Empire Comfort Systems VFD32FB0F-4 Quick start guide

Page 1
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
DELUXE VENT-FREE
UNIVERSAL FIREBOXES
GAS-FIRED
UNIVERSAL FIREBOX
FOR ALL VENT-FREE
LOG SETS MODELS:
VFD32FB0F-4 VFD36FB0F-4 VFD42FB0F-4
VFD32FB0L-4 VFD36FB0L-4 VFD42FB0L-4
VFD32FB2AF-4 VFD36FB2AF-4 VFD42FB2AF-4
VFD32FB2AL-4 VFD36FB2AL-4 VFD42FB2AL-4
VFD32FB2MF-6 VFD36FB2MF-6 VFD42FB2MF-6
VFD32FB2ML-6 VFD36FB2ML-6 VFD42FB2ML-6
VFD00FB3MF-4 VFD36FB3MF-6 VFD42FB2ML-4
This appliance may be installed in an aftermarket, permanently located,
manufactured home (USA only) or mobile home, where not prohibited
by local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use
with other gases, unless a certied kit is used.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
Do not attempt to modify or alter the construction of the rebox or its
components. Any modication or alteration of construction may void
the warranty of this rebox. Children and adults should be alerted
to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition. Young children should be carefully
supervised when they are in the same room as the rebox.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information, con-
sult a qualied installer, service agency or
the gas supplier.
FOR USE ONLY WITH A LISTED GAS-FIRED UNVENTED
DECORATIVE ROOM HEATER NOT TO EXCEED 40,000 BTU/H.
Do not build a wood re.
Carefully review the instructions supplied with the decorative type
unvented room heater for the minimum replace size requirement.
Do not install A VENT-FREE LOG SET in this rebox, unless this
rebox meets the minimum dimensions required for the installation.
ANSI Z21.91
Ventless Fireplace
Enclosures
for Gas Fired
Decorative Type
Unvented Room
Heaters

39000-1-0219Page 2
TABLE OF CONTENTS
Important Safety Information ........................................................................................... 3
Introduction...................................................................................................................... 3
Clearances ................................................................................................................. 4 - 5
Firebox Installation Instructions .................................................................................. 6 - 8
Installing Hood............................................................................................................ 8 - 9
Gas Line Connection ....................................................................................................... 9
Optional FBB5 Single Speed Blower Installation Instructions ................................ 10 - 12
Junction Box Wiring Installation Instructions ................................................................. 13
Maintenance .................................................................................................................. 13
Parts List........................................................................................................................ 14
Parts View ..................................................................................................................... 15
Accessories ............................................................................................................ 16 - 17
Master Parts Distributor List .......................................................................................... 18
How To Order Repair Parts ........................................................................................... 18
Warranty ........................................................................................................................ 19
SECTION PAGE

39000-1-0219 Page 3
The installation must conform with local codes or, in
the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1 (latest edition) and to the National
electrical Code, ANSI/NFPA70 (latest edition).
NOTE: Installation and repair should be done by a quali-
ed service person. The appliance should be inspected
before use and at least annually by a qualied service
person. More frequent cleaning may be required due
to excessive lint from carpeting, bedding material, etc.
It is imperative that control compartment, burners and
circulating air passageways of the appliance be kept
clean.
Any safety screen or guard removed for servicing an
appliance must be replaced prior to operating the appli-
ance. Provide adequate combustion and ventilation air.
The ow of combustion and ventilation air MUST NOT
be obstructed.
Provide adequate clearance around air openings into
the combustion chamber and adequate accessibility
clearance for servicing and proper operation. NEVER
obstruct the front opening of the appliance.
This Empire Comfort Systems, Inc. rebox and its
components have been tested and will operate safely
when installed in accordance with this installation
manual. Read all instructions before starting installation,
then follow these instructions carefully during
installation to maximize rebox benet and safety.
Report to your dealer any parts damaged in shipment.
The Empire Comfort Systems, Inc. warranty will be
voided by, and Empire Comfort Systems, Inc. disclaims
any responsibility for the following actions:
- Installation of any damaged rebox.
- Modication of the rebox or any of the components
parts thereof.
- Installation other than as instructed by Empire
Comfort Systems, Inc.
- Installation and/or use of any component part
or accessory not approved by Empire Comfort
Systems, Inc. in combination or assembly with
a Empire Comfort Systems, Inc. firebox, not
withstanding any independent testing laboratory
or other third party approval of such component
part or accessory.
Any such action may create a possible re hazard.
Consult your local building codes.
Firebox Screen.
The rebox screen must be in place when the rebox
is operating.
Instructions to Installer
1. Installer must leave instruction manual with owner after
installation.
2. Installermusthaveownerlloutandmailwarrantycard
suppliedwithrebox.
3. Installer should show owner how to start and operate
logsetthatisinstalledintorebox.
Important
All correspondence should refer to complete Model Number,
Serial Number.
Notice: During initial ring of this rebox with a log set
installed, its paint will bake out, and smoke will occur. To
prevent triggering of smoke alarms, ventilate the room in
which the unit is installed.
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization
equipment or accessories and repair and servicing of
equipmentshallbeperformedonlybyaqualiedagency.
The term "qualied agency" means any individual, rm,
corporation or company which either in person or through
a representative is engaged in and is responsible for (a)
the installation or replacement of gas piping or (b) the
connection, installation, repair or servicing of equipment,
who is experienced in such work, familiar with all precautions
required and has complied with all the requirements of the
authority having jurisdiction.
Commonwealth of Massachusetts: The installation
must be made by a licensed plumber or gas tter in
the Commonwealth of Massachusetts. The state of
Massachusettsrequiresthataexibleapplianceconnector
cannot exceed three feet in length.
Sellers of unvented propane or natural gas-fired
supplemental room heaters shall provide to each purchaser
a copy of 527 CMR 30 upon sale of the unit.
In the Commonwealth of Massachusetts, unvented propane
andnaturalgas-redspaceheatersshallbeprohibitedin
bedrooms and bathrooms.
The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54.*
*Available from the American National Standards Institute,
Inc., 11 West 42nd St., New York, N.Y. 10036.
IMPORTANT SAFETY INFORMATION
INTRODUCTION

39000-1-0219Page 4
2 X 4
HEADER
COMBUSTIBLE
FINISHED WALL
OR MANTEL
FINISHED WITH
TRIM KITOR
NON-COMBUSTIBLE
MATERIAL
3/4" GAP REQUIRED
2 X 4
HEADER
COMBUSTIBLE
FINISHED WALL
OR MANTEL
3/4" GAP REQUIRED
Sidewall Clearances:Theclearancefromtheinsideoftherebox
to perpendicular combustible side wall should not be less than 6
inches. See Figure 1.
Firebox Side and Back Clearances:Thereboxoutercasingside
andbackangesarezeroclearancetocombustibles.
Top Framing and Finishing: Combustible nishing materials
requires 3/4 inch to top of unit. See Figure 2.
CLEARANCES
45°
6"
3"
MAX.
PERPENDICULAR
SIDE WALL
FRONT FACE (SIDE)
FIREBOX
(TOP VIEW)
COMBUSTIBLE
MATERIALS ALLOWED
IN SHADED AREAS
Figure 1
Figure 2a - Louvered Models
Figure 2b - Flush Models

39000-1-0219 Page 5
Ceiling Clearances: The ceiling height should not be less than
42 inches from the top of the hood. See Figure 3.
Mantel Clearances: Ventfreereboxmodelsmustusethehood
suppliedwiththerebox,oroneoftheoptionalhoodkitsavailable
for each model. If a combustible mantel is installed, it must meet
the clearance requirements detailed below.
Grate Clearance: The minimum clearance between the front legs
ofthegrateandfrontedgeofthereboxis2inches.
Leaveatleast36inchesclearancefromthefrontoftherebox.
Figure 3 - Clearances to Combustibles
CLEARANCES
MANTEL
13”
10”
12”
MAX
8”
MIN.
FIREBOX
FACE
CEILING
COMBUSTIBLES
ALLOWED
3/4” COMBUSTIBLE
CLEARANCE REQUIRED
FROM TOP EDGE
OF FIREBOX
10”
8”
6 ½”
5”
3 ½”
2”
9”
3/4”
84”
MIN.
(CEILING TO FLOOR)
HOOD
42” MIN
CEILING TO
TOPOF
HOOD
21”
10 ½”
12 ½”
14 ½”
16 ½”
18 ½”
WALL
FRAMING
OPEN GAP
FINISHED
WALL

39000-1-0219Page 6
Deluxe Vent-Free Firebox Framing Dimensions (in inches)
Model
A B C
Framing
Height
Framing
Width
Framing
Depth
VFD32FB 33 3/4 35 1/2 16 1/4
VFD36FB 35 3/4 40 1/2 18 3/4
VFD42FB 35 3/4 44 1/2 18 3/4
Attention:Add3-3/4inchesto"A"Dimensionwhenusingush
mantel base.
Any vent-free Gas Log Heater must be “For use with approved ANSI
Z21.11.2 unvented room heater.”
Follow and complete the installation instructions of the gas log set
andtherequirementsofthisrebox.
Checkallttingsforleaksbeforelightingthegaslogset.
Inplanningtheinstallationfortherebox,itisnecessarytodetermine
where the unit is to be installed and whether optional accessories
are desired. Gas supply piping should also be planned at this time.
A Gas Shut Off Must Be In This Line.
Thereboxcanbemountedonanyofthesesurfaces:
1. Aathardcombustibleornon-combustiblesurface.
2. A raised platform of combustible or non-combustible material.
3. Recessedintotheoorasillustratedby Figure 4(ushface),
and Figure 5 (louvered models).
4. Supportedunderallfourcornersofthereboxsothatcontact
is made on all four perimeter edges on the bottom of the unit
(Example: Four concrete masonry blocks).
Ifthereboxisinstalleddirectlyoncarpeting,tileorothercombustible
materialotherthanwoodooring,itshouldbeinstalledonametal
or wood panel extending the full width and depth of the unit.
At this point, you should have decided what components to include
inyourinstallation,andwherethereboxistobelocated.Ifthis
has not been done, stop and consult your dealer for assistance
with this planning.
Planning Your Installation
Please note that the optional VFA2 Fresh Air kit available for use
with the Vent Free Firebox must be installed at the time of the initial
installation. Refer to pages 10, 11 and 12 for detailed instructions
for the air kit.
Accessory kits such as the FBB5 Blower kit, Trim kits, Mantels, Full
Cabinet Mantels, plus other Decorative Frame, Hood, and Door
accessorykitsmaybeinstalledafterthereboxissecuredtothe
framed opening.
Refer to the instructions provided with each of the optional accessory
kits for proper installation and operation.
Firebox Framing
Fireboxframingcanbebuiltbeforeorafterthereboxissetinplace.
Framing should be positioned to accommodate wall covering and
reboxfacingmaterial.Thereboxframingshouldbeconstructed
of 2 x 4 lumber or heavier. The framing headers must be at least
3/4inchabovethereplace.RefertoFigures 6 and 7forrebox
framing dimensions.
Figure 4 Figure 5
Figure 6
FIREBOX INSTALLATION INSTRUCTIONS
LOUVERED
FIREBOX
MODELS
COMBUSTIBLE MATERIALS ALLOWED

39000-1-0219 Page 7
Figure 7
Firebox Dimensions
FIREBOX INSTALLATION INSTRUCTIONS
D
L
M
GI
A
H
F
B
GIA
H
F
B
K
N
C
J
OUTER FIREBOX DIMENSIONS
INNER FIREBOX DIMENSIONS
E
B
A
C
D
TOPVIEW SIDE VIEW
DELUXE
FLUSH
N
J
K
DELUXE
LOUVERED
.5 inches
O
OUTER FIREBOX DIMENSIONS (in inches)
INDEX
LETTER
LOUVERED FLUSH
VFD32 VFD36 VFD42 VFD32 VFD36 VFD42
A 33 35 35 33 35 35
B 35 40 44 35 40 44
C 16 1/2 19 19 16 1/2 19 19
D 27 7/8 31 7/8 35 7/8 27 7/8 31 7/8 35 7/8
F 31 36 40 31 36 40
G 22 1/4 24 1/4 24 1/4 22 1/4 24 1/4 24 1/4
H 1 3/16 1 3/16 1 3/16 6 1/8 6 1/8 6 1/8
I 31 1/2 33 1/2 33 1/2 28 3/8 30 3/8 30 3/8
J 8 5/16 8 5/16 8 5/16 8 5/16 8 5/16 8 5/16
K 4 3/4 4 3/4 4 3/4 4 3/4 4 3/4 4 3/4
L 30 1/4 34 5/8 36 5/8 30 1/4 34 5/8 36 5/8
M 60 3/8 69 1/8 73 60 3/8 69 1/8 73
N 2 11/16 2 11/16 2 11/16 2 11/16 2 11/16 2 11/16
O 42 5/8 48 7/8 51 3/4 42 5/8 48 7/8 51 3/4
INNER FIREBOX DIMENSIONS (in inches)
INDEX
LETTER VFD32 VFD36 VFD42
WITHOUT BRICK
A 31 36 40
B 25 3/16 29 3/16 33 3/16
C 14 1/8 16 1/2 16 1/2
D 18 11/16 20 20
E 22 24 24
WITH BRICK
A 29 5/16 34 5/16 38 5/16
B 24 28 32
C 13 5/16 15 3/4 15 3/4
D 18 11/16 20 20
E 22 24 24

39000-1-0219Page 8
Locating Firebox
Placereboxinframingopening.Usethetabsonthesideofthe
reboxtoattachreboxtoframing.Differenttablocationscanbe
usedfornishingmaterialswiththicknessesof1/2inchand5/8inch.
See Figure 8.
Framingtabs should t directly against framingmaterial. Use at
least one nail per bracket to secure in place.
Checksquarenessofthereboxpriortosecuringtoframedopening.
See Figure 9.
Figure 8
Ablackhoodthatisfurnishedwitheachrebox(oroptionalhood)
MUST be installed before the rebox is used. Failure to do so
may create a possible re hazard. The hood is located behind
upper louver, or inside the rebox on ush face units. If brass,
stainless steel, or hammered pewter hoods are desired, they can
be purchased as an option. Attachment is the same as the standard
black hood.
Flush Face Models
1. Onushfacemodels,loosenthetwoscrews(A)holdingrebox
toptofacepanel,thenslidethehoodangebetweentherebox
top and face panel and re-tighten the screws.
2. Install one screw at each end of the hood as shown (C).
Louvered Models
1. If you have a louvered model, remove upper louver.
2. Placethetophoodangeontopoftherebox,theninstallthree
screwsthroughthereboxtopfrombelowandscrewintothe
pilotholesinthehoodange(B).
3. Install one screw at each end of the hood as shown (C).
4. Re-install louver.
CAUTION: The hood must be installed prior to operation of
appliance. See Figure 10.
Flush Face Models
Figure 10
Figure 9
FIREBOX INSTALLATION INSTRUCTIONS
INSTALLING HOOD
B
C
INNER FIREBOX TOP
Louvered Models
ACAC

39000-1-0219 Page 9
Thereboxisdesignedtoaccepta3/8-inchgaslineforanapproved
vent-freegaslogset.Havethelineinstalledbyaqualiedservice
person in accordance with all building codes. Consult local building
codes to properly size the gas supply line leading to the 3/8-inch
hook-up at the unit. The state of Massachusetts requires that a
exibleapplianceconnectorcannotexceedthreefeetinlength.
Gasaccessholesareprovidedonbothsidesoftherebox.See
Figure 11. On models with refractory brick panels installed, carefully
remove the knockout in the refractory brick panel using a large
standard screwdriver and hammer. First, place screwdriver in groove
next to plug and pry sideways to pop out main plug. Then remove
the remaining concrete in hole with gentle tapping with ball peen
hammer and/or screwdriver. A masonry drill and bit may also be
used to create a clean hole for the gas line to pass through. See
Figure 12.
When installing optional ceramic ber side panels into rebox,
laypanelonaatsurface.Removethegaslineknockout(round
depression) in the appropriate side panel using a drill or utility knife.
Afterthebrickpanelknockoutisremoved,thereboxwrapmay
havearoundmetalknockoutthatmustberemovedalso.Usea
screwdriver to punch out the metal knockout.
Checkgastype.Useonlythegastypeindicatedonthegaslog
set rating plate. If the gas listed on the plate is not your type of gas
supply, DO NOT INSTALL. Contact your dealer for proper model.
AlwaysuseanexternalregulatorforallPropanereboxestoreduce
the supply tank pressure to a maximum of 14 inch w.c. This is in
additiontotheregulatorttedtothelogset.
WARNING
Connection directly to an unregulated propane tank can
cause explosion.
InstallonlyaANSIZ21.11.2vent-freelogsetintothisrebox.
Figure 11
Extended Hoods
Ifyournon-combustiblefacingmaterialisover1"inthicknessthatwillbeusedtonishthisrebox,anextendedhoodisavailablethatwill
extend out 2" farther out into the room. Contact your local dealer for details.
Finishing
Alljoints(top,bottomandsides),wherethewallordecorativefacingmaterialmeetsthereboxsurroundshouldbesealedwithanon-
combustible material.
Hearthextensionsarerecommended,butnotrequiredforthesereboxes.
VB4H32BL Standard Black VB4H36BL Standard Black VB4H42BL Standard Black
INSTALLING HOOD
GAS LINE CONNECTION
Brick Panel
Figure 12
GAS ACCESS HOLES
NOTE:Wheninstallingstainlesssteelorreectivedecorativeliner
kits,gaslinesmustcomethroughthebottomoftherebox.
See Figure 11.

39000-1-0219Page 10
OPTIONAL FBB5 SINGLE SPEED BLOWER INSTALLATION INSTRUCTIONS
Attention: Install blower assembly before connecting gas inlet
supply line.
Wiring
The appliance, when installed, must be electrically grounded in
accordance with local codes or, in the absence of local codes,
with the National Electrical Code, ANSI/NFPA 70, if an external
electrical source is utilized. This appliance is equipped with
a three-prong [grounding] plug for your protection against
shock hazard and should be plugged directly into a properly
grounded three-prong receptacle. Do not cut or remove the
grounding prong from this plug. For an ungrounded receptacle,
an adapter, which has two prongs and a wire for grounding, can be
purchased, plugged into the ungrounded receptacle and its wire
connected to the receptacle mounting screw. With this wire com-
pleting the ground, the appliance cord plug can be plugged into the
adapter and be electrically grounded.
CAUTION
Label all wires prior to disconnection when servicing con-
trols. Wiring errors can cause improper and dangerous op-
eration. Verify proper operation after servicing.
NOTE: Junction box on right side of rebox must be pre-wired
at time of rebox installation for use with blower assembly. A
standard wall ON/OFF wall switch or optional SCV1 Variable
Speed Control Kit should be installed to activate power to the
Firebox, and control the operation of the FBB5 Blower assembly.
It is recommended that installation of the wiring be performed by a
qualiedelectrician.See Figure 13.
1. Ifinstalled,turnOFFgassupplytorebox/gaslog.
2. Ifapplicable,turnOFFelectricsupplytorebox.
CAUTION
All wiring should be done by a qualied electrician and
shall be in compliance with all local, city and state building
codes. Before making the electrical connection, make sure
that main power supply is disconnected. The appliance,
when installed, must be electrically grounded in accordance
with local codes, with the national electrical code ansi/nfpa
70 (latest edition).
A factory installed junction box is located on the lower right
sideoftherebox.Wiringmustbefedtothejunctionboxand
attached to the receptacle that is provided. From right side of
therebox,removethe screwsecuringthejunction boxas-
sembly. Leave approximately 6 inches of wire in the junction
box for connection.
Attach black wire to one side of the receptacle and white wire
to opposite side of receptacle. The ground wire should be at-
tached to the green (ground) screw.
Install the receptacle into the junction box. Attach cover plate.
Attention: If installed, do not damage gas inlet supply line
whenblowerassemblyisinsertedintorebox.Insomecases,
removal the gas inlet supply line may be necessary.
3. Determinewhichtypeofreboxyouhavepriortoinstallation.
See Figures 14 and 15.
Figure 13
Figure 14
Figure 15
Deluxe Louvered
Models
Deluxe Flush Face
Models

39000-1-0219 Page 11
4. Insertblowerassemblyintointerior,bottomof rebox.Posi-
tion blower assembly so that you align the notch on back of
blowerassemblywiththecenterscrewonreboxback,then
pushtheblowerassembly againstreboxback.Theblower
wheelmustbecenteredwiththebackwalloftherebox.The
magnets on the back and bottom of blower assembly will suf-
cientlyholdblowerassemblyinplace.
5. Pushtabawaywithstandardscrewdriveronupperrightre-
box .
6. Next,ndthefancontrolswitchandwireassembly.Feedthe
wiresthroughtheholeatthetopoftherebox,andsecurethe
fan control switch with two #6 screws provided. See Figure 16.
FAN CONTROL
SWITCH LOCATION
FAN CONTROL WIRES
Figure 16
7. Thefancontrolwireswillslidedownbetweenthereboxand
outer wrap near the blower assembly. See Figure 16.
8. One fan control wire will have a 1/4 inch female terminal that
must be attached to the open terminal on the blower motor.
See Figure 19, Connection A.
9. The other fan control wire has a 1/4 inch male terminal. Attach
this terminal to the open terminal on the blower power cord.
See Figure 19, Connection B.
10. Route the wires away from moving parts of the blower assem-
bly and retain wires together near the blower motor using the
plastic purse clip provided.
11. To complete the installation, plug the power cord into the junc-
tionboxreceptacleattherightrearcornerofthereboxouter
wrap. See Figure 17.
12. If room permits, the power cord can be located from the out-
side of the unit looking through the junction box access hole
(with the junction box removed), then plug up the power cord
before reinstalling the pre-wired junction box.
13. Once all connections are made electrically, it is recommended
that you test the blower fan control operation by turning on
power to the blower (CAUTION: 110 Volt). Then apply heat to
thefancontrolswitchinsidethereboxwithalighterormatch
until blower is activated. Once blower is activated, check for
proper operation. Do not place hands near blower assembly
or other wiring while power is on.
14. Replace blower access plate and/or reinstall the brick liner
panels if provided.
15. This completes the installation of the optional FBB5 Blower kit
accessory.
NOTE: This blower is equipped with a heat activated fan control
switch.Blower will operate when therebox warms up, and will
turnoffautomaticallywhenthereboxcoolsdown.
BLOWER POWER CORD
Figure 17
OPTIONAL FBB5 SINGLE SPEED BLOWER INSTALLATION INSTRUCTIONS

39000-1-0219Page 12
Blower Motor
The blower motor does not have oiling holes. Do not attempt to oil
the blower motor.
Blower Wheels
The blower wheels will collect lint and could require periodic clean-
ing. If the air output decreases or the noise level increases, it indi-
cates a dirty blower wheel. Remove fan and clean blower wheels.
WARNING
Unplugging of blower accessory will not stop the heater
from cycling. To turn off gas to the heater (millivolt model):
push in gas control knob slightly and turn clockwise to
OFF. Do not force. To turn off gas on direct ignition model,
turn gas line valve to OFF.
1 R7731 BLOWER ASSEMBLY
2 R8199 FAN CONTROL SWITCH
3 R8147 WIRE ASSEMBLY
4 R7615 CORDSET
110 VOLT AC
JUNCTION BOX
WHITE
FAN
SWITCH
BLACK
FAN/MOTOR
ASSEMBLY
Figure 18
Figure 19
OPTIONAL FBB5 SINGLE SPEED BLOWER INSTALLATION INSTRUCTIONS

39000-1-0219 Page 13
CAUTION
All wiring should be done by a qualied electrician and shall
be in compliance with all local, city and state building codes.
Before making the electrical connection, make sure that main
power supply is disconnected. The appliance, when installed,
must be electrically grounded in accordance with local codes
or, in the absence of local codes, with the national electrical
code ansi/nfpa 70 (latest edition)
A factory installed junction box is located on the lower right hand side
oftherebox.Wiringmustbefedtothejunctionboxandattached
to the receptacle that is provided. Remove the knockout in the
installed junction box to accept wiring into the junction box. Install
aULlistedcableclamp(notsupplied)intheknockouthole.Leave
approximately 6 inches of wire in the junction box for connection.
Attach black wire to one side of the receptacle and white wire to
opposite side of receptacle. The ground wire should be attached
to the green (neutral) screw.
Install the receptacle into the junction box. Attach cover plate.
Keep the control compartment, logs and burner area surrounding
the logs clean by vacuuming or brushing area at least twice a year.
THE LOGS CAN GET VERY HOT – HANDLE ONLY WHEN COOL.
Always turn off gas to the pilot before cleaning. For relighting, refer
to lighting instructions located on the log set.
Neverobstructtheowofthecombustionandventilationair.Keep
thefrontofthereboxclearofallobstaclesandmaterials.
Screens must be closed during operation.
JUNCTION BOX WIRING INSTALLATION INSTRUCTIONS
MAINTENANCE
Figure 20

39000-1-0219Page 14
PARTS LIST
INDEX
NO.
PART NUMBER DESCRIPTION
VFD32 VFD36 VFD42
1 17169 18807 17187 UPPERLOUVER
2 17170 18808 17188 LOWERLOUVER
3 39520 39520 39520 JUNCTIONBOXASSEMBLY
4 R3492 R3492 R3492 RECEPTACLE
5 R3491 R3491 R3491 COVER,JUNCTIONBOX
6 27338 27338 27338 BRACKET,TOPBRICKRETAINER(QUANTITY2)
7 19401 19401 19401 BRACKET,BOTTOMBRICKRETAINER(QUANTITY2)
8 R10388 R10392 R10392 BRICK PANEL RIGHT - REFRACTORY BRICK
8 31675 31678 31678 BRICK PANEL RIGHT - FIBER BRICK
9 R10386 R10390 R10394 BRICK PANEL BACK - REFRACTORY BRICK
9 31676 31679 31680 BRICK PANEL BACK - FIBER BRICK
10 R10387 R10391 R10391 BRICK PANEL LEFT - REFRACTORY BRICK
10 31674 31677 31677 BRICK PANEL LEFT - FIBER BRICK
11 39517 39518 39519 HOOD
12 R7051 R7052 R7053 ROD,SCREEN(QUANTITY2)
13 R8137 R8148 R8148 SCREENCURTAIN(QUANTITY2)
14 39492 39494 39496 FACEASSEMBLY-LOUVERED
15 39479 39484 39489 FACEASSEMBLY-FLUSH
16 38973 38973 38973 BLOWER COVER PLATE

39000-1-0219 Page 15
PARTS VIEW
1
2
54
3
6
10 98
7
12
12
16
11
13
14
15

39000-1-0219Page 16
Accessory Description Model Numbers
Fan Kit
Designedtoprovideforcedairow. FBB5
Variable Speed Control Kit
Wall mounted variable speed control for use
with FBB5 blower SCV-1
Brick Liners
Deluxe Firebox Contact dealer for all available
optional liner kits
Fresh Air Kit
1
2
3
Deluxe and Premium Fireboxes VFA2
Frame Kits
3-Piece Frame Kits
Black, Stainless Steel or Hammered Pewter
Contact dealer for all available
optional frame kits
Standard Hood Brass hood = BR
Stainless Steel = SS
Hammered Pewter = HP
Contact dealer for all available
optional hood accessories
ACCESSORIES

39000-1-0219 Page 17
Extended 4" Hoods Extended hoods that extend out 2" farther than the
standard hoods, to accommodate thicker surround
materials.
Available as optional kits in Brass, Hammered Pew-
ter,andStainlessSteelnishes.
Contact dealer for all avail-
able optional hood acces-
sories
Louvers
Styles include Slat, Mission, Arch, and Leaf Patterns.
Available as optional kits in Brass, Hammered Pew-
ter,andStainlessSteelnishes.
Contact dealer for all avail-
able optional louver acces-
sories
Bottom Trim Strip
Available as optional kits in Brass, Hammered Pew-
ter,andStainlessSteelnishes.
Contact dealer for all avail-
able optional trim acces-
sories
Decorative Door Kits Available as optional kits in Brass, Hammered Pew-
ter,andStainlessSteelnishes.
Contact dealer for all avail-
able optional frame kit ac-
cessories
Decorative Frame Kits Available as optional kits in Brass, Hammered Pew-
ter,andStainlessSteelnishes.
Contact dealer for all avail-
able optional decorative
door kit accessories
ACCESSORIES (CONT'D)
Accessory Description Model Numbers

39000-1-0219Page 18
ToOrderPartsUnderWarranty,pleasecontactyourlocalEmpiredealer.Seethedealerlocatoratwww.empirecomfort.
com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the
nature of the problem with the unit.
To Order Parts After the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below.
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com.
Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original
Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc.
MASTER PARTS DISTRIBUTOR LIST
Parts Not Under Warranty
Parts can be ordered through your Service Person, Dealer, or a Master Parts Distributor. See this page for the Master Parts Distribu-
tors list. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the
service person/dealer.
Warranty Parts
Warranty parts will need a proof of purchase and can be ordered by your Service Person or Dealer. Proof of purchase is required for
warranty parts.
AllpartslistedinthePartsListhaveaPartNumber.Whenorderingparts,rstobtaintheModelNumberandSerialNumberfromthe
name plate on your equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the fol-
lowing illustration and part list. Be sure to give all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipmentscontingentuponstrikes,resandallcausesbeyondourcontrol.
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401 Willow Lake Boulevard
Vadnais Heights, MN 55101
Phone: [phone]
Toll Free: 800-397-1339
Website: www.deydistributing.com
Parts: Heater, Hearth and Grills
F. W. Webb Company
200 Locust Street
Hartford, CT 06114
Phone: [phone]
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax: [phone]
Websites: www.fwwebb.com & www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10 East Route 36
West Long Branch, NJ 07764
Phone: [phone]
Toll Free: 800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills

39000-1-0219 Page 19
Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods speci-
edbelow.Hearthproductsmustbeinstalledbyaqualiedtechnicianandmustbemaintainedandoperatedsafely,inaccordancewith
the instructions in the owner’s manual. This warranty applies to the original purchaser only and is not transferable. All warranty repairs
mustbeaccomplishedbyaqualiedgasappliancetechnician.
Limited Lifetime Parts Warranty with a Five-Year Limited Labor Warranty – Combustion Chamber and Heat Exchanger
If the combustion chamber or heat exchanger (see parts list) fails because of defective workmanship or material,
Empire will repair or replace at Empire’s option.
 Withinveyearsfromthedateofpurchase,Empirewillpayreasonablelabortohavethedefectivepartrepairedor
replaced at Empire’s option.
Limited Five-Year Parts & Labor Warranty – All Other Components
(Except Remote Controls, Thermostats, Accessories and Replacement Parts)
 Shouldanypartfailbecauseofdefectiveworkmanshipormaterialwithinveyearsfromthedateofpurchase,Empirewill 
repair or replace at Empire’s option.
 Withinveyearsfromthedateofpurchase,EmpirewillpayreasonablelabortohavethatdefectrepairedatEmpire’soption.
Limited One-Year Parts Warranty – Remote Controls, Thermostats, Accessories, and Parts
Should any remote control, thermostat, accessory, or other part fail because of defective workmanship within one year from
the date of purchase, Empire will repair or replace at Empire’s option.
Duties Of The Owner
 Theappliancemustbeinstalledbyaqualiedinstallerandoperatedinaccordancewiththeinstructionsfurnishedwith
the appliance.
A bill of sale, cancelled check, or payment record should be kept to verify purchase date and establish warranty period.
Ready access to the appliance for service.
What Is Not Covered
Damages that might result from the use, misuse, or improper installation of this appliance.
Travel, diagnostic costs and freight charges on warranted parts to and from the factory.
Claims that do not involve defective workmanship or materials.
 Unauthorizedserviceorpartsreplacements.
Removal and reinstallation cost.
Inoperable due to improper or lack of maintenance.
How To Get Service
To make a claim under this warranty, please have your receipt available and contact your installing dealer. Provide the dealer
 withthemodelnumber,serialnumber,typeofgas,andpurchaseverication.Theinstallingdealerisresponsibleforproviding
service and will contact the factory to initiate any warranted parts replacements. Empire will make replacement parts available
at the factory. Shipping expenses are not covered.
If, after contacting your Empire dealer, service received has not been satisfactory, contact: Consumer Relations Department,
Empire Comfort Systems Inc., PO Box 529, Belleville, Illinois 62222, or send an e-mail to [email protected] with
“Consumer Relations” in the subject line.
Your Rights Under State Law
 Thiswarrantygivesyourspeciclegalrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate.
WARRANTY

39000-1-0219Page 20
www.empirecomfort.com
Empire Comfort Systems Inc.
Belleville, IL
If you have a general question
about our products, please e-mail
us at [email protected].
If you have a service or repair
question, please contact your dealer.
