Eneo VMC-27LEDM User guide

Installation and User's Guide
All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein
Installation and Operating Instructions
TFT LCD MONITOR
VMC-27LEDM
VMC-32LEDM

2
TABLE OF CONTENTS
Installation and User's Guide
No ITEM Page
1 SAFETY INSTRUCTION 3
- WARNING
- CAUTION
2 FCC STATEMENT 7
3 INSTALLATION 8
- PARTS
- HOW TO INSTALL
4 OSD MENU SETTING 13
- MENU STRUCTURE
- PICTURE MENU
- OPTION MENU
- INPUT SOURCE
- AUDIO VOLUME
5 FEATURES 19
6 TROUBLESHOOTING 21

3
Installation and User's Guide
1.SAFETY INSTRUCTION
* Follow this safety instruction to use the monitor properly and prevent the damage.
* Keep this user’s guide book for later use.
* This safety instruction has “Warning” & “Caution” as below
Warning - If the user does not follow this instruction,
it may cause the serious damage to the user.
Caution - If the user does not follow this instruction, it may cause the slight
damage to the user or cause some damages to the monitor.
Warning
Never remove the back cover and
touch the inside of the monitor.
If you need a service, please
contact the service center.
Keep away the monitor from the
direct sunlight and a heating appliance.
Never put objects of any kind into
this product as they may result in a
risk of fire or electric shock.
Connect the power cord to the wall
outlet tightly. If the power cord or
plug are defective and the wall outlet
is not tight, please do not use them.

4
Installation and User's Guide
1.SAFETY INSTRUCTIN
Warning
Do not install this monitor on the
outside and near water. It may cause
damage to the product, electric shock
and fire.
For cleaning do not use liquid
cleaners. Never touch the power plug
with wet-hands.
When lightning and thundering,
unplug the monitor from the wall
outlet and never touch it.
Unplug this product from the wall
outlet, when it does not operate for
a long time.
When smoking and noising from the
monitor, unplug the product from the
wall outlet and contact a service
center.
Warning : How to fix
Do not open this product as it contains high voltage inside.
It may create an electric shock.
If the user disassembles and remove the back cover, it does not make sure
to make up for the damage and do a service and exchange the monitor.

5
Installation and User's Guide
1.SAFETY INSTRUCTIN
Cautions
Install this monitor some distance
from the wall and do not install unless
proper ventilation is provided.
Place this product on a stable place.
If not, it may fall, causing serious
damages to the monitor and people.
The openings must not be blocked by
curtain, rug or other similar surface.
When carrying this monitor, be careful
not to damage the panel and drop it
It may cause some trouble.
Before carrying the monitor, turn it off
and unplug the signal cables and the
power cord from the wall outlet.
Take the power plug out from the
wall outlet. Do not pull the cable. It
may snap the inner-wires and cause
overheating and fire.

6
Installation and User's Guide
1.SAFETY INSTRUCTIN
Cautions
Install this monitor about 50cm far
from the eyes and an angle of 0~15
degrees below eyes. Too close
installation may cause having weak
sight.
Do not press the LCD panel with
hands or the sharpened material
hardly.
For cleaning, unplug the monitor from
the wall outlet. Do net use the liquid
cloth. Use the soft cloth.
Do not use the chemical liquid for
cleaning. It may cause fading and
breakage.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR WATER.
Instructions for Disposal of Electrical and Electronic Equipment in Private
Households
Disposal of used Electrical and Electronic Equipment
(Applicable in the European Union and other European
countries with garbage separate disposal and collection methods)
This symbol on the product, or in the related documents in the package, indicates that
this product shall not be treated as normal household waste. Instead, it should be
taken to a proper applicable collection point or depot for the recycling of electrical
and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent possible negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. The
recycling of materials will help to conserve natural resources. For more detailed
information about recycling of this product, please contact your local city authority,
your household waste disposal service or the place where you purchased the product.

7
Installation and User's Guide
2. FCC RF INTERFERENCE STATEMENT
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures.
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio, TV technician for help.
●Only shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not expressly approved by the
grantee or manufacturer could void
the users authority to operate such equipment.
DOC COMPLIANCE NOTICE
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus set out in the radio
interference regulation of Canadian Department of communications.

8
Installation and User's Guide
3. INSTALLATION
PARTS
User Manual
Power Cable
Adapter
(Only VMC-27LEDM)
LCD Monitor
Remote Controller
VGA Cable
Battery

9
Installation and User's Guide
HOW TO INSTALL
1) KEY BUTTON
SHORT KEY FUNCTION
OSD Key Function
MENU Activate the menu function / Exit from the menu
SOURCE / ▼Input source menu / Source selection(move down from OSD menu)
AUTO / ▲Auto-fit screen with PC-RGB input / move up from OSD menu
◀(VOL) Decrease the level of volume and move the previous menu
(VOL)▶Increase the level of volume and select the OSD menu
Power On / Off
LED
Red : Power Off state
Green : Power On and available input signal state
Orange : When DPMS "ON" state, no input signal
▲+◀Press “▲ , ◀” Key 10 seconds simultaneously to lock /
unlock OSD Key

10
Installation and User's Guide
2) CONNECTION
<VMC-27LEDM>
①HDMI 1
HDMI signal 1 input
②HDMI 2
HDMI signal 2 input
③VGA
VGA (PC RGB) signal input
④AUDIO (PC)
Stereo audio input for VGA
⑤For FW Update
①②③④⑤⑥⑦⑧⑨⑩
⑥DC12V
DC adapter input
⑦AUDIO(VIDEO-1)
Stereo audio input for VIDEO-1
⑧AUDIO(VIDEO-2)
Stereo audio input for VIDEO-2
⑨VIDEO-1 IN/OUT
VIDEO-1 signal input/looping out
⑩VIDEO-2 IN/OUT
VIDEO-2 signal input/looping out

11
Installation and User's Guide
2) CONNECTION
<VMC-32LEDM>
①HDMI 1
HDMI signal 1 input
②HDMI 2
HDMI signal 2 input
③VGA
VGA (PC RGB) signal input
④AUDIO (PC)
Stereo audio input for VGA
⑤For FW Update
①②③④⑤⑥⑦⑧⑨⑩
⑥AUDIO(VIDEO-1)
Stereo audio input for VIDEO-1
⑦AUDIO(VIDEO-2)
Stereo audio input for VIDEO-2
⑧VIDEO-1 IN/OUT
VIDEO-1 signal input/looping out
⑨VIDEO-2 IN/OUT
VIDEO-2 signal input/looping out
⑩AC POWER
AC100~240V input

12
Installation and User's Guide
2) REMOTE CONTROLLER
■MODE SELECT MENU
VIDEO1 : Select VIDEO1 mode
VIDEO2 : Select VIDEO2 mode
HDMI1 : Select HDMI1 mode
HDMI2 : Select HDMI2 mode
VGA (RGB) : Select VGA mode
■OSD CONTROL MENU
POWER : Turn ON / OFF the monitor
MUTE : Turn ON / OFF the sound
AUTO : Auto adjust position of the screen (in VGA mode)
COLOR TEMPERATURE : Select color temperature of the screen
SCAN MODE : Select the scan mode of the screen
VOL- / VOL+ : Increase / Decrease the volume level
MENU / EXIT : Activate and exit the OSD menu
KEY LOCK : Locking the button (Prevent operation)

13
Installation and User's Guide
4. OSD MENU SETTING
MENU STRUCTURE
When user presses the menu key, the first “PICTURE” menu is displayed. Select by "◀"
key then three types of menu functions are shown as below.
- PICTURE : Menu related to PICTURE Function
- OPTION : Other OSD Menu Status Control and Firmware Update
If press "▲, ▼" key, then select sub title in functions.
The PICTURE Menu can be selected from the following 7 modes by pressing the ▲or ▼key.
PICTURE MENU
Picture Mode Adjust sate of the picture
Color Temperature Change color according to the color temperature
Aspect Ratio Change the aspect ratio
Noise Reduction Adjust noise attenuation of input signal
Screen Adjust the PC-RGB input signal to fit the screen
Color Range Setting the Color Expression Range

14
Installation and User's Guide
4. OSD MENU SETTIN
1) Picture Mode
Picture Mode can select 4 modes as Mild, Dynamic, Standard and User as shown in the figure
below. Press the "◀, ▶" key to change the mode.
Three of the four modes except for User mode are shipped with fixed values at the time of
shipment from the factory.
User mode can be set with “◀, ▶” keys by selecting each item below with “▲, ▼” key only
in the User mode.
2) Color Temperature
Color Temperature can select 4 modes as Cool, Medium, Warm and User as shown in the figure
below.
Three modes except User mode are factory shipped with factory default values, and
each color item (RED, GREEN, BLUE) is selected with the "▲, ▼" keys in the User mode only.
User settings are available.
Contrast Adjust difference in the color and brightness
Brightness Adjust the dark and light
Color Adjust for desired color intensity
Sharpness Adjust for best clarity of outline detail
Tint Adjust for natural flesh tones

15
Installation and User's Guide
4. OSD MENU SETTIN
3) Aspect Ratio
Aspect Ratio allows user to select the each aspect ratio as shown in the figure below.
(However, activated list is according to the input port and the input resolution.)
4) Noise Reduction
Noise Reduction can select 5 modes as Off, Low, Middle, High, Default as shown in the figure below.
5) Screen
Screen enables to set the active area of the display when using PC-RGB input port.
Auto Adjust is an item to be set automatically, and the input signal should be operated in the
signal state where the Outline has a lot of white color.

16
Installation and User's Guide
4. OSD MENU SETTIN
6) Color Range
Color Range sets the range of color expressions on the display.
(Press the “▶ SELECT” key to select either”0~255”, “16~235”)
The Option Menu can be selected from the following 6 modes by pressing the ▲or ▼key.
OPTION MENU
OSD Language Selectable OSD Menu Language
Blending Adjust blending for OSD Menu and Main window
OSD Duration Setting Duration time of OSD Menu
Restore Factory Default
Software Update(USB)
Key Lock Locking the button(prevent operation)
DPMS When input signal is the no signal, DPMS "on" change
the power saving mode.

17
Installation and User's Guide
4. OSD MENU SETTIN
1) OSD Language
As shown in the figure below, OSD Language can be selected by "▲, ▼" key.
2) Blending
OSD Menu Blending can select 4 modes as Off, Low, Middle, High by pressing the “▶ SELECT” key.
3) OsdDuration
OSD menu Duration can select 4 modes as 5, 10, 15Sec and Off by pressing the “▶ SELECT” key.
4) Restore Factory Default
Restore factory default can be selected by pressing the "▶SELECT" key. Select Yes or No by
the “◀, ▶" key.
5) Software Update(USB)
Software update default can be selected by pressing the "Menu" key. Select Yes or No by
the “◀, ▶" key.

18
Installation and User's Guide
4. OSD MENU SETTIN
6) Key Lock
Key lock default can be selected by pressing the "▶SELECT" key.
7) DPMS
The function can be activated(ON) or deactivated(OFF) with the button ▶.
Input Source can be selected from the following four input modes by using the ▲and ▼
keys when the window as shown below is displayed by pressing the "SOURCE / ▼" key
in the Main window.
(Input Source can be selected by ▲and ▼key when window shown as below. To be in this menu,
pressing the “SOURCE” / ▼" key in the Main window.)
Audio Volume can be increased or decreased by pressing "VOL- / ◀", "VOL + / ▶" Key.
INPUT SOURCE
AUDIO VOLUME

19
Installation and User's Guide
5. FEATURE
VMC-27LEDM VMC-32LEDM
Display
Screen Size 27.0 inches 31.55 inches
Resolution 1920*1080 1920*1080
Pixel Pitch 0.311*0.311 mm 0.364*0.364 mm
Brightness 250 cd/m² 400 cd/m²
Contrast Ratio 1000:1 1300:1
Aspect Ratio 16:9 16:9
Viewing Angle (H/V) 178/178 degrees 178/178 degrees
Display Color 16.7 million 16.7 million
Response Time 8 ms 8 ms
Video System NTSC/PAL NTSC/PAL
Panel Life Time (hours) 30,000 hours 50,000 hours
Interface
Video In/Out (BNC Type) 2/2 2/2
VGA In (15Pin D-Sub) 1 1
HDMI In 2 2
Audio In(RCA Type) 2 2
PC Stereo In 1 1
Audio Built in Speakers Y (1W*2) Y (7.5W*2)
Transmitter Remote Control Y Y
Special
Features
Filter Type 3D Comb filter 3D Comb filter
Deinterlacing Y Y
LCD Protection Glass Option Option
Noise reduction Y Y
Multi Lingual Language Eng, Spa, Fre, Ger, Ita Eng, Spa, Fre, Ger, Ita

20
Installation and User's Guide
5. FEATURE
Dimension Outline Dimension
(w Stand)
25.20*16.89*6.30”
640*429*160 mm
28.82*19.14*6.30”
732*486.3*160 mm
Cabinet Cabinet color/Base Stand
Cabinet Material
Black/Desktop Stand
Electro-Galvanized Steel
Black/Desktop Stand
Electro-Galvanized Steel
Power Electrical Ratings DC 12V, 5A AC 100~240V
(50/60Hz)
Circumstance
Operating Temperature 0~40 celsius 0~40 celsius
Storage Temperature -20~60 cesius -20~60 cesius
Mounts
VESA Mounts Size 100*100 / 200*100 mm 200*200 mm
Ceiling Mount CMK-01 CMK-01 with FMA-01
Wall WB-31, 2642 WB-2642
