Universal features
All three printer models in Epson’s
TM-U220 series are optimized for
high-speed throughput so customer
receipts and kitchen orders print
faster than ever. For maximum effi-
ciency, the TM-U220A, TM-U220B
and TM-U220D all offer drop-in
paper loading and two-color, black
and red printing to highlight special
offers and print more impactful logos,
and an adjustable paper width feature
that allows you to use 58, 70 or
76mm paper rolls for more flexibility
and greater cost savings.
A model for every need
With Epson’s TM-U220 series,
you have the freedom to select the
model that best fits your needs. The
TM-U220A and TM-U220B come
with an autocutter so you can choose
between a full or partial cut, and
an Auto Status Back function that
automatically transmits changes in
the printer status. The TM-U220A
includes a take-up journal device and
the TM-U220B and the TM-U220D
have a wall-mounting option that
prints the receipt right side up for
easy reading right out of the printer.
And of course, all three printers
feature the quality, reliability and
advanced printing technology that
Epson is famous for.
Smooth and easy transition
To make upgrading even easier,
Epson’s TM-U220 series has been
designed to be 100% compatible
with existing systems that currently
use a TM-U200 printer. Because
the external dimensions of the
TM-U200 and TM-U220 printer
series are almost identical,
transitioning to a new TM-U220
printer is as simple as removing
the TM-U200 and dropping in
the new TM-U220 and AC adapter.
Epson
TM-U220
Epson’s TM-U220 printers are the enhanced,
more powerful successors to Epson’s best-selling
TM-U200 family.
Available in three different models, Epson’s TM-U220
printers are compact, reliable and fast, and offer all the
easy-to-use features important to the retail, restaurant
and hospitality industries.
POS Impact Printers
Compact, Versatile Receipt Printers
• Three impact printer models
• Easy to operate
• 30% faster than the TM-U200 series
• Drop-in paper loading
• Two-color black and red receipt and order printing
• Right-side-up printing for kitchen orders
• Flexible paper widths
• Two-year warranty
• Optional power supply case

General Print method 9-pin, serial impact dot matrix
Print font
Font 7 x 9/9 x 9
Column capacity 40/42 or 33/35
(columns)
Character size 1.2(W) x 3.1(H)/1.6(W) x 3.1(H)mm
Character set 95 Alphanumeric, 37 International, 128 x 12 Graphic
Traditional/Simplified Chinese, Thai, Japanese, Korean
Characters per inch 17.8/16 cpi or 14.5/13.3
Printer Interfaces* RS-232C, IEEE 1284 parallel; RS-485; USB; 10/100Base-T/TX; wireless
Data buffer 4 KB or 40 bytes
Print speed 4.7 lps (at 40 columns, 16 cpi), 6.0 lps (at 30 columns, 16 cpi)
Paper dimensions 57.5±0.5mm, 69.5±0.5mm, 76±0.5mm (W) x dia. 83.0
Paper thickness 0.06 to 0.085
Copy capability One original and one copy
Inked ribbon ERC-38 (Black, Black/Red)
Ribbon life Black: 3 x 106characters
B/R: 15 x 105characters (Black), 75 x 104characters (Red)
Power 24 VDC±7%
D.K.D. function 2 drivers
Reliability
MTBF 18 x 104hours
MCBF 18 x 106lines
Overall dimensions (mm) Type A: 160 (W) x 286 (D) x 157.5 (H)
Type B: 160 (W) x 248 (D) x 138.5 (H)
Type D: 160 (W) x 248 (D) x 138.5 (H)
Mass (Approx.) Type A: 2.7 Kg
Type B: 2.5 Kg
Type D: 2.3 Kg
Environmental standards WEEE, RoHS compliant
Factory options Near-end sensor, power supply cover, wall-hanging bracket WH-10, Exclusive Adaptor C (included)
Control Board EMI standards VCCI class A, FCC class A, CE marking, AS/NZS 3548 class B
Safety standards UL, CSA, TÜV (EN60950)
Epson TM-U220 POS Impact Printers
Printer Specifications TM-U220
Epson America, Inc. • 3840 Kilroy Airport Way • Long Beach, CA 90806 • [phone] • http://pos.epson.com
©2006 Epson America, Inc. Epson is a registered trademark and Exceed Your Vision is a trademark of Seiko Epson Corporation.
Connect-It is a trademark of Epson America, Inc. All other trademarks are the property of their respective owners. Specifications
are subject to change without notice.
SD-DSU220E
Inch values are approximate.
cpi: characters per 25.4mm (characters per inch)
lps: lines per second
*To find out more about our line of Connect-It interfaces, talk to your Epson Sales Representative.
Compact, Versatile Receipt Printers
Optional power supply case
secures cords under printer.
Power supply case fits under printer
without increasing footprint size.
