Esco Pro Series User manual
EQUIPMENT SUPPLY COMPANY
REV. 9.22
COPYRIGHT © 2022 EQUIPMENT SUPPLY CO., ALL RIGHTS RESERVED
Thank you for choosing ESCO tire service tools and equipment. We suggest you read this instruction manual
thoroughly before using the product. Save this instruction manual for future use.
INSTRUCTION MANUAL
ESC300 - DUAL AGRICULTURAL TIRE BEAD BREAKER
ESCO #10165
WARNING
IMPORTANT RECEIVING INFORMATION
Visually inspect all parts for shipping damage. If you find shipping damage, notify the carrier at once.
Shipping damage is not covered by your warranty. The carrier is responsible for all costs of replacement
or repair caused by shipping damage.
DESCRIPTION
The ESC300 Dual Wheel Farm Tractor Tire Bead Breaker (model 10165) is designed to be used on dual
agricultural tires to break inside bead on outside tires, eliminating the need to remove the tire off dual
farm tractors. This unit is fitted with two scissor style arms that push the tire bead away from the rim with
10,000 lbs. of hydraulic force with a minimum operating area of 4 ½ inches and can expand as wide as
12 inches. The ESC300 Dual Wheel Farm Tractor Tire Bead Breaker also comes equipped with an easy
positioning handle for better ergonomic use, as well as a 90-degree hydraulic coupler, keeping the hy-
draulic hose out of the way while trying to service the tire/wheel.
SAFETY INFORMATION
• To avoid personal injury or property damage while using this product, read and follow all DANGERS,
WARNINGS, CAUTIONS, and INSTRUCTIONS that are attached to, or included with, this product.
• Follow the instructions of the tire manufacturer and the vehicle manufacturer when deflating, de-
mounting, mounting, and inflating tires.
• These operating instructions do not apply to any specific rim. Therefore, contact the rim manufacturer
for the correct procedure for your rim.
• For the publication, “Multipiece Rim Matching Chart” contact the United States Department of Labor,
Occupational Safety, and Health Administration (OSHA), Washington, DC, 20210, 202-219-6091, or
contact ESCO at 1-800-352-9852. If you are outside the U.S., contact your local government officials.
NOTE: ESCO cannot be held responsible for damage or injury resulting from unsafe use of this
product; lack of maintenance; or incorrect product and system application.
Contact ESCO when in doubt about safety precautions or applications.
GENERAL SAFETY RULES
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
OPERATING INSTRUCTIONS
TO OPERATE TOOL
1. Jack the tractor up until the duals are clear of the ground. Place jack stands under the axle of
the tractor and lower the tractor onto the jack stands.
DO NOT WORK ON TIRE/WHEEL ASSEMBLY WITHOUT JACK STANDS.
2. Deflate outside dual and evacuate any ballast that might remain in the tire.
3. Place the Model 10165 tool between the duals with the bead breaking arm (with lip) faced
toward the inside bead of the outside dual, place the tip of the tool against the side wall of the
tire as close to the rim lip as possible.
4. Apply a small amount of pressure with the hydraulic pump, just enough to allow the side of the
tool to contact the rim flange of the inside dual.
5. Position the bead breaker between the bead seat on the rim and the tire bead of the outside
dual. Keep applying pressure with the hydraulic pump until the bead separates from the rim.
6. Rotate the tire wheel in small increments and repeat steps #3 and #4, until the bead is
separated from the rim.
WARNING! Ensure that you read, understand and apply the safety instruc-
tions and warnings before use.
WARNING! Ensure that you have familiarized yourself thoroughly with the
product and the hazards associated with its improper use.
WARNING! This product, as well as all Tire Tools, should never be used by persons un-
less they have been trained properly according to O.S.H.A. Regulation #29CFR 1910.177
entitled “Servicing Single-Piece & Multipiece Rim Wheels.” Copy of the Regulation is en-
closed or contact this manufacturer.
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
PARTS BREAKDOWN
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
• ESCO will pick up product for repair/warranty at your location.
• ESCO will guarantee Repair/Service for 30 days.
• ESCO has rental tools available
• ESCO repairs IMT, FEC, Stellar, Blackhawk, OTC, Power Team, Ame
Int., & Enerpac hydraulic pumps, bead breaker, and cylinders.
• Authorized ESCO Repair & Warranty Centers Located through the
US & Canada. For more information contact your ESCO sales repre-
sentative.
• Technical Support Over the Phone Available by Calling 1-800-352-
9852
GUARANTEED 1-Day Turnaround Service.
Received by ESCO - Repaired in 24 Hours - Returned to you!
Prompt, reliable service after the sale is very important to ESCO. ESCO maintains an in-house repair facility in
Brooksville, Florida. To insure that our customers have as little down-time as possible, we offer a 1 day turna-
round service. Our factory repair service is equipped with all the tools and machinery needed to repair your
equipment quickly and affordably. Our trained technicians are the best in the industry. Not only do we service
our own products, but we also service our competitors’ products.
In addition to ESCO’s 30 years of providing quality repair service, ESCO has reached out and partnered with
more than 50+ hydraulic repair facilities across the US & Canada, to deliver quality repair and timely return of
products. Visit www.esco.net or call 1.800.352.9852 to hear more about the newly added “Authorized ESCO
Warranty & Repair Facilities” across the US.
If you have a bead breaker, ram, or hydraulic pump that needs repair, ESCO fixes your product with factory
parts and guarantees the repair. In addition to servicing ESCO brand products, we also re-pair CP, IMT, Elrick,
Branick, Goodyear, FEC, AME Int., and Haltec lines of hydraulic bead breakers, rams, pumps, jacks, and many
other hydraulic tire service equipment.
PARTS AND REPAIR SERVICE
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
WARRANTY
Products sold by Equipment Supply Company (ESCO) are warranted to be free from de-
fects in material and workmanship under proper use, application, and maintenance in ac-
cordance with ESCO's written recommendations, instructions, and specifications for a pe-
riod of 1 year (365 days) from the date of shipment to the end user, unless otherwise noted.
ESCO's obligation under this warranty is limited to, and the sole remedy for any such de-
fect shall be the repair or replacement (at ESCO's discretion) of unaltered parts returned to
ESCO, freight prepaid, and proven to have such defect, provided such defect occurs within
the 90-day warranty period (or otherwise noted) and is reported within 14 days of occur-
rence.
This is the only authorized ESCO warranty and is in lieu of all other express or implied war-
ranties or representations, including any implied warranties of merchantability or fitness.
Warranty claims must be submitted and be processed in accordance with ESCO's estab-
lished warranty claim procedure. In no event will ESCO be liable for business interruptions,
PURCHASE DATE:___________________________________________
MODEL NO.:________________________________________________
SERIAL NO. (If Applicable):____________________________________
NOTES:
___________________________________________________________
___________________________________________________________
___________________________________________________________
___________________________________________________________
___________________________________________________________
Return to ESCO, 15270 Flight Plath Blvd. Brooksville, FL 34604
Or Visit www.esco.net/warranty
NOTES:
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
Thank you for choosing ESCO tire service tools and equipment. We suggest you read this instruction manual
thoroughly before using the product. Save this instruction manual for future use.
CONTACT INFO:
15270 Flight Path Drive
Brooksville, FL 34604
PH. 352.754.1117
Toll Free. 1.800.352.9852 (US, Canada Only) Fax: 352.754.4508
Stay Connected with ESCO….
WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov
ESC300 DUAL AGRICULTURAL TIRE BEAD BREAKER - MODEL 10165
