EnGenius ENS500EXT User manual

WIRELESS 11N LONG RANGE OUTDOOR AP / CB
ENS500EXT User Guide
V1.0

TABLE OF CONTENTS
I
TABLE OF CONTENTS
Conventions 0-vi
Copyright 0-viii
Product Overview
Package Contents 1-1
Product Overview 1-2
Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Hardware Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Software Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Environment & Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Wireless Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Product Layout 1-6

TABLE OF CONTENTS
II
Installation
System Requirements 2-1
Installing the Device 2-2
Pre-Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Installing the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Web Configuration
Logging In 3-1
Best Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Basic Network Settings
System Status 4-1
Using Save/Reload 4-1
Viewing System Information 4-2
Viewing Wireless Client List 4-4
Viewing System Log 4-5
Viewing Connection Status 4-6
Viewing DHCP Client Table 4-7
Viewing WDS Link List 4-8

TABLE OF CONTENTS
III
System Setup 4-9
Configuring Operation Mode 4-9
Configuring IP Settings 4-10
Configuring Spanning Tree Settings 4-11
Router Setup 4-12
Configuring WAN Settings 4-12
Static IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12
Dynamic IP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13
Point-to-Point Protocol over Ethernet (PPPoE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-14
Point-to-Point Tunnelling Protocol (PPTP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-15
Configuring LAN Settings 4-17
Configuring VPN Pass-Through 4-18
Configuring Port Forwarding 4-19
Configuring Demilitarized Zone 4-21
Configuring Wireless LAN 4-22
Configuring Wireless Settings 4-22
Access Point Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-22
Client Bridge Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24
WDS Bridge Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Client Router Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-27

TABLE OF CONTENTS
IV
Configuring Wireless Security 4-28
Wired Equivalent Privacy (WEP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-28
Wi-Fi Protected Access Pre-Shared Key (WPA-PSK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Wi-Fi Protected Access 2 Pre-Shared Key (WPA2-PSK). . . . . . . . . . . . . . . . . . . . . . . . . .4-30
Wi-Fi Protected Access Pre-Shared Key (WPA-PSK) Mixed . . . . . . . . . . . . . . . . . . . . . . .4-31
Wi-Fi Protected Access (WPA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Wi-Fi Protected Access 2 (WPA2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-33
Wi-Fi Protected Access (WPA) Mixed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-34
Configuring Wireless MAC Filter 4-35
Configuring WDS Link Settings 4-36
Configuring Wireless Advanced Settings 4-37
Wireless Traffic Shaping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37
Client Limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38
Management Setup 4-39
Configuring Administrator Account 4-39
Configuring Management VLAN 4-40
Configuring SNMP 4-41
Configuring Backup/Restore Settings 4-43
Configuring Auto Reboot Settings 4-44
Configuring Firmware Upgrade 4-45
Configuring System Time 4-46

TABLE OF CONTENTS
V
Configuring Wi-Fi Schedule 4-47
Add a Schedule Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-47
Schedule Services Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-48
Configuring Command Line Interface 4-49
Configuring Logging 4-50
Configuring Diagnostics 4-51
Viewing Device Discovery 4-52
Configure Denial of Service Protection 4-53
Logging Out 4-54
Appendix A
Federal Communication Commission Interference Statement A-1
Appendix B
Industry Canada Statement B-1
Appendix C
WorldWide Technical Support C-1

CONVENTIONS
VI
Conventions
The following conventions are used to give the user additional
information about specific procedures or content. It is important
to pay attention to these conventions as they provide informa-
tion to prevent damage to equipment or personal injury.
General Conventions
The following general conventions are used in this document.
N/A:
Indicates that a component or a procedure is not applica-
ble to this model.
Prerequisite:
Indicates a requirement that must be addressed before
proceeding with the current function or procedure.
CAUTION!
CAUTIONS APPEAR BEFORE THE TEXT IT REFERENCES. CAU-
TIONS APPEAR IN CAPITAL LETTERS TO EMPHASIZE THAT THE
MESSAGE CONTAINS VITAL HEALTH AND SAFETY INFORMATION.
WARNING!
Warning information appears before the text it references
to emphasize that the content may prevent damage to the
device or equipment.
Important:
Indicates information that is important to know for the
proper completion of a procedure, choice of an option, or
completing a task.
Note:
Indicates additional information that is relevant to the cur-
rent process or procedure.
!
!
Example:
Indicates information used to demonstrate or explain an
associated concept.

CONVENTIONS
VII
Typographical Conventions
The following typographical conventions are used in this docu-
ment:
Italics
Indicates book titles, directory names, file names, path names,
and program/process names.
Constant width
Indicates computer output shown on a computer screen, includ-
ing menus, prompts, responses to input, and error messages.
Constant width bold
Indicates commands lines as entered on the computer. Vari-
ables contained within user input are shown in angle
brackets (< >).
Bold
Indicates keyboard keys that are pressed by the user.

COPYRIGHT
VIII
Copyright
This user guide and its content is copyright of © EnGenius Net-
works, 2012. All rights reserved.
Any redistribution or reproduction in part or in whole in any form
is prohibited.
Do not distribute, transmit, store in any form of electronic
retrieval system or commercially exploit the content without the
expressed written permission of EnGenius Networks.

Product Overview
Chapter 1

PRODUCT OVERVIEW PACKAGE CONTENTS
1-1
1.1 Package Contents
ENS500EXT
Quick Start Guide
Technical Support Card
Pole Mounting Strap x2
Wall Mounting Screw Set
PoE Injector (EPE-1212) with Power Adapter
Two detachable 5 dBi high gain omni-directional antennas

PRODUCT OVERVIEW PRODUCT OVERVIEW
1-2
1.2 Product Overview
The ENS500EXT Wireless Outdoor unit provides not only
detachable antenna connectors for antenna upgrade, but also
high output power and high sensitivity can extend the transmis-
sion range to deliver a stable wireless connection. ENS500EXT
integrates 4 operation modes: Access Point, Client Bridge, Cli-
ent Router and WDS.
Advanced multi-function operation modes offer flexibility in con-
structing scalable wireless networks for all possible applica-
tions. ENS500EXT is designed to deliver reliable service under
harsh outdoor environment with certified IP65 protection and
tailored to accommodate multimedia streaming services with
data-rate up to 300Mbps. Most importantly, it is built-in encryp-
tion standards (WEP, WPA, WPA2, TKIP/AES and IEEE802.1x)
ensure maximum security and compatibility.
Hardware Features
High output power: Transmit high output power pro-
grammable for different country selections
High Data Rate: High speed transmitting rate up to
300Mbps with 2T2R 802.11n
Long range transmitting: Transmit power control and
distance control (ACK timeout)
Signal Strength Display: Indicate RF signal strength to
be shown as LEDs of 3 colors, making network build-up
easier. LED indicators have the best transmit and receive
signal for traffic communication
PoE Support: Support proprietary 24V passive power
over Ethernet
Software Features
Multiple SSID: 4 SSID supported. Each SSID can set
itself wireless or WAN access setting
PPPoE: Point-to-Point Protocol over Ethernet at Client
Router mode. This function will keep trying when failed or
disconnected
PPTP: Point-to-Point Tunneling Protocol (PPTP) is a
method for implementing virtual private networks
VLAN Pass-through: Support VLAN Pass-through
Firmware Upgrade: Upgrading firmware via web
browser, setting are reserved after upgrade
Reset & Backup: Reset to factory default. User can
export all setting into a file via WEB
Ping & Trace Route: Built-in PING function & Trace
Route function in Web GUI
MIB: MIB I, MIB II(RFC1213), Private MIB
SNMP: V1, V2c, V3

PRODUCT OVERVIEW BENEFITS
1-3
Benefits
The ENS500EXT is the ideal product around which you can
build your WLAN. The following list summarizes a few key
advantages that WLANs have over wired networks:
Ideal for hard-to-wire environments
There are many scenarios where cables cannot be used to con-
nect networking devices. Historic and older buildings, open
areas, and busy streets, for example, make wired LAN installa-
tions difficult, expensive, or impossible.
Temporary workgroups
WLANs make it easy to provide connectivity to temporary work-
groups that will later be removed. Examples include parks, ath-
letic arenas, exhibition centers, disaster-recovery shelters,
temporary offices, and construction sites.
Ability to access real-time information
With a WLAN, workers who rely on access to real-time informa-
tion, such as doctors and nurses, point-of-sale employees,
mobile workers, and warehouse personnel, can access the data
they need and increase productivity, without having to look for a
place to plug into the network.
Frequently changed environments
WLANs are well suited for showrooms, meeting rooms, retail
stores, and manufacturing sites where workplaces are rear-
ranged frequently.
Wireless extensions to Ethernet networks
WLANs enable network managers in dynamic environments to
minimize overhead caused by moves, extensions to networks,
and other changes.
Wired LAN backup
Network managers can implement WLANs to provide backup
for mission-critical applications running on wired networks.
Mobility within training/educational
facilities
Training sites at corporations and students at universities are a
few examples where wireless connectivity can be used to facili-
tate access to information, information exchanges, and learn-
ing.

PRODUCT OVERVIEW TECHNICAL SPECIFICATION
1-4
Technical Specification
Hardware Specification
Physical Interface:
2 x RJ-45 for 10/100 Fast Ethernet; one port is compat-
ible with PoE
1 x Reset Button
Power Requirements:
Active Ethernet (Power over Ethernet)
Proprietary PoE design
Power Adapter 24V / 0.6A
Software Specification
Operation Mode: Client Bridge, Access Point, Client
Router, WDS AP, WDS Bridge, WDS Station
Wireless/Network:
Auto Channel Selection (Setting varies by Regular
Domains)
Obey Regulatory Power
Distance Control (802.1x ACK (acknowledgement)
timeout)
CLI Supported
802.1x Supplicant (CB Mode)
4 SSIDs
WDS AP / WDS Bridge / WDS Station
Multicast Supported
RADIUS Accounting
VLAN Tag / VLAN Pass-through
Auto Reboot
WiFi Scheduling
Security:
WEP Encryption-64/128/152 bit
WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
WPA/WPA2 Enterprise (WPA-EAP using TKIP)
Hide SSID in beacons
MAC address filtering, up to 50 field
Wireless STA (Client) connected list
QoS: WMM
Environment & Mechanical
Temperature Range:
Operating -20°C~70°C
Storage -30°C to 80°C
Humidity (non-condensing): 0%~90% typical
Dimensions

PRODUCT OVERVIEW TECHNICAL SPECIFICATION
1-5
with antenna: 100mm (4”) x 37.5mm (1.375””) x
205mm (8”) (W x D x H)
without antenna: 100mm (4”) x 37.5mm (1.37”) x
189mm (7.375”) (W x D x H)
Weight
with antenna: 242g (0.11 lbs) ± 2g
without antenna: 275g (0.125lbs) ±2g
Wireless Specification
Frequency Band: 802.11a/n
Data rate: 300 Mbps
Antenna: 2 x Detachable SMA Connector
Note:
The maximum power of the radio frequency band may
be different depending on local regulations.

PRODUCT OVERVIEW PRODUCT LAYOUT
1-6
1.3 Product Layout
Figure 1-1: Back Panel View
AB C D
E
BACK PANEL VIEW DESCRIPTION
A Power LED OFF = ENS500EXT is not receiving power
ON = ENS500EXT is receiving power
B LAN (2) LEDs
OFF = ENS500EXT is not connected to the
network.
ON = ENS500EXT is connected to the
network, but not sending or receiving data
Blink = ENS500EXT is sending or receiving
data
CWLANLED
(Access Point or Client Bridge Mode)
OFF = ENS500EXT radio is off and the
device is not sending or receiving data over
the wireless LAN.
ON = ENS500EXT radio is on, and the
device is not sending or receiving data over
the wireless LAN.
Blinking = ENS500EXT radio is on, and the
device is sending or receiving data over the
wireless LAN.
D Signal Indicator LED
(Client Bridge, WDS Station and Client
Router Mode)
Green - Signal is good
Orange - Signal is normal
Red - Signal is weak or non-existent
E Antenna Connectors

PRODUCT OVERVIEW PRODUCT LAYOUT
1-7
BOTTOM VIEW DESCRIPTION
A Reset Button To reset to factory settings, press button for >
10 seconds.
B LAN Connector
To configure the ENS500EXT, connect an
Ethernet cable to an Ethernet adapter on a
computer. For more information about
configuring individual features, see Logging
In.
C PoE LAN Connector The PoE interface allows the ENS500EXT to
be powered using the supplied PoE injector
AB C

Installation
Chapter 2

INSTALLATION SYSTEM REQUIREMENTS
2-1
2.1 System Requirements
To install the ENS500EXT, you need the following:
Computer (Windows, Linux, Mac OS X Operating System)
Web Browser (Internet Explorer, FireFox, Chrome, Safari)
Network Interface equipped: (one of the following)
Wired connectivity: Network Interface with an open
RJ-45 Ethernet Port
Wireless Connectivity:
Embedded 802.11n Wi-Fi wireless networking, IEEE
802.11a/n compatible
Wi-Fi Card, USB Wi-Fi Dongle (802.11 a/n)
An existing router or access point (AP) with SSID broad-
cast
1x CAT5e Ethernet Cable

INSTALLATION INSTALLING THE DEVICE
2-2
2.2 Installing the Device
Installing the ENS500EXT on a pole or wall optimizes the wire-
less access range.
Pre-Installation Guidelines
Select the optimal location for the equipment using the following
guidelines:
The ENS500EXT should be mounted on a pole 1" to 4"
(2.54cm to 10.16cm) in diameter. Its location should
enable easy access to the unit and its connectors for
installation and testing.
The higher the placement of the antenna, the better the
achievable link quality.
The antenna should be installed to provide a direct, or
near line of sight with the Base Station antenna. The
antenna should be aligned to face the general direction of
the Base Station.
Installing the Device
To install the ENS500EXT, use the following procedure to
mount the device on a pole and refer to the figure below.
1. Remove the bottom cover protecting the RJ-45 connec-
tors.
Figure 2-1: Removing the RJ-45 Port Cover
Note:
Only experienced installation professionals who are
familiar with local building and safety codes and, wherever
applicable, are licensed by the appropriate government
regulatory authorities should install the ENS500EXT.
