EMPORIA TALKsmart User manual

TALKsmart
English
Wi-Fi
connection
or mobile
data tariff
required

›YOUR MOBILE PHONE AT A GLANCE
1Loudspeaker
2Message line
3Display (screen)
4Navigation ring
• For navigation in menu and lists
5Left function key
• Press this to select the option shown in the bottom
left-hand corner of the screen (e.g. Menu, OK, …)
6Selection key
• To conrm selections
7Right-hand function key
• Press this to select the option shown in the bottom
right-hand corner of the screen (e.g. Name, Back,…)
8Green key
• Start or accept a call
• Standby: Open numeric input for call
1
2
3
4
5 7
8
10
11 12
13
17
15 16
14
9
6

9Red key
• Standby: Lock phone
• When in a call: End
• In menu: Back to standby mode
• Press and hold: Switch phone on/o
10
1
key (voicemail)
11 key (unlock keypad)
12 key (MUTE)
13 Headset port
14 Port for USB charging cable
15 Camera lens and ash
16 Loudspeaker
17 Battery cover
›Icons in the message line
Network signal strength
Roaming (abroad)
Battery scale
Missed call
Call redirect
New message
Prole: Mute
Prole: Outdoor
Prole: Meeting
Alarm on
Bluetooth activated
Bluetooth connected
USB connection
Upload/download
Wi-Fi
WhatsApp
Radio

1. GETTING STARTED
›Inserting a SIM card
Lift o the battery cover–
start with the recess at the
bottom left corner of the
battery cover.
Slide the SIM card into the
SIM card holder with the gold
contacts facing down.
Slide your data card into the
card holder with the gold
contacts facing down.
Press the locking tab down
to remove the SIM card or
data card.

›Inserting and charging the battery
! Attention: Charge the battery for at least four hours before you use it for the rst time.
Only use batteries and chargers that are permitted for use with this specic model.
• Insert the battery, making
sure that the battery
contacts touch the phone's
gold contacts.
• Put on the battery cover–
press the battery cover
down onto the phone until
it clicks into place on each
side.
• Plug the charging cable
into the USB port on the
top of the phone.

›Turning on the phone
• Pressing the key for at least two
seconds switches the phone on.
• To turn the phone o, press the key
for two seconds again.
›Using a new SIM card for the first time:
Enter the four-digit PIN code (personal
identication number) _Press the left
function key for OK to conrm.
! The PIN code is a four-digit number that is
intended to prevent somebody else from
being able to switch on your mobile phone.
You have a maximum of three attempts to
enter the correct number. If you enter the
wrong number three times in a row, you will
only be able to unblock the SIM card with
the PUK code. You will nd the PIN code and
PUK code in the documents supplied by your
network operator.

After starting, the phone is in standby
mode.
In standby mode the phone is on, but is
not running any applications (calls, SMS
messages, etc.). One of three menu pages
is displayed.
›Menu items: Contacts, Camera,
WhatsApp, SMS/MMS, History,
Browser, Calendar, Gallery, Radio,
Clock, Settings, Google Video, Music,
Cleaner, Tools, App Folder
›Unlocking the phone:
Press the key for at least two sec. to
unlock the screen.
Changing the screen lock: Settings
_Security _Screen lock
›Using the menu
• Press to toggle between the main
menu pages.
Three dots at the bottom edge of the
screen show the menu page you are
viewing.
• Navigate through the menu items with
the .
The selection is highlighted with a white
border.
• Press the selection key to open the
selected menu item.
• Options which you can select with
the function keys are shown at the
bottom of the screen.
• To return to the main menu,
press the red key.
2. USING THE PHONE

›Saving energy
If a few seconds pass without the phone
receiving any input from you, the screen
will go blank to save energy. In the event
of an incoming call or you pressing any
key, the screen will automatically light
up again.
• Change the duration before switching to
Phone idle:
Settings _Display _Phone idle
›Dual-function keys
Some keys have additional functions if
they are pressed and held down for a few
seconds:
•
1
key: Listen to your voicemail
Changing the voice mail settings:
_Options
_Settings
_Name of provider
_Voicemail or call forwarding
• key: Unlock keypad
• key: Silent mode on/o
• key: Switch phone on/o
• left function key: Open message
line

›How to write text
Use the key to toggle between
numeric and text input (language).
• Pressing the number key multiple times
displays a list of letters; upper case letters
follow the lower case letters.
g h i G HI 4
• To input text, press the a number key
multiple times (e.g. 2x
4ghi
, 1x
2abc
,
3x
5jkl
, 3x
5jkl
, 3x
6mno
for Hallo)
• Non-standard characters:
Press the key to open the menu for
non-standard characters,
press to select the navigation ring, and
then selection key to apply.
• The symbols available vary according to
which language you are using.
›Using the mouse pointer
Navigation in WhatsApp and in the
browser relies on the mouse pointer and
the selection key:
• Use the navigation ring to move the
mouse pointer (cursor) to the position
you want to click
• Now press the selection key
• Use left function key to change from
an arrow display to a scroll display in
mouse mode
• Press right-hand function key to go
back

›Incoming call
• Accept the call with the key or reject
it with the key
• Press the selection key to reject the call
and send a text message in response
›Connecting:
• Dialling: Enter the number you want to
dial using the keypad
• Open contact: Open Contacts in the
main menu, select the desired contact
from the list
• Redialling:Open History in the main
menu, select the contact from the list
_Start the call with the key and end
it with the key.
›During a call:
Use the left function key to open the
Options:
Loudspeaker/Headset earpiece,
Mute/Unmute, Hold/Resume, Add call,
Send message
• Use the navigation ring to change the
in-call volume
• Press the right-hand function key to
end the call
3. CALLS

4. CONTACTS
›Saving contacts
(name and number)
Open Contacts in the main menu
_Press the left function key to open
theOptions
_Press the selection key
to open Add contact
_Select the storage location for the
contact
_Enter the name and number;
press the key to toggle between
numeric and text input
_Options _Save
! Always save names and numbers with the
international dialling code,
e.g. +41 for Switzerland, +43 for Austria and
+49 for Germany.
›Searching for contacts:
In the main menu open Contacts
_Use the navigation ring to browse
the entries, or use the keypad to type the
rst letter of the entry you are looking for
in the search box.
_The selected contact is highlighted
in blue
_Press the key to start the call
_Press the selection key to open the
contact

5. CAMERA 6. WHATSAPP
›Taking a photo or filming
Open Camera in the main menu
_The camera mode currently used
(photo or video ) is shown at the
centre.
• Use the selection key to take a photo or
start/stop a video recording
• Use the navigation ring to change to
photo or video camera or gallery
• Depending on the mode, you can select
camera settings or ash settings
Open WhatsApp in the main menu
›Navigation
Navigation in WhatsApp relies on the
mouse pointer and the selection key:
See Section 2 »Using the phone«
›Setting up WhatsApp
You need to set up WhatsApp before you
can use it for the rst time:
• Enter your own phone number
• WhatsApp sends a text message to verify
the input
• Enter a user name of your own choice
! In WhatsApp only contacts that you have
saved in Contacts and that are additionally
registered with WhatsApp are displayed.

›Receiving a WhatsApp message
A new message is indicated by the
WhatsApp icon in the message bar, and
by a red circle 1in the menu eld.
›Opening a message
Open SMS/MMS in the main menu
• Use the navigation ring to select an
entry from the message list, and press the
selection key to open it
• Press the left function key to open
theOptions:
New message, Settings, Delete thread,
Cell Broadcasts, Messages in SIM
7. SMS/MMS

›Composing a new message
Open SMS/MMS in the main menu
_Options _New message
• Use the keypad to enter text, press the
key to toggle between numeric and
text input
• Entering the recipient:
Type the rst letter to search for the
contact, or press to go to Contacts
• Entering text:
See Section 2 »Using the phone«
• Sending a message:
Press the left function key to open
theOptions _press the selection key
to select Send
›Receiving a message
An incoming text message is indicated
by an acoustic signal, a sign in the lock
screen and a red circle marker 1 in the
menu eld. The unread message is
highlighted in blue in the list of messages.

›Opening call history
Open History in the main menu
• Menu items: All, missed, outgoing,
incoming
• Press the navigation ring to select the
list, and select an entry in the list
• The selected contact is highlighted in
blue
• Press the green key to start the call
• A missed call is indicated by a red circle
marker 1in the menu eld.
›Viewing call details
• Use the navigation ring to change to
the clock icon
• Press the selection key to view details
such as the call duration and call time
• Options: Add to contacts, remove from
call log, edit number before call
›Deleting calls
Use Options to delete a call or
the whole list
8. CALL HISTORY

9. BROWSER 10. CALENDAR
Open Browser in the main menu
›Navigation
Navigation in WhatsApp relies on the
mouse pointer and the selection key:
See Section 2 »Using the phone«
Open Calendar in the main menu
›Open the day view
• Use the navigation ring to browse the
calendar, press the key and key
to change months
• Use Option _View to view the
appointments for the selected day

11. GALLERY
Photos are grouped in albums if they come
from the same source. This means there is
one album for camera photos, and another
for WhatsApp photos, etc.
›Viewing a photo or video
Open Gallery in the main menu
• Press the selection key to open the
album; use the navigation ring to
switch between images
• Press the selection key to display an
• Options: Share, Delete, Slideshow,
Rotate left, Rotate right, Set picture
as wallpaper/WhatsApp prole image,
Details
! You can connect your phone to a PC
using the USB data cable and transfer
your photos. After establishing the USB
connection, activate Connect as media
device.
You can use a data card to increase the
storage capacity of your mobile phone.
You can purchase these cards from
electronics stores.

›Using the radio
Open Radio in the main menu
• Options: Auto search, Radio list,
Headphones, Start recording,
Recording le list
• Adjusting the volume:
Use the navigation ring up, down
• Turning the radio on and o:
Press the selection key
›Searching for a radio station
• Selecting a frequency:
Use the navigation ring left, right
• Automatic station search
Options _Auto Search
• Selecting a station from the list:
Options _Radio list
›Recording the radio signal
• Recording:
While the radio station is broadcasting
press Options _Start recording
• Stopping recording:
Press the selection key
• Playing back a recording:
Options _Recording le list _Select
detail and press the selection key
12. RADIO

Open Clock in the main menu
• Menu items: Alarm, World Time, Timer,
Stopwatch
›Setting the alarm clock
_Press the navigation ring to select
an entry from the list
_The selected entry is highlighted in
blue
_Press the selection key to open and
edit the Settings
13. ALARM CLOCK
• Enable/disable wake-up time
• Enter a label
• Dene the repeat behaviour:
Every day, Workdays, Single
• Dene the ringtone
• Enable/disable vibration
• Mute: Dene duration
• Deleting

›Menu items
• Popular
Wi-Fi, Bluetooth, Proles, Display,
Data usage
• User
Location, Security, Date & Time,
Language and input,
Scheduled power on and off, More
• System
Storage, Battery, Mouse control, Apps,
Backup & Reset, About your phone
To set up a Wi-Fi connection, you need
the name of the Wi-Fi network and the
matching password.
! If you already have a Wi-Fi network at
home, you can usually nd this information
on the underside of the Wi-Fi router.
In the main menu, open Settings
_Wi-Fi:
• The slider at the top of the screen is
highlighted in blue
• Press the selection key to switch on
the Wi-Fi function on the device;
the slider turns green
14. SETTINGS 14.1 Wi-Fi connectivity
