Endress+Hauser Proline Promass 83 User manual

BA063D/06/en/03.05
50100078
Valid as of version
PROFIBUS DP V 3.00.XX (device software)
PROFIBUS PA V 2.03.XX (device software)
Operating Instructions
Proline Promass 83
PROFIBUS DP/PA
Coriolis Mass Flow Measuring System
8

Brief operating instructions Proline Promass 83 PROFIBUS DP/PA
2Endress+Hauser
Brief operating instructions
These brief operating instructions show you how to configure your measuring device quickly and
easily:
Safety instructions Page 9 ff.
▼
Installation Page 15 ff.
▼
Wiring Page 26 ff.
▼
Display and operating elements Page 40 ff.
▼
Basic configuration (device parameters, automation functions) Page 48 ff.
Configuration programs of various manufacturers are used to configure device-specific
parameters and specify automation functions for the PROFIBUS interface.
If the measuring device is equipped with a local display, device-specific parameters and
functions can also be configured quickly and easily by means of the “Commissioning” Quick
Setup menu, e.g. display language, measured variables, engineering units, type of signal,
settings for operation with gas, etc. →See following page.
▼
Commissioning with “QUICK SETUP” Page 58 ff.
You can commission your measuring device quickly and easily, using the special “Quick
Setup” menu. It enables you to configure important basic functions using the local display, for
example display language, measured variables, units of measures, type of signal, etc.
The following adjustments can be made separately as necessary:
–Devicefunctions
– Zero point adjustment
– Density adjustment
–Gasmeasurement
▼
Application-specific commissioning Page 59 ff.
You have the option of launching other, application-specific Quick Setups, for instance the
menu for measuring pulsating flow, etc.
▼
System integration Page 86 ff.
Cyclic data exchange, configuration examples
▼
Customer-specific configuration Page 90 ff.
Complex measuring operations necessitate additional functions that you can configure as
necessary with the aid of device parameters, and customise to suit your process parameters.
This can be effected in two ways:
– Configuring by means of the configuration program (e.g. Fieldcare)
– Configuring by means of the local display (optional) →Page 40
All functions and device parameters are described in detail in the “Description of Device
Functions” manual which is a separate part of these Operating Instructions!
▼

Proline Promass 83 PROFIBUS DP/PA Brief operating instructions
Endress+Hauser 3
!Note!
Always start trouble-shooting with the checklist on Page 119 if faults occur after commissioning or
during operation. The routine takes you directly to the cause of the problem and the appropriate
remedial measures.
Data storage Page 115 ff.
The configuration of the transmitter can be stored on the integrated T–DAT data storage
device.
!Note!
For time-saving commissioning,
the settings stored in the T–DAT can be transmitted:
▼
Additional configuration (only PROFIBUS DP) Page 73 ff.
The inputs and outputs can be modified on convertible boards by configuring the current
output and relay contacts. The F-CHIP module gives the user the added option of using
software packages for diagnosis, concentration measurement and viscosity.

Brief operating instructions Proline Promass 83 PROFIBUS DP/PA
4Endress+Hauser
QUICK SETUP “Commissioning”
!Note!
More detailed information on running Quick Setup menus, especially for devices without a local
display, can be found in the “Commissioning” section. see Page 58
a0003255-en
Fig. 1: Quick Setup “Commissioning”
04200400
6461
0421 6462
6463
6464
4200
4221
4222
4223
4225
4227
4226
4000
4001
4002
4004
4006
4003
4005
4201
4203
4204
4206
4208
4209
4205
4207
0422
646030013001
04040402
2000
1002
B
+
+
E+
E
n
o
p
q
m
Esc
E
+
-
XXX.XXX.XX
rs
Batching
Yes
Yes
Yes
No
No
No
No
Configure another system unit ?
Current output Freq./Pulse output
Selection output type
Automatic configuration of display ?
Carrying out another Quick Setup ?
Quit
Assign
Current output
Current span
Value 0/4 mA
Value 20 mA
Meas. mode Meas. mode
Meas. mode
Time constant
Time constantFailsafe mode
Failsafe mode
Failsafe mode
Assign
Freq. output
End value freq.
Value F Low
Value F High
Output signal
Assign
Pulse output
Pulse value
Pulse width
Output signal
Operation Mode
Frequency Pulse
Automatic parameterization of the display
Reference Calculated
Fix. Density
Density
Unit
Ref. Density Exp. Coeff. Lin
Exp. Coeff. SQR
Reference temp.
Volume flow Corr. Vol. flow Mass flow Density
Selection system units
Temperature Quit
Unit
Volume flow
Unit
Corr. Vol. flow
Unit
Mass flow
Unit
Density
Unit
Temperature
Unit
Totalizer
Corr. Vol.
calculation
Unit
Totalizer
Language
Pre-setting
Quick Setup
HOME-POSITION
QS
Commission
Pulsating flow Gas meas.
Configure another output ?
Carrying out the selected Quick Setup
Communication

Proline Promass 83 PROFIBUS DP/PA Brief operating instructions
Endress+Hauser 5
!Note!
• The display returns to the cell SETUP COMMISSIONING (1002) if you press the ESC key combination during
parameter interrogation. The stored parameters remain valid.
• The “Commissioning” Quick Setup must be carried out before one of the Quick Setups explained below is run.
mOnly units not yet configured in the current Setup are offered for selection in each cycle. The unit for mass, volume
and corrected volume is derived from the corresponding flow unit.
nThe “YES” option remains visible until all the units have been configured.
“NO” is the only option displayed when no further units are available.
oThis prompt only appears if a current output and/or frequency output is available. Only the outputs not yet
configured in the current Setup are offered for selection in each cycle.
pThe “YES” option remains visible until all the outputs have been parameterized.
“NO” is the only option displayed when no further outputs are available.
qThe “automatic parameterisation of the display” option contains the following basic settings/factory settings
YES Main line = mass flow
Additional line = totalizer 1
Information line = operating/system condition
NO The existing (selected) settings remain.
rThe QUICK SETUP BATCHING is only available when the optional software package BATCHING is installed and
PROFIBUS DP is present.
sThe QUICK SETUP PULSATING FLOW is only available when a current output and/or frequency output is
available.

Brief operating instructions Proline Promass 83 PROFIBUS DP/PA
6Endress+Hauser

Proline Promass 83 PROFIBUS DP/PA Table of contents
Endress+Hauser 7
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . 9
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 Installation, commissioning and operation . . . . . . . . 9
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.5 Notes on safety conventions and icons . . . . . . . . . . 10
2 Identification . . . . . . . . . . . . . . . . . . . 11
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 Nameplate of the transmitter . . . . . . . . . . . 11
2.1.2 Nameplate of the sensor . . . . . . . . . . . . . . 12
2.1.3 Nameplate for connections . . . . . . . . . . . . 13
2.2 Certificates and approvals . . . . . . . . . . . . . . . . . . . 14
2.3 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . 14
3 Installation . . . . . . . . . . . . . . . . . . . . . 15
3.1 Incoming acceptance, transport and storage . . . . . . 15
3.1.1 Incoming acceptance . . . . . . . . . . . . . . . . . 15
3.1.2 Transport . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1.3 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . . 16
3.2.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2.2 Mounting location . . . . . . . . . . . . . . . . . . . 16
3.2.3 Orientation . . . . . . . . . . . . . . . . . . . . . . . . 18
3.2.4 Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.2.5 Thermal insulation . . . . . . . . . . . . . . . . . . 21
3.2.6 Inlet and outlet runs . . . . . . . . . . . . . . . . . 21
3.2.7 Vibrations . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.2.8 Limiting flow . . . . . . . . . . . . . . . . . . . . . . . 21
3.3 Installation instructions . . . . . . . . . . . . . . . . . . . . . 22
3.3.1 Turning the transmitter housing . . . . . . . . 22
3.3.2 Installing the wall-mount transmitter
housing . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3.3 Turning the local display . . . . . . . . . . . . . . 25
3.4 Post-installation check . . . . . . . . . . . . . . . . . . . . . . 25
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . 26
4.1 PROFIBUS cable specifications . . . . . . . . . . . . . . . 26
4.1.1 PROFIBUS DP cable specifications . . . . . . . 26
4.1.2 PROFIBUS PA cable specifications . . . . . . . 27
4.1.3 Shielding and grounding . . . . . . . . . . . . . . 29
4.2 Connecting the remote version . . . . . . . . . . . . . . . 30
4.2.1 Connecting connecting cable for
sensor/transmitter . . . . . . . . . . . . . . . . . . . 30
4.2.2 Cable specification for connecting cable . . . 30
4.3 Connecting the measuring unit . . . . . . . . . . . . . . . 31
4.3.1 Terminal assignment . . . . . . . . . . . . . . . . 31
4.3.2 Transmitter connection . . . . . . . . . . . . . . . 32
4.3.3 PROFIBUS DP connection diagram . . . . . . 33
4.3.4 PROFIBUS PA connection diagram . . . . . 35
4.4 Degree of protection . . . . . . . . . . . . . . . . . . . . . . . 37
4.5 Post-connection check . . . . . . . . . . . . . . . . . . . . . . 38
5 Operation . . . . . . . . . . . . . . . . . . . . . . 39
5.1 Quick operation guide . . . . . . . . . . . . . . . . . . . . . . 39
5.2 Local display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.1 Display and operating elements . . . . . . . . . 40
5.2.2 Display (operating mode) . . . . . . . . . . . . . . 41
5.2.3 Additional display functions . . . . . . . . . . . . 41
5.2.4 Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.2.5 Controlling the batching processes using the
local display . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3 Brief operating instructions to the function matrix . 45
5.3.1 General notes . . . . . . . . . . . . . . . . . . . . . . 46
5.3.2 Enabling the programming mode . . . . . . . . 46
5.3.3 Disabling the programming mode . . . . . . . . 46
5.4 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.4.1 Type of error . . . . . . . . . . . . . . . . . . . . . . . 47
5.4.2 Error message type . . . . . . . . . . . . . . . . . . . 47
5.5 Operating options . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.5.1 Fieldcare . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.5.2 Operating program
“ToF Tool – Fieldtool Package” . . . . . . . . . 48
5.5.3 Operating program
“SIMATIC PDM” (Siemens) . . . . . . . . . . . . 48
5.5.4 Device description data for
operating programs . . . . . . . . . . . . . . . . . 49
5.6 PROFIBUS DP hardware settings . . . . . . . . . . . . . 51
5.6.1 Configuring the write protection . . . . . . . . 51
5.6.2 Configuring the device address . . . . . . . . . . 52
5.6.3 Configuring the terminating resistors . . . . . 53
5.6.4 Current output configuration . . . . . . . . . 54
5.6.5 Relay output configuration . . . . . . . . . . . 55
5.7 PROFIBUS PA hardware settings . . . . . . . . . . . . . . 56
5.7.1 Configuring the write protection . . . . . . . . 56
5.7.2 Configuring the device address . . . . . . . . . . 57
6 Commissioning . . . . . . . . . . . . . . . . . . 58
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.2 Switching on the measuring device . . . . . . . . . . . . 58
6.3 Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
6.3.1 Quick Setup “Commissioning” . . . . . . . . . 59
6.3.2 Quick Setup “Batching” . . . . . . . . . . . . . . 61
6.3.3 Quick Setup “Pulsating Flow” . . . . . . . . . . 65
6.3.4 Quick Setup “Gas Measurement” . . . . . . . . 68
6.3.5 Quick Setup “Communication” . . . . . . . . . 70
6.3.6 Data back-up with “T-DAT SAVE/LOAD” . 72
6.4 Device configuration . . . . . . . . . . . . . . . . . . . . . . . 73
6.4.1 Concentration measurement . . . . . . . . . . . 73
6.4.2 Advanced diagnostic functions . . . . . . . . . . 78
6.5 Commissioning the PROFIBUS interface . . . . . . . 80
6.5.1 PROFIBUS DP commissioning . . . . . . . . . 80
6.5.2 PROFIBUS PA commissioning . . . . . . . . . 84
6.6 PROFIBUS system integration . . . . . . . . . . . . . . . . 86
6.6.1 Device master file (GSD file) . . . . . . . . . . . 86
6.6.2 Compatibility with previous PROFIBUS model
PROMASS 63 with Profile Version 2.0 . . . 89

Proline Promass 83 PROFIBUS DP/PA Table of contents
8Endress+Hauser
6.7 PROFIBUS DP cyclic data exchange . . . . . . . . . . . . 90
6.7.1 Block model . . . . . . . . . . . . . . . . . . . . . . . 90
6.7.2 Modules for cyclic data exchange . . . . . . 90
6.7.3 Configuration information for
integrating modules . . . . . . . . . . . . . . . . . 99
6.7.4 Configuration examples with
Simatic S7 HW-Konfig . . . . . . . . . . . . . . . 100
6.8 PROFIBUS PA cyclic data exchange . . . . . . . . . . . 103
6.8.1 Block model . . . . . . . . . . . . . . . . . . . . . . 103
6.8.2 Modules for cyclic data exchange . . . . . 103
6.8.3 Configuration information for
integrating modules . . . . . . . . . . . . . . . . 108
6.8.4 Configuration examples with
Simatic S7 HW-Konfig . . . . . . . . . . . . . . . 109
6.9 Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
6.9.1 Zero point adjustment . . . . . . . . . . . . . . . 112
6.9.2 Density adjustment . . . . . . . . . . . . . . . . . 113
6.10 Purge and pressure monitoring connections . . . . . 115
6.11 Data storage device (HistoROM), F–CHIP . . . . . . 115
6.11.1 HistoROM/S–DAT (sensor–DAT) . . . . . . 115
6.11.2 HistoROM/T–DAT (transmitter–DAT) . . . 115
6.11.3 F-CHIP (Function-Chip) . . . . . . . . . . . . . 115
7 Maintenance . . . . . . . . . . . . . . . . . . . 116
7.1 Exterior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 116
7.2 Cleaning with pigs (Promass H, I) . . . . . . . . . . . . 116
7.3 Replacing seals . . . . . . . . . . . . . . . . . . . . . . . . . . 116
8 Accessories . . . . . . . . . . . . . . . . . . . . 117
8.1 Device-specific accessories: . . . . . . . . . . . . . . . . . 117
8.2 Measuring principle-specific accessories: . . . . . . . 117
8.3 Service-specific accessories: . . . . . . . . . . . . . . . . . 118
9 Trouble-shooting . . . . . . . . . . . . . . . . 119
9.1 Trouble-shooting instructions . . . . . . . . . . . . . . . . 119
9.2 System error messages . . . . . . . . . . . . . . . . . . . . . 121
9.2.1 Displaying the device status on
PROFIBUS . . . . . . . . . . . . . . . . . . . . . . . 121
9.2.2 List of system error messages . . . . . . . . . 122
9.3 Process error messages . . . . . . . . . . . . . . . . . . . . . 132
9.3.1 Displaying the device status on
PROFIBUS . . . . . . . . . . . . . . . . . . . . . . . 132
9.3.2 List of process error messages . . . . . . . . . 132
9.4 Process errors without messages . . . . . . . . . . . . . 135
9.5 Response of outputs to errors . . . . . . . . . . . . . . . . 136
9.6 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
9.6.1 PROFIBUS DP . . . . . . . . . . . . . . . . . . . . . 137
9.6.2 PROFIBUS PA . . . . . . . . . . . . . . . . . . . . . 138
9.6.3 Removing and installing printed circuit
boards . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
9.6.4 Replacing the device fuse . . . . . . . . . . . . . 143
9.7 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
9.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
9.9 Software history . . . . . . . . . . . . . . . . . . . . . . . . . 145
10 Technical data . . . . . . . . . . . . . . . . . . 147
10.1 Technical data at a glance . . . . . . . . . . . . . . . . . . 147
10.1.1 Applications . . . . . . . . . . . . . . . . . . . . . . 147
10.1.2 Function and system design . . . . . . . . . . 147
10.1.3 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
10.1.4 PROFIBUS DP output . . . . . . . . . . . . . 149
10.1.5 Power supply . . . . . . . . . . . . . . . . . . . . . 150
10.1.6 Performance characteristics . . . . . . . . . . . 150
10.1.7 Operating conditions: Installation . . . . . . 157
10.1.8 Operating conditions: Environment . . . . . 157
10.1.9 Operating conditions: Process . . . . . . . . . 158
10.1.10 Mechanical construction . . . . . . . . . . . . 166
10.1.11 Human interface . . . . . . . . . . . . . . . . . . 169
10.1.12 Certificates and approvals . . . . . . . . . . . . 170
10.1.13 Ordering information . . . . . . . . . . . . . . . 171
10.1.14 Accessories . . . . . . . . . . . . . . . . . . . . . . 171
10.1.15 Documentation . . . . . . . . . . . . . . . . . . . 171
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Proline Promass 83 PROFIBUS DP/PA Safety instructions
Endress+Hauser 9
1 Safety instructions
1.1 Designated use
The measuring device described in these Operating Instructions is to be used only for measuring the
mass flow rate of liquids and gases. At the same time, the system also measures fluid density and
fluid temperature. These parameters are then used to calculate other variables such as volume flow.
Fluids with widely differing properties can be measured.
Examples:
• Chocolate, condensed milk, liquid sugar
• Oils, fats
• Acids, alkalis, lacquers, paints, solvents and cleaning agents
• Pharmaceuticals, catalysts, inhibitors
• Suspensions
• Gases, liquefied gases, etc.
Resulting from incorrect use or from use other than that designated the operational safety of the
measuring devices can be suspended. The manufacturer accepts no liability for damages being
produced from this.
1.2 Installation, commissioning and operation
Note the following points:
• Installation, connection to the electricity supply, commissioning and maintenance of the device
must be carried out by trained, qualified specialists authorised to perform such work by the
facility's owner operator. The specialist must have read and understood these Operating
Instructions and must follow the instructions they contain.
• The device must be operated by persons authorised and trained by the facility's owner-operator.
Strict compliance with the instructions in the Operating Instructions is mandatory.
• Endress+Hauser will be happy to assist in clarifying the chemical resistance properties of parts
wetted by special fluids, including fluids used for cleaning. However the user is responsible for
the choice of fluid wetted materials as regards to their in-process resistance to corrosion. The
manufacturer refuses to accept liability.
• If carrying out welding work on the piping, the welding unit may not be grounded by means of
the measuring device.
• The installer must ensure that the measuring system is correctly wired in accordance with the
wiring diagrams. The transmitter must be grounded, unless the power supply is galvanically
isolated.
• Invariably, local regulations governing the opening and repair of electrical devices apply.
1.3 Operational safety
Note the following points:
• Measuring systems for use in hazardous environments are accompanied by separate
“Ex documentation”, which is an integral part of these Operating Instructions. Strict compliance
with the installation instructions and ratings as stated in this supplementary documentation is
mandatory.
The symbol on the front of this supplementary Ex documentation indicates the approval and the
certification body (0Europe, 2USA, 1Canada).
• The measuring device complies with the general safety requirements in accordance with
EN 61010, the EMC requirements of EN 61326/A1, and NAMUR recommendation NE 21,
NE 43 and NE 53.
• For measuring systems used in SIL 2 applications, the separate manual on functional safety must
be observed.

Safety instructions Proline Promass 83 PROFIBUS DP/PA
10 Endress+Hauser
• The manufacturer reserves the right to modify technical data without prior notice. Your
Endress+Hauser distributor will supply you with current information and updates to these
Operating Instructions.
1.4 Return
The following procedures must be carried out before a flowmeter requiring repair or calibration, for
example, is returned to Endress+Hauser:
• Always enclose a duly completed “Declaration of contamination” form. Only then can
Endress+Hauser transport, examine and repair a returned device.
• Enclose special handling instructions if necessary, for example a safety data sheet as per
EN 91/155/EEC.
• Remove all residues. Pay special attention to the grooves for seals and crevices which could
contain residues. This is particularly important if the substance is hazardous to health, e.g.
flammable, toxic, caustic, carcinogenic, etc.
With Promass A and Promass M the threaded process connections must first be removed from the
sensor and then cleaned.
!Note!
You will find a preprinted “Declaration of contamination” form at the back of this manual.
#Warning!
• Do not return a measuring device if you are not absolutely certain that all traces of hazardous
substances have been removed, e.g. substances which have penetrated crevices or diffused
through plastic.
• Costs incurred for waste disposal and injury (burns, etc.) due to inadequate cleaning will be
charged to the owner-operator.
1.5 Notes on safety conventions and icons
The devices are designed to meet state-of-the-art safety requirements, have been tested, and left the
factory in a condition in which they are safe to operate.
The devices comply with the applicable standards and regulations in accordance with EN 61010
“Protection Measures for Electrical Equipment for Measurement, Control, Regulation and
Laboratory Procedures”.
The devices can, however, be a source of danger if used incorrectly or for anything other than the
designated use. Consequently, always pay particular attention to the safety instructions indicated in
these Operating Instructions by the following icons:
#Warning!
“Warning” indicates an action or procedure which, if not performed correctly, can result in injury
or a safety hazard. Comply strictly with the instructions and proceed with care.
"Caution!
“Caution” indicates an action or procedure which, if not performed correctly, can result in incorrect
operation or destruction of the device. Comply strictly with the instructions.
!Note!
“Note” indicates an action or procedure which, if not performed correctly, can have an indirect
effect on operation or trigger an unexpected response on the part of the device.

Proline Promass 83 PROFIBUS DP/PA Identification
Endress+Hauser 11
2 Identification
2.1 Device designation
The “Promass 80/83” flow measuring system consists of the following components:
• Promass 80 or 83 transmitter
• Promass F, Promass M, Promass E, Promass A, Promass H or Promass I sensor
Two versions are available:
• Compact version: transmitter and sensor form a single mechanical unit.
• Remote version: transmitter and sensor are installed separately.
2.1.1 Nameplate of the transmitter
a0002581
Fig. 2: Nameplate specifications for the “Promass 83” transmitter (example)
1 Order code / Serial number: See the specifications on the order confirmation for the meanings of the individual
letters and digits
2 Power supply / frequency: 20...55 V AC /16...62 V DC / 50...60 Hz
Power consumption: 15 VA / 15 W
3 F-CHIP option
4 Available inputs / outputs:
PROFIBUS DP
I-OUT: with current output
f–OUT: with pulse/frequency output
RELAY: with relay output
STATUS–IN: with status input
(auxiliary input)
5 Reserved for information on special products
6 Ambient temperature range
7 Degree of protection
PROMASS 83
ENDRESS+HAUSER
Order Code:
Ser.No.:
TAG No.:
16-62VDC/20-55VAC
50-60Hz 15VA/W
IP67/NEMA/Type4X83F25-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
–20°C (–4°F) < Tamb < +60°C (+140°F)
i
1
7
6
2
4
5
Pat. US 5,479,007
Pat. US 4,768,384
Pat. UK 261 435
5,648,616
4,801,897
EP 262 573 EP 618 680
PROFIBUS DP, STATUS-IN
RELAY, RELAY
3
BATCHING
R

Identification Proline Promass 83 PROFIBUS DP/PA
12 Endress+Hauser
2.1.2 Nameplate of the sensor
F06-8xFxxxxx-18-05-xx-xx-000
Fig. 3: Nameplate specifications for the “Promass F” sensor (example)
1 Order code / Serial number: See the specifications on the order confirmation for the meanings of the individual
letters and digits
2 Calibration factor: 2.5100 / zero point: –11
3 Nominal diameter device: DN 25 / 1"
4 Flange nominal diameter: DN 25 / 1"
Nominal pressure: EN (DIN) PN 100 bar
5 Material of measuring tubes: Stainless steel 1.4539/904L
6 TMmax +200 °C / +392 °F (max. fluid temperature)
7 Pressure range of secondary containment: max. 40 bar (600 psi)
8 Accuracy of density measurement: ±0.001 g/cc
9 Additional information (examples):
– With 5-point calibration
– With 3.1 B certificate for wetted materials
10 Reserved for information on special products
11 Ambient temperature range
12 Degree of protection
13 Flow direction
14 Reserved for additional information on device version (approvals, certificates)
1
2
4
5
6
7
8
9
11
12
13
200°C / 392°F
40 bar / 600 psi Container
2.5100 / -11
DN25 / 1" EN (DIN) PN100
1.4539 / 904L
5P-CAL, 3.1B
Density cal.:
-20°C (-4°F)<Tamb<+60°C (+140°F)
PROMASS F
ENDRESS+HAUSER
Pat. US 5,796,011
Materials:
TMmax.:
Order Code:
K-factor:
TAG No.:
Ser.No.:
IP67/NEMA/Type4X
+/-0.001g/cc
XXF25-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
i
14
DN25 / 1"
Size :
3
10

Proline Promass 83 PROFIBUS DP/PA Identification
Endress+Hauser 13
2.1.3 Nameplate for connections
a0002256
Fig. 4: Nameplate specifications for Proline sensor (example)
1 Serial number
2 Possible configuration of current output
3 Possible configuration of relay contacts
4 Terminal assignment, cable for power supply: 85...260 V AC, 20...55 V AC, 16...62 V DC
Terminal No. 1: L1 for AC, L+ for DC
Terminal No. 2: N for AC, L- for DC
5 Signals present at inputs and outputs, possible configuration and terminal assignment (20...27), see also “Electrical
values of inputs/outputs”
6 Version of device software currently installed
7 Installed communication type
8 PROFIBUS ID No.
9 Date of installation
10 Current updates to data specified in points 6 to 9
Communication:
Revision:
Device SW:
ID 1529 (HEX)
3.00.02
PROFIBUS DP
Date:
01.MAR.05
SW-version
Ex-works
26(+) / 27(-)
NC:
Versorgung /
Tension d'alimentation
Observer manuel d'instruction
See operating manual
Betriebsanleitung beachten
12345678912 Ser.No.:
Supply /
24(+) / 25(-)
22(+) / 23(-)
20(+) / 21(-)
N/L-
PE
A:
NO:
P:
L1/L+
12
319475-00XX
X
P
active
passive
normally open contact
normally closed contact
X
X
Update 1 Update 2
2
3
1
4
5
6
7
8
9
10
max. 30 VAC / 0.5 A
max. 60 VDC / 0.1 A
max. 30 VAC / 0.5 A
3...30 VDC, Ri = 3 kOhm
max. 60 VDC / 0.1 A
STATUS–IN
RELAY
RELAY
26 = A (RS485)
27 = B (RS485)
PROFIBUS DP

Identification Proline Promass 83 PROFIBUS DP/PA
14 Endress+Hauser
2.2 Certificates and approvals
The devices are designed in accordance with good engineering practice to meet state-of-the-art
safety requirements, have been tested, and left the factory in a condition in which they are safe to
operate. The devices comply with the applicable standards and regulations in accordance with
EN 61010 “Protection Measures for Electrical Equipment for Measurement, Control, Regulation
and Laboratory Procedures” and with the EMC requirements of EN 61326/A1.
The measuring system described in these Operating Instructions thus complies with the statutory
requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by
affixing to it the CE mark.
The Promass 83 flowmeter has successfully passed all the test procedures carried out and is certified
and registered by the PNO (PROFIBUS User Organisation).
The device thus meets all the requirements of the following specifications:
• Certified to PROFIBUS Specification Profile 3.0 version
Device certification number: on request
• The measuring device can also be operated with certified devices of other manufacturers
(interoperability).
2.3 Registered trademarks
KALREZ®and VITON®
Registered trademarks of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI-CLAMP®
Registered trademark of Ladish & Co., Inc., Kenosha, USA
SWAGELOK®
Registered trademark of Swagelok & Co., Solon, USA
PROFIBUS®
Registered trademark of the PROFIBUS User Organisation, Karlsruhe, D
HistoROM™, S-DAT®, T-DAT™, F-CHIP®, ToF Tool - Fieldtool®Package, Fieldcheck®,
Applicator®
Registered or registration-pending trademarks of Endress+Hauser Flowtec AG, Reinach, CH

Proline Promass 83 PROFIBUS DP/PA Installation
Endress+Hauser 15
3 Installation
3.1 Incoming acceptance, transport and storage
3.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Check the packaging and the contents for damage.
• Check the shipment, make sure nothing is missing and that the scope of supply matches your
order.
3.1.2 Transport
The following instructions apply to unpacking and to transporting the device to its final location:
• Transport the devices in the containers in which they are delivered.
• The covers or caps fitted to the process connections prevent mechanical damage to the sealing
faces and the ingress of foreign matter to the measuring tube during transportation and storage.
Consequently, do not remove these covers or caps until immediately before installation.
• Do not lift measuring devices of nominal diameters DN 40...250 by the transmitter housing or
the connection housing in the case of the remote version (Fig. 5). Use webbing slings slung round
the two process connections. Do not use chains, as they could damage the housing.
• In the case of the Promass M / DN 80 sensor, use only the lifting eyes on the flanges to lift the
assembly!
#Warning!
Risk of injury if the measuring device slips. The center of gravity of the assembled measuring device
might be higher than the points around which the slings are slung.
At all times, therefore, make sure that the device does not unexpectedly turn around its axis or slip.
F06-xxxxxxxx-22-00-00-xx-000
Fig. 5: Instructions for transporting sensors with DN 40...250

Installation Proline Promass 83 PROFIBUS DP/PA
16 Endress+Hauser
3.1.3 Storage
Note the following points:
• Pack the measuring device in such a way as to protect it reliably against impact for storage (and
transportation). The original packaging provides optimum protection.
• The permissible storage temperature is –40...+80 °C (preferably +20 °C).
• Do not remove the protective covers or caps on the process connections until you are ready to
install the device.
• The measuring device must be protected against direct sunlight during storage in order to avoid
unacceptably high surface temperatures.
3.2 Installation conditions
Note the following points:
• No special measures such as supports are necessary. External forces are absorbed by the
construction of the instrument, for example the secondary containment.
• The high oscillation frequency of the measuring tubes ensures that the correct operation of the
measuring system is not influenced by pipe vibrations.
• No special precautions need to be taken for fittings which create turbulence (valves, elbows,
T-pieces, etc.), as long as no cavitation occurs.
• For mechanical reasons and in order to protect the pipe, it is advisable to support heavy sensors.
3.2.1 Dimensions
All the dimensions and lengths of the sensor and transmitter are provided in the separate
documentation “Technical Information”.
3.2.2 Mounting location
Accumulated air or gas bubbles in the measuring tube can result in an increase in measuring errors.
Avoid the following locations:
• Highest point of a pipeline. Risk of air accumulating.
• Directly upstream of a free pipe outlet in a vertical pipeline.
F06-xxxxxxxx-11-00-00-xx-004
Fig. 6: Mounting location

Proline Promass 83 PROFIBUS DP/PA Installation
Endress+Hauser 17
The proposed configuration in the following diagram, however, permits installation in a vertical
pipeline. Pipe restrictors or the use of an orifice plate with a smaller cross-section than the nominal
diameter prevent the sensor from running empty during measurement.
F06-xxxxxxxx-11-00-00-xx-002
Fig. 7: Installation in a vertical pipe (e.g. for batching applications)
1Supplytank
2Sensor
3 Orifice plate, pipe restrictions (see Table)
4Valve
5Batchingtank
System pressure
It is important to ensure that cavitation does not occur, because it would influence the oscillation
of the measuring tube. No special measures need to be taken for fluids which have properties similar
to water under normal conditions.
In the case of liquids with a low boiling point (hydrocarbons, solvents, liquefied gases) or in suction
lines, it is important to ensure that pressure does not drop below the vapour pressure and that the
liquid does not start to boil. It is also important to ensure that the gases that occur naturally in many
liquids do not outgas. Such effects can be prevented when system pressure is sufficiently high.
Consequently, it is generally best to install the sensor:
• downstream from pumps (no danger of vacuum),
• at the lowest point in a vertical pipe.
1
2
3
4
5
Promass F, M, E / DN 81525405080
1) 1002) 1502) 2502)
∅Orifice plate, pipe restriction 6 mm 10 mm 14 mm 22 mm 28 mm 50 mm 65 mm 90 mm 150 mm
1) Promass F, M only
2) Promass F only
Promass A / DN 124
∅Orifice plate, pipe restriction 0.8 mm 1.5 mm 3.0 mm
Promass H, I / DN 81515
1) 25 251) 40 401) 50
∅Orifice plate, pipe restriction 6 mm 10 mm 15 mm 14 mm 24 mm 22 mm 35 mm 28 mm
1) DN 15, 25, 40 “FB” = Full bore versions of Promass I

Installation Proline Promass 83 PROFIBUS DP/PA
18 Endress+Hauser
3.2.3 Orientation
Make sure that the direction of the arrow on the nameplate of the sensor matches the direction of
flow (direction in which the fluid flows through the pipe).
Orientation Promass A
Vertical:
Recommended orientation with upward direction of flow. When fluid is not flowing, entrained
solids will sink down and gases will rise away from the measuring tube. The measuring tubes can
be completely drained and protected against solids build-up.
Horizontal:
When installation is correct the transmitter housing is above or below the pipe. This arrangement
means that no gas or solid deposits can accumulate in the curved measuring tube (single-tube
system).
Do not install the sensor in such a way that it is suspended in the pipe, in other words without
support or attachment. This is to avoid excessive strain at the process connection. The base plate of
the sensor housing is designed for mounting on a tabletop, wall or post.
F06-xxxxxxxx-11-00-00-xx-005
Fig. 8: Vertical and horizontal orientation (Promass A)

Proline Promass 83 PROFIBUS DP/PA Installation
Endress+Hauser 19
Orientation Promass F, M, E, H, I
Make sure that the direction of the arrow on the nameplate of the sensor matches the direction of
flow (direction in which the fluid flows through the pipe).
Vertical:
Recommended orientation with upward direction of flow (View V). When fluid is not flowing,
entrained solids will sink down and gases will rise away from the measuring tube. The measuring
tubes can be completely drained and protected against solids build-up.
Horizontal (Promass F, M, E):
The measuring tubes of Promass F, M and E must be horizontal and beside each other. When
installation is correct the transmitter housing is above or below the pipe (View H1/H2). Always
avoid having the transmitter housing in the same horizontal plane as the pipe.
Horizontal (Promass H, I):
Promass H and Promass I can be installed in any orientation in a horizontal pipe run.
Promass F, M, E, H, I Standard, compact Promass F, M, E, H, I Standard, remote Promass F High-temperature, compact Promass F High-temperature, remote
Fig. V: Vertical orientation
F06-xxxxxxxx-11-00-00-xx-008
ÃÃ ÃÃ ÃÃ ÃÃ
Fig. H1: Horizontal orientation
Transmitter head up
F06-xxxxxxxx-11-00-00-xx-009
ÃÃ ÃÃ
✘
(TM = >200 °C)
m
Ã
(TM = >200 °C)
m
Fig. H2: Horizontal orientation
Transmitter head down
F06-xxxxxxxx-11-00-00-xx-010
ÃÃ
n
ÃÃ
n
ÃÃ
n
ÃÃ
n
ÃÃ = Recommended orientation
Ã= Orientation recommended in certain situations
✘= Impermissible orientation

Installation Proline Promass 83 PROFIBUS DP/PA
20 Endress+Hauser
In order to ensure that the maximum permissible ambient temperature for the transmitter
(–20...+60 °C, optional –40...+60 °C) is not exceeded, we recommend the following orientations:
m= For fluids with very high temperatures (> 200 °C), we recommend the horizontal orientation
with the transmitter head pointing downwards (Fig. H2) or the vertical orientation (Fig. V).
n= For fluids with low temperatures, we recommend the horizontal orientation with the
transmitter head pointing upwards (Fig. H1) or the vertical orientation (Fig. V).
Special installation instructions for Promass F, E and H
"Caution!
The two measuring tubes of Promass F and Promass E and the one of Promass H are slightly curved.
The position of the sensor, therefore, has to be matched to the fluid properties when the sensor is
installed horizontally .
F06-xxxxxxxx-11-00-00-xx-003
Fig. 9: Promass F, E, H installed horizontally
1 Not suitable for fluids with entrained solids. Risk of solids accumulating.
2 Not suitable for outgassing fluids. Risk of air accumulating.
3.2.4 Heating
Some fluids require suitable measures to avoid loss of heat at the sensor. Heating can be electric,
e.g. with heated elements, or by means of hot water or steam pipes made of copper.
"Caution!
• Risk of electronics overheating! Consequently, make sure that the adapter between sensor and
transmitter and the connection housing of the remote version always remain free of insulating
material. Note that a certain orientation might be required, depending on the fluid temperature.
→Page 18,
• With a fluid temperature between 200...350 °C, heating is not permitted for the compact version
of the high-temperature version.
When using electrical heat tracing whose heat is regulated using phase control or by pulse packs,
it cannot be ruled out that the measured values are influenced by magnetic fields which may
occur, (i.e. at values greater than those permitted by the EC standard (Sinus 30 A/m)). In such
cases, the sensor must be magnetically screened (except for Promass M).
The secondary containment can be shielded with tin plates or electric sheets without privileged
direction (e.g. V330-35A) with the following properties:
– Relative magnetic permeability µr≥300
– Plate thickness d * 0.35 mm
• Information on permissible temperature ranges →Page 158
Special heating jackets which can be ordered as accessories from Endress+Hauser are available for
the sensors.
12
