ergolet ErgoSlings Standing sling 1-belt User manual
Standing slings
User manual
- Standing sling, 1-belt
- Standing sling, 2-belts
Important information
Read this user manual before using
the product.
This user manual is aimed at care
personnel, family members and
therapists in connection with the use
and maintenance of slings made by
ErgoSling.
Date: 23.05.2019 - Version 06
Scan the QR-code for further information
2
3
Contents
1. PURPOSE...................................................................................................4
2. SAFETY INSTRUCTIONS .............................................................................4
3. CHECK BEFORE USE...................................................................................5
4. LIFTING......................................................................................................6
5. STANDING SLINGS.....................................................................................7
6. MAINTENANCE .........................................................................................8
6.1 Washing instructions ..........................................................................8
6.2 Storage................................................................................................8
7. INSPECTION ..............................................................................................8
8. QUALITY AND THE ENVIRONMENT...........................................................9
8.1 Disposal...............................................................................................9
8.2 Quality ................................................................................................9
8.3 Symbols and abbreviations.................................................................9
4
1. PURPOSE
This range of slings from ErgoSlings are all standing sling that are intended for use for supporting
people with reduced mobility in a transfer situation.
Transfer can be achieved in combination with a stand-aid lifter.
•These slings can be used at hospitals, in the context of home care, at institutions and in
private homes.
•The slings can be used for transfers from a wheelchair/chair or from a chair to a bathing
and toilet chair etc.
•All models of the sling are available in various sizes. See the specifications for the
various sling models in this user manual.
NOTE: All sling models described in this manual. Illustrations and descriptions are applicable to
all versions, unless a separate description is provided.
NOTE: ErgoSlings must not be used for any purposes other than those described in this user
manual.
2. SAFETY INSTRUCTIONS
Read the user manual and these safety instructions thoroughly before using the sling:
•Do not exceed the sling's maximum lifting capacity.
•Use the correct size and model of sling for the user.
•Make sure the sling has no visible damage or signs of wear. In particular check that the
seams are intact. The hoist straps must not be frayed, and they must not be knotted.
•For hygiene reasons, the sling must be clean. See the washing instructions in section 5.
•Qualified personnel must always be present when attaching the sling and during lifting.
•It must be ensured that hazardous situations do not arise when using any other equipment,
e.g.: the sling straps becoming caught in the wheels of a wheelchair, or similar.
•It must be ensured that neither the helper nor the user can be injured while using the sling.
•The user must never be left alone in the sling.
•The helper is responsible for ensuring that the sling is used properly and is also responsible
for ensuring that safety is maintained. See section - 3. Check before use.
!
Important –Warning!
!
5
3. CHECK BEFORE USE
The helper is responsible for ensuring that the sling is checked before use, and that
instructions for use have been provided.
Check the following points before use:
1) Check that the sling used is the correct model and is the right size, so that it is right
for the lifting situation and the user.
Note: All the slings have a coloured loop that indicates
the size and the centre line of the sling.
Size chart (all measurements are approx.)
2) Check that the fabric of the sling and the straps are intact. There must not be any
wear or damaged seams.
3) Check that the sling is clean.
4) If in any doubt about how to use the sling, Winncare Nordic can be contacted for
advice and guidance.
Colour
White
Red
Yellow
Green
Blue
Black
6
4. LIFTING
Note: The lifting situation must always be planned, and it must be ensured that the user
feels secure when being lifted in the sling.
1) Place the sling behind the user's back with the
colored loop by the label indicating the
centerline. The centerline must be aligned
with the user's spine.
2) The non-slip piece must face the user's back.
3) The standing sling with 2-buckles has a velco-
piece that must be tightly closed around the
user.
4) Click the buckle / buckles together and tighten
the belt.
5) Attach the straps on the lifting arms hooks.
See instructions on page 7.
6) Now lift the user carefully, when the straps are
stretched the sail can be straightened so that
it sits correctly.
7
Attach the sling to the spreader bar
Winncare Nordic excludes any liability if the sling is not correctly attached to the
hook on the spreader bar.
It is always the responsibility of the helper to ensure that the correct sling is used
and that it is suitable for the need/purpose
1) Attach the sling strap to the open hook.
2) Pulling the strap down causes the lock to close with a “click”.
Note: The lifting hook is designed in such a way that the user's weight
automatically keeps the hook locked.
To unhook the strap, pulling the strap up causes the hook to open.
Care should be taken to avoid the user’s fingers becoming
caught in the hook.
5. STANDING SLINGS
Standing sling with one buckle
Standing sling with two buckles
Use:
•Standing sling is for users who can stand by themselves during the transfer, but needs
assistance getting up from sitting position or assistance to sit down.
•Standing sling are used for users with standing function and a good upper body control.
!
!
8
Specification:
Standing sling with one buckle
SWL
250 kg
Material
Polyester
Padding
Yes
Sling is available in sizes
S - XXL
Standing sling with two buckles
SWL
250 kg
Material
Polyester
Padding
Yes
Sling is available in sizes
XS - XL
6. MAINTENANCE
6.1 Washing instructions
ErgoSlings can be machine-washed. We recommend that the buckles on the slings are closed
and washed in a laundry bag to protect the buckles.
Note: Do not use softener.
Standing sling can be tumble-dried at a low temperature.
Follow the washing instructions as indicated by symbols and printed instructions on the sling
label.
A key to the symbols can be found under section 7.3 - Symbols and abbreviations
6.2 Storage
If the sling is not being used, it should be packed in its original packaging and stored in a clean
and dry place at a temperature between 0-40°C.
7. INSPECTION
ErgoSlings should be inspected at least once every six months in accordance with EN/ISO
10535, Annex B, which recommends that inspection should be carried out by a qualified person
who is familiar with use of the sling.
The legal owner of the product is responsible for ensuring that inspection is carried out. An
inspection schedule can be requested from Winncare Nordic
Warranty
There is a two-year guarantee on materials and manufacture defects, on condition that there is
compliance with safety and washing instructions.
9
8. QUALITY AND THE ENVIRONMENT
ErgoSlings have an expected lifetime of 5 - 10 years assuming normal daily use. This also
assumes that the recommended inspection and maintenance is carried out.
8.1 Disposal
ErgoSlings may be disposed of together with flammable materials at the recycling centre, or
they can be returned to Winncare Nordic.
8.2 Quality
Winncare Nordic is certified in accordance with ISO 9001 and ISO 13485 quality standards.
These certificates mean that the product and the company meet applicable international
standards for quality management and standards for traceability for medical products.
ErgoSlings are classified as Medical equipment class 1 product.
8.3 Symbols and abbreviations
Machine-wash at the indicated temperature.
Do not iron.
Do not use bleach.
Do not dry-clean.
Tumble-dry at low temperature.
See the user manual.
The product can be disposed of with general waste.
SWL
Safe working load = (user + accessories)
The product is CE-marked.
10
