER INSTALLATION INSTRUCTIONS .................................................................................................................... 72
ACCESSORIES....................................................................................................................................................................... 73
QUICK REFERENCE GUIDE............................................................................................................................................. 74-75
WARRANTY ............................................................................................................................................................................ 76

31451-2-1013 Page 3
DO NOT OPERATE THIS APPLIANCE WITHOUT GLASS FRONT PANEL INSTALLED
Beforeenclosingtheventpipeassembly,operatetheappliancetoensureitisventingproperly.
DANGER: Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE: Addresses practices not related to personal injury.
• If this appliance is installed directly on carpeting, tile or
othercombustiblematerialotherthanwoodooringthe
appliance shall be installed on a metal or wood panel
extending the full width and depth of the appliance.
 Thebasereferredtoabovedoesnotmeanthereproof
baseasusedonwoodstoves.Theprotectionisforrugs
thatareextremelythickandlightcoloredtile.
• Childrenandadultsshouldbealertedtothehazardsof
highsurfacetemperaturesandshouldstayawaytoavoid
burnsorclothingignition.
• Youngchildrenshouldbecarefullysupervisedwhenthey
areinthesameroomastheappliance.
• Clothingorotherammablematerialshouldnotbeplaced
on or near the appliance.
• Adequateaccessibilityclearancesforservicingandproper
operation.
• Thisappliancemustnotshareorbeconnectedtoaue
servingaseparatesolid-fuelburningappliance.
• Keeptheareaaroundyourapplianceclearofcombustible
materials,gasolineandotherammablevaporandliquids.
• Undernocircumstancesshouldanysolidfuels(wood,
coal,paperorcardboardetc.)beusedinthisappliance.
• Theowofcombustionandventilationairmustnotbe
obstructedinanyway.
• Duetohightemperaturestheapplianceshouldbelocated
outoftrafcandawayfromfurnitureanddraperies.
• The glass front or any part removed for servicing the
appliance must be replaced prior to operating the
appliance.Workshouldbedonebyaqualiedservice
person.
• Keepburnerandcontrolcompartmentclean.
• Ventcapishotwhilereplaceisinoperation.
• InstallationandrepairshouldbedonebyaQUALIFIED
SERVICE PERSON. Theapplianceshouldbeinspected
beforeuseand atleastannuallybyaqualiedservice
person.Morefrequentcleaningmayberequireddueto
excessivelintfromcarpeting,beddingmaterials,etc.It
is imperative that control compartments, burners and
circulating air passageways of the appliance be kept
clean.
• DO NOT putanythingaroundthereplacethatwillobstruct
theowofventilationair.
• Clearance in accordance with local installation codes and
therequirementsofthegassupplier.
• DOkeeptheapplianceareaclearandfreefromcombustible
material,gasolineandotherammablevaporsandliquids.
• DO examine venting system periodically and replace
damagedparts.
• DO makeaperiodicvisualcheck ofpilotandburners.
Cleanandreplacedamagedparts.
• CAUTION:Theglassusedinyourreplaceistempered
glass.Iftheglassiscrackedordamagedinanyway,it
should be replaced only with a complete glass frame
assemblyfromEmpire.SeepartslistonPages 67 and 68
for ordering.
• DO NOT use this replace if any part has been under
water.Immediatelycallaqualiedservicetechnicianto
inspect the heater and to replace any part of the control
systemandanygascontrolwhichhasbeenunderwater.
• Any safety screen or guard removed for servicing
an appliance must be replaced prior to operating the
appliance.
IMPORTANT SAFETY INFORMATION

31451-2-1013Page 4
Somepeoplecannotsmellwell.Somepeoplecannotsmellthe
odorofthechemicalputintothegas.Youmustndoutifyou
cansmelltheodorantinpropane. Smoking can decrease your
ability to smell. Being around an odor for a time can affect your
sensitivity or ability to detect that odor. Sometimes other odors in
the area mask the gas odor. People may not smell the gas odor
or their minds are on something else. Thinking about smelling a
gas odor can make it easier to smell.
The odorant in LP-Gas is colorless, and it can fade under
somecircumstances. For example, if there is an underground
leak, the movement of the gas through soil can lter the odorant.
Odorants in LP-Gas also are subject to oxidation. This fading can
occur if there is rust inside the storage tank or in iron gas pipes.
The odorant in escaped gas can adsorb or absorb onto or into
walls, masonry and other materials and fabrics in a room. That will
take some of the odorant out of the gas, reducing its odor intensity.
LP-Gas may stratify in a closed area, and the odor intensity could
vary at different levels. Since it is heavier than air, there may be
more odor at lower levels. Always be sensitive to the slightest gas
odor. If you detect any odor, treat it as a serious leak. Immediately
go into action as instructed earlier.
Propane(LP-Gas)isaammablegaswhichcancauseres
and explosions. In its natural state, propane is odorless and
colorless.Youmaynotknowallthefollowingsafetyprecau-
tionswhichcanprotectbothyouandyourfamilyfroman
accident.Readthemcarefullynow,thenreviewthempoint
by point with the members of your household. Someday
whentheremaynotbeaminutetolose,everyone’ssafety
willdependonknowingexactlywhattodo.If,afterread-
ingthefollowinginformation,youfeelyoustillneedmore
information,pleasecontactyourgassupplier.
• LearntorecognizetheodorofLP-Gas. Your local LP-Gas
Dealer can give you a “Scratch and Sniff” pamphlet. Use it to
nd out what the propane odor smells like. If you suspect that
your LP-Gas has a weak or abnormal odor, call your LP-Gas
Dealer.
• If you are not qualied, do not light pilot lights, perform service,
or make adjustments to appliances on the LP-Gas system. If
you are qualied, consciously think about the odor of LP-Gas
prior to and while lighting pilot lights or performing service or
making adjustments.
• Sometimes a basement or a closed-up house has a musty
smell that can cover up the LP-Gas odor. Do not try to light
pilot lights, perform service, or make adjustments in an area
where the conditions are such that you may not detect the odor
if there has been a leak of LP-Gas.
• Odor fade, due to oxidation by rust or adsorption on walls of
new cylinders and tanks, is possible. Therefore, people should
be particularly alert and careful when new tanks or cylinders
are placed in service. Odor fade can occur in new tanks, or
reinstalled old tanks, if they are lled and allowed to set too
long before relling. Cylinders and tanks which have been out
of service for a time may develop internal rust which will cause
odor fade. If such conditions are suspected to exist, a periodic
sniff test of the gas is advisable. If you have any question
about the gas odor, call your LP-Gas dealer. Aperiodic
sniff test of the LP-Gasisagoodsafetymeasureunder
any condition.
• If, at any time, you do not smell the LP-Gas odorant and you
think you should, assume you have a leak. Then take the same
immediate action recommended above for the occasion when
you do detect the odorized LP-Gas.
• If you experience a complete “gas out,” (the container is under
no vapor pressure), turn the tank valve off immediately. If the
container valve is left on, the container may draw in some air
through openings such as pilot light orices. If this occurs, some
new internal rusting could occur. If the valve is left open, then
treat the container as a new tank. Always be sure your con-
tainer is under vapor pressure by turning it off at the container
before it goes completely empty or having it relled before it is
completely empty.
• Do not operate electric switches, light matches, use your phone.
Do not do anything that could ignite the gas.
• Get everyone out of the building, vehicle, trailer, or area. Do
that IMMEDIATELY.
• Close all gas tank or cylinder supply valves.
• LP-Gas is heavier than air and may settle in low areas such as
basements. When you have reason to suspect a gas leak, keep
out of basements and other low areas. Stay out until reghters
declare them to be safe.
• Use your neighbor’s phone and call a trained LP-Gas service
person and the re department. Even though you may not
continue to smell gas, do not turn on the gas again. Do not
re-enter the building, vehicle, trailer, or area.
• Finally, let the service man and reghters check for escaped
gas. Have them air out the area before you return. Properly
trained LP-Gas service people should repair the leak, then
check and relight the gas appliance for you.
SOME POINTS TO REMEMBER
NO ODOR DETECTED - ODOR FADE
LP-GAS WARNING ODOR
Ifagasleakhappens,youshouldbeabletosmellthegasbecauseoftheodorantputintheLP-Gas.
That’syoursignaltogointoimmediateaction!
SAFETY INFORMATION FOR USERS OF LP GAS

31451-2-1013 Page 5
REQUIREMENTS FOR MASSACHUSETTS
For all side wall horizontally vented gas fueled equipment installed
in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the
Commonwealth and where the side wall exhaust vent termination
is less than seven feet above nished grade in the area of the
venting, including but not limited to decks and porches, the
following requirements shall be satised:
1. INSTALLATION OF CARBON MONOXIDE
DETECTORS.
At the time of installation of the side wall horizontal vented
gas fueled equipment, the installing plumber or gastter shall
observe that a hard wired carbon monoxide detector with an
alarm and battery back-up is installed on the oor level where
the gas equipment is to be installed. In addition, the installing
plumber or gastter shall observe that a battery operated
or hard wired carbon monoxide detector with an alarm is
installed on each additional level of the dwelling, building or
structure served by the side wall horizontal vented gas fueled
equipment. It shall be the responsibility of the property owner
to secure the services of qualied licensed professionals for
the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas
fueled equipment is installed in a crawl space or an attic,
the hard wired carbon monoxide detector with alarm and
battery back-up may be installed on the next adjacent
oor level.
b. In the event that the requirements of this subdivision
can not be met at the time of completion of installation,
the owner shall have a period of thirty days to comply
with the above requirements; provided, however, that
during said thirty day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each
carbon monoxide detector as required in accordance with the
above provisions shall comply with NFPA 720 and be ANSI/
UL 2034 listed and IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be
permanently mounted to the exterior of the building at a
minimum height of eight feet above grade directly in line
with the exhaust vent terminal for the horizontally vented gas
fueled heating appliance or equipment. The sign shall read, in
print size no less than 1/2 inch in size,
4. INSPECTION. The state or local gas inspector of the side
wall horizontally vented gas fueled equipment shall not
approve the installation unless, upon inspection, the inspector
observes carbon monoxide detectors and signage installed
in accordance with the provisions of 248 CMR 5.08(2)(a) 1
through 4.
(b) EXEMPTIONS: The following equipment is exempt from
248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled
“Equipment Not Required To Be Vented” in the most
current edition of NFPA 54 as adopted by the Board;
and
2. Product Approved side wall horizontally vented gas
fueled equipment installed in a room or structure
separate from the dwelling, building or structure
used in whole or in part for residential purposes.
(d) MANUFACTURER REQUIREMENTS - GAS
EQUIPMENT VENTING SYSTEM NOT PROVIDED.
When the manufacturer of a Product Approved side
wall horizontally vented gas fueled equipment does not
provide the parts for venting the ue gases, but identies
“special venting systems”, the following requirements
shall be satised by the manufacturer:
1. The referenced “special venting system” instructions
shall be included with the appliance or equipment
installation instructions; and
2. The “special venting systems” shall be Product
Approved by the Board, and the instructions for
that system shall include a parts list and detailed
installation instruction.
(e) A copy of all installation instructions for all Product
Approved side wall horizontally vented gas fueled
equipment, all venting instructions, all parts lists for
venting instructions, and/or all venting design instructions
shall remain with the appliance or equipment at the
completion of the installation.

31451-2-1013Page 6
INTRODUCTION
Instructions to Installer
1. Installer must leave instruction manual with owner after
installation.
2. Installer must have owner ll out and mail warranty card supplied
with the replace.
3. Installer should show owner how to start and operate the replace.
This direct vent gas replace heater is designed to operate with
all combustion air being siphoned from the outside of the building
and all exhaust gases expelled to the outside of the building. The
information contained in this manual pertains to all models and gas
control systems unless otherwise noted.
WARNING
This unit is not for use with solid fuels.
ApplianceCertication
This replace is design certied in accordance with American
National Standard/CSA Standard ANSI Z21.88/CSA 2.33 and by
Underwriters Laboratories as a Direct Vent Gas Fireplace Heater
and shall be installed according to these instructions.
Consult your local building code agency, prior to installation, to ensure
compliance with local codes-including permits and inspections.
The replace, when installed, must be electrically grounded in
accordance with local codes or, in absence of local codes, with the
National Electric Code ANSI/NFPA 70 or Canadian Electric code,
CSA C22.1, if an external electrical source is utilized.
These models may be installed in a bedroom or bed-sitting room
in the U.S.A. and Canada.
QualiedInstallingAgency
Installation and replacement of gas piping, gas utilization equipment
or accessories and repair and servicing of equipment shall be
performed only by a qualied agency. The term “qualied agency”
means any individual, rm, corporation or company which either in
person or through a representative is engaged in and is responsible for
(a) the installation or replacement of gas piping or (b) the connection,
installation, repair or servicing of equipment, who is experienced in
such work, familiar with all precautions required and has complied
with all the requirements of the authority having jurisdiction.
State of Massachusetts: The installation must be made by
a licensed plumber or gas tter in the Commonwealth of
Massachusetts.
The installation must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code ANSI Z223.1/NFPA
54* Natural Gas and Propane Installation Code, or CSA B149.1 in
Canada. *Available from the American National Standards Institute,
Inc. 11 West 42nd St., New York, N.Y. 10036.
WARNING
ANY CHANGE TO THIS FIREPLACE OR ITS CONTROLS
CAN BE DANGEROUS.
Improper installation or use of the replace can cause
serious injury or death from re, burns, explosions, or
carbonmonoxidepoisoning.
Any alteration of the original design, installed other than as
shown in these instructions or use with a type of gas not
shownontheratingplateistheresponsibilityoftheperson
andcompanymakingthechange.
Important
All correspondence should refer to complete Model Number, Serial
Number and type of gas.
High Altitude
When installing this unit at an elevation above 2000 feet (in the
United States) it may be necessary to decrease the input rating by
changing the existing burner orice to a smaller size. Generally,
input should be reduced 4 percent for each 1000 feet above sea
level. However, if the heating value of the gas has been reduced,
this general rule may not apply. Check with local gas utility for proper
orice size identication.
Canadian High Altitude
Altitude: 0-4500 feet (0-1370 m)
When installing this unit at an elevation above 4500 feet (in Canada),
check with local authorities.
Consult your local gas utility for assistance in determining the proper
orice for location.
Preparation
This direct vent gas replace and its components are tested and
safe when installed in accordance with this Installation Manual.
Report to your dealer any parts damaged in shipment, specically
check glass condition. Do not install unit with damaged, incomplete,
or substitute parts. Read all instructions before starting installation
and follow these instructions carefully during installation to insure
maximum benet and safety. Failure to follow them will void your
warranty and may present a re hazard.
The warranty will be voided by, and the warranter disclaims any
responsibility for the following actions:
• Installation of any damaged replace or vent system component.
• Modication of the replace or direct vent system.
• Installation other than as instructed by Empire Comfort Systems,
Inc.
• Improper positioning of the logs, glass door or decorative rock.
• Installation and/or use of any component part not manufactured
or approved by manufacturer.

31451-2-1013 Page 7
RemoteControlOptions
& Accessories
Description
FRBC Millivolt/IP Battery Remote ON/OFF
FRBTC Millivolt/IP Battery Remote Thermostat
TRW Millivolt/IP Wireless Wall Thermostat
TMV Millivolt/IP Reed Switch Wall Thermostat
FWS-1 Direct Ignition/Millivolt/IP Wall Switch
FREC Electric Remote
Venting
Options
Description
DVVK-4TSP
(DVVK-4TS)
Top Vent Kit (Horizontal) - 5" to 7" wall thickness
DVVK-4TP
(DVVK-4T)
Top Vent Kit (Horizontal) - 8" to 11" wall thickness
DVVK-4RP
(DVVK-4R)
Rear Vent Kit (Horizontal) - 5" to 7" wall thickness
DVVK-4VP
(DVVK-4V)
Vertical Vent Kit
DVVK-4F Horizontal Flex Vent Kit (4' Flex)
DVVK-4RE Horizontal Round Termination wall thickness (up to 13 3/4")
DV822 Vinyl Siding Kit for DVVK-4RE
DVVK-4FV Vertical Flex Vent Kit
DVEK-10 10' Vent Extension Kit
DVEK-25 25' Vent Extension Kit
NOTICE:Rearventinstallationcanonlybeventedonnaturalgas.
SPECIFICATIONS
DVP36 Nat Models
Input Btu/hr Maximum 25,000
Btu/hr Minimum (millivolt only) 18,000
KWH (Maximum) 7.3
(Minimum) 5.2
Orice #41 (P-256)
Air Shutter Opening 1/8" (DVP36DP(3,7,9))
1/4" (DVP36DP5)
DVP36 LP Models
Input Btu/hr Maximum 27,000
Btu/hr Minimum (millivolt only) 21,000
KWH (Maximum) 7.9
(Minimum) 5.2
Orice 1.55mm (P-258)
Air Shutter Opening FULL OPEN
DVP36 Nat and LP Models
Height without standoff 34 3/4"
Width 39"
Depth 19 7/8"
Gas Inlet Shutoff Valve (pipe) 1/2" NPT
NOTICE: Air shutter settings are factory minimum settings. Some
venting congurations may require minor air shutter adjustments
for optimum performance.

31451-2-1013Page 8
VENT SYSTEM IDENTIFICATION
SpecialVentingComponents(SimpsonDuravent)
See Empire Comfort Systems Retail Price List for Simpson Duravent part
numbers and pricing.
Special DV Vent Kits
Available from Empire Comfort Systems, Inc. dealers.
DVVK-4VP
(DVVK-4V)
Direct-Vent Fireplace Vent Kit - Vertical, Includes 46DVA-VCH,
46DVA-SC and 46DVA-F6
DVVK-4TP
(DVVK-4T)
Direct-Vent Fireplace Vent Kit for Top Vent, Thru-the-wall,
8 to 11 inch wall thickness, Includes 46DVA-09, 46DVA-08A,
46DVA-HC, 46DVA-E90 and 46DVA-WT
DVVK-4TSP
(DVVK-4TS)
Direct-Vent Fireplace Vent Kit for Top Vent, Thru-the-wall,
5 to 7 inch wall thickness, Includes 46DVA-06, 46DVA-HC,
46DVA-E90 and 46DVA-WT
DVVK-4FV Direct-Vent Fireplace Vertical Flex Vent Kit
DVVK-4RE Direct-Vent Fireplace Vent Kit, Thru-the-wall, 5 to 13 3/4 inch
wall thickness
Notice: Rear vent installation can only be vented on natural gas.
SPECIAL VENT SYSTEMS
The following vent systems are acceptable for use with the DVP36 series replaces:
Simpson Duravent® GS 4" - 6 ⅝"
AmericanMetalProducts4"-6⅝"
SelkirkDirect-Temp®4"-6⅝"
SecuritySecureVent®4"-6⅝"
ExcelDVVenting4”-6⅝”
Empire Horizontal Round Termination Kit DVVK-4RE
Empire Flexvent Kit DVVK-4F
Empire Flexvent Kit DVVK-4FV Vertical Flex Vent Kit
Begin the vent system installation by selecting the type of venting
to be installed and the path that it will take. Verify that clearances
are met throughout the path of the venting system. Determine if the
replace is to be vented out the top or out the rear.
NOTICE: Some replaces cannot be vented out the rear of the
replace.
Determine how the vent system will be terminated out the side of
the house or through the roof. Verify clearances for the termination.
When selecting a vent system for use with the replace, refer to
the “Special Vent Systems” section in this manual to determine
what systems are acceptable. Check all clearances and venting
components. Identify if any problems existing in the vent system.
Use Figure 21 on page 17 for top venting, or Figure 33 on page
23 for rear venting to eliminate issues after installation. Check pipe
diameter on vent system and replace to verify the size is the same.
NOTICE: All outer connection joints must be sealed with
aluminum tape, screws or silicone sealant rated above
300°F/149°C.Theinneruejointsdonotrequireanysealant.
Figure 1
*Note: If using three 90° elbows during horizontal
termination, see Figure 31.

31451-2-1013 Page 9
Figure 2
Dimension
A 34 3/4" (882.7 mm)
B 39" (990.6 mm)
C 19 7/8" (505 mm)
D 25" (635 mm)
E 36" (914.4 mm)
G 26 1/2" (673.1 mm)
H 37 3/4" (958.9 mm)
I 13 1/4" (336.6 mm)
J 7 1/8" (181 mm)
FIREPLACE DIMENSIONS
LEFT SIDE VIEW FRONT VIEW
RIGHT SIDE VIEW
ELECTRICAL
ACCESS
VENT COLLAR
TOP VIEW
GAS LINE ACCESS
A
C
J
G
I
GAS LINE
ACCESS
H
D
E
B
VENT COLLAR
STANDOFFS
NAILING
FLANGES
GLASS
FRAME
ASSEMBLY
GAS LINE
ACCESS
RATING PLATE
AND LABELS
GAS CONTROLS
AND SWITCHES

31451-2-1013Page 10
CLEARANCES
Clearance to Combustibles
Back 0" (0 mm)
Side 0" (0 mm)
Floor 0" (0 mm)
Top Stand-off 0" (0 mm)
Top Framing Edge 3" (76 mm)
Note A: See Figure 5 for maximum mantle depth.
Note B: See Figure 5 for minimum height above unit.
Figure 3
CombustibleMaterial
No greeting cards, stockings or ornamentation of any type should
be placed on or attached to the replace. The ow of heat can
ignite combustibles.
NOTICE: Empire “Standard Mantels” are not approved for use with
the DVP36DP(31,71,91)(N,P) Series replaces.
Mantel Chart
Figure 4
Figure 5
Clearances
Clearance from top of replace to ceiling is 36”
Clearance from side of replace to adjacent sidewall is 6”. See
Figure 6.
Figure 6

31451-2-1013 Page 11
Figure 7
NOTICE: Island and Room Divider installation is possible as long as the horizontal portion of the vent system does not exceed 20 feet
with a minimum vertical run of 8 feet. See details in Venting Section.
When you install your Direct Vent Fireplace in Room divider or Flat on wall corner positions, a minimum of 6 inches clearance must be
maintained from the perpendicular wall and the front edge of the appliance.
LOCATING FIREPLACE

31451-2-1013Page 12
GAS SUPPLY
The gas pipeline can be brought in through the right or left side of
the appliance. Consult the current National Fuel Gas Code, ANSI
Z223.1 CAN/CGA-B149 (.1 or .2) installation code.
RecommendedGasPipeDiameter
Pipe Length Schedule 40 Pipe
InsideDiameter
Tubing,TypeL
OutsideDiameter
Nat. L.P. Nat. L.P.
0-10ft
0-3m
1/2"
12.7mm
3/8"
9.5mm
1/2"
12.7mm
3/8"
9.5mm
11-40ft
4-12m
1/2"
12.7mm
1/2"
12.7mm
5/8"
15.9mm
1/2"
12.7mm
41-100ft
13-30m
1/2"
12.7mm
1/2"
12.7mm
3/4"
19mm
1/2"
12.7mm
101-150ft
31-46m
3/4"
19mm
1/2"
12.7mm
7/8"
22.2mm
3/4"
1.9 mm
NOTICE: Never use plastic pipe. Check to conrm whether your
local codes allow copper tubing or galvanized.
NOTICE:Since some municipalities have additional local codes, it
is always best to consult your local authority and installation code.
The use of the following gas connectors is recommended:
— ANS Z21.24Appliance Connectors of Corrugated Metal Tubing
and Fittings.
— ANS Z21.45Assembled FlexibleAppliance Connectors of Other
Than All-Metal Construction
The above connectors may be used if acceptable by the authority
having jurisdiction. The state of Massachusetts requires that a
exible appliance connector cannot exceed three feet in length.
Figure 8
GasSupplyPressure(inchesw.c.)
Minimum Normal Maximum
Natural Gas 4.5" 7.0" *14.0"
LP (Propane) 10.8" 11.0" *14.0"
Manifold Pressure (inches w.c.)
Normal (HI)
Natural Gas 3.5"
LP (Propane) 10.0"
*NOTICE: Remote "RF" Models - 10.5" w.c. maximum
InstallingaNewMainGasCock
Each appliance should have its own manual gas cock.
A manual main gas cock should be located in the vicinity of the unit.
Where none exists, or where its size or location is not adequate,
contact your local authorized installer for installation or relocation.
Compounds used on threaded joints of gas piping shall be resistant
to the action of liqueed petroleum gases. The gas lines must be
checked for leaks by the installer. This should be done with a soap
solution watching for bubbles on all exposed connections, and if
unexposed, a pressure test should be made.
Neveruseanexposedametocheckforleaks.Appliancemust
bedisconnectedfrompipingatinletofcontrolvalveandpipe
capped or plugged for pressure test. Never pressure test with
applianceconnected;controlvalvewillsustaindamage!
NOTICE: The millivolt gas controls are equipped with a captured
screw type pressure test point, therefore it is not necessary to
provide a 1/8” test point up stream of the control.
On direct ignition valves, hex plugs may be replaced with hose ttings
for pressure checks, then reinstalled before operating replace.
When using copper or ex connector use only approved ttings.
The appliance and it’s individual shut off valve must be disconnected
from supply piping system during any pressure testing of that system
at test pressures in excess of 1/2 psig (3.5kPa).
The appliance must be isolated from the gas supply piping system
by closing its individual manual shut off valve during any pressure
testing of the gas supply piping system at test pressures equal to
or less than 1/2 psig (3.5kPa).
CAUTION
If one of the procedures results in pressures in excess of 1/2
psig (14” w.c.) (3.5 kPa) on the replace gas valve, it will result
in a hazardous condition.
CheckingManifoldPressures
Both Propane and Natural gas valves have a built-in pressure
regulator in the gas valve. Natural gas models will have a manifold
pressure of approximately 3.5” w.c. (.871kPa) at the valve outlet
with the inlet pressure to the valve from a minimum of 4.5” w.c.
(1.120kPa) for the purpose of input adjustment to a maximum of
14.0” w.c. (3.484kPa). Propane gas models will have a manifold
pressure approximately 10.0” w.c. (2.49kPa) at the valve outlet
with the inlet pressure to the valve from a minimum of 10.8” w.c.
(2.68kPa) for the purpose of input adjustment to a maximum of
14.0” w.c. (3.484kPa).
Figure 9

31451-2-1013 Page 13
INSTALLATION
FramingandFinishing
1. Choose unit location.
2. Frame in replace with a header across the top. It is important
to allow for nished face when setting the depth of the frame.
See Figure 10B.
3. Attach replace to frame using adjustable nailing ange. Preset
depthtosuitfacingmaterial (adjustable to3/8”,1/2”or3/4”depths).
NOTICE: Fireplace must mount ush to facing material. If facing
material requires more depth than 3/4”, mark and drill two 1/8”
holes into replace side at appropriate depth. Bend standoff
tabs as needed to move replace ush with facing material.
See Figure 10A.
4. Use eight 1/2” hex-head screws supplied in hardware package,
to screw through slotted holes in nailing ange and then screw
into pre-drilled holes on replace side. Measure from face of
replace to face of nailing ange to determine nal depth.
Figure 10A
Figure 10B
Vent Pipe Clearance
NOTICE:Maintain one inch of clearance around top vent pipe.
See Figure 11B. For rear vent, maintain a minimum 1” clearance to
the bottom and sides of the vent, and 3” clearance to combustibles
above the vent pipe. See Figure 11A.
Figure 11A - Rear Vent
Figure 11B - Top Vent

31451-2-1013Page 14
INSTALLATION
Flush Mount Mantel Installation
The replace must extend 3/4” beyond nished wall surface when
using a ush mount mantel. Refer to Figure 12 to locate nailing
anges on replace sides. Mark and drill two 1/8” holes into replace
side to mount each nailing ange. Use eight 1/2” hex-head screws
supplied in hardware package to attach nailing anges to replace
sides.
Figure 12
Attention: When replace is installed in optional full cabinet mantel
or corner mantel the four nailing anges shown in Figure 12 will
not be installed on the side of outer casing. The replace will be
attached to the full cabinet mantel or corner mantel with the two
nailing anges located on the top of the outer casing assembly.
Framing
Fireplace framing can be built before or after the replace is set in
place. Framing should be positioned to accommodate wall covering
and replace facing material. The replace framing should be
constructed of 2 x 4 lumber or heavier. The framing headers may
rest on the replace standoffs. Refer to Figure 13 for minimum
framing dimensions.
CAUTION
MEASURE FIREPLACE DIMENSIONSAND VERIFYFRAMING
METHODS, AND WALL COVERING DETAILS BEFORE
FRAMING CONSTRUCTION BEGINS.
Framing dimension "A" includes a three inch clearance
for standoffs on replace. After installing replace into
framing, the nished non-combustible wall surface must
coverthethreeinchopeningabovethereplace.
NOTICE: For nishing to top of replace, refer to Figure 13.
Dimension
"A" 37 7/8" (962 mm)
"B" 40 3/8" (1025.5 mm)
"C" 19 7/8" (505 mm)
Figure 13
Attention: Add 3-3/4” to “A” dimensions when using a ush mantel
base.
WARNING
If a base or mantel is not used and the appliance is installed
directly on carpeting, tile or other combustible material other
than wood ooring, it shall be installed on a metal or wood panel
extending the full width and depth of the appliance. The vertical
dimension in Figure 13 must be adjusted when a metal or wood
panel is placed beneath the appliance.
Finishing
Finish the walls with the material of your choice. Figure 4 on page 10
shows the minimum vertical and corresponding maximum horizontal
dimensions of mantels or other combustible projections above the
top front edge of the replace.
Only non-combustible materials may be used to cover the black
replace front.
WARNING
Whennishingthereplaceneverobstructormodifythe
air inlet/outlet louvers in any manner. Provide adequate
clearances around air openings into the combustion
chamber.
CAUTION
If the joints between the nished wall and the replace surround
(top and sides) are sealed, a 300°F minimum sealant material
must be used. These joints are not required to be sealed. Only
non-combustible material (using 300°F minimum adhesive if
needed), can be applied as facing to the replace surround.

31451-2-1013 Page 15
Flush Wall Installation
Figure 14
CombustibleSurroundInstallation
Figure 15
Attention: Cold climate installation recommendation:
When installing this unit against a non-insulated exterior
wall, it is recommended that the outer walls be insulated
to conform to applicable insulation codes.
Vent Runs
In planning the installation for the replace, it is necessary to install
certain components before the appliance is completely positioned
and installed. These include the direct vent system, gas piping for
the appliance and the electrical wiring. (If the fan option is used.)
The appliance can be mounted on any of the following surfaces:
1. A at, hard combustible (burnable) surface.
2. A raised wooden platform.
3. Four corner supports. (Example: Four concrete masonry blocks.)
These supports must be positioned so they contact all four
perimeteredgesonthebottom of theunit(ifallowedbylocal codes.
NOTICE: Fireplace must be mounted above oor surfaces. Doors
will not operate properly if replace rests below room ooring.
NOTICE: Discard insulation and retainer when venting from
the top of the replace. See page 22.
TOP, 90° ELBOW WITH HORIZONTAL TERMINATION
LPandNatmodels
Figure 16
INSTALLATION

31451-2-1013Page 16
INSTALLATION
REAR ONLY, STRAIGHT OUT THE BACK
Natmodelsonly
"A" "B"
6"
(152.4mm)
5 1/8" to 6 1/2"
(130mm to 165mm)
9"
(228.6mm)
8 1/8" to 9 1/2"
(206.4mm to 241mm)
12"
(304.8mm)
11 1/8" to 12 1/2"
(282.6mm to 317.5mm)
Figure 17
TOP, 90° ELBOW TO HORIZONTAL OUT THE WALL
LPandNatmodels
"A" "B" "C"
6"
(152.4mm)
11 1/4" to 12 3/4"
(285.8mm to 324mm)
4 3/4" to 6 1/4"
(121mm to 159mm)
9"
(228.6mm)
14 1/4" to 15 3/4"
(362mm to 400mm)
7 3/4" to 9 1/4"
(197mm to 235mm)
12"
(304.8mm)
17 1/4" to 18 3/4"
(438mm to 476mm)
10 3/4" to 12 1/4"
(273mm to 311mm)
Figure 18
CORNER INSTALLATION TOP, 90° ELBOW TO HORIZONTAL
OUT THE WALL
LPandNatmodels
A44 7/8"
(1140mm)
B31 3/4"
(806.5mm)
C13 7/16"
(341.3mm)
D63 7/16"
(1611.3mm)
Figure 19
CORNER INSTALLATION REAR, 45° ELBOW TO
HORIZONTAL OUT THE WALL
Natmodelsonly
"A" "B"
6"
(152.4mm)
4" to 5 1/2"
(101.6mm to 140mm)
9"
(228.6mm)
6" to 7 1/2"
(152.4mm to 190.5mm)
12"
(304.8mm)
9" to 10 1/2"
(229mm to 267mm)
Figure 20

31451-2-1013 Page 17
To Use the Vent Graph
1. Determine the height of the center of the horizontal
vent pipe. Using this dimension on the Sidewall Vent
Graph, locate the point it intersects with the slanted
graph line.
2. From the point of this intersection, draw a vertical
line to the bottom of the graph.
3. Select the indicated dimension, and position the unit
in accordance with same.
EXAMPLE A:
If the vertical dimension from the oor of the unit is 35
feet, the horizontal run to the outer wall ange must not
exceed 6.5 feet.
EXAMPLE B:
If the vertical dimension from the oor of the unit is 6.5
feet, the horizontal run to the outer wall ange must not
exceed 14.5 feet.
SPECIALNOTICE:For each 45 degree elbow installed in
the horizontal run, the length of the horizontal run MUST
be reduced by 18" (45cm). This does not apply if the 45
degree elbows are installed on the vertical part of the
vent system. Reduce 3' for every 90° elbow.
Example:According to the chart the maximum horizontal
vent length is 20' and if two 45 degree elbows are required
in the horizontal vent it must be reduced to 17'.
The maximum number of 45 degree elbows permitted
per side wall installation is two. These elbows can be
installed in either the vertical or horizontal run.
NOTICE: On vertical venting the rst elbow does not
get counted.
NOTICE: LP and Nat gas models can be top vented.
NOTICE: Flue heat shield must be installed for venting
applications with less than two feet of vertical pipe off
the top of the replace.
Figure 21
Acceptable vertical and horizontal vent run.
(40' maximum vertical and 20' maximum horizontal)
Unacceptable vertical and horizontal vent run.
VentingGraph(DimensionsinFeet)
VENTINGFIREPLACE-TOP(LP&NATMODELS)

31451-2-1013Page 18
VENTINGFIREPLACE-TOP(continued)
Installation of Flue Heat Shield
1. Remove ue insulation.
2. Remove two screws on outside of inlet vent adapter.
See Figure 22.
3. Lift top shield placing ue heat shield around ue.
4. Replace two screws on outside of inlet vent adapter.
See Figure 23.
5. Bend tab at top front of ue heat shield if necessary to maintain
air gap between ue pipe and ue heat shield.
6. Replace ue insulation.
Figure 22 Figure 23

31451-2-1013 Page 19
VENTINGFIREPLACE-TOP(continued)
Below Grade Installation
When it is not possible to meet the required vent terminal clearances
of 12" (305mm) above grade level, a snorkel kit is recommended.
It allows installation depth down to 7" (178mm) below grade level.
The 7" (178mm) is measured from the center of the horizontal vent
pipe as it penetrates through the wall.
Ensure the sidewall venting clearances are observed. If venting
system is installed below ground, we recommend a window well
with adequate and proper drainage to be installed around the
termination area.
TYPICAL BASEMENT INSTALLATION
Figure 24
Examples of possible venting systems using one 90° elbow. Eight
feet is listed as minimum vertical vent run with 20 feet of maximum
horizontal vent run. Vertical dimensions are based on centerline to
centerline of pipe. Horizontal dimensions are based on centerline
of pipe to end of termination.
Figure 25
Examples of possible venting systems using two 90° elbows.
V is listed as minimum vertical dimensions and H1 + H2 is listed
as total of maximum horizontal dimensions. The maximum vertical
and horizontal distances for two 90° elbows as shown in Figure
26 is 20 feet.
Attention: Refer to Figure 21 for additional venting requirements.
Figure 26

31451-2-1013Page 20
VENTINGFIREPLACE-TOP(continued)
Figure 27
MINIMUM HOLE LOCATION DIMENSIONS FOR THROUGH
THE WALL HORIZONTAL INSTALLATIONS WITH 90 DEGREE
ELBOW OFF TOP OF FIREPLACE
Positioning the Fireplace
FIREPLACE
SERIES
HARD ELBOW DIMENSIONS
"A" "B" "C"
DVP36DP 43-1/2"
(1105mm)
4-1/2"
(114mm)
6-1/2"
(165mm)
FIREPLACE
SERIES
FLEX PIPE 90 DEGREE BEND
"A" "B" "C"
DVP36DP 45"
(1143mm)
4-1/2"
(114mm)
6-1/2"
(165mm)
Determine the exact position of the appliance so the direct vent
termination will be centered (if possible) between two studs. This
will avoid any extra framing. All vent kit pipes should be assembled
on the unit after the unit is moved into the nal position.
Cutting the Hole
After the replace has been positioned in its permanent location, the
hole through the exterior wall of the house can be cut. This hole must be
11" (280mm) high x 10" (254mm) wide with its center line determined
by the amount of vertical rise and horizontal run of the termination.
See Figure 27. When locating the hole it must be noted that the
bottom of the cap must be 12" (305mm) above the ground level,
and top of the cap must be no less than 18" (457mm) below a
combustible projection, and no closer than 9" (229mm) to any wall
running parallel to vent termination. See Figure 28.
Figure 28
Figure 29
