ENH200EXT LONG RANGE WIRELESS 11N OUTDOOR CB/AP
• IEEE802.11/b/g/n
• 1T+1R
• 150Mbps
• High Performance
Learn more about EnGenius Solutions at www.engeniustech.com.sg
BUSINESS CLASS
ENH200EXT
ENH200EXT Datasheet Version 120711
* Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
OVERVIEW
ENH200EXT Wireless Outdoor unit provides not only a external antenna
connector for antenna upgrade, but also high output power and high
sensitivity can extend the transmission range to deliver a stable wireless
connection. ENH200EXT integrates 4 operation modes: Access Point, Client
Bridge, Client Router and WDS.
Advanced multi-function operation modes offer flexibility in constructing
scalable wireless networks for all possible applications. ENH200EXT is
designed to deliver reliable service under harsh outdoor environment with
certified IP65 protection and tailored to accommodate multimedia
streaming services with data-rate up to 150Mbps. Most importantly, it is
built-in encryption standards (WEP, WPA, WPA2, TKIP/AES and
IEEE802.1x) ensure maximum security and compatibility.

Learn more about EnGenius Solutions at www.engeniustech.com.sg
Datasheet
ENH200EXT
BUSINESS CLASS
ENH200EXT
ENH200EXT Data sheet Version 120711
* Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
SPECIFICATIONS
MCU Atheros AR7240
RF Atheros AR9285
Memory 32MB
Flash 8MB
Standard IEEE 802.11 b/g/n
Physical Interface
- 1 x RJ-45 Port with PoE support
- 1 x SMA connector
- 1 x Reset
Data rate 150 Mbps
LEDs status - Power Status
- LAN (10/100Mbps)
FEATURES
SPECIFICATIONS
High output power Transmit high output power programmable for different country selections
High Data Rate High speed transmitting rate up to 150Mbps with 1T1R 802.11n
Long range transmitting Transmit power control and distance control (ACK timeout)
Signal Strength Display RF signal strength status shown LEDs of 3 colors, making network build-up easier. LED
indicators have the best transmit and receive signal for traffic communication
Multiple SSID 4 SSID supported. Each SSID can set itself wireless or WAN access setting
NETWORKING
Narrow Bandwidth Provide different bandwidth selection (5MHz/10MHz/20MHz/40MHz) for wireless
communication
PPPoE Point-to-Point Protocol over Ethernet at Client Router mode. This function will keep trying
when failed or disconnected
PPTP Point-to-Point Tunneling Protocol (PPTP) is a method for implementing virtual private
networks
802.11i & 802.1x WPA, WPA2 & IEEE802.1x Authenticator
MANAGEMENT
Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade
Reset & Backup Reset to factory default. User can export all setting into a file via WEB
Ping & Trace Route Built-in PING function & Trace Route function in Web GUI
MIB MIB I, MIB II(RFC1213), Private MIB
SNMP V1, V2c

Learn more about EnGenius Solutions at www.engeniustech.com.sg
Datasheet
ENH200EXT
BUSINESS CLASS
ENH200EXT
ENH200EXT Data sheet Version 120711
* Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
- WLAN (Wireless is up)
- 3 x Link Quality (Client Bridge mode)
Security
- WEP Encryption-64/128/152 bit
- WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
- WPA/WPA2 Enterprise (WPA-EAP using TKIP)
- 802.1x Authenticator
- Hide SSID in beacons
- MAC address filtering, up to 50 field
- Wireless STA (Client) connected list
Power Requirements
- Active Ethernet (Power over Ethernet)
- Proprietary PoE design
- Power Adapter 24VAC / 0.6A
Antenna 1 x external SMA connector
Certifications FCC, CE, IC
RADIO FREQUENCY BAND
Channel Tx Avg. Power
Optimal (dBm)
Rx Sensitivity
Optimal (dBm)
802.11b(2.412 ~ 2.472GHz)
1Mbps 27 -97
2Mbps 27 -95
5.5Mbps 27 -92
11Mbps 27 -89
802.11g(2.412 ~ 2.472GHz)
6Mbps 26 -96
9Mbps 26 -93
12Mbps 26 -89
18Mbps 26 -85
24Mbps 25 -81
36Mbps 24 -79
48Mbps 23 -76
54Mbps 22 -75
6Mbps 26 -96
802.11n(2.412 ~ 2.472GHz)
MCS0 / MCS8 26 -95
MCS1 / MCS9 26 -92
MCS2 / MCS10 26 -87
MCS3 / MCS11 26 -85
MCS4 / MCS12 24 -80

Learn more about EnGenius Solutions at www.engeniustech.com.sg
Datasheet
ENH200EXT
BUSINESS CLASS
ENH200EXT
ENH200EXT Data sheet Version 120711
* Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
MCS5 / MCS13 23 -79
MCS6 / MCS14 22 -74
MCS7 / MCS15 21 -73
ENVIRONMENT & MECHANICAL
Operating -20°C ~ 70°C
Storage -30°C ~ 80°C
Temperature Range
Humidity (non-condensing)
0%～90 % typical
Waterproof IP65
PACKAGE CONTENTS
►Wireless Long Range 11N CB/AP(ENH200EXT)
►PoE Injector (EPE-24R)
►Power Adaptor
►CD with User’s Manual
►QIG
►Mounting Set
►Special screw set
