Epson SureColor F6000 Installation instructions

• Designedforcustomsportswear,sportsgearandmerchandiseproduction
• EpsonUltrachrome™DyeSublimationinkprovidesenhancedcolourand
 brightnesswithpredictableperformanceandexceptionalwash/UVdurability
• Compact,fastandexiblewithsupportforresolutionsupto720x1440dpiand
 printspeedsupto63.4m2/hr
• Designedforcost-effectivead-hocproductionwithultra-lowpowerconsumption,
 alarge6LContinuousInkSupplySystem(CISS),FastSpindle-LessMedia
 Loading,RemoteStatusNoticationandManagement
• Supportsawiderangeoftransfermediaandfeaturesahigh-speedauto-cutter
• EpsonPrecisionCore™ThinFilmPrint(TFP)headwithVariableSizeDot
 Technology™(VSDT)forsuperiorhalftonesandoptimisedinkusage
• Oeko-Tex™certicationensuresgarmentscanbewornbyadults,childrenandinfants
Epson SureColor®F6000 DS System

Product Specifications
Compact with front loaded
consumables and all connections on
the right. Can be installed against a
wall or in a corner.
Fast & flexible production with spindle-
less media loading and an integrated
auto-cutter.
Continuous Ink Supply System with
cost-effective 1L refills that are easy to
store and produce less waste.
PHYSICAL
Dimensions 1608 mm x 1128 mm x 917 mm (WxHxD)
Weight 90kg with stand & CISS, no ink
Shipping Carton (Main Unit) 1978 mm x 1051 mm x 816 mm (WxHxD), 135 kg
WHAT’S IN THE BOX2
Printer, Stand, Power Cable, 1 x Set 1L Inks, 1 x Roll
Media Adaptor Set, 1 x Roll Epson Transfer Media, 2 x
Maintenance Tanks, Utility Software & User manual
(on CD), Warranty Docs, Ergosoft RIP software
CONFIGURATION OPTIONS3
SCF6000AS1Y Delivered with 1Yr On-Site Warranty & ErgoSoft
Sublimation Standard s/w
SCF6000AP1Y Delivered with 1Yr On-Site Warranty & ErgoSoft
Sublimation Professional s/w
SCF6000AS3Y Delivered with 1Yr On-Site Warranty 2Yr Service Pack
& ErgoSoft Sublimation Standard s/w
SCF6000AP3Y Delivered with 1Yr On-Site Warranty 2Yr Service Pack
& ErgoSoft Sublimation Professional s/w
OPTIONAL ACCESSORIES
C12C811391 Additional Roll Media Adapter set
CONSUMABLES
C13T619300 Replacement Maintenance Tank
C13S902006 Replacement Auto Cutter Blade
C13T741100 6 x 1L Black UltraChrome DS Ink Refills
C13T741200 6 x 1L Cyan UltraChrome DS Ink Refills
C13T741300 6 x 1L Magenta UltraChrome DS Ink Refills
C13T741400 6 x 1L Yellow UltraChrome DS Ink Refills
PRINTING TECHNOLOGY
Print Head Epson PrecisionCoreTM TFP with VSDT
Print Modes Uni & Bi-directional
Configuration 2x360 Nozzles per colour
Maximum Resolution 720x1440 dpi
Minimum Droplet Size 5.3 pl
INK SYSTEM
Ink Type Epson Ultrachrome®DS
Colours C+Y+M+Bk
Storage 4 x 1.5L CISS with 1L refills
PERFORMANCE1
Draft 63.4m2/hr 1 Pass (360x720dpi)
High Speed 30.2m2/hr 2 Pass (720x720dpi)
Production 22.7m2/hr 3 Pass (720x720dpi)
Quality 11.2m2/hr 6 Pass (720x1440dpi)
MEDIA SUPPORT
Roll Format Single Roll, 103mm max diameter with 2"core or
150mm max diameter with 3"core, 0.08-0.5mm
thick (75gsm or greater), 254-1118mm width,
Printing Width Max 1112mm with 3mm margin each side
OPERATION
Control Panel 2.5"Colour LCD with in-built help
Ultility Software Communications driver, LFP RemotePanel 2, EpsonNet
setup, Config & Print utilities
RIP Software Epson Sublimation software from ErgoSoft in a choice
of Standard or Professional edition (Pro includes
additional facilities for precision colour mgmt, job
costing & volume batch processing)
Interface USB 2.0 & Ethernet 100Base-TX/1000Base-T
Memory 512 MB Main + 128MB Network
Media Cutter High Speed with Manual & Auto Modes
ENVIRONMENTAL
Operational Temp 15-35oC (15-25oC recommended)
Operational Humidity 20-80% (no condensation,40-60% recommended)
Power Supply AC 100 V - 240 V, 50 Hz - 60 Hz, 1.0-0.5A
Power Consumption 65W Operating / 20W Standby / 3W Sleep
Operating Noise 55.1dB
ThefourcolourEpsondyesublimationinksusedintheSureColorSCF6000printer,whenappliedtopolyester
fabrics,passtherequirementsoftheOeko-TexStandard100forhumanecologicalrequirementsofClassIproducts
foradults,children,andbabiesupto36months.Thestandardspeciestestingcriteriaforthepresenceofharmful
substanceswithinatextileproductandbelongstotheInternationalAssociationforResearchandTestingintheeld
ofTextileEcology(Oeko-Tex).
1. Performance figures are printer speeds only; actual production times will vary depending on computing platform, print application, file format/
size and networking configuration.
2. The independent sourcing of a sheet based press will be required. The use of an external heater/ blower unit is also recommended.
3 Delivery & on-site service is provided free of charge within limited areas. Service cover is also conditional. Please see the Epson Australia web
site for terms and conditions.
EpsonistheregisteredtrademarkofSeikoEpsonCorporation.Allothernamesandcompanynamesusedhereinareforidenticationpurposeonlyandmay
bethetrademarksorregisteredtrademarksoftheirrespectiveowners.Epsondisclaimsanyandallrightsinthosemarks.Allprintsamplesshownhereinare
simulations.Specicationsaresubjecttochangewithoutnotice.
EPSON AUSTRALIA
3 Talavera Road
North Ryde NSW 2113
Tel: [phone]
www.epson.com.au
ABN 91 002 625 783
05/14
