ermengineering AFP-200 User manual

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
www.ermengineering.com 󰞟󰞠󰞡󰞢󰞣info@ermengineering ✆([phone]
P a g . 1
(Original) Use and maintenance manual
Type: Auto-Puncher for Conveyor Belts
Model: AFP-200
IMPORTANT:
Read this user manual and follow the instructions and warnings before operating this device.
Any modification or transformation performed on this machine may cause loss of the
manufacturer’s guarantee and liability
This manual must always remain near to the machine and visible to all the operating and
maintenance staff, for any future consultation, forming part of the equipment

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 2
Index:
Page
-CE Declaration of conformity:................................................................................................................................................3
-Transport and unloading the machine:..............................................................................................................................4
-Dimensions and weights:.........................................................................................................................................................5
-Installation and connection:...................................................................................................................................................5
-Description: ..................................................................................................................................................................................6
-Technical characteristics:........................................................................................................................................................7
-Using instructions: .....................................................................................................................................................................7
Safety systems and messages .............................................................................................................................................................................. 8
Programming:........................................................................................................................................................................................................... 9
Belt cutting measurements for the different punches. ............................................................................................................................10
Changing punch: ....................................................................................................................................................................................................10
PUNCH CUTTING A-A direct finger.................................................................................................................................................................12
PUNCH CUTTING A-A diagonal ........................................................................................................................................................................16
PUNCH CUTTING finger over finger:..............................................................................................................................................................18
Changing support plate:......................................................................................................................................................................................24
Maintenance and care: ........................................................................................................................................................................................25
-Troubleshooting: ..................................................................................................................................................................... 26
-Pneumatic scheme: ................................................................................................................................................................. 27
-Spare parts:................................................................................................................................................................................ 28
-Electric schemes....................................................................................................................................................................... 34

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 3
-CE Declaration of conformity:
WE DECLARE, under our responsibility, that the machine:
- Type: Automatic Puncher
- Brand: ERM Engineering
- Model: AFP-200
- Serial No.: xxxxxx
- Manufacturer date: 2021
Inspired by the directives of the Official Journal of the European Communities:
2006/42/CE Machinery Directive
2014/35/UE Low Voltage Directive
2014/30/UE Electromagnetic Compatibility Directive
Complies with the design and construction specifications of the European Standards on General
Machine Safety:
EN 349 –EN 614-1 –EN 614-2 –EN 1005-1 –EN 1005-2 –EN 1005-3 –EN 1005-4 –EN
14118 - EN 12100–EN 13850 –EN 13857 –EN 14118 - EN 14120 –EN 60204-1 –EN
11161 –EN 61310-1 - EN 13849-1 –EN 13849-2 –EN 60204-1
General Manager: Eduardo Ramos Martínez
Arenys de Munt (Barcelona)-SPAIN
Date: 2021/08

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 4
-Transport and unloading the machine:
Due to the fragility of some components of the machine, wood packaging is required with
reinforced board to attach it to the base by bolts through the openings in the rubber feet.
To keep the weight of the load well balanced, moving the punch cutting head to halfway across its
run before proceeding to pack is recommended.
For sea transport, the linear rails and drive screw located at the bottom of the cutting head must
be lubricated and full plastic cover provided.
A pallet truck must be used to move the machine, lifting it by the bottom cross bars of the bench
just as shown in the picture.
Fit the four rubber feet and proceed to level.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 5
-Dimensions and weights:
Total weight: 615 Kg
Measurements: 2775x1070x1325 mm.
-Installation and connection:
Provide compressed air through a tube with a minimum interior diameter of 8 mm., connected to
the intake.
WARNING: DO NOT LUBRICATE THE COMPRESSED AIR that supplies the machine, all
pneumatic elements are self-lubricated.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 6
WARNING: Avoid the entry of air with humidity or condensation. For this, it is
recommended to use a compressor with a drying unit.
NOTE: While the compressed air is connected, we will hear a slight air leak coming from the
pressure regulator. This is not an abnormality.
NOTE:
One must bear in mind that the air consumption of this punch cutter is 220 litres/minute.
Connect the power cable to the control board at 230v monophasic.
NOTE:
It is recommendable for the air and power lines to be run from above to prevent the staff
tripping or falling.
-Description:
Pneumatic punch cutter with a motorised head to cut conveyor belts in zigzag, with ball screw
activated by a stepper motor and positioning control. Pressure and punch cutting time control.
-Exchangeable cutting heads for different cutting geometries, with the possibility of
programming diverse forward steps.
-Support bench with material positioning guides.
This punch cutter is especially designed to cut thermoplastic materials with interior fabric.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 7
-Technical characteristics:
Dimensions 2775 x 1070 x 1325 (l x w x h)
Weight 615 Kg
Max. thickness 8 mm.
Voltage 1 x 230
Power 0.40 kW
Max. pressure 7 bar
Belt width 2010 mm.
Advance speed 1 metre/minute
-Using instructions:
WARNING:
HAND AND ARM TRAPPING HAZARD WITH THIS DEVICE DUE TO THE MOVEMENT OF THE
CUTTING HEAD. GREAT CARE MUST ALSO BE TAKEN BETWEEN THE CUTTING HEAD AND
SUPPORT PLATE, AS THERE IS THE DANGER OF LIMBS BEING SEVERED
Once the machine electrical and air connections are made, proceed to start it up using the ON
switch.
Check that the regulator pressure is between 2 and 6 bar according to the cutting head installed.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 8
Safety systems and messages
This die cutter has been equipped with the following safety systems:
1- EMERGENCY STOP
This system allows an emergency stop to be performed at any time using the two push buttons
located at both ends of the bench.
MESSAGE: EMERGENCY BUTTON PRESSED
To deactivate it, we must unlock the push button and then press RESET to return the head to the
starting point.
2- TREAD BAR
This device does not allow engagement of the cutting head if the bar holding the belt is not
lowered.
MESSAGE: CLAMP OPEN
To deactivate it, all one need do is lower the bar and press START.
3- DOOR OPEN
This device detects that the rear door of the blade head is open.
MESSAGE: COVER OPEN
The door must be closed to deactivate it.
4- CYLINDER DETECTOR
This device does not allow displacement of the head because it detects that the cutting
cylinder is not raised. This may happen due to lack of air or failure of the detector.
MESSAGE: CYLINDRE WRONG
To deactivate it, provide the machine with air or replace the detector.
1. CYLINDER DETECTOR
This device does not allow displacement of the head because it detects that the cutting cylinder is
not raised. This may happen due to lack of air or failure of the detector.
Message: CYLINDER DETECTOR
To deactivate it, provide the machine with air or replace the detector.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 9
Programming:
We must know the functions of the push buttons on the board to program the die cutter.
1. RESET
This must be pressed after an emergency stop or position the head at the starting point
after STOP.
2. A-A
Selection of the A-A program
This program is used in the majority of cases, to always operate on the left guide rail and
cut the belts performing the first end with the coverage on top and the second end with
the fabric on top, both for direct finger die cutting as well as finger over finger die cutting.
3. A-B
Selection of the A-B program
This program is only used in cases of diagonal belts, or belts with an hi profile, to operate
the first end on the left guide rail and the second on the right guide rail, always with the
coverage on top.
4. STOP
Allows the cutting process to be halted at any moment, to change the time or cutting
pressure, for example.
On pressing START, it will continue the process without losing the positioning memory
5. START
Starts the cutting process or acts to reboot following a STOP.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 10
6. WIDTH
We shall use this button to program the width of the belt in centimeters using the
keyboard, accept the value and press ENTER
7. STEP
We shall use this button to program the cutting step depending on the assembled head,
using the keyboard set the number in millimetres, between 3mm to 50mm, to accept the
value press ENTER.
8. TIME
We shall use this button to program the cut time with the keyboard, the values accepted
are between 3 to 10, to accept press ENTER.
9. ESC
We shall us this button to correct or delete any wrong value during programming
Belt cutting measurements for the different punches.
80 x 10 90º………………………………………………… 100 mm. Longer
80 x 10 75 º…………………….…………………….…… 100 mm. Longer
120 x 15 90 º……………………………………………… 135 mm. Longer
50 x 20 finger overlapping 90º…………………… 125 mm. Longer (cloth opening 130mm.)
Changing punch:
WARNING:
When changing punches, switching off the equipment at the OFF switch is recommended
for greater safety.
Open the sliding door.
Loosen the 2 bolds using a 13 mm. spanner.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 11
Take out the punch and insert the new one.
Retighten the 2 bolts.
Close the sliding door and program the correct step in button STEP XX and ENTER
NOTE:
The cutting pressure must be adjusted for each type of punch or material.
If not, excess pressure may cause the blades to break or premature wear of the cutting
nylon.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 12
PUNCH CUTTING A-A direct finger.
First place the first end of the belt by the guide with the cover upward and place the end of the
belt just by the Ref. 0 mark.
Then pencil in the insert measurement for the relevant material according to the punch
required.
Then place the belt under the tread bar until the mark made coincides with Ref. 0, ensuring it is
fully in contact with the guide.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 13
Lower the tread bar using the down push button.
We select function A-A if it is not activated.
We use the WIDTH button to adjust the width of the belt in centimeters and press ENTER.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 14
Check the STEP is correct. If not, use the STEP button and input the required value with between
5 and 30 then press ENTER.
NOTE:
The values programmed shall not be lost, even when the equipment is switched off; the
program always memorizes the last values input.
We press START to begin cutting at the first end.
NOTE:
During the cutting process, no programmed value may be changed, except the cutting
time. To do so, we press STOP after change that value with TIME button enter the value
between 03 and 07 and ENTER to save that value, Them, press START to continue.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 15
NOTE:
The programmed values will not be lost, even if the equipment is switched off. The program
always memorises the last values input.
Press START to begin cutting at the first end.
Once the first cut is completed, release the belt by pressing the bar raise button.
Place the second end of the belt by the Left side by the guide and position the end of the belt just
by the Ref. 0 mark.
Then mark the insert measurement is pencil for the relevant material, according to the required
punch.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 16
Then place the belt under the tread bar until the mark made is next to Ref. 0 and make sure it is
fully in contact with the guide.
Lower the tread bar using the drop push button and press START.
Once the operation has concluded, release the material by raising the tread bar.
PUNCH CUTTING A-A diagonal
Select the A-A function if not activated.
Insert punch 80x10 75º
Program the step to 10 mm.
Adjust the cutting pressure between 4 and 6 bar

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 17
Program the width in centimeters 4% wider than the belt width.
Example: if the belt is 400 mm. wide, program 42 instead of 40.
Replace the 90º straight guide and fit the new 75º diagonal guide.
To do so, release the two nuts that hold it to the bench.
Extract the straight guide rail by separating it from the side of the machine.
Insert the new 75º guide plate the same way.
Move the guide right up to the side of the machine and fix it down by tightening the two nuts.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 18
Place the cut belt on the 75º diagonal by the supplementary guide to mark the advance measure
of 80x10 75º from Ref. 0.
Then insert the belt until the mark made is level with Ref 0.
Lower the tread bar using the drop push button and press START
Once the first cut has concluded, note that the head will be positioned at point 0 at the opposite
end of the control board. On reaching this point, release the belt by pressing the raise bar button.
Place the second end of the band at the other end of the bridge next to the right diagonal guide and
with the cover upward too, positioning the end of the belt right at the Ref. 0 mark, to pencil the
insert mark for the material that will be 80x10 75º.
Then insert the material until the mark matches Ref. 0, lower the tread bar and press START.
PUNCH CUTTING finger over finger:
For finger over finger there are two possibilities about different geometries
With program A-B

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 19
With this function A-B the puncher always changes the step when return the head in second
operation.
With program A-A and A-B pressing together both buttons for three seconds.
With this function A-A + A-B the puncher changes the step each two operations.

Use and maintenance manual
Auto-Puncher for conveyor belts
Model: AFP-200
____________________________________________________________________________________________________________________
P a g . 20
NOTE:
This type of punch cutting requires prior separation of the cloths using the PS-15
separation device
Separate the cloths of the belt 130 mm. at both ends.
Fit 50x20 mm. punch.
Check that the A-B function is activated.
Program STEP 20 mm. and the required width in centimeters.
Adjust the pressure to 2 bar, as the cutting surface is less due to the blade length.
NOTE:
To perform finger on finger cutting, the two ends of the belt must be done on the same side
of the machine. The A-B program changes the step progress every two operations.
Place the first end of the belt next to the guide and position the end of the belt just by the Ref. 0
mark.
Then mark the two material insert measures for STEP-1 and STEP-2 in pencil.
After making the two marks (STEP-1 and STEP-2) place the cut-proof plate between the previously
separated cloths, so it comes out on both sides.
