Operating Instructions
FieldGate SWG50
Functional WirelessHART Gateway
BA02235S/04/EN/01.22-00
71574495
2022-03-31

FieldGate SWG50 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ........... 4
1.1 Document function ................... 4
1.2 Symbols ............................ 4
1.3 Documentation ...................... 5
1.4 Registered trademarks ................ 5
2 Basic safety instructions ....... 5
2.1 Requirements for the personnel ........ 5
2.2 Designated use ...................... 5
2.3 Workplace safety .................... 6
2.4 Operational safety ................... 6
2.5 Product safety ....................... 6
2.6 IT security .......................... 6
3 Product description ............. 7
3.1 Product design ....................... 9
4 Incoming acceptance and
product identification ......... 10
4.1 Incoming acceptance ................ 10
4.2 Product identification ................ 10
4.3 Storage and transport ............... 11
5 Mounting ...................... 11
5.1 Mounting requirements .............. 11
5.2 Mounting the device ................ 11
5.3 Post-mounting check ................ 14
6 Electrical connection .......... 14
6.1 Connecting requirements ............ 14
6.2 Connecting the device ............... 15
6.3 Special connection instructions ........ 16
6.4 Post-connection check ............... 16
7 Operation options ............. 16
7.1 Overview of operation options ........ 16
8 System integration ............ 27
8.1 Modbus TCP ....................... 27
8.2 HART IP ........................... 35
9 Commissioning ................ 36
9.1 Function check ..................... 36
9.2 Configuring the device ............... 36
9.3 Login ............................. 37
10 Diagnostics and
troubleshooting ............... 39
10.1 General troubleshooting ............. 39
10.2 Diagnostic information via light
emitting diodes ..................... 39
10.3 Diagnostic information in web
browser ........................... 40
10.4 Event logbook ...................... 40
10.5 Resetting the device ................. 40
11 Maintenance .................. 41
11.1 Firmware update ................... 41
11.2 Utilities ........................... 42
11.3 Reboot ............................ 42
12 Repair .......................... 43
12.1 General information ................. 43
12.2 Spare parts ........................ 43
12.3 Return ............................ 43
12.4 Disposal ........................... 43
13 Accessories .................... 43
14 Technical data ................. 44

About this document FieldGate SWG50
4 Endress+Hauser
1 About this document
1.1 Document function
These Operating Instructions contain all the information required in the various life cycle
phases of the device: from product identification, incoming acceptance and storage, to
installation, connection, operation and commissioning, through to troubleshooting,
maintenance and disposal.
1.2 Symbols
1.2.1 Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2.2 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
A
Reference to page
Reference to graphic

FieldGate SWG50 Basic safety instructions
Endress+Hauser 5
Symbol Meaning
Notice or individual step to be observed
1.
,
2.
,
3.
… Series of steps
Result of a step
Help in the event of a problem
Visual inspection
1.3 Documentation
FieldGate SWG50 Technical Information TI01677S/04/EN
1.4 Registered trademarks
HART®, WirelessHART® is the registered trademark of the FieldComm Group, Austin, TX
78759, USA.
All other brand and product names are trademarks or registered trademarks of the companies
and organizations in question.
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the application).
‣Follow instructions and comply with basic conditions.
The operating personnel must fulfill the following requirements:
‣Are instructed and authorized according to the requirements of the task by the facility's
owner-operator.
‣Follow the instructions in this manual.
2.2 Designated use
FieldGate SWG50 is a gateway for WirelessHART networks. It enables WirelessHART field
devices to communicate with each another and manages network security and connectivity.
The FieldGate SWG50 converts and stores data from wireless field devices in a format that is

Basic safety instructions FieldGate SWG50
6 Endress+Hauser
compatible with other systems. It has Ethernet interfaces for connecting to host applications
such as SCADA tools.
Incorrect use
Non-designated use can compromise safety. The manufacturer is not liable for damage caused
by using the device incorrectly or for purposes for which it was not intended.
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
If working on and with the device with wet hands:
‣Due to the increased risk of electric shock, gloves must be worn.
2.4 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with Endress+Hauser.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from Endress+Hauser only.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet state-
of-the-art safety requirements, has been tested, and left the factory in a condition in which it
is safe to operate.
It meets general safety standards and legal requirements. It also complies with the EU
directives listed in the device-specific EU Declaration of Conformity. The manufacturer
confirms this by affixing the CE mark.
2.6 IT security
Our warranty is valid only if the product is installed and used as described in the Operating
Instructions. The product is equipped with security mechanisms to protect it against any
inadvertent changes to the settings.

FieldGate SWG50 Product description
Endress+Hauser 7
IT security measures, which provide additional protection for the product and associated data
transfer, must be implemented by the operators themselves in line with their security
standards.
3 Product description
The FieldGate SWG50 is a functional WirelessHART gateway. It comprises a network manager
application, a WirelessHART (access point) interface module and a gateway application. Up to
100 wireless or wired devices with WirelesssHART adapter can be connected to the FieldGate
SWG50. The application supplies data from the WirelessHART network via Modbus TCP or
HART-IP. A CommDTM makes it possible to configure the field devices or adapters connected
to the WirelessHART network via their device DTMs.

Product description FieldGate SWG50
8 Endress+Hauser
5
6
1
2
3
4
A0048889
 1 FieldGate SWG50
1 Antenna connection
2 Reset button
3 4-port Ethernet switch (RJ45)
4 LEDs
5 Connector for power supply
6 Ground connection

FieldGate SWG50 Product description
Endress+Hauser 9
3.1 Product design
2567 9
Netilion
8
3 4
11
6
1
WirelessHART
12 10
A0048719
 2 Example of WirelessHART network architecture with FieldGate SWG50
1 Endress+Hauser Field Xpert, e.g. SMTxx
2 Host application / FieldCare SFE500
3 Ethernet communication
4 FieldGate SWG50
5 FieldEdge SGC500
6 https Internet connection
7 Netilion Cloud
8 Application Programming Interface (API)
9 Browser-based Netilion Service app or user application
10 WirelessHART adapter SWA70 used as a repeater
11 HART field device with WirelessHART adapter SWA70
12 Encrypted wireless connection via WirelessHART

Incoming acceptance and product identification FieldGate SWG50
10 Endress+Hauser
4 Incoming acceptance and product identification
4.1 Incoming acceptance
Visual inspection
• Check the packaging for visible damage arising from transportation
• Open the packaging carefully
• Check the contents for visible damage
• Check that the delivery is complete and nothing is missing
• Retain all the accompanying documents
The device may not be put into operation if the contents are found to be damaged
beforehand. In this case, please contact your Endress+Hauser Sales Center:
www.addresses.endress.com
Return the device to Endress+Hauser in the original packaging where possible.
Scope of delivery
• FieldGate SWG50
• Operating Instructions with Safety Instructions
4.2 Product identification
4.2.1 Nameplate
 3 Phoenix Contact nameplate

FieldGate SWG50 Mounting
Endress+Hauser 11
 4 Endress+Hauser nameplate
4.2.2 Manufacturer's address
PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstraße 8
32825 Blomberg
Germany
www.phoenixcontact.com
4.3 Storage and transport
Always use the original packaging when transporting the product.
4.3.1 Storage temperature
–40 to 85 °C
5 Mounting
5.1 Mounting requirements
The device must be installed in a housing that has a minimum protection rating of IP54 as per
EN/IEC 60079-15. The device must be used only in areas with a maximum pollution degree of
2, as defined in EN/IEC 60664-1. The device can be installed in Zone 2 hazardous areas.
Routing and remote installation of the antenna must comply with the relevant site regulations
when installed in unclassified Zone 2 or Class I, Division 2 hazardous areas. Otherwise, the
antenna must be installed within the end-use housing.
A remote antenna can be mounted outside a cabinet. If there is a risk of lightning, install
lightning/EMP protection between the gateway and the remote antenna.
5.2 Mounting the device
The FieldGate SWG50 is mounted on an NS 35 mounting rail. To prevent the device from
slipping, end clamps must be mounted on both sides. The device can be mounted either
horizontally or vertically. The modules are mounted on the mounting rail from left to right.

Mounting FieldGate SWG50
12 Endress+Hauser
A0048928
 5 Mounting on a standard DIN rail

FieldGate SWG50 Mounting
Endress+Hauser 13
Mounting the device
1.
A0048933

Electrical connection FieldGate SWG50
14 Endress+Hauser
Position the keyway on the mounting rail.
2. Push the device back until it locks into place.
3. Ground the mounting rail.
5.3 Post-mounting check
Is the device properly attached to the mounting rail?
6 Electrical connection
6.1 Connecting requirements
6.1.1 Power supply
Connect a regulated class 2 DC power source to the gateway. The supply voltage can be from
10.8 to 30 VDC, with a recommended nominal voltage of either 12 VDC or 24 VDC. The power
supply must be able to supply 290 mA current at 24 VDC. External connecting cables must be
used in accordance with NEC, ANSI/NFPA70 (for US applications) and Canadian Electrical
Code, Part 1, CSA C22.1 (for Canadian applications) or in accordance with local country codes
for all other countries.
The control cabinet or switch box must meet the specifications of EN 60950-1: 2001 for fire
enclosures.
The power supply to the device must meet the following requirements:
• Class 2 circuit in accordance with National Electrical Code, NFPA-70 and Canadian
Electrical
• Limited Power Supply (LPS) as per EN/IEC 60950-1 or EN/IEC 62368-1
• Limited-energy circuits EN/IEC 61010-1
6.1.2 Ethernet
The FieldGate SWG50 has an Ethernet interface (RJ45) on the front for connecting a twisted-
pair cable with an impedance of 100 Ω. Data transmission is 10, 100 or 1 000 Mbit/s. Slide
the Ethernet cable with the RJ45 connector into the device until it locks into place. When two,
three or four Ethernet ports are used, the FieldGate SWG50 is classified as a switch. If only
one port is used, it is a straightforward end-node device. The maximum number of linked
gateways and the maximum distance between the units are based on the Ethernet standards
and are determined by the environment and the compliance of the network with the standard.

FieldGate SWG50 Electrical connection
Endress+Hauser 15
6.2 Connecting the device
3
1
2
A0050154
1 Antenna
2 Ethernet
3 Power supply
Power supply
P1 10.8 to 30 VDC
P2 10.8 to 30 VDC

Operation options FieldGate SWG50
16 Endress+Hauser
6.3 Special connection instructions
6.3.1 Antenna
The device is equipped with an RSMA antenna socket for connecting an external antenna.
Install the antenna outside the cabinet or building. The maximum permitted HF line as per
federal, state and local regulations must be observed. Use antenna and cables that are
recommended by the manufacturer.
6.4 Post-connection check
• Are the device and cable undamaged (visual check)?
• Do the cables used comply with the requirements?
• Is the terminal assignment correct?
• Have the cables been connected in such a way that no wires, insulation and / or cable
shields are jammed?
• Is the supply voltage correct?
• Is the FieldPort SWG50 grounded, if necessary?
7 Operation options
The FieldGate SWG50 has an integrated web server with which the WirelessHART network is
configured.
 6 Start screen
1 Navigation bar
2 Page name
7.1 Overview of operation options
7.1.1 Overview of start screen
After login, the start screen appears with basic information about the FieldGate SWG50.

FieldGate SWG50 Operation options
Endress+Hauser 17
 7 Gateway information
Field Description
Name Information about the gateway and location.
Contact Person responsible for operating the device.
Long Tag Identification of device in the WirelessHART network, can be identical to the Name field.
Message Notification about the device or network.
Time Internal device time.
Data Internal device date.
Uptime Length of time device is in operation since last power-up.
Device Status Current operating status of device and error messages.
7.1.2 Overview of general information
‣In the Navigation menu, click Gateway Information -> General.
 The General Information dialog box appears.
Field Description
LAN IP Address IP address uniquely identifies this device with the LAN.
LAN Subnet Mask IP subnet mask for this device in the LAN.
LAN Default Gateway IP address of default gateway.
LAN MAC Adresse Media Access Control (MAC) address of LAN network card.

Operation options FieldGate SWG50
18 Endress+Hauser
Field Description
WirelessHART AP MAC-Address Media Access Control (MAC) address of WirelessHART interface module.
Firmware Version Software version in device
Hardware Version Device version
7.1.3 Overview of basic configuration
Changing the data displayed on the home screen
1. In the Navigation menu, click Configuration -> General.
 The General Configuration dialog box appears.
2. Make any necessary changes.
3. Click Submit.
The changes are accepted.
• Long Tag: maximum 32 characters (excess characters will be truncated following
restart).
• Message: maximum 32, only capital letters, numbers and certain special characters
Configuring the time manually
1. Make any necessary changes.
2. Click Update System Time.

FieldGate SWG50 Operation options
Endress+Hauser 19
7.1.4 Configuring the WirelessHART profile
1. In the Navigation menu, click Configuration -> WirelessHART -> Gateway Profil.
 The WirelessHART Gateway Profile Configuration dialog box appears.
2. Make changes and click Submit.
 The changes are accepted automatically.
Profile Description Upload Download Commercial traffic
Default Standard WirelessHART frame Standard Standard Standard
25-note Fast
Profile
Faster update, recommended
for time-critical applications.
128 128 128
Legacy Profile For networks consisting of
loop-powered WirelessHART
adapters, to reduce power
consumption.
1024 256 128
Normal Profile - P1 Enables the supply of approx.
4.5 pkt/s through the gateway
into the network.
1024 256 128
Low Power Profile -
P2
Reduces the FieldGate SWG50
to one eighth of downstream
capacity. Battery power may
be saved but the network
setup takes longer and
significantly reduces
application bandwidth
downstream.
1024 2048 128

Operation options FieldGate SWG50
20 Endress+Hauser
7.1.5 Configuring the WirelessHART network
‣In the Navigation menu, click Configuration -> WirelessHART -> Network
Configuration.
 The Network Configuration dialog box appears.
Field Field Description
Network WirelessHART Network ID In hexadecimal or decimal
format, depending on
setting.
Security Hide/Show Join Key Displays or hides the
password.
Accept Common Join Key
Common Join Key (Hex)
Activates general network
password.
General network password
in hexadecimal format (32
characters).
Required Access List Entry
MAC Address
Join Key (Hex)
Enables access via an
external join list in addition
to a network password.
List of MAC addresses of all
permitted devices.
Key in hexadecimal format
(32 characters).
Key generator Automatically generates a
random network password.
Migrate Network Migration of entire device
network. The network ID
and/or network password
of all connected
WirelessHART network
subscribers is migrated.
