Enerpac V17 User manual

Document Number: L4698
Document Revision: B
Document Revision Date: OCT-2022
Document Language: ENGLISH EN
Operation and Maintenance Manual
Check Valve
Enerpac V17
To reduce the risk of injury, user must read and understand this document before use.

Doc L4698_b 1
ABOUT US
Enerpac is a global market leader in high pressure
hydraulic tools, controlled force products, portable
machining, on-site services and solutions for precise
positioning of heavy loads. As a leading innovator with a
110-year legacy, Enerpac has helped move and maintain
some of the largest structures on earth. When safety and
precision matters, elite professionals in industries such as
aerospace, infrastructure, manufacturing, mining, oil & gas
and power generation rely on Enerpac for quality tools,
services and solutions. For additional information, visit
www.enerpac.com.
WARRANTY
Refer to the Enerpac Global Warranty document for terms and conditions of the product warranty. Such warranty
information can be found at www.enerpac.com.
NAMEPLATE
www.facebook.com/enerpac
www.youtube.com/enerpac
www.linkedin.com/company/enerpac
www.twitter.com/enerpac

2Doc L4698_b
Contents
1. SAFETY.......................................................................................................................................................... 3
1.1 SAFETY PRECAUTIONS ...................................................................................................................... 3
2. COMPLIANCE STATEMENT......................................................................................................................... 4
2.1 EU DECLARATION OF CONFORMITY ............................................................................................... 4
3. FEATURES & COMPONENTS ...................................................................................................................... 4
3.1 FEATURE DIAGRAM ............................................................................................................................. 4
4. TECHNICAL PRODUCT DATA...................................................................................................................... 5
4.1 DIMENSIONAL CALLOUT ART ............................................................................................................ 5
4.2 DIMENSIONAL TABLE.......................................................................................................................... 5
4.3 V17 DESCRIPTION................................................................................................................................ 5
4.4 V17 CAPABILITIES ................................................................................................................................ 5
5. OPERATION................................................................................................................................................... 5
6. PARTS LIST ................................................................................................................................................... 6
6.1 EXPLODED VIEW ................................................................................................................................. 6
6.2 TABLE OF PARTS.................................................................................................................................. 6

Doc L4698_b 3
1. Safety
1.1 Safety Precautions
Failure to observe and comply with the following
precautions could result in death or serious personal
injury. Property damage could also occur.
• Always wear protective head-wear, ear protectors,
footwear and gloves (at a minimum rigger type
gloves) suitable for safe operation of the tool.
The protective clothing must not interfere with
safe operation of the tool or restrict the ability to
communicate with co-workers.
• Be sure your workplace is safe. Follow the
instructions in your workplace’s standard
operating procedures and be sure to observe all
communicated safety precautions.
• V17 check valves are designed for a maximum
working pressure of 10,150 psi [700 bar]. Do not
exceed equipment ratings.
• The system operating pressure must not exceed
the pressure rating of the lowest rated component
in the system
• Make sure that all system components are
protected from external sources of damage, such
as excessive heat, flame, moving machine parts,
sharp edges, and corrosive chemicals.
• Always be sure that pump is stopped and all pressure
is fully relieved (0 psi/bar) before disconnecting
or connecting hydraulic hoses. The sudden and
uncontrolled release of pressurized oil could occur
if hoses are disconnected while under pressure.
• Never attempt to connect or disconnect hoses while
the pump is on and/or the system is pressurized.
• Be certain that all hose couplings are fully
connected at both the pump and cylinder couplers
before applying any hydraulic pressure. If the
couplings are not fully connected, oil flow will be
blocked, and the cylinder could be subjected to
excessive hydraulic pressures. Catastrophic failure
of cylinder could result.
• Always perform a visual inspection of the equipment
before placing it into operation. If any problems are
found, do not use it. Have the equipment repaired
and tested by an Enerpac Authorized Service
Center before it is returned to service.
• Never use a tool that is leaking oil. Do not use a
tool that is damaged, altered or in need of repair.
• Be sure the operator has completed safety induction
training, specific to the work surroundings. The
operator should be thoroughly familiar with the
controls and the proper use of the tool.
• The operator must be of at least the minimum age
required by applicable local regulations, laws and
the facility standard operating procedures.
• Take every precaution to prevent oil leaks from
occurring. High pressure oil leaks can penetrate
the skin, resulting in serious injury.
• Never strike the tool while it is pressurized or under
WARNING
Read all instructions carefully. Follow all recommended
safety precautions to avoid personal injury as well
as damage to the product and / or damage to other
property. Enerpac cannot be responsible for any
damage or injury from unsafe use, lack of maintenance,
or incorrect operation. Do not remove warning labels,
tags, or decals. In the event that any questions or
concerns arise, contact Enerpac or a local Enerpac
distributor for clarification.
Save these instructions for future use.
If you have never been trained on high-pressure
hydraulic safety, consult your distributor or service
center for information about Enerpac Hydraulic Safety
Courses.
This manual follows a system of safety alert symbols,
signals, words, and safety messages to warn the user of
specific hazards. Failure to comply with these warnings
could result in death or serious personal injury, as well
as damage to the equipment or other property.
The Safety Alert Symbol appears throughout
this manual. It is used to alert you to potential
physical injury hazards. Pay close attention
to Safety Alert Symbols and obey all safety
messages that follow this symbol to avoid the possibility
of death or serious injury.
Safety Alert Symbols are used in conjunction with certain
Signal Words that call attention to safety messages or
property damage messages and designate a degree or
level of hazard seriousness. The Signal Words used in
this manual are DANGER, WARNING, CAUTION, and
NOTICE.
Indicates a hazardous situation that, if not
avoided, will result in death or serious personal injury.
Indicates a hazardous situation that, if not
avoided, could result in death or serious personal injury.
Indicates a hazardous situation that, if not
avoided, could result in minor or moderate personal
injury.
Indicates information considered
important, but not hazard related (e.g. messages related
to property damage). Please note that the Safety Alert
Symbol will not be used with the signal word.
DANGER
WARNING
CAUTION
NOTICE

4Doc L4698_b
load. Components under tension may become
dislodged, allowing them to become dangerous
projectiles. Uncontrolled release of pressurized
hydraulic oil could also occur.
• Avoid striking the tool at any time, even when it is
not pressurized or under load. Striking the tool could
cause permanent damage to cylinder components
and may affect the cylinder calibration.
Failure to observe and comply with the following
precautions could result in minor or moderate
personal injury. Property damage could also occur.
• Be careful to avoid damaging hydraulic hoses.
Avoid sharp bends and kinks when routing hydraulic
hoses. Do not exceed the minimum bend radius
specified by the hose manufacturer. Using a bent
or kinked hose will cause severe backpressure.
Sharp bends and kinks will internally damage the
hose, leading to premature hose failure.
• Keep hydraulic equipment away from flames and
heat. Excessive heat will soften packings and
seals, resulting in fluid leaks. Heat also weakens
hose materials and packings.
• For optimum performance, do not expose hydraulic
equipment to temperatures of 150˚F [65˚C] or
higher. Protect all hydraulic equipment from weld
spatter.
• Immediately replace worn or damaged parts with
genuine Enerpac parts. Enerpac parts are designed
to fit properly and to withstand high loads. Non-
Enerpac parts may break or cause the product to
malfunction.
Failure to observe and comply with the following
precautions could result in property damage and/or
void the product warranty.
• Always use Enerpac pumps and hoses.
• Hydraulic equipment must only be serviced by a
qualified hydraulic technician. For repair service,
contact the Enerpac Authorized Service Center in
your area.
• To help ensure proper operation and best
performance, use of Enerpac oil is strongly
recommended.
CAUTION
NOTICE
2. Compliance State-
ment
2.1 EU Declaration of Conformity
Enerpac declares that this product has been tested and
conforms to applicable standards and is compatible
with all EU and UKCA requirements.
• V17
This tool conforms with
the requirements of CE
and UKCA
A copy of an EU Declaration as well as an UK Self-
Declaration are encclosed with each shipment.
3. Features & Com-
ponents
3.1 Feature Diagram
1. Spring
2. Ball Seat (in port)
3. Ball Seat (out port)
4. Body
5. Threaded protector (2)
6. Ball
Figure 1: Major Features and Components of V17

Doc L4698_b 5
4.2 Dimensional table
Dimension mm in
A 3/8" NPT
B 101 4
C 31 1.25
4.3 V17 Description
V17 is a one-way in-line check valve that controls
hydraulic pressure or oil flow.
These valves are used in conjunction with other valves
and system components to provide full automation and
control.
4.4 V17 Specifications
VALVE SPECIFICATIONS
Maximum operating pressure 700 bar 10,150 psi
Maximum oil flow 30 l/min 1,830 in³/min
Flow capacity 30 l/min 1,830 in³/min
Oil ports 3/8" NPT
5. Operation
In a hydraulic system, the V17 check valve is used to
block the flow in one direction while allowing free flow in
the opposite direction.
Refer to the flow direction shown in Figure 3.
4. Technical Product
Data
4.1 Dimensional Callout Art
A
B
C
A
Figure 2: V17 Check Valve Dimensions
IN
IN OUT
OUT
BALL
SPRING
Figure 3: V17 Check Valve Flow Direction

6Doc L4698_b
6. Parts List
Product Date Code Beginning With: A
6.1 Exploded View
Figure 4: V17 Exploded View
6.2 Table of Parts
Repair Parts List V17 - Refer to Figure 4
Item Description Qty. Part number
1 Spring 1 BL10983
2 Ball Seat (IN port) 1 BL60044
3 Ball Seat (OUT port) 1 BL60045
4 Body 1 BL60046
5 Gasket 1 P6037
6 Ball 1 B1015016
7 Threaded protector 1 Y809271

NOTES
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
7

www.enerpac.com
© 2023 Enerpac Tool Group, All Rights Reserved.
