Enfora Enabler IIG User manual

Transition Guide:
EDG0108TG001
Enfora Enabler IIG
To Enabler II-E Modem
Transition Guide
Rev. 1.00

Transition Guide
Ver. 1.00
Document Title: Enfora Enabler II-G to Enabler II-E Transition Guide
Version: Released
Date: 11/03/2005
Status: Released
Document Control ID: EDG0108TG001
General
All efforts have been made to ensure the accuracy of material provided in this document at the time of release.
However, the items described in this document are subject to continuous development and improvement. All
specifications are subject to change without notice and do not represent a commitment on the part of Enfora, Inc.
Enfora, Inc. will not be responsible for any loss or damages incurred related to the use of information contained in
this document.
This product is not intended for use in life support appliances, devices or systems where a malfunction of the
product can reasonably be expected to result in personal injury. Enfora, Inc. customers using, integrating, and/or
selling this product for use in such applications do so at their own risk and agree to fully indemnify Enfora, Inc. for
any damages resulting from illegal use or resale.
Copyright
Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under
copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or
transmitted in any form or by any means (electronic, mechanical, photocopying, recording or otherwise), or for any
purpose, without the express written permission of Enfora, Inc.
Enfora may have patents, patent applications, trademarks, copyrights or other intellectual property rights covering
subject matter in this document. Except as expressly provided in any written license agreement from Enfora, the
furnishing of this document does not give you any license to these patents, trademarks, copyrights or other
intellectual property.
©2002-2005 Enfora, Inc. All rights reserved.
Enabler and Spider are either registered trademarks or trademarks of Enfora, Inc. in the United States.

Transition Guide
Ver. 1.00
Table of Contents
1.0 MANUAL OVERVIEW..................................................................................................................................... 1
1.1 REVISION HISTORY............................................................................................................................................. 1
1.2 REFERENCE DOCUMENTS.................................................................................................................................... 1
2.0 INTRODUCTION............................................................................................................................................... 2
2.1 GENERAL COMMENTS......................................................................................................................................... 2
2.1.1 Test Specification Reference Material....................................................................................................... 2
2.1.2 Physical Dimension Differences ............................................................................................................... 2
2.1.3 Mounting Differences................................................................................................................................7
2.1.4 Interface Pin-out Differences.................................................................................................................... 7
3.0 ELECTRICAL CHANGES................................................................................................................................9
3.1 PIN 22 CHANGES............................................................................................................................................... 9
3.2 PIN 24 CHANGES ............................................................................................................................................... 9
3.3 USING THE SDK0107 DEVELOPMENT BOARD WITH THE EDG0108 MODULE ..................................................... 9
3.4 REGULATION AND COMPLIANCE DIFFERENCES ................................................................................................. 11
Enabler II-G GCF Approval (Formerly FTA)......................................................................................................... 11
Enabler II-E GCF and PTCRB Approval................................................................................................................ 11
Enabler II-G EMC/Safety Requirements for the Countries of the European Union (EU)....................................... 12
Enabler II-E EMC/Safety Requirements for the Countries of the European Union (EU)....................................... 12
Enabler II-E Assembly Requirements ..................................................................................................................... 12
3.5 RF POWER SPECIFICATIONS.............................................................................................................................. 13
4.0 SOFTWARE CHANGES................................................................................................................................. 14
4.1 NEW COMMANDS ............................................................................................................................................. 14
4.2 CHANGED COMMANDS ..................................................................................................................................... 14
4.3 COMMANDS NOT CURRENTLY IN USE............................................................................................................... 14
5.0 TABLES AND FIGURES................................................................................................................................. 15
6.0 CONTACTING ENFORA ............................................................................................................................... 15

Transition Guide
Ver. 1.00
EDG0108PB002 Page 1 Rev. 1.00 – 11/03/2005
1.0 Manual Overview
This document describes the differences between the Enfora Enabler II-G triple and quad band (GSM0107
and GSM0108) modems as they compare to the Enfora Enabler II-E EDGE (EDG0108) modem. This
document describes the hardware interface differences between the platforms as to streamline the process
of migrating solutions to the Enabler II-E EDGE technology.
1.1 Revision History
Date Rev Author Description
3/2/05 Draft Matt Glover Initial Draft.
3/12/05 Draft Matt Glover Added EGPRS Operating Power Rx values
3/15/05 Draft Matt Glover Added mechanical drawings
3/16/05 Draft Matt Glover Revised mechanical drawings
4/11/05 Draft Matt Glover Added Pin 22 and 24 changes/details
5/24/05 Draft Matt Glover Added Development Board diagram reference
11/03/05 Rel Matt Glover Added Section 4 (Software Changes)
1.2 Reference Documents
• GSM0107IG001 – Enabler II-G Triple-Band GSM/GPRS Radio Modem Integration Guide
• GSM0108IG001 – Enabler II-G Quad-Band GSM/GPRS Radio Modem Integration Guide
• EDG0108IG001 – Enabler II-E Quad-Band GSM/GPRS/EDGE Radio Modem Integration Guide

Transition Guide
Ver. 1.00
EDG0100TG001 Page 2 Rev. 1.00 – 11/03/2005
2.0 Introduction
2.1 General Comments
If you are integrating the GSM0107 or GSM0108 for the first time, please refer to the Enfora Enabler II-G
Triple-Band Radio Modem Integration Guide GSM0107IG001 or Enfora Enabler II-G Quad-Band Radio
Integration Guide GSM0108IG001 documents respectively. If you are integrating the EDG0108 for the first
time, please refer to the document Enfora Enabler II-E Quad-Band Integration Guide EDG0108IG003.
There are several items to consider when migrating from the GSM0107/GSM0108 to the EDG0108 platform.
The following areas should be understood completely prior to any migration effort. Each area will be
covered in detail in the following sections. The details provided are separated into Minor and Major impact
categories. Minor differences will require very few changes in a migration effort. Major differences will
impact a design in a somewhat substantial way and should be researched thoroughly for any transition
project.
Major differences
 Power Consumption
Minor differences
 Interface pin-out (Minor)
 Slight mechanical differences
2.1.1 Test Specification Reference Material
 GSM Test Specification
 3GPP TS 51.010-1
2.1.2 Physical Dimension Differences
There are some minor dimensional changes between the EDG0108 and GSM0107/GSM0108
modules. The following drawings provide the differences.
EDG0108 Module Mechanical Notes
• Mated 60-pin I/O connector stack height is 2.0 MM
• 60-pin connector is Molex 53729-0608 (this is the same module connector used on current
designs). The PCB mating connector, Molex 52974-0604, is the same as in prior designs.
• The RF connector is Sunridge MCB-ST-00T or approved equivalent. Mates with Sunridge MCB2
series cable assembly

Transition Guide
Ver. 1.00
EDG0100TG001 Page 3 Rev. 1.00 – 11/03/2005
Figure 1 - EDG0108 Mechanical – without SIM carrier

Transition Guide
Ver. 1.00
EDG0100TG001 Page 4 Rev. 1.00 – 11/03/2005
Figure 2 - EDG0108 Mechanical - with SIM carrier

Transition Guide
Ver. 1.00
EDG0100TG001 Page 5 Rev. 1.00 – 11/03/2005
Figure 3 - GSM0107/GSM0108 Mechanical – without SIM carrier
Figure 4 - GSM0107/GSM0108 Mechanical - with SIM carrier

Transition Guide
Ver. 1.00
EDG0100TG001 Page 6 Rev. 1.00 – 11/03/2005

Transition Guide
Ver. 1.00
EDG0100TG001 Page 7 Rev. 1.00 – 11/03/2005
2.1.3 Mounting Differences
The mounting hole that existed on the GSM0107/GSM0108 is no longer present on the EDG0108. The
solder tab positions on the EDG0108 are backward compatible with the GSM0107/GSM0108.
2.1.4 Interface Pin-out Differences
The following table provides differences between the existing GSM0107/0108 modules and the new
EDG0108 platform. The pins that have changed will be detailed in sections immediately following the chart.
GSM0107/0108 EDG0108
Name Description
Pin
Name
Type
Description
BATT Battery/Vcc
1 BATT PI Battery/Vcc
BATT Battery/Vcc
2 BATT PI Battery/Vcc
BATT Battery/Vcc
3 BATT PI Battery/Vcc
BATT Battery/Vcc
4 BATT PI Battery/Vcc
BATT Battery/Vcc
5 BATT PI Battery/Vcc
BATT Battery/Vcc
6 BATT PI Battery/Vcc
GND Ground 7 GND PR Ground
GND Ground 8 GND PR Ground
INTERNAL_SPK(–) Handset Speaker (-) 9 INTERNAL_SPK(–) O Handset Speaker (-)
BATT Battery/Vcc
10 BATT PI Battery/Vcc
GND Ground 11 GND PR Ground
BATT Battery/Vcc
12 BATT PI Battery/Vcc
INTERNAL_SPK(+) Handset Speaker (+) 13 INTERNAL_SPK(+) O Handset Speaker (+)
GPIO-1 General Purpose I/O 14 GPIO-1 IO General Purpose Input-Output
GND Ground 15 GND PR Ground
GND Ground 16 GND PR Ground
VMIC Microphone Bias
17 VMIC O Microphone Bias
GPIO-5 General Purpose I/O 18 GPIO-5 IO General Purpose Input-Output
GND Ground 19 GND PR Ground
Reserved Reserved for future use 20 Reserved Reserved for future use
INT_MIC(–) Handset Microphone
(Negative) 21 INT_MIC(–) I Handset Microphone (Negative)
PWRDN_RADIO Radio Power Down/
Remote ON 22 RESET I Module Reset
GND Ground 23 GND PR Ground
GND
PWR_CTL_SIGNAL Ground (0107)
Power Control Signal
(0108)
24 PWR_CTL_SIGNAL I Power Control Signal
INT_MIC(+) Handset Microphone (+) 25 INT_MIC(+) I Handset Microphone (Positive)
Reserved Reserved for future use 26 Reserved Reserved for future use
GPIO-3 General Purpose I/O 27 GPIO-3 IO General Purpose Input-Output
GPIO-2 General Purpose I/O 28 GPIO-2 IO General Purpose Input-Output
Reserved Reserved for future use 29 Reserved Reserved for future use
GPIO-4 GPIO/MCSI TX
30 GPIO-4 IO GPIO/MCSI TX
Reserved Reserved for future use 31 Reserved Reserved for future use
GPIO-6 GPIO/MCSI RX
32 GPIO-6 IO GPIO/MCSI RX
GND Ground 33 GND PR Ground
GPIO-7 GPIO/MCSI CLK
34 GPIO-7 IO GPIO/MCSI CLK
DAC Digital to Analog Output 35 DAC O Digital to Analog Output
VBACKUP Vcc for Real-Time-Clock 36 VBACKUP P Vcc for Real-Time-Clock
Reserved Reserved for future use 37 Reserved Reserved for future use
HEADSET_SPK(+) Headset Earphone (+) 38 HEADSET_SPK(LE
FT) (+) O Stereo Headset Earphone – Left (Positive)
GPIO-8 GPIO/MCSI FSNC
39 GPIO-8 IO GPIO/MCSI FSNC
HEADSET MIC (-) Headset Microphone (-) 40 CLK_OUT_ENABLE O Enable Output Clocks
GND Ground 41 GND PR Ground
HEADSET_MIC(+) Headset Microphone (+) 42 HEADSET_MIC (+) I Headset Microphone (Positive)
RXD_RADIO Serial Data to Host 43 RXD_RADIO O Serial Data to Host
GND Ground 44 GND PR Ground

Transition Guide
Ver. 1.00
EDG0100TG001 Page 8 Rev. 1.00 – 11/03/2005
GSM0107/0108 EDG0108
Name Description
Pin
Name
Type
Description
DSR_RADIO DSR to Host 45 DSR_RADIO O DSR to Host
ADC2 A to D Input 46 ADC2 I A to D Input
DCD DCD to Host 47 DCD O DCD to Host
SIM_CLK SIM Clock 48 SIM_CLK O SIM Clock
RI Ring Indicator
49 RI O Ring Indicator
GND Ground 50 GND PR Ground
TXD_RADIO Serial Data from Host 51 TXD_RADIO I Serial Data from Host
SIM_IO SIM Data 52 SIM_IO IO SIM Data
RTS_RADIO RTS to Host 53 RTS_RADIO I RTS to Host
SIM_RST SIM Reset 54 SIM_RST O SIM Reset
CTS_RADIO CTS to Host 55 CTS_RADIO O CTS to Host
ADC1 A to D Input 56 ADC1 I A to D Input
DTR_RADIO DTR to Host 57 DTR_RADIO O DTR to Host
SIM_VCC SIM Power 58 SIM_VCC O SIM Power
GND Ground 59 GND PR Ground
GND Ground 60 GND PR Ground
Table 1 - Enabler II-G/Enabler II-E Pin Assignment Comparison
I=Input into Enabler; O=Output from Enabler; P=Power Input to Enabler; R=Power Return from Enabler;
I/O=Input/Output into/from Enabler

Transition Guide
Ver. 1.00
EDG0100TG001 Page 9 Rev. 1.00 – 11/03/2005
3.0 Electrical Changes
3.1 PIN 22 Changes
GSM0107/0108 Radio Power Down/
Remote ON I High = Module Run
Float = Module Run
Low = Module OFF
On GSM0107/0108, the
PWRDN_RADIO input controlled an
internal power switch that physically
disconnected power to a majority of the
module.
22
EDG0108 Module Reset I
High Pulse = Module Reset
Float = No reset;
Low = No reset;
On EDG0108, this pin (22) is now a
“module hardware reset input”. This
input is “active high”. It can be left
floating if the user does not want to
control “reset” or grounded. To reset, a
high-pulse of at least 50 mS will
reset/restart the module.
• If GSM0107/0108 customer had
this pin pulled high with resistor,
don’t stuff resistor and it will work
for all designs.
• If GSM0107/0108 customer was
using this pin for power control,
they should use Pin-24 (below).
3.2 PIN 24 Changes
GSM0107 Ground (0107) PR
GSM0108
Power Control Signal
(0108) I
Currently this input can only be used to
turn the module ON. Code to turn the
module OFF is not in the standard
software release.
The Power Control Signal was added to
GSM0108.
24
EDG0108 Power Control Signal
I
When the modem is OFF, a high-to-low
pulse of > 100 mS will turn the modem
ON.
When the modem is ON, a high-to-low
pulse of > XXX mS will deregister from
the network and turn the modem OFF.
XXX is > 100 mS and can be configured
via AT Command for pulses up to 10,000
mS.
The Power Control Signal is equivalent to
a “Phone ON Button”.
This is a hardware-controlled pin on
power-up. It must be grounded
momentarily or continuously to start the
modem.
Subsequent signals to this pin (active
high-to-low transition) will cycle power to
the module.
3.3 Using the SDK0107 Development Board with the EDG0108 Module
The existing Enabler II-G development board, SDK0107, can be used with the new EDG0108 module. Due
to the minor pin changes, certain procedures will need to be followed for proper operation.

Transition Guide
Ver. 1.00
EDG0100TG001 Page 10 Rev. 1.00 – 11/03/2005
SW204
SW203
J208
SW201
Figure 5 - SDK0107 Block Diagram
There are two ways to control the power sequence using the combination of the development board and the
module.
The first method is to place SW203 in the OFF position. Apply power to the SDK and the module will turn on
and off with SW201.
The second method is to remove the jumper from J208 and use SW204 to turn the module on. Make sure
SW201 is in the ON position.

Transition Guide
Ver. 1.00
EDG0100TG001 Page 11 Rev. 1.00 – 11/03/2005
3.4 Regulation and Compliance Differences
Enabler II-G GCF Approval (Formerly FTA)
The Enfora Enabler II-G module is type approved in accordance with the requirements of
and through the procedures set forth by the GSM industry association. The relevant
conformance specification is GSM 11.10-1 for GSM 850, 900, and 1800 MHz devices.
For PCS 1900 MHz devices, the relevant standard is PCS 11.10, a version of GSM 11.10-
1 that has been modified as appropriate for the North American GSM market. For
applications that use an unmodified version of the Enfora Enabler II-G module, further
testing in this area may not be required. Any OEM changes in the SIM interface, antenna
port, software or the physical makeup of the unit may require an incremental FTA to
ensure continued compliance with the above-mentioned standards. For more information
concerning type approval, please contact Enfora.
Enabler II-E GCF and PTCRB Approval
The Enfora Enabler II-E module is type approved in accordance with the requirements of
and through the procedures set forth by the GSM industry association. The relevant
conformance specification is TS 51.010-1. For applications that use an unmodified
version of the Enfora Enabler II-E module, further testing in this area may not be required.
Any OEM changes in the SIM interface, antenna port, software or the physical makeup of
the unit may require an incremental delta FTA to ensure continued compliance with the
above-mentioned standard. For more information concerning type approval, please
contact Enfora.

Transition Guide
Ver. 1.00
EDG0100TG001 Page 12 Rev. 1.00 – 11/03/2005
Enabler II-G EMC/Safety Requirements for the Countries of the European Union (EU)
The European Union (EU) is comprised of fifteen countries that follow a harmonized set of
standards, utilizing the CE mark as a uniform mark of acceptance. The member countries
are:
• Austria
• Belgium
• Denmark
• Finland
• France
• Germany
• Greece
• Ireland
• Italy
• Luxembourg
• The Netherlands
• Portugal
• Spain
• Sweden
• United Kingdom
Enabler II-E EMC/Safety Requirements for the Countries of the European Union (EU)
The European Union (EU) is comprised of more than fifteen countries that follow a
harmonized set of standards, utilizing the CE mark as a uniform mark of acceptance. The
member countries are:
Austria Belgium Cyprus*
Czech Republic* Denmark Estonia*
Finland France Germany
Greece Hungary* Ireland
Italy Latvia* Lithuania*
Luxembourg Malta* The Netherlands
Poland* Portugal Slovakia*
Slovenia* Spain Sweden
United Kingdom
* As of May 1st 2004
Enabler II-E Assembly Requirements
The Enabler II-E is designed using integrated circuits that support lead-free requirements.
The modem is assembled using a lead-free assembly process.

Transition Guide
Ver. 1.00
EDG0100TG001 Page 13 Rev. 1.00 – 11/03/2005
3.5 RF Power Specifications
!
Note that the RF power specifications are not the
same. Refer to the EDG0108PB003MAN for the latest
specifications.

Transition Guide
Ver. 1.00
EDG0100TG001 Page 14 Rev. 1.00 – 11/03/2005
4.0 Software Changes
4.1 New Commands
+CGDSCONT – Define Secondary PDP Context
+CGEQREQ – 3G Quality of Service Profile (Request)
+CGEQMIN - 3G Quality of Service Profile
+CGEQNEG – 3G Quality of Service Profile
+CGCMOD – PDP Context Modify
+CGTFT – Traffic Flow Template
+CSIM – Generic SIM Access
+CIND – Indicator Control
+CMER – Mobile Termination Event Reporting
+CKPD – Keypad Control
$CGEER – Get PDP context Activation Reject
%CLCC – List Current Calls
%VTS – DTMF and Tone Generation
%CHPL – Network Operator
%CREG - Extended Network Registration Info
%CMGRS – Retransmit Failed Message
%CSCN – network Service Change Notifications
%RDL – Redial Mode
%RDLB – Redial Black List Phone Numbers
%CSTAT – Unsolicited SIM Status
%CHLD – Call Hold and Multiparty
%CPRSM – Pause Receiving of SMS
%CPKY – Press Key Mode
%CKWP – Key Was Pressed
%CNIV – Network Identity Report
%PVRF – PIN Status
%CWUP – Force Power Campaign
%SIMIND – SIM Status Indication
%CSSN – Extended Supplementary Service
%COPS – Extended Operator Selection
%CGEREP – Extended GPRS Event Reporting
4.2 Changed Commands
%CGPCO – Set the GPRS Protocol Configuration
4.3 Commands Not Currently in Use
Input/Output Commands
UDP API Commands
Dynamic IP/Wakeup-Keep Alive Commands
PAD Commands
Event Processing Commands
Real-Time Clock Commands
$HOSTIF – Configure Host to Modem Interface
$CONN – Initiate Network Connection
$DISC – Disconnect Network Connection
$LOCIP – Display Local Modem to Host IP and DNS
$NETIP – Display Network Assigned IP and DNS
$SNDMSG – Send Test Message

Transition Guide
Ver. 1.00
EDG0100TG001 Page 15 Rev. 1.00 – 11/03/2005
5.0 Tables and Figures
TABLES
Table 1 - Enabler II-G/Enabler II-E Pin Assignment Comparison.................................................................... 8
FIGURES
Figure 1 - EDG0108 Mechanical – without SIM carrier................................................................................... 3
Figure 2 - EDG0108 Mechanical - with SIM carrier......................................................................................... 4
Figure 3 - GSM0107/GSM0108 Mechanical – without SIM carrier.................................................................. 5
Figure 4 - GSM0107/GSM0108 Mechanical - with SIM carrier ....................................................................... 5
Figure 5 - SDK0107 Block Diagram...............................................................................................................10
6.0 Contacting Enfora
Please use the following contact information for customer or technical support questions.
Customer Support
http://www.enfora.com/support
Internet www.enfora.com
North America Enfora, Inc.
661 E. 18th Street
• Plano, TX 75074
