Eonon G2213D User manual

MIC
G2213D
PWR
MUTE
SRC/NAV
SEL
Model:G2213D

Thank you for buying this product, please read through these operating instructions,
so you will know how to operate your model properly. After you have finished reading
the instructions, put them away in a safe place for future reference .
NOTE: Due to the continuous product improvement, specifications and design are
subject to change without prior notice.
CONTENTS
IMPORTANT: Please adjust screen to make the touching effect function best when
you initiate the unit for the first time.
For the details, please refer to the operation at Page 9.
PRECAUTIONS
FRONT PANEL
BASIC OPERATION
REMOTE CONTROL
RADIO OPERATION
SYSTEM SETUP
CABLE CONNECTION
ACCESSORIES
INSTALLATION
TROUBLE SHOOTING
SPECIFICATION
MP3 OPERATION
SYSTEM MENU
DVB-T OPERATION
2
4
17
13
18
DVD/VCD/CD OPERATION 25
28
37
39
42
41
41
33
6
23
1
BLUETOOTH OPERATION 20
NAVIGATION OPERATION 35

1. Be sure to connect the color coded leads according to the diagram. Incorrect connec-
tions may cause the unit to malfunction or damage the vehicles electrical system.
2. Be sure to connect the speaker (-) leads to the speaker (-) terminal. Never connect
the left and right channel speaker cables each other or to the vehicle body.
3.Make sure all the connections are completely correct before turning on your unit.
4. When replacing the fuse(s), the replacement must be of the same amperage as shown
on the fuse holder.
5. Do not block vents or radiator panels. Heat may be caused inside and some accident
may be resulted by fire.
6 After completing the installation and beginning to play the unit (including replacing the
battery),please press RESET button on the front panel with pointed object (such as ball-
point pen) to set the unit to initial status.
7.Keep hands, finger, or any other object away from the back of the front panel or gaps of
the base top (shown as picture) when closing or opening to avoid damage or injury.
PRECAUTIONS
Replacing the Fuse
Make sure the amperage matches the specified value when replacing the fuses. If the
fuse is blown, check the power connection and replace with a new one. If the same
problem occurs, it would be subjected to the malfunction in-house.In such cases, please
consult the nearest service dealer.
WARNING:
Never use the fuse with the rated amperage more than that supplied to your unit, other -
wise the unit will be damaged .
2

This unit can play the following discs only:
F
PRECAUTIONS
*Do not attempt to modify the unit, modifying the unit may cause an accident.
*Stop the vehicle before carrying out any operation that could interfere with your driving.
*Do not work in extremely high or low temperature. Be sure the temperature inside the
vehicle is between +60 C and -10 C before turning on your unit .
*To enjoy optimum sound and images while playing, handle the discs as follows:
Handle the disc by its edge to keep the disc clean, and do not touch the surface.
Do not use your CDs with paste residue or ink attached.
Do not use CDs with labels or stickers attached, which may leave a sticky residue
while beginning to peel off. (Shown as the picture)
Clean the discs with an optional cleaning cloth. Wipe each disc from the center out.
(Shown as the picture)
Type of disc
12cm
VIDEO
DVD
Label on the disc Recorded material Size of disc
Sound and moving
pictures
VCD
MP3
12cm
CD 12cm
NOTE: The unit is compatible with VCD1.0/2.0/3.0 version and DVCD disc.
12cm
Sound and moving
pictures
Sound only
Sound only
TM
3

FRONT PANEL
4
13
14
1 2 3456
7
10
8 9
11
12
G2213D
PWR
MUTE
SRC/NAV
SEL
MIC
15

FRONT PANEL
1.AUX IN
Connect the audio cable to the unit then you can enjoy the music.
2. MIC
3. POWER /MUTE
Press the button to turn on the unit and press and hold the button to turn off the unit.
In power on, press to shut off the sound output and press it again to resume previous sound.
4. RESET
5. /
In radio mode, press and hold to manual seek a station. Press to automatic seek a station.
In playback mode, long press to select fast forward or fast backward. Press to select last
or next track(chapter)
6.SEL +/-
In radio mode, press this button to start the system setup.
Then press + button to increase the corresponding item level and press - button to
decrease the corresponding item level.
In playback mode, press this button to start setup page.
7.
Press to eject a disc.
Press and hold this button to force ejecting a disc when the system becomes frozen.
accidentally.
8.SRC/NAV
ress the button repeatedly to switch sources.
Press and hold this button to start navigation operation.
9.
.
14. SD slot
Insert the SD card, the unit will play the items automatically.
Note:
When the SD card could not eject automatically after pressing, it is suggested to
take it out manually.
P
Press to open/close the front panel. During opening the front panel, you can press
the button to set the panel angle.
10. IR WINDOW
11 USB SLOT
12. TFT DISPLAY
13. DISC LOADING SLOT
5

MENU SYSTEM
The users can perform operation by touching screen directly.
RADIO OPERATION
1. CURRENT STATUS
2/10. < / >
To switch bands.
3.Station preset button
To display the preset station list
(touch one of the station preset button to recall the radio which stored on the position;
long touch to save the current frequency into the station)
4.AMS
To browse preset stations.
To search and store stations automatically(long touch).
5/6. >> / <<
To seek a station automatically.
7/8. /
To seek a station manually.
9. RDS
To go to RDS operation
11. BACK
To be back to display the SOURCE screen
12. MUTE
To shut off the audio output and touch again to resume.
13/15. +/-
To increase or decrease the volume.
14. Volume bar
16. BAND AND PRESET STATION DISPLAY
6
87.50MHz
FM1 P6
6 7 9
10
8
1
4
3
2
5
11
1214
16 13 15

1
2
3
4
5 6
87.50MHz
FM1 P1
MENU SYSTEM
RDS OPERATION
7
1.AF
ON: To turn on AF function.
OFF: To turn off AF function.
2.TA
ON: To turn on TA function.
OFF: To turn off TA function.
3.ST
ON: To turn on STEREO function.
OFF: To turn on MONO function.
4.LOC
ON: To tune in local area.
OFF: To tune in local and distant area.
5.PTY
To select one of the program types.
6.RADIO
To go to radio operation.

1815 16 19
17 20
11
8 9 12
10 13 14
In DVD/VCD mode, the touch screen displays as following after tapping at random position.
MULTI-- PLAYER OPERATION
8
1.
To start/pause the playback.
2.
To stop playing, touch twice to stop
To select previous/next chapter or track.
5/6.
To play in fast rewind or fast forwards mode.
7/14/20.
To select more items.
8.
To play in random order.
9.
To select one of the repeat modes.
10.OSD
T
11.SUB-T.
To select the subtitle type if the DVD supports.
12.
DVD supports.
DVD supports.
completely.
3/4.
o select title elapsed, title remain, chapter elapsed, chapter remain, display off.
MENU
To display the DVD SETUP screen.
13.TITLE
To display the title menu.
15.ANGLE
To change the DVD viewing angle if the
16. ZOOM
To change the DVD viewing scale if the
17.PBC
To display the PBC menu in VCD mode.
18.P/N
T
19.A-B
To play the selectedA-B section.
o select PAL ,AUTO or NTSC system
NOTE: Touch the left middle position twice to display the TITLE MENU selection screen, touch the
right middle position twice to display the ROOT MENU selection screen, touching the right top
position to display the number keyboard.
You can select chapter(track) by press the touchable screen or the RC.
4
1 2 5
3 67
Fig.1 Fig.2 Fig.3
MENU SYSTEM

Setup Operation
TOUCH ON THE TOP RIGHT POSITION TO ENTER SOURCE INTERFACE.
The unit will return to the previous mode if no operation is performed in 5 seconds.
9
Touch on SET button on the above fig.. The user can start the system setting.
1. SETUP
Touch on the SETUP button and the screen will display as following:
TIME MODE
Set the time display mode(12H/24H).
TOUCH SCREEN
To calibrate the touch screen.
RADIO REGION
To select the right region as per the user locates.
Fig.1 Fig.2
Tapping on button to turn to next page shown as fig.2.
In FIG.2
TIME ADJUSTMENT
To adjust the time by tapping button;
TIME DISPLAY
ON: To display the time
OFF: To turn off the time display mode.

10
Fig.3 Fig.4
Tapping on button to turn to next page shown as fig.3.
Please refer to the following sequential order to
Note:
1.The group-setting can be erased by press
finish the setting:
1. Touch on one of the 6 BLANK columns position on the screen;
2. Press one button on the SW control;
3. The relative information jumps out on the screen;
4. Touch one of the functions as the wanted function for the pointed button on SW control;
ing and holding the selected group.
2. If there is already a set item, press the corresponding button on the SW control
and the screen will display: Exist key X.
3. Different buttons on the SW can be defined to the same function. The defined button
can be redefined after erasing the previous function.
SW control
To set 6 short-cut bottons for the steering wheel control.
The screen will display as fig.4 if there is no set for the system.
MUTE, PAUSE, and .
There are 10 buttons for selection in each item:
POWER, SRC, PREV, NEXT, VOL+,VOL-,
SW CONTROL OPERATION

11
SW CONTROL INSTALLATION
Before installing the SW control, please make sure all the wires are in good condition.
For installation, please refer to the illustrations below:
Key1
Key2
GND CAR AUDIO
SWC1, orange
SWC2, brown
GND, black
SWC
Please consult the professional technicians for advice if the unit cannot work as expected.
In case of connecting to the SWC (steering wheel control):
in case of connecting to the SW remote control:
X XX
SW remote control CAR AUDIO
SWC(IR), Blue/yellow
B+
GND
Key1
GND
Key2
IR X
XXX

2.Audio
Touch on the AUDIO button and the screen will display as following:
In FIG.1, the user can adjust the value of BASS, TREBLE and SUB WOOFER by
tapping on + / - on the touch screen.
12
3.Video
Press on the VIDEO button and the screen will display as following:
Fig.1 Fig.2 Fig.3
Tapping on button to turn to previous page shown as fig.2.
In FIG.2, the user can turn on/off the BEEP and LOUD function by tapping ON or
OFF button.
Tapping on button to turn to next page shown as fig.3.
In FIG.3, the user can adjust the sound output effect leftwards or rightwards by
tapping button; the sound output effect frontwards or rearwards by
tapping button.
In this setting, the user can adjust the value of CONTRAST, BRIGHTNESS and COLOR
by tapping on the items at the left/right end of each value bar.
According to the specific condition, the user can adjust the light effect on screen by
tapping SOFT, USER, NORMAL and BRIGHT modes.

REMOTE CONTROL
1 15
16
19
20
18
17
21
22
23
2
4
6
5
14
8
9
10
3
12
11 24
25
13
7
13

REMOTE CONTROL
Installing the battery
Slide the tray out on the back of the remote control and insert the battery with the plus
(+)and minus(-)poles pointing in the proper direction.
Use and care of the remote control
Point the remote control in the direction of the front panel to operate to use it.
Notes:
Using batteries improperly can cause them to explode. Take note of the following points:
* Keep the battery out of the reach of children. Should the battery be swallowed,
immediately consult a doctor.
* Use one CR2025(3V)lithium battery.
* Remove the battery if the remote control is not to be used for a month or longer.
* Do not short-circuit, disassemble or heat batteries.
* Do not dispose of batteries into fire or flames.
* Dispose of spent batteries properly.
* Do not let the remote control fall onto the floor, where it may become jammed under the
brake or accelerator pedals.
14

REMOTE CONTROL
1.PWR
Press this button to turn on the unit. Press and hold this button to turn off.
In power on, press to shut off the sound output, press it again to resume the previous sound level.
2.EQ
Press to select the corresponding preset modes to adjust the sound quality.
In BT mode, press to dial up a call.
3.ANGLE/AMS
Press to change the viewing angle in DVD mode.
In radio mode, press to browse each stored station for 5 seconds respectively which have been stored.
Long press to scan and automatically store stations.
4.SUB-T/LOC
5.PROG/A-B
In DVD/VCD/CD mode, short press to set the program order to play.
In DVD/VCD/CD mode, press and hold to repeat selected A-B section.
6.OSD/*
In DVD mode, press to display Title Elapsed, Title Remain, Chapter Elapsed, Chapter Remain,
DisplayOff.
In VCD/CD mode, press to display Single Elapsed, Single Remain, Total Elapsed, Total Remain,
Display Off.
7.GOTO/#
In DVD mode, press GOTO button and cursor button to select TITLE, CHAPTER, AUDIO, SUBTITLE,
ANGLE, TT TIME, CH TIME, REPEAT, TIME DISP. Then press ENTER button to set the item.
In VCD mode, press GOTO button and cursor button to select TRACK, DISC TIME, TRACK TIME,
REPEAT, TIME DISP. Then press ENTER button to set the item.
In CD mode, press GOTO button to select "Disc Go To:_ _ _", "Track Go To _:_ _:_ _", “Select
Track:_ _:xx".
Then press 0-9 number buttons to set the track or time what you want.
In radio mode ,press the button and the number button to set the frequency.
8.MENU
Press to return to the root menu in DVD mode.
9. [ / ][ / ][ / / / ]/ENTER
In playback mode perform [fast reverse /fast forward][previous track/next track][upwards/downwards/
leftwards/rightwards] and then press ENTER to execute the entering or the selected item in the
system setting menu.
In radio mode, press / button to recall a stored station. Press / button to seek a station
automatically by short press and to seek a station manually by press and hold.
In DVD playback mode, press to change the subtitle language.
In radio mode, press to select a local station or distance station.
In any mode, long press to display current time, current mode.
In BT mode, press this button to function as the button does on your cell phone.
In BT mode, press this button to function as the button does on your cell phone.
15

10.RPT/NAV
In disc playback mode, press this button to repeat playing.
Press and hold this button to start navigation mode.
ress the button repeatedly to switch sources.
Press and hold LED button to switch between two LED modes.
Press and hold this button to force ejecting a disc when the system becomes frozen.
In radio mode, number buttons(from 1to 6)can help you store you favourite station.
In DVD/VCD/CD mode, press to select any chapter or track directly.
Press the button to clear the erroneous number what you import.
In DVD mode, press the button to return the title menu.
In VCD mode, press this button to display PBC function.
21.
Press once to stop play. Press twice to stop completely.
11. /PTY
In radio mode, press this button to function PTY on/off.In DVD/VCD mode, press to play slowly.
12. ZOOM/AF
In radio mode, press this button to function AF on/off.
In DVD/VCD mode, press to increase or decrease the picture in size.
13. SRC
P
14. VOL-/SEL/VOL+,LED
Press VOL-/VOL+ to adjust volume.
15.
Short press to eject a disc.
16. LOUD
Press this button to activate LOUD function.
In bluetooth mode, press this button to reject your calling.
17. 0~9 numerals
18.CLEAR
19.
Press to pause playing and press again to resume playing.
20.TITLE
22. BAND/P/N
In radio mode, press to select bands.
In DVD/VCD mode, press P/N button to select PAL, AUTO or NTSC.
23.SETUP
In playback mode, short press to display DVD setting.
Press and hold in DVD mode and press in other modes will display system settings.
24. AUDIO/ST
In DVD/VCD mode, press to change the audio language.
In FM mode, press to select stereo or mono reception.
25.RDM/TA
In radio mode, press this button to function TA on/off.
In playback mode, press to play tracks in a random order.
Press the button to start the system setup.
16

ROCK
POP CLASSIC
EQ OFF
¼òµ¥¹ÊÕÏÅųýÖ¸ÄÏ
1.Reset the Unit
Operating the unit for the first time or after replacing the car battery, you must reset the
unit.Press RESET button on the head unit with a pointed object, (such as a ballpoint
pen) to set the unit to initial status.
*This function can only be operated by the head unit.
2.Turning the Unit On/Off
Press PWR/ button on the remote control to turn on the unit. In unit ON, when insert
a disc, the unit will automatically start playing. Long press it to turn off the unit completely.
Pressing PWR/MUTE button on the front panel also performs the same operation.
Note:
After the unit is off, the volume level is memorized during the area between 0 and 30.
If it is set less than 6, it will resume to 6; if the set volume level is higher than 30,
it will resume to 30; if it is between 6 and 30, it still stores in the status which you set.
3.Volume Control
Press VOL+ button on the remote control to increase the sound level and press VOL-
button on the remote control to decrease the sound level.
Press ( + or -) on the front panel also performs the same operation.
4. Mute Function
6.EQ Setting
While listening to the popular music, classic music or rock music, you can select the
corresponding preset modes to adjust the sound quality perfectly by using EQ button on
the remote control. Repeatedly pressing EQ button to choose the following modes in turn:
Press PWR/ button to shut off the sound output. MUTE will be displayed on the
screen. Press it again to resume to previous volume level.
Press PWR/MUTE button on the panel also performs the same operation.
BASIC OPERATION
17

FM2
MW2 MW1
FM3
FM1
5.DX/LOC Selector
In radio mode, press LOC button on the remote control to select strong or weak station
reception.
(1). It is set to LOC mode when LOC button is first pressed. Loc:ON appears on the
screen and only strong signal station will be tuned.
(2).It is switched to DX mode when Loc: OFF is pressed again. Both strong and weak
stations can be received.
Note: The initial mode is DX mode.
6.MO/ST Selector
In FM of radio mode, you can press ST button on the remote control to select Mono mode
or Stereo mode.
1.Band Selector
In radio mode, repeatedly press BAND/P/N button on the remote control OR >/< button
one the touch screen to select a band in the following order:
Selecting the radio mode, the TFT display as the follows:
3.Recalling a preset station
A total of 30preset stations (18-FM,12-MW) are available in memory.
Press / button on the remote control to recall a preset station.
The display shows the preset number and frequency of the stored station, touch one of
these to select a corresponding station to listening.
*Press one of the station preset button on the remote control also selects preset station.
4.Automatic/Manual Store
Auto store is a function for storing up to 6 stations.
(1)Select the desired band.
(2)Hold down AMS button ,the stations with good reception are stored automatically.
Manual store: turn in a station you wish to store in the preset memory, press and hold
one the preset buttons (1-6) that you want to store on.
*If you store a station in a preset memory which already has a station the current station
will be cleared and replaced with the new station.
2.Manual/Automatic Tuning
(1).Automatic Tuning: Press / button on the remote control to search for a station in
the direction of lower frequency or higher frequency.
(2). Manual Tuning: Press or button repeatedly to move downward or upward
one step respectively until the desired station frequency is displayed.
*Press(press and hold) / button on panel also performs the operation.
RADIO OPERATION
87.50MHz
FM1 P6
18
