Epson LX-300+II RTP User manual

SPECIFICATIONS
• Improved processing speed with a 64KB Input Data Buffer
• Fast print speed of up to 337 Characters Per Second (12 CPI)
• Achieve optimum efficiency with 5 Part Forms printout (1 original + 4 copies)
• Greater connectivity with built-in USB, Serial and Parallel Interface options
• Choice of 8 Built-in Bar Code formats for maximum versatility
Minimum cost,
maximum workload
9-PIN WIDE CARRIAGE IMPACT PRINTER

PRINT DIRECTION Bi-directional with logic seeking
PRINT SPEED HIGH SPEED DRAFT 10/12/15 CPI 300/337/337 cps
HIGH SPEED DRAFT CONDENSED 17/20 CPI 321/300 cps
DRAFT 10/12/15 CPI 225/270/225 cps
DRAFT CONDENSED 17/20 CPI 191/225 cps
NLQ 10/12/15/17/20 CPI 56/67/56/47/56 cps
PRINT CHARACTER SETS 13 International character sets; 13 character code tables (Standard); Italic, PC437, PC850, PC860, PC861,
CHARACTERISTICS PC863, PC865, Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15
BITMAP FONTS Epson Draft: 10, 12, 15 CPI; Epson Roman and Sans Serif: 10, 12, 15 CPI, Proportional
BAR CODE FONT EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, PostNet
PRINTABLE PITCH (CPI) Character per line
COLUMNS 10 CPI 80
12 CPI 96
15 CPI 120
17 CPI CONDENSED 137
20 CPI CONDENSED 160
PAPER HANDLING
PAPER PATH MANUAL INSERTION: Rear in, Top out
PUSH TRACTOR: Rear in, Top out
PULL TRACTOR: Rear/Bottom in, Top out
CUT SHEET FEEDER: Rear in, Top out
PAPER SIZE
CUT SHEET MANUAL INSERTION Width: 100 ~ 257 mm (3.9 ~ 10.1")
Length: 100 ~ 364 mm (3.9 ~ 14.3")
Thickness: 0.065 ~ 0.14 mm (0.0025 ~ 0.0055")
CSF SINGLE-BIN Width: 182 ~ 216 mm (7.2 ~ 8.5")
Length: 257 ~ 356 mm (10.1 ~ 14.0")
Thickness: 0.07 ~ 0.14 mm (0.0028 ~ 0.0055")
MULTI PART Width: 100 ~ 257 mm (3.9 ~ 10.1")
Length: 100 ~ 364 mm (3.9 ~ 14.3")
Thickness: 0.12 ~ 0.39 mm (0.0047 ~ 0.015") (Total)
ENVELOPE No. 6 Width: 165 mm (6.5")
Length: 92 mm (3.6")
Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total)
No. 10 Width: 241 mm (9.5")
Length: 105 mm (4.1")
Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total)
CONTINUOUS PAPER Width: 101.6 ~ 254 mm (4.0 ~ 10.0")
Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0")
Thickness: 0.065 ~ 0.39 mm (0.0025 ~ 0.015") (Total)
LABEL Width: 101.6 ~ 254 mm (4.0 ~ 10.0")
Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0")
Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035") (Base)
0.16 ~ 0.19 mm (0.0063 ~ 0.0075") (Total)
ROLL PAPER Width: 216 mm (8.5 ")
Length: –
Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035")
PAPER FEEDING STANDARD Friction: Rear in, Top out
Push Tractor: Rear in, Top out
Pull Tractor: Rear/Bottom in, Top out
OPTIONAL Cut Sheet Feeder: Rear in, Top out
Push-Pull Tractor: Rear in, Top out
COPIES Original + 4 copies
LINE SPACING 1/6 inch or programmable by 1/216 inch
INPUT DATA BUFFER 64 KByte
INTERFACE STANDARD Bi-directional parallel interface (IEEE-1284 nibble mode
supported); Serial interface; USB interface (ver 1.1)
RIBBON CARTRIDGE STANDARD FABRIC RIBBON RIBBON LIFE:
CARTRIDGE (BLACK) Approx. 3 million characters (Draft 10 CPI, 14 dots/character)
OPTION FABRIC RIBBON RIBBON LIFE:
CARTRIDGE (COLOUR) Black Approx. 1 million characters
(Draft 10 CPI, 14 dots/character)
Magenta Approx. 0.7 million characters
(Draft 10 CPI, 14 dots/character)
Cyan Approx. 0.7 million characters
(Draft 10 CPI, 14 dots/character)
Yellow Approx. 0.5 million characters
(Draft 10 CPI, 14 dots/character)
ACOUSTIC NOISE Approx. 49dB (A) (ISO 7779 pattern)
RELIABILITY MVBF (Mean Print Volume Between Failure) 12 million lines (Except print head)
MTBF (Mean Time Between Failure) 6000 POH (25% duty cycle)
PRINT HEAD LIFE Approx. 400 million strokes/wire
CONTROL PANEL 4 switches, 4 LEDs
ENVIRONMENTAL TEMPERATURE 5 ~ 35 °C
CONDITIONS HUMIDITY 10 ~ 80 % RH
(OPERATING)
ELECTRICAL RATED VOLTAGE AC 120 V, AC 220 ~ 240 V
SPECIFICATIONS RATED FREQUENCY 50 ~ 60 Hz
POWER CONSUMPTION Approx. 23 W (ISO/IEC 10561 Letter Pattern);
ENERGY STAR compliant
DIMENSIONS (D X W X H) 275 x 366 x 159 mm
WEIGHT Approx. 4.4 kg
PRINTER DRIVER OS Microsoft®Windows®98/2000/Me/XP and Microsoft®
/UTILITY Windows®NT®4.0
UTILITY Epson Status Monitor 3 (Microsoft®Windows®98/2000/Me/XP
and Microsoft®Windows®NT®4.0 environment only)
Weight – approx. 4.4 kg
www.epson.com.sg
SPECIFICATIONS
Dealer’s Stamp
1 Harbourfront Place
#03-02 HarbourFront Tower One
Singapore 098633
(65) 6586 5500
(65) 6334 2710
Printed July 2006
275mm
366mm
159mm
9-PIN WIDE CARRIAGE IMPACT PRINTER
OPTIONS
FABRIC RIBBON CARTRIDGE (BLACK)
FABRIC RIBBON PACK (BLACK)
FABRIC RIBBON CARTRIDGE (COLOUR)
SINGLE BIN CUT SHEET FEEDER
PULL TRACTOR UNIT
COLOUR UPGRADE KIT
ROLL PAPER HOLDER
