LOG SET FOR USE
WITH DIRECT-VENT
FIREPLACE MODELS:
DVLXG55BP90N-1
DVLXG55SP90N-1
DVLXB55BP90N-1
DVLXB55SP90N-1
GAS-FIRED
LS55CD-1
DRIFTWOOD LOG
WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas
supplier, call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
This decorative media set includes an unusual
assortment of logs and rocks in varying
textures and colors to complement your linear
replace - plus stainless steel coils to add a
unique air.
For ease of installation, unpack all pieces and
lay out so that any identifying letters are visible.
WARNING
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
Page 1

41485-0-0120Page 2
TABLE OF CONTENTS
Important Installation Guidelines....................................................................................................3
General Information........................................................................................................................3
Log Identication ...................................................................................................................... 4 - 5
Log Placement ....................................................................................................................... 6 - 16
Completing Installation.................................................................................................................17
Master Parts Distributor List.........................................................................................................18
How To Order Repair Parts ..........................................................................................................18
Fireplace Service History .............................................................................................................19
SECTION PAGE

41485-0-0120 Page 3
Proper Log Placement
Log placement is critical to proper burner performance. Logs must
be correctly positioned. The photos in this manual show the proper
position for logs in this set. Owners need to be shown proper log
placement and instructed not to move the logs.
Proper Placement of Crushed Glass Media
This replace is designed to use crushed glass media on the burner.
The maximum amount of crushed glass media should not exceed
6 Sq. Ft. Spread out over the entire burner and burner screen. It is
recommended that the crushed glass media be added after the log
has been properly installed.
CAUTION
Do not place crushed glass around the pilot assembly.
Crushed glass is only to be placed on the burner screen
and burner cover.
Make Owners Aware of Proper Log Set Operation
Properly installed and properly maintained log sets should not
deposit soot on the logs. If users see excessive soot appearing
on a log, call for service. Do not continue to operate the replace.
IMPORTANT INSTALLATION GUIDELINES
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization equip-
ment or accessories and repair and servicing of equipment shall be
performed only by a qualied agency. The term "qualied agency"
means any individual, rm, corporation, or company that either in
person or through a representative is engaged in and is responsible
for (a) the installation, testing, or replacement of gas piping or (b) the
connection, installation, testing, repair, or servicing of equipment;
that is experienced in such work; that is familiar with all precautions
required, and that has complied with all the requirements of the
authority having jurisdiction.
The installation must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA54.*
*Available from the American National Standards Institute, Inc. 11
West 42nd St., New York, N.Y. 10018.
GENERAL INFORMATION
Commonwealth of Massachusetts: The installation must be
made by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.
Sellers of unvented propane or natural gas-red supplemental
room heaters shall provide to each purchaser a copy of 527 CMR
30 upon sale of the unit.
Appliance Certication
This logset is design certied in accordance with American National
Standard/CSA Standard ANSI Z21.88/CSA 2.33 and by Underwrit-
ers Laboratories for use with a Direct Vent Gas Fireplace Heater
and shall be installed according to these instructions.

41485-0-0120Page 4
PART NUMBER
& DESCRIPTION
TOP VIEW FRONT VIEW
R12928
Log (A)
R12929
Log (B)
R12930
Log (C)
R12931
Log (D)
R12932
Log (E)
LOG IDENTIFICATION

41485-0-0120 Page 5
PART NUMBER
& DESCRIPTION
TOP VIEW FRONT VIEW
R12933
Log (F)
R12934
Log (G)
R12935
Log (H)
R12936
Log (I)
LOG IDENTIFICATION

41485-0-0120Page 6
Tools Needed:
• Protective Gloves
All Logs
The positioning of the logs is critical to the safe and clean operation
of this heater. Sooting and other problems may result if the logs are
not properly and rmly positioned in the appliance.
Refer to Figure 1 for the following warning.
WARNING
Failure to position the parts in accordance with this diagram
or failure to use only parts specically approved with this
appliance may result in property damage or personal injury.
Attention: Refer to Pages 4 and 5 Parts List and Parts View to
order logs or rocks.
LOG PLACEMENT
NOTICE: Once the installation is complete with the logs, decorative
media in place, operate the replace to verify ame appearance.
If there are ames directly impinging a log, turn off replace, then
remove the media directly below where the ame impingement
occurred. This should eliminate sooting on the log, and provide a
more pleasing ame appearance.

41485-0-0120 Page 7
LOG PLACEMENT
1. Place Log (A) onto burner pin as shown.
TOP VIEW
FRONT VIEW

41485-0-0120Page 8
LOG PLACEMENT
2. Place Log (B) onto burner as shown.
TOP VIEW
FRONT VIEW

41485-0-0120 Page 9
LOG PLACEMENT
3. Place Log (C) onto burner as shown.
TOP VIEW
FRONT VIEW

41485-0-0120Page 10
LOG PLACEMENT
4. Place Log (D) onto burner and Log (C) as shown.
TOP VIEW
FRONT VIEW

41485-0-0120 Page 11
LOG PLACEMENT
5. Place Log (E) onto burner as shown.
TOP VIEW
FRONT VIEW

41485-0-0120Page 12
LOG PLACEMENT
6. Place Log (F) onto burner as shown.
TOP VIEW
FRONT VIEW

41485-0-0120 Page 13
LOG PLACEMENT
7. Place Log (G) onto Log (B). Log (G) will rest on the burner and touch Logs (A) and (D) as shown.
TOP VIEW
FRONT VIEW

41485-0-0120Page 14
LOG PLACEMENT
8. Place Log (H) on top of Logs (C) and (E) as shown. Log (H) will not touch the burner.
TOP VIEW
FRONT VIEW

41485-0-0120 Page 15
LOG PLACEMENT
9. Place Log (I) on the burner and into the groove of Log (F) as shown.
TOP VIEW
FRONT VIEW

41485-0-0120Page 16
NOTICE: After the Log set is installed, place crushed glass on the burner and burner screen area as directed in the Fireplace installation
instruction manual. If excessive ame impingement occurs on any of the cross Logs (D), (G), and (H), these logs can be rotated left/right
away from the ame to improve performance. In addition, thinning out the glass directly under the cross logs will help to reduce ame
impingement and sooting.
LOG PLACEMENT
TOP VIEW
FRONT VIEW

41485-0-0120 Page 17
COMPLETING INSTALLATION
Crushed Glass Media
1. Place crushed glass media onto the burner and burner
screen. See the Installation Instructions supplied with the
replace for more information.
NOTICE: Crushed glass should not be placed on the burner
screen area more than one layer deep. Excessive use of crushed
glass may create a greater chance of developing soot on logs.
Do not allow crushed glass to restrict the pilot ame. Do not
place crushed glass in the pilot bracket accessed area.
Decorative Media Kits
1. Place embers covering all burner ports as shown in the area
below.
2. Mix remaining decorative media together as desired and
spread across burner screen. Also ll area between the two
pieces of glass.
Final Steps
1. Re-install the glass door assembly. Test re to ensure there
is minimal contact between the ame and the logs.
2. If the test re is acceptable, re-install the barrier screen/glass
assembly.
3. If during the test ring there seems to be signicant ame
impingement on the cross logs, there are two steps that can
be taken to reduce the impingement:
a. Pivot log left or right to move away from ame.
b. Thin out crushed glass directly under the cross log. This
can reduce the height of the ame directly under the log.
TOP VIEW

41485-0-0120Page 18
MASTER PARTS DISTRIBUTOR LIST
To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.
com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the
nature of the problem with the unit.
To Order Parts After the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below.
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com.
Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment
repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc.
Parts Not Under Warranty
Parts can be ordered through your Service Person, Dealer, or a Master Parts Distributor. See this page for the Master Parts Distribu-
tors list. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the
service person/dealer.
Warranty Parts
Warranty parts will need a proof of purchase and can be ordered by your Service Person or Dealer. Proof of purchase is required for
warranty parts.
All parts listed in the Parts List have a Part Number. When ordering parts, rst obtain the Model Number and Serial Number from the
name plate on your equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the fol-
lowing illustration and part list. Be sure to give all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, res and all causes beyond our control.
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401 Willow Lake Boulevard
Vadnais Heights, MN 55101
Phone: [phone]
Toll Free: 800-397-1339
Website: www.deydistributing.com
Parts: Heater, Hearth and Grills
F. W. Webb Company
200 Locust Street
Hartford, CT 06114
Phone: [phone]
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax: [phone]
Websites: www.fwwebb.com & www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10 East Route 36
West Long Branch, NJ 07764
Phone: [phone]
Toll Free: 800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills

41485-0-0120 Page 19
FIREPLACE SERVICE HISTORY
Date Dealer Name Service Technician Name Service Performed/Notes

41485-0-0120Page 20
www.empirecomfort.com
Empire Comfort Systems Inc.
Belleville, IL
If you have a general question
about our products, please e-mail
us at [email protected].
If you have a service or repair
question, please contact your dealer.
