Escea IB850 User manual

Installing an IB850 Log Template
G0200
Removing the log set and glass:
Step 1: Lift off the inner fascia by pulling
the base of inner fascia out and
lifting it up and off.
Step 2: Unscrew the top glass
retainer and remove it. Take
care that the glass does
not fall forwards at this
stage.
Step 3: Lift out glass and place it carefully
aside.
Step 4: Take out log set and gently brush any
soot from log with a soft hearth brush.
The burner tops can be vacuumed to
remove any excess material.
Step 6: Install the Log Template as per instructions
on the opposite page.

To attach the Log Template at the left hand side, use the existing screw which is holding the
middle burner in place. Remove this screw and re-attach with the log bracket in place.
To attach to the right hand side, use the supplied screw and brass washer as shown in the
diagrams below. In some cases it may be necessary to drill a 1/8” (3.3mm) hole in the lower
baffle.
Position the logs as shown below, ensuring that the logs do not block any of the holes on the
top of the burners. Blocked or covered holes on the burners may result in reduced flame
efficiency.
Note: The front right hand log will be raised slightly off the burners to improve airflow.
