1
Welcome!
Your EPSON Stylus®Photo 2200 is the ultimate desktop printer for professional and
amateur photography. Your outstanding printouts result from these advanced
features:
■EPSON’s 7-color inks let you print up to 2880 × 1440 dpi (dots per inch).
■Large gamut, pigment-based, EPSON®UltraChrome™inks and compatible,
lightfast papers deliver long-lasting, water-resistant prints.
■Four-picoliter variable ink droplets give you finer shadow detail, dazzling
highlights, and better fill across a wider range of colors.
■Interchangeable Photo Black and optional Matte Black ink cartridges for
precision ink coverage on any type of paper.
■Large format capabilities let you print panoramics, portraits, and specialty prints
up to 13 × 44 inches.
■Straight-through, manual feed slot for thick paper (up to 0.05-inch) gives you
more media choices than ever before.
■Roll paper feeder and automatic roll paper cutter enable continuous printing and
cutting of multiple photos.

2Welcome!
PRINT Image Matching and Exif Print
Your EPSON Stylus Photo 2200 printer supports these innovative digital image
formats to give you the best photo prints possible:
■PRINT Image Matching™(both P.I.M. and P.I.M. II)
■Exif Print
About PRINT Image Matching
EPSON’s revolutionary PRINT Image Matching (P.I.M.) technology lets your digital
camera and printer work together automatically to produce the best prints possible.
Digital camera manufacturers that support PRINT Image Matching include EPSON,
Casio,
®Konica, ®Kyocera, ®Minolta, ®Nikon, ®Olympus, ®Pentax, ®Ricoh, ®Sanyo, ®
Sony,
®and Toshiba. ®Check with your camera’s manufacturer or visit
www.printimagematching.com to find out if PRINT Image Matching technology is
included with your camera.
With PRINT Image Matching, the digital camera manufacturer can set specific
printing options for each camera model. These options include:
■contrast, sharpness, and brightness
■gamma level, color space, color saturation, and noise reduction
■shadow point, highlight point, and color balance
The camera saves this information in each JPEG or TIFF image file. Your printer—
along with EPSON Software™Film Factory™or the P.I.M. II Plug-in for Adobe®
Photoshop®(included with your printer)—uses the information to ensure the most
accurate image reproduction.
But don’t worry if your camera doesn’t include PRINT Image Matching
technology—your EPSON Stylus Photo 2200 gives great photo printing results, just
without the adjustments P.I.M.-enabled cameras may add.

Welcome! 3
About Exif Print
The Exif (Exchangeable Image File) Print format includes information about your
digital camera settings in JPEG/TIFF files so your printer and application can use
them to create accurate print settings. Most digital cameras store Exif Print
information such as shutter speed, metering, flash, and exposure settings, resolution,
and lens use in the JPEG/TIFF image file. Your printer—along with EPSON
Software Film Factory and the P.I.M. II Plug-in for Adobe Photoshop—uses the
information to ensure the most accurate image reproduction.
About Your Software
Your printer CD-ROM includes all the software you need for printing. See the
Start Here sheet for installation instructions.
■Your printer driver runs your printer and lets you control how your documents
look. You can’t print without it.
Tip: It’s a good idea to check EPSON’s support web site periodically for free
updates to your printer driver. Visit http://support.epson.com. Download
instructions are posted for your convenience.
■Your photo software includes these great tools:
EPSON Software Film Factory is a photo management program
that lets you organize, beautify, and print your photos in a flash.
Supports PRINT Image Matching, P.I.M. II, and Exif Print.
P.I.M. II Plug-in for Adobe Photoshop lets you retain PRINT Image Matching,
P.I.M. II, and Exif Print image quality when you import JPEG or TIFF files from
your P.I.M.-enabled digital camera. (Compatible with Photoshop 6.0 and 7.0,
and Photoshop Elements 1.0 and 2.0.)
■Your EPSON Printer Information Center gives you quick, on-screen
access to information about your printer. It includes EPSON Print
Show animated tutorials on loading roll paper, replacing ink
cartridges, and other tasks. It also includes an on-screen Reference
Guide for additional information about your printer. (The desktop
icon may be different on some Mac OS X systems.)

4Welcome!
■EPSON PhotoCenter is EPSON’s free photo-sharing web site
where you can store, organize, and share your photos; print
high-resolution photos straight from the web; and create free online
postcards with your photos. Your printer software installer lets you add
a link to EPSON PhotoCenter on your desktop.
■Exclusive software offers, demos, and trial versions:
nik Color Efex Pro!™provides the most award-winning collection of digital
photographic filters available, including Polarization, Skylight, Graduated Blue,
Soft Focus, and other filters. (Works only with full versions of Photoshop.)
nik Sharpener Pro!™provides the most accurate and easiest method for
sharpening images without oversharpening or creating halos.
Monaco Systems™MonacoEZcolor™lets you build ICC device profiles for
accurate color between scanned, displayed, and printed images.
About Your Documentation
To set up your printer and install its software, see the Start Here sheet.
This book contains system requirements, important safety information, your
warranty, and instructions on:
■Using the EPSON Printer Information Center
■Loading all types of paper
■Printing with Windows®or on a Macintosh®
■Maintaining the printer
■Solving basic problems
S
M

Welcome! 5
Please follow these guidelines throughout:
Warnings must be followed carefully to avoid bodily injury.
Cautions must be observed to avoid damage to your equipment.
Notes contain important information about your printer.
Tips contain hints for better printing.
For more details about your printer, see your Print Show movies and Reference Guide,
as described below.
Using the EPSON Printer Information
Center
Need help loading roll paper or installing the cutter? Use the EPSON Printer
Information Center to view printer movies and a manual that quickly tell you how.
Follow the instructions on the Start Here sheet to install the EPSON Printer
Information Center, if you haven’t already.
Note: You need a browser—such as Microsoft®Internet Explorer 4.0 or later or
Netscape®Navigator®3.0 or later—to view the manual. If you are using a
different browser, the pages may not display correctly.
Launching the Movies
1. Double-click the EPSON
Printer Information Center icon
on your desktop.
2. Click Print Show.
3. Click a movie title.
Use the program tools to pause a
movie, replay a step, or skip ahead.
4. Click Exit to exit EPSON Print
Show.

6Welcome!
Launching the Manual
1. Double-click the EPSON Printer Information Center icon on your
desktop.
2. Click Reference Guide. You see this screen:
3. Click a topic on the left to expand the table of contents.
4. Click on the topic you want to view.
■Click right arrows to view subtopics, then click on a topic.
■Click down arrows to close a subtopic list.
Note: If you see an icon for a graphic when viewing your Reference Guide in
Netscape Navigator, click the Reload button to load the graphic.
Click a topic
to expand
the table of
contents
Closed list,
click to
expand
Click to go
to topic

Welcome! 7
Printer Buttons and Lights
The tables below summarize the functions of the printer buttons and lights. See the
instructions in your documentation for details on using the buttons. To diagnose
problems indicated by the printer lights, see page 74.
Printer buttons
Printer buttons Uses
Ppower Turns the printer on and off. Hold down the button until the Power
light comes on or goes off.
mpaper Loads or ejects paper.
Resumes printing after a paper-out or multiple-sheet-feed error.
Hink Moves the print head to the ink cartridge replacement position and
returns it to its home position.
Cleans the print head. Hold down the button for three seconds
when all the red HInk Out lights are off.
zroll paper Prints a cutting guideline and feeds roll paper to the removal
position after roll paper printing.
Returns roll paper to the printing position after cutting.
When using the automatic roll paper cutter, cuts, feeds, and
returns the paper to printing position automatically.
Reverses roll paper out of the printer. Hold down the button for
three seconds.
Printer lights
Printer lights Meaning
Ppower On: printer is turned on.
Flashing: printer is receiving data, printing, in ink replacement
mode, charging ink, or cleaning the print head.
mpaper out On: printer is out of paper or multiple sheets have been fed.
Flashing: paper is jammed in the printer.
Hink (seven) On: the indicated ink cartridge is empty.
Flashing: the indicated ink cartridge is low on ink.
Lights flash in a pattern: the printer is performing an ink operation.

8Welcome!

9
Loading Paper
You can load a variety of paper types in your printer, as described in these sections:
■“Loading Paper in the Sheet Feeder” below
■“Loading Envelopes” on page 11
■“Loading Roll Paper” on page 12
■“Loading and Printing on Thick Paper” on page 17
Loading Paper in the Sheet Feeder
Follow these steps to load plain paper and many special papers in the sheet feeder:
1. Slide the left edge guide to the position for your paper size, as marked on the
paper support.
2. Place your paper in the printer on
the right side of the sheet feeder.
3. Adjust the left edge guide to fit
lightly against the paper.
4. Open the output tray extensions.
Also follow these loading guidelines:
■Always load the short edge first,
even for printing landscape-
oriented documents.
■Load the printable side face up. It’s usually whiter or brighter than the other side.
■Load letterhead or preprinted paper into the printer top edge first.
■Don’t load paper above the arrow on the left edge guide.
Load paper against
this side

10 Loading Paper
Loading Special Paper
Load EPSON ink jet papers as follows:
■Load EPSON Velvet Fine Art Paper only in the manual feed slot, following the
instructions on page 17.
■Check the paper package for additional handling instructions.
■Set the adjust lever on the side of the printer to the mposition.
■If ink smears on thicker paper, try printing with the lever set to the ^position.
Paper type Loading capacity
EPSON Enhanced Matte Paper 20 sheets of letter-size paper with a
support sheet beneath the stack;
10 sheets of A3- or Super B-size paper
EPSON Premium Semigloss Photo Paper 20 sheets of letter-size paper;
1 sheet of Super B-size paper
EPSON Watercolor Paper - Radiant White 1 sheet at a time
EPSON Premium Luster Photo Paper 20 sheets of letter-size paper;
1 sheet of A3- or Super B-size paper
EPSON Premium Glossy Photo Paper 1 sheet at a time
EPSON Velvet Fine Art Paper 1 sheet at a time; manual feed slot only
EPSON Premium Bright White Paper Up to 0.3-inch (8 mm) total thickness
(about 30 sheets)

Loading Paper 11
Loading Envelopes
You can load up to 10 envelopes at a time, as described below.
Tip: For best results, press each envelope flat before loading it, or load one
envelope at a time. You’ll get the best results printing on envelopes using the
optional Matte Black ink cartridge.
1. Load envelopes as shown, with the flap side down and the flap edge against the
right side of the sheet feeder.
2. Slide the left edge guide against the envelopes.
3. Set the adjust lever to the ^position.
4. Choose these settings in your printer
software:
■Plain Paper as the Type (Windows) or
Media Type (Macintosh) setting
■Black Ink Only (Windows) or Black as
the Ink setting (Macintosh)
■The envelope size as the Size (Windows)
or Paper Size (Macintosh) setting
■Landscape as the Orientation setting
See page 20 (Windows), page 22 (Macintosh OS X), or page 26 (Macintosh
OS 8.6 to 9.x) for instructions.
Load with the
printable side up,
flap edge right

12 Loading Paper
Loading Roll Paper
You can load roll paper in these sizes:
■4 inches wide
■8.3 inches wide
■13 inches wide
1. Place the roll paper on the holders as
shown, then remove the tape and
protective paper from the end of the roll.
2. Make sure the end of the paper is cut
straight across, with 90° corners. If the
end is cut diagonally, you may have
problems feeding the paper.
3. If the paper curls at the end, roll it
backwards between a folded sheet of
paper to uncurl it.
Avoid touching the printable surface of
the roll paper.
4. Remove any paper that’s in the sheet
feeder at the top of the printer. Then
remove the paper support, lower the
output tray, and turn on the printer.

Loading Paper 13
5. Set the adjust lever to the mposition.
6. Install the roll paper holders on the printer. Insert the left holder into the far left
slot, then insert the other holder into the corresponding slot on the right.
7. Load the paper part of the way into the
roll paper feeder, then slide the right roll
paper edge guide to fit lightly against
the paper.
Don’t load roll paper in the cut
sheet feeder
Roll paper feeder
Caution: Don’t load roll paper into the
sheet feeder at the top of the printer.

14 Loading Paper
8. Push the paper into the feeder as far as it
will go; the printer feeds the paper
automatically.
9. To verify that the paper is loaded
straight, open the printer cover and look
into the printer.
If the paper is crooked, press the zroll
paper button for three seconds to back
the paper all the way out.
Then turn the roll paper holder knobs to
roll up the paper. Press the zroll paper
button to clear the paper out error.
Repeat steps 7 through 9 to reload the
paper.
If you want to use the cutter, follow the steps on page 15 to install it.
If not, follow the instructions on page 32 to print on roll paper.
If crooked, press
zbutton for three seconds
