Epson SC-F9200 series User guide

SC-F9200 Series Rev.A
1
SETUP MANUAL
SE Group Confidential (Related Staff Only)
SC-F9200 Series

SC-F9200 Series Rev.A
2
•Please inform the user of the next page certainly!
•Please print and pass the next page to user and
encourage the points of caution.
IMPORTANCE

SC-F9200 Series Rev.A
SC‐F‐Series
Checkinklevels
■Inkrefill
Ink level is more than 70mm:
Recommends to continue using the
printer until the ink level reaches
70mm from the bottom.
Ink level is about or less than 70mm:
Go to step 2.
1
34
Replace chip unit with
new one attached
new ink pack.
Refill ink.
-Use up all ink in the pack at a time. (No remaining)
When this message appears,
check ink level of the tank
which is indicated by .
Shake the new ink pack as shown
in the illustration horizontally for
approximately 5cm left and right
for 5seconds approximately
15times.
2
Important

SC-F9200 Series Rev.A
4
The instructions and procedures included herein are intended
for the experienced repair technicians, and attention should
be given to the precautions on the preceding page.
CHECK
AGAIN
IMPORTANCE
Symbols Used in this Manual
Indicates an operating or maintenance procedure, practice, or
condition that, if not strictly observed, could result in damage
to, or destruction of, equipment.
May indicate an operating or maintenance procedure, practice or
condition that is necessary to accomplish a task efficiently.
It may also provide additional information that is related to a
specific subject, or comment on the results achieved through
a previous action.
Indicates should be confirmed by tentative When assembling it
until the present stage. Write the check when it is possible to
confirm it.
Indicates important point about assembly.
Wear protective eyewear and gloves when performing
assembly, and maintenance.
About This Manual
C A U T I O N
CHECK
P O I N T

SC-F9200 Series Rev.A
5
Revision Date of Issue Description
0 April 22,2015 Temporary release for AMP unit
A July 10,2015 First release for MP unit
Revision Status

SC-F9200 Series Rev.A
6
1.1 Caution for Installation
Installation
Serviceman must set it up.（Not User）
1.2 Choosing a Place for the Printer
Instructions for Placing the Printer
• keep adequate room as shown.
• Choose a level and stable location that can support the
weight of the printer (about 288 kg).
1.3 Used Tools
• Phillips screwdriver, No.2 (Long driver: more than 250mm)
• Rule Scale
• Scissors

SC-F9200 Series Rev.A
7
1.4 Inside of carton box
Printer
Media Feeding Unit, Auto Take-up Reel Unit
Epson Genuine Ink Supply System

SC-F9200 Series Rev.A
8
2. Setup Flow
Assemble according to the following flow charts.
Stand
Printer Installation
Media Feeding Unit
Auto Take-up Reel Unit
Ink Supply System
Only Frame of
Media Guide Bar
(without Guide bar)
Connecting the
Power Cable
Customer
Service
engineer
Before assembling the printer, clear the work area by putting
away the removed packing materials and bundled items.
C A U T I O N
Media Guide Bar

SC-F9200 Series Rev.A
9
<<Stand>>
It is recommended to assemble the stand by 3persons.
CHECK
P O I N T
Remove the tapes.
Insert the strut into the stands with supporting the stands.
Tighten 4screws.

SC-F9200 Series Rev.A
10
Check the markings of L & R on both stands and strut.
Tighten 4screws with supporting the stands.
Tighten 1screw.
Tighten 2screws.

SC-F9200 Series Rev.A
11
<<Printer>>
Take out the Carrying Bar
Insert the Carrying Bar
Set the carrying bar for printer to be between two screws of
the carrying bar, locate the screws upside.

SC-F9200 Series Rev.A
12
Confirm the stand to be fixed.
Lift the printer on the stand.
•When carrying the printer, use at least 6persons.
•Be careful for Waste Ink Tube not to be sandwiched when you
set Printer on Stand.
C A U T I O N
•Before moving the printer, be sure the stand is fixed in place.
•Be sure the casters are not floating on floor.
C A U T I O N
Pull out the carrying bar from the printer

SC-F9200 Series Rev.A
13
Tighten 3screws with washer
Peel tapes off as below.
Open the front cover.
Be careful not to trap your hands or fingers when opening or
closing the front cover.
C A U T I O N
Pressing the tabs on both sides of the media holding plates to center
as shown. Temporarily in the center of the platen before adjustment
of parallelism (Reel/Roll/Media Guide bar).
The media holding plate is used when printing on media
with a thickness of less than 0.4 mm.
CHECK
P O I N T

SC-F9200 Series Rev.A
14
Remove 2screws, and remove the plate below.
plate
Dispose 2screws and this plate.
CHECK
P O I N T

SC-F9200 Series Rev.A
15
<<Media Feeding Unit>>
Fix the parts at both sides by tightening screws (total: 4pcs).
Rear side
Set the Media Feeding Unit firstly from the left side as below.
Carry the Media Feeding Unit (approx. 34.3 kg) using 2persons,
each holding the 2bars as shown
C A U T I O N
Rear side

SC-F9200 Series Rev.A
16
Slide core holder and tighten 5screws.
Tighten 4screws temporarily until parallel adjustment is
completed.
C A U T I O N Temporarily tighten (Only home side)
Set cable by clamps

SC-F9200 Series Rev.A
17
Open the cover.
Plug the connector.
Set the cable by clamps.
Close the cover

SC-F9200 Series Rev.A
18
<<Auto Take-up Reel Unit>>
Tighten each 2screws (total: 4pcs).
Set Reel Unit.

SC-F9200 Series Rev.A
19
Slide core holder and tighten 5screws.
Tighten 4screws temporarily until parallel adjustment is
completed.
Temporarily tighten (Only home side)
Set the cable through the bottom clamp behind the printer.
Plug the connector, fix it by 2screws.
Set the cable by 3clamps.
このイメージは、現在表示できません。
C A U T I O N

SC-F9200 Series Rev.A
20
<<Media Guide Bar (Only two frames for Right and Left)>>
Set 2screws temporarily, and set parts on stand, and slide it to right.
Tighten 2screws.
Temporarily tighten Tighten
Slide it to right
D2 2
It was already assembled at factory.
