Epson S5U13L01P00C100 User manual

SEIKO EPSON CORPORATION Rev. 1.0
S1D13L01 Display Controller
S5U13L01P00C100
Evaluation Board User
Manual
Downloaded from Arrow.com.

NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko
Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any lia-
bility of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or cir-
cuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as,
medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is
no representation or warranty that anything made in accordance with this material will be free from any patent or copyright
infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic
products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from
the Ministry of International Trade and Industry or other approval from another government agency.
All other product names mentioned herein are trademarks and/or registered trademarks of their respective companies.
©SEIKO EPSON CORPORATION 2014, All rights reserved.
Downloaded from Arrow.com.Downloaded from Arrow.com.

S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 3
Table of Contents
Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 CNF[2:0] Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.2 Configuration Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.3 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3.4 Zero Ohm Resistor Configuration . . . . . . . . . . . . . . . . . . . . . . . 11
3.5 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5.1 IOVDD, COREVDD, PLLVDD . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5.2 3.3V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5.3 Backlight Power Supply for LCD Panel . . . . . . . . . . . . . . . . . . . . . . . 11
3.6 LED Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 4 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 CN1, CN2, CN5 Panel Interface Connector . . . . . . . . . . . . . . . . . . . 14
4.2 CN3, CN4 Host Bus Interface Connector . . . . . . . . . . . . . . . . . . . . 14
4.3 P1, P2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board . . . . . . 15
Chapter 5 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 Current Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Oscillator Support for CLKI input . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Hardware Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 6 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 7 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Chapter 8 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 9 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 Introduction
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 5
Chapter 1 Introduction
This manual describes the setup and operation of the S5U13L01P00C100 Evaluation Board. The evaluation board
is designed as an evaluation platform for the S5U13L01 Display Controller.
The S5U13L01P00C100 evaluation board can also connect to the S5U13U00P00C100 USB Adapter board so that
it can be used with a laptop or desktop computer, via USB 2.0. The S5U13L01P00C100 evaluation board can be
used with many native platforms via the host connector which provides the appropriate signals to support a variety
of CPUs. However, if you do not use the S5U13U00P00C100 USB Adapter board, there are locations for connectors
for the other host interface. Please use the alocated locations to connect to the host interface.
This user manual is updated as appropriate. Please check the Epson Electronics America Website at vdc.epson.com
for the latest revision of this document before beginning any development.
We appreciate your comments on our documentation. Please contact us via email at documen-
[e-mail].
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 2 Features
6 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Chapter 2 Features
The S5U13L01P00C100 Evaluation Board includes the following features:
• QFP 128pin S1D13L01F00A100 Display Controller
• Headers for connection to the S5U13U00P00C100 USB Adapter board
Note
The SPI interface is not available when the S5U13L01P00C100 evaluation board is used with the
S5U13U00P00C100 USB adapter board.
• Headers for connection to various host interface
Note
These headers are not mounted. There is space available for mounting.
• Headers for connection to various LCD panels
• On-board 24MHz crystal (EPSON SG-210)
• On-board voltage regulator with 1.5V output, for CORE/PLLVDD
• On-board voltage regulator with adjustable 1.5~3.8V output, for IOVDD
• On-board voltage regulator with 3.3V output, for on-board OSC
• On-board voltage regulator with adjustable 38V/60mA max, to provide power for LED back-light of LCD
panels.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 7
Chapter 3 Installation and Configuration
The S5U13L01P00C100 evaluation board incorporates a DIP switch, jumpers, and 0 ohm resistors which allow it
to be used with a variety of different configurations.
3.1 CNF[2:0] Configuration
The S1D13L01 has 3 configuration inputs CNF[2:0], whichare usedto configure the S1D13L01 host interface type
through DIP switch SW1. Depending on the CNF[2:0] setting, some host interface pins will not be used. Those pins
should be terminated by SW2 and SW3.
Note
1. For SW2~3, the setting must be Off if there is no suggestion in table.
2. For JP105~109, the setting must be 1-2 if there is no suggestion in table.
3. Low means internal pull-down for address bus active.
4. The SPI interface is not available when the S5U13L01P00C100 evaluation board is used with the
S5U13U00P00C100 USB adapter board.
Table 3-1: Host Interface Pin Mapping
S1D13L01
Pin Name Direct 16-bit Mode 1 Direct 16-bit Mode 2 Indirect 16-bit Mode 1 Indirect 16-bit Mode 2 Direct 8-bit Indirect 8-bit SPI
CNF[2:0] 000 001 010 011 100 101 111
CS# CS# CS# CS# CS# CS# CS# CS#
WR# WR# RDU# WR# RDU# WR# WR# SCK
RD# RD# RDL# RD# RDL# RD# RD# SW2-3=On
UB# UB# WRU# UB# WRU# SW2-1=On SW2-1=On SW2-1=On
LB# LB# WRL# LB# WRL# SW2-2=On SW2-2=On SW2-2=On
AB0 TE (JP108 2-3) TE (JP108 2-3) TE (JP108 2-3) TE (JP108 2-3) AB0 TE (JP108 2-3) TE (JP108 2-3)
AB1 AB1 AB1 P/C# P/C# AB1 P/C# Low
AB[18:2] AB[18:2] AB[18:2] Low Low AB[18:2] Low Low
DB0 DB0 DB0 DB0 DB0 DB0 DB0 SI
DB1 DB1 DB1 DB1 DB1 DB1 DB1 SO
DB[7:2] DB[7:2] DB[7:2] DB[7:2] DB[7:2] DB[7:2] DB[7:2] SW2-5~10=On
DB8 DB8 DB8 DB8 DB8 TE (JP108 3-4) SW3-1=On SW3-1=On
DB[15:9] DB[15:9] DB[15:9] DB[15:9] DB[15:9] SW3-2~8=On SW3-2~8=On SW3-2~8=On
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
8 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
3.2 Configuration Switches
The S5U13L01P00C100 evaluation board includes the following switch blocks which control the functions
described in Table 3-2: “Switch Settings”. For jumper locations on the evaluation board, see Figure 3-1: “Configu-
ration Switch and Jumper Locations (Red)” on page 10.
Table 3-2: Switch Settings
Switch bit On Off Comment
SW1
1CNF0 is Pull Up (1) CNF0 is Pull Down (0) CNF[2:0] configuration. See Table
3-1: “Host Interface Pin Mapping”
2CNF1 is Pull Up (1) CNF1 is Pull Down (0)
3CNF2 is Pull Up (1) CNF2 is Pull Down (0)
4not used not used
SW2
1UB# is Pull Up UB# is not tied
Host interface pin termination when
not used pin. See Table 3-1: “Host
Interface Pin Mapping”
2LB# is Pull Up LB# is not tied
3RD# is Pull Up RD# is not tied
4not used not used
5DB2 is Pull Down DB2 is not tied
6DB3 is Pull Down DB3 is not tied
7DB4 is Pull Down DB4 is not tied
8DB5 is Pull Down DB5 is not tied
9DB6 is Pull Down DB6 is not tied
10 DB7 is Pull Down DB7 is not tied
SW3
1DB8 is Pull Down DB8 is not tied
2DB9 is Pull Down DB9 is not tied
3DB10 is Pull Down DB10 is not tied
4DB11 is Pull Down DB11 is not tied
5DB12 is Pull Down DB12 is not tied
6DB13 is Pull Down DB13 is not tied
7DB14 is Pull Down DB14 is not tied
8DB15 is Pull Down DB15 is not tied
= suggested settings
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 9
3.3 Configuration Jumpers
The S5U13L01P00C100 evaluation board includesthe following 2-pin, 3-pin, 5-pin and 8-pin jumper blocks which
control the functions described in Table 3-3: “2-Pin Jumper Settings”, Table 3-4: “3-Pin Jumper Settings” , Table
3-5: “5-Pin Jumper Settings” and Table 3-6: “8-PinJumper Setting”. For jumper locations on the evaluation board,
see Figure 3-1: “Configuration Switch and Jumper Locations (Red)” on page 10.
Note
For normal S5U13L01P00C100 operation, JP102 should be in Position 1-2. Also, when using the
S5U13L01P00C100 with the S5U13U00P00C100, JP102 should be in Position 1-2 (JP1 on the
S5U13U00P00C100 must be in Position 1-2). For IOVDD current measurement, JP102 should be removed.
Table 3-5: 5-Pin Jumper Settings
Table 3-3: 2-Pin Jumper Settings
Jumper Position 1-2 No Jumper (Open)
JP101 Connect COREVDD Power Supply Connect a current meter for power measurement
JP102 NOTE Connect IOVDD Power Supply to S5U13U00P00C100 No IOVDD Power Supply to S5U13U00P00C100
JP104 Connect PLLVDD Power Supply Connect a current meter for power measurement
= suggested settings
Table 3-4: 3-Pin Jumper Settings
Jumper Position 1-2 Position 2-3 Off
JP105 WR# is from P1 and CN3 WR# is from P2 WR# is not connected
JP106 DB0 is from P1 and CN3 DB0 is from P2 DB0 is not connected
JP107 DB1 is from P1 and CN3 DB1 is from P2 DB1 is not connected
= suggested settings
Jumper Position Function
JP108 Position 1-2 Position 2-3 Position 1-2: AB0 is AB0 (only for Direct 8bit mode)
Position 2-3: AB0 is TE
Position 3-4 Position 4-5 Position 3-4: DB8 is TE (only for Direct 8bit mode)
Position 4-5: DB8 is DB8
= suggested settings
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
10 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Table 3-6: 8-PinJumper Setting
Figure 3-1: Configuration Switch and Jumper Locations (Red)
Jumper Position Function
JP503
Position 1-2 No Jumper In connect case, TPS61161A is Enable
Position 3-4 No Jumper In connect case, Vout = 20mA
Position 5-6 No Jumper In connect case, Vout = 40mA (add connect Position 3-4)
Position 7-8 No Jumper In connect case, Vout = 60mA (add connect Position3-4 and
Position5-6)
= suggested settings
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 11
3.4 Zero Ohm Resistor Configuration
Between the S5U13U00P00C100 connector (P1, P2) and the S1D13L01 there are zero ohm resistors.
3.5 Power Requirements
3.5.1 IOVDD, COREVDD, PLLVDD
The S5U13L01P00C100 evaluation board is designed to generate COREVDD, PLLVDD and IOVDD from 5V via
the S5U13U00P00C100 USB adapter board or connector CN4. Since PLLVDD and COREVDD must be same,
these two voltages are generated by one voltage regulator, separated by an inductance. 5V must be supplied from
the S5U13U00P00C100 or CN4. IOVDD for the S5U13U00P00C100 should be supplied from the
S5U13L01P00C100 (both JP102 on the S5U13L01P00C100 evaluation board and JP1 on the S5U13U00P00C100
USB adapter board should be set to position 1-2). These power supplies are adjustable. See Table 3-7:
“S5U13L01P00C100 Power Mapping” for detail.
Note
Connector CN4 is not mounted. Space is allocated on the board for mounting.
3.5.2 3.3V
The S5U13L01P00C100 evaluation board is designed to generate 3.3V for on board OSC from 5V via the
S5U13U00P00C100 USB adapter board or connector CN4. 5V must be supplied from the S5U13U00P00C100 or
CN4. The 3.3V power supply is fixed output. See Table 3-7: “S5U13L01P00C100 Power Mapping” for detail.
Note
Connector CN4 is only land.
3.5.3 Backlight Power Supply for LCD Panel
The S5U13L01P00C100 evaluation board is designed to generate backlight power supply for LCD panel from 5V
via the S5U13U00P00C100 USB adapter board or connector CN4. The 5V must be supplied from the
S5U13U00P00C100 or CN4. This power supply is adjustable. It is possible to change the current value by the
connection of JP503. See Table 3-6: “8-PinJumper Setting” and Table 3-7: “S5U13L01P00C100 Power
Mapping”for detail.
Note
Connector CN4 is only land.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
12 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Figure 3-2: Voltage Adjustment Locations (Red)
Table 3-7: S5U13L01P00C100 Power Mapping
Name Purpose Adj. Range
COREVDD S1D13L01 COREVDD 1.5V Fixed —1.5V
PLLVDD S1D13L01 PLLVDD 1.5V Fixed
IOVDD\ S1D13L01 IOVDD 1.8/3.3V Typical VR1 1.5~3.8V
3.3V SG-210 VDD 3.3V Fixed —3.3V
LED+ Backlight for panel, 38V/60mA max JP503 12~38V
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 3 Installation and Configuration
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 13
3.6 LED Status Indicators
The S5U13L01P00C100 evaluation board has 3 LED status indicators which provide a quick visual status of the
following conditions as described in Table 3-8: “LED Status Indicators”.
Note
Connector CN4 is not mounted. Space is allocated on the board for mounting.
Figure 3-3: LED Locations (Red)
Table 3-8: LED Status Indicators
LED Color Signal Comment
HB RED HEARTBEAT HEARTBEAT from the S5U13U00P00C100
ENUM RED ENUMARETED ENUMARETED from the S5U13U00P00C100
POWER RED 5V 5.0V is present from the S5U13U00P00C100 or CN4
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 4 Connectors
14 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Chapter 4 Connectors
4.1 CN1, CN2, CN5 Panel Interface Connector
The LCD interface uses the VS, HS, DE, PCLK and PDT[23:0] pins. All signals on these pins are available on
connectors CN1, CN2 and CN5.
Connectors CN1 and CN2 and CN5are 0.1” x 0.1”, 40-pin headers (20 x 2) forCN1, 16-pin headers (8 x2) for CN2,
0.5mm pitch, 40-pin FPC Connector for CN5. See Figure 4-1: “Host and Panel Bus Connector Location (CN1, CN2,
CN3, CN4, CN5)” on page 15 for the location of these connectors. For the pinout of connectors CN1, CN2 and
CN5, see Section Chapter 7, “Schematic Diagrams” on page 22.
Note
Connector CN1 and CN2 are not mounted.
4.2 CN3, CN4 Host Bus Interface Connector
All S1D13L01 host interface pins are available on connectors CN3 and CN4. This allows the S5U13L01P00C100
evaluation board to be connected to a variety of development platforms. For S1D13L01 host interface pin mapping,
see Table 3-1: “Host Interface Pin Mapping,” on page 7.
See Figure 4-1: “Host and Panel Bus Connector Location (CN1, CN2,CN3, CN4, CN5)” on page 15 for the location
of host bus connectors CN3 and CN4. CN3 and CN4 are 0.1” x 0.1” 26-pin header (13x2). For the pinout of
connectors CN3 and CN4, see Section Chapter 7, “Schematic Diagrams” on page 22.
Note
Connector CN3 and CN4 are not mounted.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 4 Connectors
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 15
Figure 4-1: Host and Panel Bus Connector Location (CN1, CN2, CN3, CN4, CN5)
4.3 P1, P2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board
The S5U13L01P00C100 evaluation board is designed to connect to aS5U13U00P00C100 USB AdapterBoard. The
USB adapter board provides a simple connection to any computer via a USB 2.0 connection. The
S5U13L01P00C100 directly connects to the USB adapter board through connectors P1 and P2.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 4 Connectors
16 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
Note
The SPI interface is not available when the S5U13L01P00C100 evaluation board is used with the
S5U13U00P00C100 USB adapter board.
The S5U13U00P00C100 USB adapter board supplies the 5V power required bythe S5U13L01P00C100 evaluation
board. The S5U13L01P00C100 evaluation board then supplies the IOVDD for the S5U13U00P00C100 USB
adapter board. Therefore, both JP102 on the S5U13L01P00C100 evaluation board and JP1 on the
S5U13U00P00C100 USB adapter board should be set to position 1-2.
When the S5U13L01P00C100 is connected to the S5U13U00P00C100 USB Adapter board, there are 2 LEDs on
the S5U13L01P00C100 which provide a quick visual status of the USB adapter. HB (D300) blinks to indicate that
the USB adapter board is active. ENUM (D301) turns on to indicate that the USB has been enumerated by the PC.
The following diagram shows the location of connectors P1 and P2. P1 and P2 are 2mm x 2mm, 40-pin headers
(20 x 2) located on the underside of the board.
Figure 4-2: USB Adapter Connector Locations (P1, P2)
For the pinout of connectors P1 and P2, see Section Chapter 7, “Schematic Diagrams” on page 22.
Note
A windows driver must be installed on the PC when the S5U13L01P00C100 is used with the S5U13U00P00C100
USB Adapter Board. The S1D13xxxUSB driver is available at vdc.epson.com.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 5 Technical Description
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 17
Chapter 5 Technical Description
5.1 Current Measurement
Current measurement can be performed individually for the following S1D13L01 power supplies: COREVDD,
PLLVDD, IOVDD. For a details on which jumper block is used for each power supply, refer to Table 3-3: “2-Pin
Jumper Settings,” on page 9.
To measure current for a particular S1D13L01 power supply, remove the corresponding jumper shunt and place an
ammeter on the jumper terminals to measure the current draw. Use the lowest possible range for the measurement
to minimize loading from the ammeter.
For IOVDD current measurement, shunts for JP102 should be removed and an ammeter connected across JP102.
JP1 on S5U13U00P00C100 must be set to position 2-3.
Note
Attaching an ammeter while doing other tests can cause a voltage drop across the ammeter and may produce in-
valid test results.
5.2 Oscillator Support for CLKI input
The S5U13L01P00C100 evaluation board has an on-board 24MHz oscillator (Y1) which drives the input for the
S1D13L01 CLKI pin.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 5 Technical Description
18 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
5.3 Hardware Reset
The S5U13L01P00C100 evaluation board has an on-board reset IC which drives the RESET# input pin on the
S1D13L01. This occurs when push button SW4 is pressed.
Figure 5-1: Reset Switch (SW4) Location
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 6 Parts List
S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0) EPSON 19
Chapter 6 Parts List
Table 6-1 : S5U13L01P00C100 Parts List
Item Qty Reference Part Description Manufacture Part No. /
Comments
1 1 U1 S1D13L01 LCD Controller QFP15-128 0.5mm
Pitch EPSON S1D13L01F
2 1 U2 TPS73615DRB Single Channel LDO Fixed TI TPS73615DRB
3 1 U3 TPS73633DRB Single Channel LDO Fixed TI TPS73633DRB
4 1 U4 TPS73601DRB Single Channel LDO Adjustable TI TPS73601DRB
5 1 U7 TPS3801-01DCKR SUPPLY VOLTAGE
SUPERVISORS Vref 1.14V Delay
200ms TI TPS3801-01DCKR
6 1 U8 TPS61161ADRVT White LED Driver with Digital and
PWM Brightness Control TI TPS61161ADRVT
7 1 C123 GRM155B11H
102KA01D cap 1000p 1005 MURATA
8 3 C404, C409, C414 GRM155B11E103KA0
1D cap 10n 1005 MURATA
912
C102, C104,
C106, C108,
C110, C112,
C114, C116,
C118, C120,
C501, C507
GRM155B11E103KA0
1D cap 0.01u 1005 MURATA
10 20
C101, C103,
C105, C107,
C109, C111,
C113, C115,
C117, C119,
C121, C400,
C402, C405,
C407, C410,
C412, C500,
C506, C509
GRM155R71C104KA8
8D cap 0.1u 1005 MURATA
11 7C122, C401,
C403, C406,
C408, C411, C413
GRM21BB31C106KE
15L cap 10u 16v 2012 MURATA
12 1C508 cap 0.22u/50V
13 1C510 cap 1.0u/50V
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 6 Parts List
20 EPSON S5U13L01P00C100 Evaluation Board User Manual (Rev. 1.0)
14 46
R300, R301,
R302, R303,
R304, R305,
R306, R307,
R308, R309,
R310, R311,
R312, R314,
R315, R316,
R317, R318,
R319, R320,
R321, R322,
R323, R324,
R326, R327,
R328, R329,
R330, R331,
R332, R333,
R334, R335,
R336, R337,
R338, R339,
R340, R341,
R342, R343,
R344, R345,
R508, R509
ERJ-1GE0R00C res 0 0603 Panasonic
15 2R325, R500 RK73Z2ATTD res 0 2012 KOA
16 2R367, R368 RK73B1JTTD 331J res 330 1608 KOA
17 1R369 RK73B1JTTD 621J res 620 1608 KOA
18 20
R101, R102,
R103, R350,
R351, R352,
R353, R354,
R355, R356,
R357, R358,
R359, R360,
R361, R362,
R363, R364,
R365, R366
ERJ-1GEJ102C res 1k 0603 Panasonic
19 1R401 RK73B1JTTD 223J res 22k 1608 KOA
20 4R104, R105,
R106, R400 RK73B1JTTD 473J res 47k 1608 KOA
21 1R502 MCR006YZPF33R0 res 33 1% 0603 ROHM
22 1R506 RK73H1JTTD 5621F res 5.62k 1% 1608 KOA
23 1R507 RK73H1JTTD 4532F res 45.3k 1% 1608 KOA
24 1R313 NM res NM 0603 not mounted
25 3R510, R511, R512 res 10
26 1R513 res 10k
27 1VR1 ST32ETA204 SMD Trimming Potentiometer
200k COPAL ST32ETA204CT-ND
28 3D300, D301, D302 SML-310VTT86 LED red 1608 ROHM SML-310VT
Table 6-1 : S5U13L01P00C100 Parts List
Item Qty Reference Part Description Manufacture Part No. /
Comments
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
