Enable-IT 864 Mini User manual

All Rights Reserved 1997 - 2015 ENABLE-IT-Proprietary and Confidential
Ethernet Extension Experts
Enable-IT 864 Mini
Ethernet Extender DSLAM
Quickstart Guide


Page 2 of 5Ethernet Extension Experts
INSTALLING THE 864 EXTENDED ETHERNET DSLAM
Installation
The Enable-IT 864 Extended Ethernet DSLAM can support (4) 864 Pro CPE units up to
6,000ft or 1,828m over 1-pair copper wiring end to end.
Total distance limitation of 6,000ft or 1,829m from end to end.
1 Pair copper wiring .30 Gage or better cabling is required for the 864 Interlink
ports transmission.
For the Interlink wiring you can use either RJ-45 or RJ-11 connectors. Crimp a RJ-
45 Male Head to each end of the contiguous wire run and using the following pins (1
& 2) straight through. This will deliver 1 Voice line, Ethernet Data. If you desire to use
the second voice line, you can also use pins (3 & 6) on each end straight through.
The 864 Interlink port (RJ-45 interface) carries this 1-pair signaling over the RJ-45
pins (1 & 2) - used for transport for both voice and data. If you use more than 1-pair
of wiring such as a CAT5 segment, the RJ-45 pins (3 & 4) are used for Voice line 2
and the remaining pins 4,5,7 & 8 are can transport native PoE or are unused. As an
option the RJ-11 interface on the side of the 864 for use with existing RJ-11 wiring.
The RJ-11 dongles do not transport PoE currently but can be easily added if needed
on request at time of ordering.
The Overview Diagram: This diagram shows the contents of the product box inside the
rectangle. Devices outside the rectangle above are your equipment that can be attached.
We highly recommend a quick test to ensure the working order of your 864 mini
DSLAM to your 864 Pro CPE units.

Page 3 of 5Ethernet Extension Experts
Step 1 –Use an Ethernet patch cord and attach to any 864 Interlink port to an 864 Pro
CPE unit. Power up both devices.
Step 2 –The Green Sync LEDs will start flickering slowly and then fast as the units talk
to each other. After a few seconds you should see a solid Green Interlink Sync LED on
each unit to confirm a link is established. This confirms basic proper operation of the
units.
LED indicators will provide visual operational status of the 864 units.
Sync - Slow to fast flicker on power up –indicates negotiation of a link.
Solid Green LED indicates link established and rapid pulse is traffic.
Pwr - Solid Green LED indicates that both units are receiving 5v power.
Mode - Solid Yellow LED on CPE unit only –No LED lit on CO
ACT - Yellow LEDs –Lit solid indicates the presence of local LAN
–Blinking indicates the presence of local LAN traffic
Step 3 –Next for a more detailed test and to confirm your LAN Equipment works with the
864 Mini DSLAM, connect your local Ethernet LAN to the 864 LAN port 1 or LAN 2 and
remote device to any 864 Pro CPE LAN ports and test connectivity. The Green Interlink
Sync LED will pulse rapidly as it detects traffic.
Dongle pins: DSL port center pair (2&3) = Data
Phone port –center pair (2&3) = Voice 1 Outside pair (1&4) = Voice 2
864 Pro CPE
864 CO

Page 4 of 5Ethernet Extension Experts
Performance Settings
If you are experiencing performance issues with your Ethernet connection you may use the
following Dip switch settings to adjust your application. For Dip switch 2-4 you must toggle
both symmetrically, in other words the CO and CPE must match. If you turn 3 up on the CO
you must do so for the CPE and vice-versa.
Dip Switch 1: Toggles the 864 Pro for either CO or CPE mode. (CO mode Up, CPE mode
Down)
Dip Switch 2: This toggles your 864 Pro for either Interleave or Fast mode –Default setting is
set to Fast which is preferred for streaming multimedia, where an occasional dropped bit is
acceptable, but lags are less so. Interleave channel works better for file transfers, where the
delivered data must be error free but latency incurred by the retransmission of errored
packets is acceptable.
Dip Switch 3: This toggles symmetrical/asymmetrical mode for dsl transmissions.
Symmetrical balances out the download/upload speed for transmitting data packets.
Asymmetrical mode weighs in favor of download speed while sacrificing upload speed
bandwidth. We suggest flipping Dip switch 3 Up (OFF) at a distance of 1,500 feet or less.
Dip Switch 4: This toggles the Signal Noise Ratio (SNR). Default is set to 9dB which is
excellent for long distance communications whereas flipping the switch Up (OFF) toggles
6dB mode. If you experience issues of noise bleeding over the lines or high interference in
your environment it is suggested that you switch to 6dB mode and change to interleave
mode. This will help clean up any noise bleeding over your cabling.

Default DIP settings
860 Pro CPE –All down set in the ON position
860 Pro CO –DIP position 1 up (OFF)
DIPs 2-4 down (ON)

Page 5 of 5Ethernet Extension Experts
Technical Support
Enable-IT OEM Technical Support is available directly to customers and distributors. All
support requests are processed through the online support portal. This allows us to provide
assigned support ticket numbers in order to bring closure to any technical issues.
Online Technical Services
The Enable-IT Support Portal is available 24/7. No password or user account is necessary.
Please use this support website as your first source for help as it contains an on line
knowledge base of articles, documentation, FAQ's and other problem-solving resources. This
web-based support resource provides the quickest solution to the most common technical
support issues.
http://support.enableit.com
ENABLE-IT LIMITED WARRANTY
Enable-IT warrants the Enable-IT 864 Mini Extended Ethernet DSLAM Kits solely pursuant
to the following terms and conditions.
1. PRODUCT WARRANTY
a. Express Warranty Enable-IT warrants to the original purchaser of the Product ("you" or the "End
User") that, for the four (4) year period commencing on the date the Product was purchased (the
"Warranty Period"), the Product will be substantially free from defects in materials and workmanship
under normal use and conditions. This warranty does not apply to Products which are resold as
used, repaired or reconditioned or consumables (such as batteries) supplied with the Product.
Electrical damage is not an item that is covered under this warranty or extended warranties.
Enable-IT does not make any warranty with respect to any third party product, software or accessory
supplied with or used in connection with the Product and such third party products, software and
accessories, if any, are provided "AS IS." Warranty claims related to such third party products,
software and accessories must be made to the applicable third party manufacturer.
