Endress+Hauser Levelflex FMP53 Manual

Application
•FMP53 - premium device for the highest hygiene
requirements. ASME BPE and USP Class VI
compliant.
• Measuring range up to 6 m (20 ft)
• Process connections for hygiene applications (Tri-
Clamp, DIN 11864, Ingold fitting, ...)
• Temperature range: –20 to +150 °C (–4 to +302 °F)
• Pressure range: –1 to 16 bar (–14.5 to 232 psi)
• The following interfaces are available for system
integration:
– HART with 4...20 mA analog
– PROFIBUS PA (Profile 3.02)
– FOUNDATION Fieldbus
• Used for level monitoring (MIN, MAX, range) up to
SIL 2 (single device) or SIL 3 (redundancy, even if
homogeneous), independently assessed by TÜV as
per IEC 61508
Your benefits
• Reliable measuring:
– in case of moved surface and foam
– for changing media
– for filling via spray head
• High availablility
• Integrated data memory
• Factory precalibrated to probe length
• Intuitive, menu-guided operating concept in national
languages
• Simple integration into control or asset management
systems
• Exact instrument and process diagnosis to assist fast
decisions
• Approvals: ATEX, IEC Ex, CSA, FM, NEPSI
Sanitary compatibility: CoC (Certificate of
Compliance)
3-A
Technical Information
Levelflex FMP53
Guided Level-Radar
Level measurement in liquids and hygienic applications
TI01002F/00/EN/15.12
71206471

Table of contents Levelflex FMP53
2 Endress+Hauser
Table of contents
Important document information ................ 3
Document conventions ........................... 3
Function and system design .................... 5
Measuring principle ............................. 5
Measuring system .............................. 7
Input ..................................... 8
Measured variable .............................. 8
Measuring range ............................... 8
Blocking distance .............................. 8
Measuring frequency spectrum ...................... 9
Output .................................... 9
Output signal ................................. 9
Signal on alarm ................................ 9
Linearization ................................. 9
Galvanic isolation ............................. 10
Protocol-specific data ........................... 10
Auxiliary energy ........................... 14
Electrical connection ........................... 14
Supply voltage ............................... 19
Terminals .................................. 20
Cable entries ................................ 20
Cable specification ............................. 20
Device plug connectors .......................... 21
Power consumption ............................ 21
Current consumption ........................... 21
Power supply failure ............................ 22
Maximum load ............................... 22
Potential equalization ........................... 23
Overvoltage protection .......................... 24
Performance characteristics ................... 24
Reference operating conditions ..................... 24
Maximum measured error ........................ 24
Resolution .................................. 25
Reaction time ................................ 26
Influence of ambient temperature ................... 26
Operating conditions: Installation .............. 26
Suitable mounting position ........................ 26
Applications with restricted mounting space ............. 27
Notes on the mechanical load of the probe .............. 28
Special mounting conditions ....................... 29
Operating conditions: Environment ............. 33
Ambient temperature range ....................... 33
Ambient temperature limits ....................... 33
Storage temperature ............................ 35
Climate class ................................ 35
Geometric height ............................. 35
Degree of protection ............................ 35
Vibration resistance ............................ 35
Cleaning the probe ............................ 35
Electromagnetic compatibility (EMC) ................. 35
Operating conditions: Process ................. 36
Process temperature range ........................ 36
Process pressure limits .......................... 36
Materials in contact with process .................... 36
Dielectric constant (DC) ......................... 37
Mechanical construction ..................... 38
Design, dimensions ............................ 38
Tolerance of probe length ........................ 43
Weight .................................... 44
Materials ................................... 44
Operating options .......................... 46
Overview .................................. 46
The operating menu ............................ 50
Display and operating module ...................... 53
Certificates and approvals .................... 55
CE mark ................................... 55
C-Tick symbol ............................... 55
Ex approval ................................. 55
Functional Safety .............................. 55
Sanitary compatibility ........................... 55
Pharma (CoC) ............................... 55
AD2000 ................................... 55
Telecommunications ........................... 55
Track record ................................ 55
Other standards and guidelines ..................... 55
Ordering information ........................ 56
Compact device Levelflex ........................ 56
Product structure FMP53 ........................ 56
Accessories ............................... 62
Device-specific accessories ........................ 62
Communication-specific accessories .................. 64
Service-specific accessories ........................ 65
System components ............................ 66
Documentation ............................ 66
Standard documentation ......................... 66
Supplementary documentation ..................... 66
Certificates ................................. 67
Registered trademarks ....................... 68
Patents .................................. 68

Levelflex FMP53
Endress+Hauser 3
Important document information
Document conventions Safety symbols
Symbol Meaning
DANGER
A0011189-EN
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious
or fatal injury.
WARNING
A0011190-EN
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious
or fatal injury.
CAUTION
A0011191-EN
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor
or medium injury.
NOTICE
A0011192-EN
NOTICE!
This symbol contains information on procedures and other facts which do not result in personal
injury.
Electrical symbols
Symbol Meaning
A0011197
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
A0011198
Alternating current
A terminal to which alternating voltage is applied or through which alternating current flows.
A0017381
Direct current and alternating current
•A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
A0011200
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.
A0011199
Protective ground connection
A terminal which must be connected to ground prior to establishing any other connections.
A0011201
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a potential
equalization line or a star grounding system depending on national or company codes of practice.
Symbols for certain types of information
Symbol Meaning
A0011182
Allowed
Indicates procedures, processes or actions that are allowed.
A0011183
Preferred
Indicates procedures, processes or actions that are preferred.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0011194
Reference to documentation
Refers to the corresponding device documentation.

Levelflex FMP53
4 Endress+Hauser
Symbol Meaning
A0011195
Reference to page
Refers to the corresponding page number.
A0011196
Reference to graphic
Refers to the corresponding graphic number and page number.
Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
,… ,
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
-
A0011187
Hazardous area
Indicates a hazardous area.
.
A0011188
Safe area (non-hazardous area)
Indicates a non-hazardous location.
Symbols at the device
Symbol Meaning
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables.

Levelflex FMP53
Endress+Hauser 5
Function and system design
Measuring principle Level measurement
The Levelflex is a "downward-looking" measuring system that functions according to the ToF method (ToF =
Time of Flight). The distance from the reference point to the product surface is measured. High-frequency
pulses are injected to a probe and led along the probe. The pulses are reflected by the product surface,
received by the electronic evaluation unit and converted into level information. This method is also known
as TDR (Time Domain Reflectometry).
F
L
DE
100%
0%
LN
R
A0014124
LN = probe length R = reference point of measurement
D = distace E = empty calibration (= zero)
L = level F = full calibration (= span)
If, for rope probes, the DC value is less than 7, then measurement is not possible in the area of the
straining weight (0 to 250 mm from end of probe; lower blocking distance).
Dielectric constant
The dielectric constant (DC) of the medium has a direct impact on the degree of reflection of the
highfrequency pulses. In the case of large DC values, such as for water or ammonia, there is strong pulse
reflection while, with low DC values, such as for hydrocarbons, weak pulse reflection is experienced.
Input
The reflected pulses are transmitted from the probe to the electronics. There, a microprocessor analyzes the
signals and identifies the level echo which was generated by the reflection of the high-frequency pulses at
the product surface. This clear signal detection system benefits from over 30 years' experience with pulse
time-of-flight procedures that have been integrated into the development of the PulseMaster® software.
The distance D to the product surface is proportional to the time of flight t of the impulse:
D = c · t/2,
where c is the speed of light.
Based on the known empty distance E, the level L is calculated:
L = E – D
The reference point R of the measurement is located at the process connection. For details see the
dimensional drawing:
FMP53: (® ä 43)
The Levelflex possesses functions for interference echo suppression that can be activated by the user. They
guarantee that interference echoes from e.g. internals and struts are not interpreted as level echoes.

Levelflex FMP53
6 Endress+Hauser
Output
The Levelflex is preset at the factory to the probe length ordered so that in most cases only the application
parameters that automatically adapt the device to the measuring conditions need to be entered. For models
with a current output, the factory adjustment for zero point E and span F is 4 mA and 20 mA, for digital
outputs and the display module 0 % and 100 %. A linearization function with max. 32 points, which is based
on a table entered manually or semi-automatically, can be activated on site or via remote operation. This
function allows the level to be converted into units of volume or mass, for example.
Life cycle of the product
Engineering Procurement Installation Commissioning Operation Maintenance Retirement
A0013773-EN
Engineering
•Universal measuring principle
• Measurement unaffected by medium properties
• Hardware and software developed according to SIL IEC 61508
• Genuine, direct interface measurement
Procurement
• Endress+Hauser being the world market leader in level measurement guarantees asset protection
• Worldwide support and service
Installation
• Special tools are not required
• Reverse polarity protection
• Modern, detachable terminals
• Main electronics protected by a separate connection compartment
Commissioning
• Fast, menu-guided commissioning in only 6 steps
• Plain text display in national languages reduces the risk of error or confusion
• Direct local access of all parameters
• Short instruction manual at the device
Operation
• Multi-echo tracking: Reliable measurement through self-learning echo-search algorithms taking into
account the short-term and long-term history in order to check the found echoes for plausibility and to
suppress interference echoes.
• Diagnostics in accordance with NAMUR NE107
Maintenance
• HistoROM: Data backup for instrument settings and measured values
• Exact instrument and process diagnosis to assist fast decisions with clear details concerning remedies
• Intuitive, menu-guided operating concept in national languages saves costs for training, maintenance and
operation
• Cover of the electronics compartment can be opened in hazardous areas
Retirement
• Order code translation for subsequent models
• RoHS-conforming (Restriction of certain Hazardous Substances), unleaded soldering of electronic
components
• Environmentally sound recycling concept

Levelflex FMP53
Endress+Hauser 7
Measuring system Probe selection
The various types of probe in combination with the process connections are suitable for the following
applications:
Levelflex FMP53
Type of probe Rod probe
A0013673
Feature 060 - Probe: Option:
DA 8 mm (316L), Ra<0.76mm/30mm
DB 0.31 in (316L), Ra<0.76mm/30mm
EA 8 mm (316L), ep=electro-polished, Ra<0.38mm/15mm
EB 0.31 in (316L), ep=electro-polished, Ra<0.38mm/15mm
FA 8 mm (316L), 500 mm divisible, Ra<0.76mm/30mm
FB 0.31 in (316L), 20 in divisible, Ra<0.76mm/30mm
GA 8 mm (316L), 500 mm divisible, ep=electro-polished, Ra<0.38mm/15mm
GB 0.31 in (316L), 20 in divisible, ep=electro-polished, Ra<0.38mm/15mm
HA 8 mm (316L), 1000 mm divisible, Ra<0.76mm/30mm
HB 0.31 in (316L), 40 in divisible, Ra<0.76mm/30mm
IA 8 mm (316L), 1000 mm divisible, ep=electro-polished, Ra<0.76mm/30mm
IB 0.31 in (316L), 40 in divisible, ep=electro-polished, Ra<0.76mm/30mm
Max. probe length 6 m (20 ft)
For application level measurement in liquids
Option Reference probe can be connected
Calibration kit FMP53 - order number: 71041382(® ä 64)
If required, the rod probes can be replaced. They are secured with a thread coating.
For further information on service and spare parts please contact the Endress+Hauser service.

Levelflex FMP53
8 Endress+Hauser
Input
Measured variable The measured variable is the distance between the reference point and the product surface.
Subject to the empty distance entered "E" the level is calculated.
Alternatively, the level can be converted into other variables (volume, mass) by means of linearization (32
points).
Measuring range The following table describes the media groups and the possible measuring range as a function of the media
group.
Levelflex FMP53
Media group DC (er)Typical liquids
Measuring range
rod probes 1)
1 1.4...1.6 condensed gases, e.g. N2, CO2on request
2 1.6...1.9 • liquefied gas, e.g. propane
•solvent
• Freon
• palm oil
4/6 m (13/20 ft)
3 1.9...2.5 mineral oils, fuels 4/6 m (13/20 ft)
4 2.5...4 • benzene, styrene, toluene
• furan
• naphthalene
4/6 m (13/20 ft)
5 4...7 • chlorobenzene, chloroform
• cellulose spray
• isocyanate, aniline
4/6 m (13/20 ft)
6 > 7 • aqueous solutions
• alcohols
• acids, alkalis
4/6 m (13/20 ft)
1) not divisible up to 4 m (13 ft), divisible up to 6 m (20 ft)
Reduction of the max. possible measuring range through buildup, above all of moist products.
Blocking distance The upper blocking distance (= UB) is the minimum distance from the reference point of the measurement
(mounting flange) to the maximum level.
F
UB
E
100%
0%
LN
RSD
A0011279
R = reference point of measurement E = empty calibration (= zero)
LN = probe length F = full calibration (= span)
UB = upper blocking distance SD = safety distance

Levelflex FMP53
Endress+Hauser 9
Blocking distance (factory setting):
with rod probes up to 6 m (20 ft): 200 mm (8 in)
The specified blocking distances are preset on delivery. Depending on the application these settings can
be changed.
When using a spray ball, the blocking distance must be at least 50 mm (2").
For rod and rope probes and for media with DC > 7 (or generally for stilling well/bypass applications)
the blocking distance may be reduced to 100 mm (4").
Within the blocking distance, a reliable measurement can not be guaranteed.
A safety distance SD can be defined in addition to the blocking distance. A warning is generated if the
level rises into this safety distance.
Measuring frequency
spectrum
100 MHz to 1.5 GHz
Output
Output signal HART
Signal coding FSK ±0.5 mA over currency signal
Data transmission rate 1200 Baud
Galvanic isolation Yes
PROFIBUS PA
Signal coding Manchester Bus Powered (MBP)
Data transmission rate 31,25 KBit/s, voltage mode
Galvanic isolation Yes
FOUNDATION Fieldbus
Signal coding Manchester Bus Powered (MBP)
Data transmission rate 31,25 KBit/s, voltage mode
Galvanic isolation Yes
Signal on alarm Depending on the interface, failure information is displayed as follows:
•Current output (for HART devices)
– Failsafe mode selectable (in accordance with NAMUR Recommendation NE 43):
Minimum alarm: 3.6 mA
Maximum alarm (= factory setting): 22 mA
– Failsafe mode with user-selectable value: 3.59 to 22.5 mA
• Local display
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
• Operating tool via digital communication (HART, PROFIBUS PA, FOUNDATION Fieldbus) or service
interface (CDI)
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
Linearization The linearization function of the device allows the conversion of the measured value into any unit of length
or volume. Linearization tables for calculating the volume in cylindrical tanks are pre-programmed. Other
tables of up to 32 value pairs can be entered manually or semi-automatically.

Levelflex FMP53
10 Endress+Hauser
Galvanic isolation All circuits for the outputs are galvanically isolated from each other.
Protocol-specific data HART
Manufacturer ID 17 (0x11)
Device type ID 0x34
HART specification 6.0
Device description files (DTM,
DD)
Information and files under:
•www.endress.com
•www.hartcomm.org
HART load Min. 250 W
HART device variables The measured values can be freely assigned to the device variables.
Measured values for PV (primary variable)
•Level linearized
• Distance
• Electronic temperature
• Relative echo amplitude
Measured values for SV, TV, FV (second, third and fourth variable)
• Level linearized
• Distance
• Terminal voltage
• Electronic temperature
• Absolute echo amplitude
• Relative echo amplitude
• Calculated DC
Supported functions • Burst mode
• Additional transmitter status
PROFIBUS PA
Manufacturer ID 17 (0x11)
Ident number 0x1558
Profile version 3.02
GSD file Information and files under:
•www.endress.com
•www.profibus.org
GSD file version
Output values Analog Input:
•Level linearized
• Distance
• Terminal voltage
• Electronic temperature
• Absolute echo amplitude
• Relative echo amplitude
• Calculated DC
Digital Input:
• Extended diagnostic blocks 1)
• Status output PFS Block

Levelflex FMP53
Endress+Hauser 11
Input values Analog Output:
•Analog value from PLC (for sensor block external pressure and temperature)
• Analog value from PLC to be indicated on the display
Digital Output:
• Extended diagnostic block 1)
• Level limiter
• Sensor block measurement on
• Sensor block save history on
• Status output
Supported functions • Identification & Maintenance
Simple device identification via control system and nameplate
• Automatic Ident Number Adoption
GSD compatibility mode with respect to the previous device Levelflex M FMP4x
• Physical Layer Diagnostics
Installation check of the PROFIBUS segment and the Levfelflex FMP4x via
terminal voltage and telegram monitoring
• PROFIBUS Up-/Download
Up to 10 times faster reading and writing of parameters via PROFIBUS Up-/
Download
• Condensed Status
Simple and self-explanatory diagnostic information due to categorization of
diagnostic messages
1) in preparation
FOUNDATION Fieldbus
Manufacturer ID 452B48 hex
Device type 1022 hex
Device Revision 02 hex
DD Revision Information and files can be found:
•www.endress.com
•www.fieldbus.org
CFF Revision
Device Tester Version (ITK
Version)
6.01
ITK Test Campaign Number IT080500
Link Master (LAS) capable yes
Link Master / Basic Device
selectable
yes; default: Basic Device
Node address Default: 247 (0xF7)
Features supported Following methods are supported:
•Restart
• ENP Restart
• Setup
• Linearization
• Self Check
Virtual Communication Relationships (VCRs)
Number of VCRs 44
Number of Link Objects in VFD 50
Permanent entries 1
Client VCRs 0
Server VCRs 10
Source VCRs 43
Sink VCRs 0
Subscriber VCRs 43
Publisher VCRs 43

Levelflex FMP53
12 Endress+Hauser
Device Link Capabilities
Slot time 4
Min. inter PDU delay 8
Max. response delay 20
Transducer Blocks
Block Content Output values
Setup Transducer Block Contains all parameters for a standard commissioning
procedure
• Level or volume 1)
(Channel 1)
•Distance (Channel 2)
Advanced Setup Transducer
Block
Contains all parameters for a more detailed configuration
of the device
no output values
Display Transducer Block Contains all parameters for the configuration of the
display module
no output values
Diagnostic Transducer Block Contains diagnostic information no output values
Expert Configuration
Transducer Block
Contains parameters which require detailed knowledge
of the functionalities of the device
no output values
Expert Information
Transducer Block
Contains information about the state of the device no output values
Service Sensor Transducer
Block
Contains parameters which can only be operated by
Endress+Hauser service personnel
no output values
Service Information
Transducer Block
Contains information on the state of device which is
relevant for service operations
no output values
Data Transfer Transducer
Block
Contains parameters which allow to backup the device
configuration in the display module and to restore it into
the device.
no output values
1) depending on the configuration of the block
Function Blocks
Block Content Number of
permanent
blocks
Number of
instantiable
blocks
Execution
time
Functionality
Resource Block The Resource Block contains all the data
that uniquely identifies the field device.
It is an electronic version of a nameplate
of the device.
1 0 - enhanced
Analog Input
Block
The AI block takes the manufacturer's
input data, selected by channel number,
and makes it available to other function
blocks at its output.
2 3 25 ms enhanced
Discrete Input
Block
The DI block takes a discrete input value
(e.g. indication of an level limit), and
makes it available to other function
blocks at its output.
1 2 20 ms standard
PID Block The PID block serves as proportional-
integralderivative controller and is used
almost universally to do closed-loop-
control in the field including cascade and
feedforward.
1 1 25 ms standard
Arithmetic
Block
This block is designed to permit simple
use of popular measurement math
functions. The user does not have to
know how to write equations. The math
algorithm is selected by name, chosen by
the user for the function to be done.
1 1 25 ms standard

Levelflex FMP53
Endress+Hauser 13
Block Content Number of
permanent
blocks
Number of
instantiable
blocks
Execution
time
Functionality
Signal
Characterizer
Block
The signal characterizer block has two
sections, each with an output that is a
non-linear function of the respective
input. The non-linear function is
determined by a single look-up table
with 21 arbitrary x-y pairs.
1 1 25 ms standard
Input Selector
Block
The input selector block provides
selection of up to four inputs and
generates an output based on the
configured action. This block normally
receives its inputs from AI blocks. The
block performs maximum, minimum,
middle, average and ‘first good’ signal
selection.
1 1 25 ms standard
Integrator
Block
The Integrator Function Block integrates
a variable as a function of the time or
accumulates the counts from a Pulse
Input block. The block may be used as a
totalizer that counts up until reset or as a
batch totalizer that has a setpoint, where
the integrated or accumulated value is
compared to pre-trip and trip settings,
generating discrete signals when these
settings are reached.
1 1 25 ms standard
Analog Alarm
Block
1 1 25 ms standard
Up to 20 blocks can be instantiated in the device altogether, including the blocks already instantiated
on delivery.

Levelflex FMP53
14 Endress+Hauser
Auxiliary energy
Electrical connection 2 wire, 4-20 mA HART
+
–
4...20 mA
4...20 mA
5
5
4
4
1
1
2
2
8
9
3
3
+
+
–
–
1
+
2
4...20mA
HART
10 mm
Spare part
71108xxx
2- wire level
4-20 mA 4-20 mA
HART
[21]
open
-
1
+2
4-20mA
1-channel overvoltage protection
-
71128617
[16]
A
+
–
7
B
6
A0011294
å 1 Terminal assignment 2-wire; 4-20mA HART
A Without integrated overvoltage protection
B With integrated overvoltage protection
1Active barrier with power supply (e.g. RN221N): Observe terminal voltage (® ä 19)
2HART communication resistor (³250 W): Observe maximum load (® ä 22)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 22)
5Cable screen; observe cable specification (® ä 20)
6 Terminals for 4-20mA HART (passive)
7 Overvoltage protection module
8 Terminal for potential equalization line
9 Cable entry

Levelflex FMP53
Endress+Hauser 15
2 wire, 4-20 mA HART, 4-20mA
1
3
+
+2
4
4...20mA
HART
4...20mA
10 mm
Spare part
71108xxx
2- wire level
4-20 mA 4-20 mA
HART
[04/05]
open
-
-
11
A
1
3+
+2
4
4-20mA/
FIELDBUS
4-20mA/
2-channel overvoltage protection
-
-
71128619
[17]
14
13
12
+
+
+
+
+
-
-
-
-
1
1
2
2
3
3
9
9
5
5
8
8
6
6
7
7
4
4
+
+
–
–
+
+
–
–
4...20 mA
4...20 mA
10
B
4...20 mA
4...20 mA
A0013923
å 2 Terminal assignment 2-wire; 4-20mA HART, switch output
A Without integrated overvoltage protection
B With integrated overvoltage protection
1 Connection current output 2
2 Connection current output 1
3Supply voltage for current output 1 (e.g. RN221N); Observe terminal voltage (® ä 19)
4Cable screen; observe cable specification (® ä 20)
5HART communication resistor (³ 250 W): Observe maximum load (® ä 22)
6 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
7Analog display device ; observe maximum load (® ä 22)
8Analog display device ; observe maximum load (® ä 22)
9Supply voltage for current output 2 (e.g. RN221N); Obesrve terminal voltage (® ä 19)
10 Overvoltage protection module
11 Terminals for current output 2
12 Terminal for the potential equalization line
13 Cable entry for current output 1
14 Cable entry for current output 2
This version is also suited for single-channel operation. In this case, current output 1 (terminals 1 and
2) must be used.

Levelflex FMP53
16 Endress+Hauser
4 wire: 4-20mA HART (10.4 to 48 VDC)
3
1+
L+ 4
2
4...20 mA
HART
10.4...48 V=
10 mm
Spare part
71108xxx
2- wire
4-20 mA
HART
[08]open
-
L-
A
13
12
11
910
+
-
2 3 4
6
7
8
5
1
4...20 mA
³ W250
A0011340
å 3 Terminal assignment 4-wire; 4-20mA HART (10.4 to 48 VDC)
1 Evaluation unit, e.g. PLC
2HART communication resistor (³250 W): Observe maximum load (® ä 22)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 22)
5Signal cable including screening (if required), observe cable specification (® ä 20)
6 Protective connection; do not disconnect!
7Protective earth, observe cable specification (® ä 20)
8 Terminals for 4...20mA HART (active)
9 Terminals for supply voltage
10 Supply voltage: Observe terminal voltage(® ä 19), observe cable specification (® ä 20)
11 Terminal for potential equalization
12 Cable entry for signal line
13 Cable entry for power supply
!CAUTION
To ensure electrical safety:
►Do not disconnect the protective connection (7).
►Disconnect the supply voltage before disconnecting the protective earth (8).
Connect protective earth to the internal ground terminal (8) before connecting the supply voltage. If
necessary, connect the potential matching line to the external ground terminal (12).
In order to ensure electromagnetic compatibility (EMC): Do not only ground the device via the
protective earth conductor of the supply cable. Instead, the functional grounding must also be
connected to the process connection (flange or threaded connection) or to the external ground
terminal.
An easily accessible power switch must be installed in the proximity of the device. The power switch
must be marked as a disconnector for the device (IEC/EN61010).

Levelflex FMP53
Endress+Hauser 17
4 wire: 4-20mA HART (90 to 253 VAC)
3
1+
L4
2
4...20 mA
HART
90...253 V~
10 mm
Spare part
71108xxx
2- wire
4-20 mA
HART
[09]open
-
N
A
13
12
11
910
+
-
2 3 4
6
7
8
5
1
4...20 mA
³ W250
A0018965
å 4 Terminal assignment 4-wire; 4-20mA HART (90 to 253 VAC)
1 Evaluation unit, e.g. PLC
2HART communication resistor (³250 W): Observe maximum load (® ä 22)
3 Connection for Commubox FXA195 or FieldXpert SFX100 (via VIATOR Bluetooth modem)
4Analog display device: Observe maximum load (® ä 22)
5Signal cable including screening (if required), observe cable specification (® ä 20)
6 Protective connection; do not disconnect!
7Protective earth, observe cable specification (® ä 20)
8 Terminals for 4...20mA HART (active)
9 Terminals for supply voltage
10 Supply voltage: Observe terminal voltage (® ä 19), observe cable specification (® ä 20)
11 Terminal for potential equalization
12 Cable entry for signal line
13 Cable entry for power supply
!CAUTION
To ensure electrical safety:
►Do not disconnect the protective connection (7).
►Disconnect the supply voltage before disconnecting the protective earth (8).
Connect protective earth to the internal ground terminal (8) before connecting the supply voltage. If
necessary, connect the potential matching line to the external ground terminal (12).
In order to ensure electromagnetic compatibility (EMC): Do not only ground the device via the
protective earth conductor of the supply cable. Instead, the functional grounding must also be
connected to the process connection (flange or threaded connection) or to the external ground
terminal.
An easily accessible power switch must be installed in the proximity of the device. The power switch
must be marked as a disconnector for the device (IEC/EN61010).

Levelflex FMP53
18 Endress+Hauser
PROFIBUS PA / FOUNDATION Fieldbus
1
3+
+2
4
FIELDBUS
2-channel overvoltage protection
-
-
71128619
[17]
4-20mA/
4-20mA/
B
1
1+
+2
2
FIELDBUS
Spare part
71023457
PA/FF
[06/07]
FIELDBUS
-
-1
3+
+2
4
PA/FF
10 mm
Spare part
71108xxx
2- wire level
4-20 mA PFS
FIELDBUS
[26/27] open
-
-
A
4
1
1
2
3
6
5
3+
3+
4-
4-
A0011341
å 5 Terminal assignment PROFIBUS PA / FOUNDATION Fieldbus
A Without integrated overvoltage protection
B With integrated overvoltage protection
1Cable screen: Observe cable specifications (® ä 20)
2 Terminals for switch output (open collector)
3 Terminals PROFIBUS PA / FOUNDATION Fieldbus
4 Terminal for potential equalization line
5 Cable entries
6 Overvoltage protection module

Levelflex FMP53
Endress+Hauser 19
Connection examples for the switch output
For HART devices, the switch output is available as an option. See product structure, feature 20:
"Power Supply, Output", option B: "2-wire; 4-20mA HART, switch output"
Devices with PROFIBUS PA and FOUNDATION Fieldbus always have a switch output.
3+
+
-
4-
A0015909
å 6 Connection of a relay
Suitable relays (examples):
•Solid-state relay: Phoenix Contact OV-24DC/480AC/5 with mounting
rail connector UMK-1 OM-R/AMS
• Electromechanical relay: Phoenix Contact PLC-RSC-12DC/21
3+ 2
1
+
4-
A0015910
å 7 Connection of a digital input
1 Pull-up resistor
2 Digital input
Supply voltage An external power supply is required.
Various supply units can be ordered from Endress+Hauser: see "Accessories section (® ä 66)
2-wire, 4-20mA HART, passive
"Power Supply, Output" 1) Outputs Terminal voltage "Approval" 2)
A: 2-wire; 4-20mA HART 1 11.5 to 35 V 3) Non-Ex, Ex nA, CSA GP
11.5 to 32 V 3) Ex ic
11.5 to 30 V 3) Ex ia / IS
13.5 to 30 V 4) Ex d / XP, Ex ic(ia), Ex tD / DIP
C: 2-wire; 4-20mA HART, 4-20mA 1 13.5 to 30 V 4) all
2 12 to 30 V all
1) Feature 020 of the product structure
2) Feature 010 of the product structure
3) For ambient temperatures Ta £ -30 °C (-22 °F) a minimum voltage of 14 V is required for the satrtup of the device
at the MIN error current (3.6 mA). The startup current can be parametrized. If the device is operated with a fixed
current I ³ 4.5 mA (HART multidrop mode), a voltage of 10,4 V is sufficient throughout the entire range of
ambient temperatures.
4) For ambient temperatures Ta £ -30 °C (-22 °F) a minimum voltage of 16 V is required for the startup of the device
at the MIN error current (3.6 mA).
Load (® ä 22)
Residual ripple:
•< 1 VSS (0 to 100 Hz)
• < 10 mVSS (100 to 10 000 Hz)
4-wire, 4-20mA HART, active
"Power supply; Output" 1) Terminal voltage
K: 4-wire 90-253VAC; 4-20mA HART 90 to 253 VAC (50 to 60 Hz), overvoltage category II
L: 4-wire 10,4-48VDC; 4-20mA HART 10.4 to 48 VDC
1) Feature 020 of the product structure

Levelflex FMP53
20 Endress+Hauser
PROFIBUS PA
"Power supply; Output" 1) Terminal voltage
G: 2-wire; PROFIBUS PA, switch output 9 to 32 VDC
1) Feature 020 of the product structure
FOUNDATION Fieldbus
"Power supply; Output" 1) Terminal voltage
E: 2-wire; FOUNDATION Fieldbus, switch output 9 to 30 VDC (Ex)
9 to 32 VDC (non Ex)
Device withstanding voltage 35 V
Polarity sensitive No
FISCO/FNICO compliant according to IEC 60079-27 Yes
1) Feature 020 der Produkstruktur
Terminals •Without integrated overvoltage protection
Plug-in spring terminals for wire cross-sections 0.5 to 2.5 mm2 (20 to 14 AWG)
•With integrated overvoltage protection
Screw terminals for wire cross-sections 0.2 to 2.5 mm2 (24 to 14 AWG)
Cable entries •Cable gland (not for Ex d):
–Plastics M20x1.5 with cable Æ 5 to 10 mm (0.2 to 0.39 in): non-Ex, ATEX/IECEx/NEPSI Ex ia/ic
–Metal M20x1.5 with cable Æ 7 to 10 mm (0.28 to 0.39 in): dust-Ex, FM IS, CSA IS, CSA GP, Ex nA
• Thread for cable entry:
– ½" NPT
– G ½"
– M20 × 1.5
• Connector (only for non-Ex, Ex ic, Ex ia): M12 or 7/8"
Cable specification HART
•For ambient temperature TU³60 °C (140 °F): use cable for temperature TU +20 K.
•A normal device cable suffices if only the analog signal is used.
• A shielded cable is recommended if using the HART protocol. Observe grounding concept of the plant.
PROFIBUS
Use a twisted, screened two-wire cable, preferably cable type A.
For further information on the cable specifications, see Operating Instructions BA00034S "Guidelines
for planning and commissioning PROFIBUS DP/PA", PNO Guideline 2.092 "PROFIBUS PA User and
Installation Guideline" and IEC61158-2 (MBP).
FOUNDATION Fieldbus
•Endress+Hauser recommends using twisted, shielded two-wire cables.
• Terminals for wire cross-sections: 0.5 to 2.5 mm2 (20 to 14 AWG)
• Cable outer diameter: 5 to 9 mm (0.2 to 0.35 in)
For further information on the cable specifications, see Operating Instructions BA00013S
"FOUNDATION Fieldbus Overview", FOUNDATION Fieldbus Guideline and IEC 61158-2 (MBP).
