Epson STYLUS C43UX Manual

Unpacking
UnpackingUnpacking
Unpacking
1. Unpack the printer.
Note:
Store the protective materials in case you want to ship the printer in the future.
2. Attach the printer parts.
cCaution:
If the printer comes on when you plug in the power cord, turn off the printer by
pressing down the Ppower button until the printer lights go out.
3. Connect the printer.
Setting Up
Setting UpSetting Up
Setting Up
Installing the Printer Software
Note:
❏When the country selection window appears, select your country of residence.
❏If the language selection window appears, select your preferred language.
❏For installing the Photo Print Software, refer to the Photo Print Software Setup in the
online Reference Guide.
For Windows
1. Make sure that the printer is off.
2. Insert the printer software CD in the CD-ROM drive.
If the Installer dialog box does not appear, double-click
SETUP.EXE on the CD-ROM.
3. Select Install Software, and then click .
4. Follow the on-screen instructions. After the printer
software has been installed, the on-screen instructions
continue with the installation of the ink cartridges.
For Macintosh (EPSON Stylus C43UX only)
cCaution:
Turn off all virus protection programs before you install the printer software.
For users of Mac OS 8.6 to 9.x (except Mac OS X)
1. Make sure that the printer is off.
2. Insert the printer software CD in the CD-ROM drive.
3. Double-click the EPSON icon, select Install Software, and then click .
4. Follow the on-screen instructions to install the printer software.
5. Press the Ppower button to turn on the printer. The print head moves to the ink
cartridge installation position.
6. After installing the software, click Chooser in the Apple
menu, and then select the icon for your printer and the
port that your printer is connected to.
For users of Mac OS X
1. Make sure that the printer is off.
2. Insert the printer software CD in the CD-ROM drive.
3. Open the Mac OS X Driver folder, then double-click the C43Series_xxxx.pkg
icon. If the Authorization dialog box appears, click the icon, enter the Password
or phrase, then click OK.
4. Follow the on-screen instructions to install the printer software.
5. Press the Ppower button to turn on the printer. The print head moves to the ink
cartridge installation position.
6. Open the Applications folder on your hard drive, then open the Utilities folder
and double-click the PrintCentericon. Click AddPrinterin the Printer List dialog box.
7. Select EPSON USB from the pop-up menu. Select Stylus C43 in the Product list,
then select All from the Page Setup pop-up menu. Click Add.
8. Make sure the Printer List contains the printer(margin-type) options, then close Print
Center. See the Reference Guide on the printer software CD-ROM for more details.
Note:
When you print, be sure to match the Format for setting in the Page Setup dialog
box and the Printer setting in the Print dialog box. Otherwise, the data may not be
printed correctly. See the Reference Guide for more details.
Installing the Ink Cartridges
1. Turn on the printer.
2. Remove the new ink cartridges from their protective bag.
3. Insert the ink cartridges as shown in the illustration below.
Note:
Install all ink cartridges. The printer will not work unless all cartridges are installed
properly.
4. Press the bink button.
The printer begins the ink charging process. It
takes about one and a half minutes. While
charging ink, the printer produces a variety of
mechanical sounds. This is normal. When the
green lamp stops flashing, ink charging is
complete.
cCaution:
❏Do not turn the power off during the ink charging process.
❏Do not load paper until ink charging is complete.
Note:
In order to produce high quality printouts, the print head in your printer must be
fully charged with ink during the initial setup. This process consumes ink from the ink
cartridges packaged with your printer. Replacement cartridges will last for their full
rated life.
The contents may vary depending on the place of purchase.
Setup
The power cord may come attached in some countries.
Do not touch this part.
Do not remove or tear the label on the
cartridge.
Setup
cCautions must be observed to
avoid damage to your
equipment.
Notes contain important information
andusefultipsontheoperationofyour
printer.
English
xxxxxxx-00
xxx
Cautions and Notes

Checking the Printer
Checking the PrinterChecking the Printer
Checking the Printer
Loading Paper
Your printer is now ready to use.
See “Printing Basics” in the online Reference Guide for detailed instructions when
printing for the first time.
The online Reference Guide also contains the following information:
❏Various printing options
❏Printer Software Functions
❏How To
❏Problem Solver
❏Product Information
❏Safety Instructions
Please refer to the online Reference Guide for more details.
Accessing the Online Reference Guide
Follow these steps to access the online Reference Guide.
1. Insert the printer software CD in the CD-ROM drive.
2. For Windows, select User Guides in the dialog box, and then click .
For Macintosh, double-click the EPSON icon, select User Guides, and then click .
In Mac OS X, the dialog box does not appear when the printer software CD is inserted. To access
the online Reference Guide, double-click English\User Guides\REF_G\INDEX.HTM.
Problem Solver
Online problem-solving
The Problem Solver and EPSON’s Technical Support Web site provide you with tips to help solve problems. Access
the Problem Solver or Technical Support in the following ways:
For Windows
❏Click Start, point to Programs (for users of Windows Me, 98, 95, and
2000) or All Programs (for users of Windows XP), then to EPSON,
and then click ESC43 Problem Solver.
❏You can also click Technical Support in the Status Monitor 3 dialog
box or on the Main menu of the printer software.
For further information on the customer support services available in
your area, see the online Reference Guide.
For users of Mac OS 8.6 to 9.x (except Mac OS X)
1. Insert the CD in the CD-ROM drive.
2. Double-click the EPSON icon.
3. Select Technical Support Web Site, and then click .
For further information on the customer support services available in your area, see the online Reference Guide.
For users of Mac OS X
Access the Web site at:
http://support.epson.net/StylusC43/
Error indicators
You can identify many common problems using the lights on the printer’s control
panel. Use the following table of light patterns to diagnose the problem, and then
apply the recommended solution.
O = on, N = off, k k = flashing
Safety Instructions
Read all of the instructions in this section when setting up and using your printer.
When choosing a place for the printer:
❏Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct
sunlight, strong light, or heat sources.
❏Avoid places subject to dust, shocks, and vibrations.
❏Leave enough room around the printer to allow for sufficient ventilation.
❏Place the printer near a wall outlet where the plug can be easily unplugged.
❏Place the printer on a flat, stable surface that extends beyond the printer base in all directions. If you place
the printer by the wall, leave more than 10 cm between the back of the printer and the wall. The printer will
not operate properly if it is tilted.
❏When storing or transporting the printer, do not tilt it, put it vertically, or turn it upside down; otherwise, ink may
leak from the cartridge.
When choosing a power source:
❏Use only the type of power source indicated on the printer’s label.
❏Use only the power cord that comes with this product. Use of another cord may result in fire or electric shock.
❏This product’s power cord is for use with this product only. Use with other equipment may result in fire or electric
shock.
❏Be sure your power cord meets the relevant local safety standard.
❏Do not use a damaged or frayed power cord.
❏If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged
into the extension cord does not exceed the cord’s ampere rating. Also, make sure that the total ampere rating
of all devices plugged into the wall outlet does not exceed the wall outlet’s ampere rating.
❏If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit
breaker to provide adequate short-circuit protection and over-current protection for this printer.
When handling ink cartridges
❏Do not open the ink cartridge packages until just before you install them.
❏Keep ink cartridges out of the reach of children. Do not allow children to drink from or otherwise handle the cartridges.
❏Be careful when you handle used ink cartridges, as there may be some ink remaining around the ink supply port.
If ink gets on your skin, wash the area thoroughly with soap and water. If ink gets into your eyes, flush them
immediately with water. If discomfort or vision problems remain after a thorough flushing, see a doctor immediately.
❏Do not shake the ink cartridges; this can cause leakage.
❏You must remove the yellow tape seals from the cartridges before installing them; otherwise, the cartridges will
become unusable.
❏Do not remove the blue portion of the tape seals from the top of the cartridges.
❏Do not remove the tape seals from the bottom of the cartridges.
❏Do not touch the green IC chip on the side of the cartridge.
❏The IC chip on this ink cartridge retains a variety of cartridge-related information, such as the amount of ink
remaining, so that a cartridge may be removed and reinserted freely. However, each time the cartridge is
inserted, some ink is consumed because the printer automatically performs a reliability check.
When using the printer:
❏Do not put your hand inside the printer or touch the ink cartridges during printing.
❏Do not block or cover the openings in the printer’s cabinet.
❏Do not attempt to service the printer yourself.
❏Unplug the printer and refer servicing to qualified service personnel under the following conditions:
The power cord or AC plug is damaged; liquid has entered the printer; the printer has been dropped or the
cabinet damaged; the printer does not operate normally or performs differently.
❏Do not insert objects through the slots in the printer’s cabinet.
❏Take care not to spill liquid on the printer.
❏Leave the ink cartridges installed. Removing the cartridges can dehydrate the printer head and may prevent
the printer from printing.
locking tab
left edge guide
output tray extension
To adjust the left edge guide, hold down the locking tab and slide the guide against the paper stack.
Windows
Macintosh
Lights Problem and solution
O bPaper out No paper is loaded in the printer.
Load paper in the sheet feeder, and then press the bmaintenance button. The printer resumes
printing and the light goes out.
O bPaper jam Paper has jammed in the printer.
Press the bmaintenance button to eject the jammed paper. If the error does not clear, open the
printer cover and remove all of the paper inside, including any torn pieces. Then, reload the paper
in the sheet feeder and press the bmaintenance button to resume printing.
k bInk low The black or color ink cartridge is nearly empty.
Obtain a replacement black ink cartridge (T038) or color ink cartridge (T039). To determine which
cartridge is nearly empty, check the ink level using EPSON Status Monitor 3 (Windows) or EPSON
StatusMonitor (Macintosh).
O bInk out The black or color ink cartridge is empty or not installed.
Replace the black ink cartridge (T038) or color ink cartridge (T039) with a new one.
N P
O bCarriage error The print head carriage is obstructed by jammed paper or other
foreign material and cannot return to the home position.
Turn off the printer. Open the printer cover and remove any paper or other obstructions from the
paper path by hand. Then, turn the printer back on.
If the error does not clear, contact your dealer.
k P
k bUnknown printer error An unknown printer error has occurred.
Turn off the printer and contact your dealer.
