ergolet ErgoSlings Series User manual

Comfort
Disposable Sling
User manual
Important information
Read this user manual before using
the product.
This user manual is aimed at care
personnel, family members and
therapists in connection with the use
and maintenance of slings made by
ErgoSling.
Date: 26.02.2021 - Version 01
Universal
Comfort Disposable Sling
Scan QR-code for future information

2

3
Contents
1. PURPOSE .......................................................................................1
2. SAFETY INSTRUCTIONS..................................................................4
3. CHECK BEFORE USE.......................................................................5
4. LIFTING..........................................................................................6
5. UNIVERSAL COMFORT DISPOSABLE..............................................8
5.1 Universal Comfort, Nonwoven –disposable.................................8
6. ACCESSORIES.................................................................................9
7. MAINTENANCE............................................................................10
7.1 Washing instructions...................................................................10
7.2 Storage ........................................................................................10
8. INSPECTION.................................................................................10
9. QUALITY AND THE ENVIRONMENT .............................................10
9.1 Disposal .......................................................................................10
9.2 Quality.........................................................................................10
9.3 Symbols and abbreviations .........................................................11

4
1. PURPOSE
This series of ErgoSlings concerns only with disposable sling, that are intended for use in lifting
or transferring people with reduced mobility.
Transfer can be achieved in combination with stationary or mobile hoist.
•Disposable slings can be used at hospitals, in the context of home care, at institutions
and in private homes.
•Disposable slings can be used for transfers from a wheelchair/chair or from a chair to
a bathing and toilet chair etc.
•Disposable sling are available in various sizes, and some are available with or without
a head support. See the specifications for the various sling models in this user
manual.
NOTE: All illustrations and descriptions are applicable to all versions of disposable slings unless
a separate description is provided.
NOTE: ErgoSlings disposable slings must not be used for any purposes other than those
described in this user manual.
2. SAFETY INSTRUCTIONS
Read the user manual and these safety instructions thoroughly before using the sling:
•Do not exceed the sling's maximum lifting capacity.
•Use the correct size and model of sling for the user.
•Make sure the sling has no visible damage or signs of wear. In particular check that the
seams are intact. The hoist straps must not be frayed, and they must not be knotted.
•For hygiene reasons, the sling must be clean.
•Qualified personnel must always be present when attaching the sling and during lifting.
•It must be ensured that hazardous situations do not arise when using any other
equipment, e.g.: the sling straps becoming caught in the wheels of a wheelchair, or
similar.
•It must be ensured that neither the helper nor the user can be injured while using the
sling.
•The user must never be left alone in the sling.
•The helper is responsible for ensuring that the sling is used properly and is also
responsible for ensuring that safety is maintained. See section - 3. Check before use.
!
Important –Warning!

5
3. CHECK BEFORE USE
The carer is responsible for ensuring that the sling is checked before use, and that instructions
for use have been provided.
Check the following points before use:
1) Check that the sling used is the correct model and is the right size, so that it is right for
the lifting situation and the user.
Note: All the slings have a coloured loop that indicates the size
and the centre line of the sling.
Size chart with head support (all measurements are approximate)
Y
42 cm
48 cm
52 cm
68 cm
Z
80 cm
91 cm
100 cm
100 cm
Colour
Red
Yellow
Green
Blue
Size chart without head support (all measurements are approximate)
Y
42 cm
48 cm
52 cm
68 cm
X
55 cm
66 cm
75 cm
75 cm
Colour
Red
Yellow
Green
Blue
2) It is important to check that a sling with the correct spreader bar size is used in order to
fit the user's shoulder measurement.
3) Check that the fabric of the sling and the straps are intact. There must not be any wear or
damaged seams.
4) Check that the Nonwoven sling have not been exposed to moisture - in case of doubt,
replace Nonwoven sling.
5) Check that the sling is clean.
6) If in any doubt about how to use the sling, Winncare Nordic can be contacted for advice
and guidance.
S
M
L
XL
S
M
L
XL

6
4. LIFTING
Note: The lifting situation must always be planned, and it must be ensured that the user
feels secure when being lifted in the sling.
Lifting from a sitting position:
1) Place the sling behind the user's back with the
coloured loop by the label indicating the centre
line. The centre line must be aligned with the
user's spine.
2) Push your hand down into the positioning
pocket and push the sling as far as possible
beneath the user's lower back.
3) Place the sling's leg supports alongside the
user's legs and carefully feed the leg straps
underneath the legs.
Note: Make sure you do not pull on the straps
when placing them underneath the user's
legs. It can help the procedure to place the
user's feet on a footstool or by using a slider.
4) Cross the short, coloured strap over the lifting
strap on the opposite side. (A)
Next cross the straps from the legs supports
with the leg straps from the insides of the thigh
(B).
5) Attach the sling straps to the hook on the
spreader bar. See page 7 of the instructions.
6) Now carefully lift the user. Once the straps are
straightened out, the sling can be straightened
so that it is positioned correctly.
A
B

7
Lifting from a lying position:
1) Place the user on his or her side and fold up the
sling to its centre line. Place the folded part
beneath the user.
2) Next roll the user onto his or her other side,
completely unfold the sling and then return the
user to a lying position.
3) Place the leg straps underneath the legs and pull
them out between the user's legs.
Note: Be careful not to pull on the straps when they are under the user's legs. It can be
facilitated by using a slider. The coloured short strap is crossed over the lifting strap
on the opposite side. Then cross the straps from the leg supports with the leg straps
from the inner thigh.
4) Attach the sling straps to the hook on the spreader bar. See section Attach the sling to the
spreader bar.
5) Now carefully lift the user. Once the straps are straightened out, the sling can be
straightened so that it is positioned correctly.
Attach the sling to the spreader bar:
Winncare Nordic excludes any liability if the sling is not correctly attached to the
hook on the spreader bar.
It is always the responsibility of the helper to ensure that the correct sling is used and
that it is suitable for the need/purpose.
1) Attach the sling strap to the open hook.
Note: On some models, there are straps of different colours. It is
important here that the same colour is used on the hooks on
each side in order to avoid an uneven lift.
2) Pulling the strap down causes the lock to close with a “click”.
Note: The lifting hook is designed in such a way that the
user's weight automatically keeps the hook locked.
To unhook the strap, pulling the strap up causes the hook to open.
Care should be taken to avoid the user’s fingers becoming caught in the hook.
!
!

8
5. UNIVERSAL COMFORT DISPOSABLE
Universal Comfort with head support
Universal Comfort without head support
Use:
•Universal Comfort for users with reduced physical functionality or amputation, or
users requiring upper body support.
•Universal Comfort available with a head support, which can be used for users who
do not have full head control.
•Universal Comfort, Nonwoven –disposable, for one time use only.
5.1 Universal Comfort, Nonwoven –disposable
Note: NOT to be washed. If the sling gets wet/moisture, do NOT use it.
Note: Nonwoven disposable can be used for maximum 14 days and with
maximum of two transfers per day.

9
Specifications:
SWL
275 kg
Material
Nonwoven
Padding
Yes
Sling is available in sizes
XL - XXL
Spreader bar compatibility
2, 3 and 4-point
Divided leg support
Yes
6. ACCESSORIES
Extension strap
Application:
•Extension straps - are used when having to adjust the lifting gear further for the current
patient and lifting situation. The extension straps can be used, for example, to increase
the distance between the user's head and spreader bar or to open the user's hip angle.
Note: It is always the lowest weight capacity part of the lifting system that applies to the
complete lifting equipment.
Specifications:
Extension strap
SWL
400 kg
Material
Polyester
Padding
Yes
Strap size options
14 cm + 28 cm
Fits the following yoke
2-, 3- and 4-point

10
7. MAINTENANCE
7.1 Washing instructions
Universal Comfort Disposable sling are not washable - DO NOT wash.
A key to the symbols can be found under section 7.3 - Symbols and abbreviations.
7.2 Storage
If the sling is not being used, it should be packed in its original packaging and stored in a clean
and dry place at a temperature between 0-40°C.
8. INSPECTION
ErgoSlings disposable slings are thoroughly inspected each time before use, including whether
the material has visible signs of having been exposed to moisture, moist skin, sweat, etc. If the
sling has been exposed to a minimum of moisture, the sling must not be used again and have to
be replaced.
We recommend that a start date is noted for commissioning of sling, to ensure that the
disposable sling is discarded after max. 14 days use.
The legal owner of the product is responsible for ensuring that inspection is carried out.
An inspection schedule can be requested from Winncare Nordic.
Guarantee
There is a two-year guarantee on materials and manufacture defects, on condition that there is
compliance with safety.
9. QUALITY AND THE ENVIRONMENT
9.1 Disposal
ErgoSlings may be disposed of together with flammable materials at the recycling centre, or
they can be returned to Winncare Nordic.
9.2 Quality
Winncare Nordic is certified in accordance with ISO 9001 and ISO 13485 quality standards.
These certificates mean that the product and the company meet applicable international
standards for quality management and standards for traceability for medical products.
ErgoSlings are classified as Medical equipment class 1 product.

11
9.3 Symbols and abbreviations
If Disposable Sling is wet/moisture - it must be discarded/thrown out
Wash is not allowed
Warning symbol
Do not iron
Do not use bleach
Do not dry-clean
See the user manual
The product can be disposed of with general waste
SWL
Safe working load = (user + accessories)
The product is CE-marked
!

12
Manufacturer:
Winncare Nordic ApS
Taarnborgvej 12 C
4220 Korsoer
Denmark
Phone: + 45 70 27 37 20
Fax: + 45 70 27 37 19
Email: [email protected]k
www.Winncare.com
(EU) 2017/745 CLASS I
EN/ISO 10535:2007
IEC 60601-1-2:2015
UM-910-00795UK
