OPERATING INSTRUCTIONS
A N D S E R V I C E G U I D E

CON EN S
Instructions Available Online........................ 5
About ESQ by Movado Watches ................ 7
Care & Maintenance .................................... 8
Battery Information .................................... 12
Operating Instructions
Basic Models .......................................... 13
Calendar Models .................................... 14
Automatic Models .................................. 15
Big Date 3-Hand Models ........................ 17
Big Date Chronographs .......................... 22
Analog Chronographs 1/10 Second ........ 26
Rotating Bezel ........................................ 71
Screw-Down Crown .............................. 72
Warranty Information ................................ 73
Obtaining Service ...................................... 74
Authorized Service Centers .................... 113
INS RUC IONS AVAILABLE ONLINE
This booklet provides watch care and
maintenance information, and detailed
operating instructions for all standard
ESQ by Movado models.
Separate operating instructions sheets for
those ESQ watches with additional features
and functions, are now offered as PDF files,
along with this booklet, that can be viewed
or downloaded from our website.
To access them, visit us online at
http://www.esqbymovado.com. Click on
the GET SUPPORT tab at the top of our
home page, or the smaller GET SUPPORT
button at the bottom of any page. From the
“Select” list of topics, click on “Operating
Instructions and Service Guides”, then
choose the booklet or specific watch
instructions you want from the list of
available options.
5

76
If you don’t have access to the internet
or would prefer to receive printed operating
instructions for a model with additional
features or functions, please contact
ESQ by Movado U.S. Customer Service at
1 800 810 2311, or your nearest ESQ by
Movado Authorized Service Center. You
will find a worldwide listing at the back
of this booklet.
You can also search service center
locations online by visiting
http://service.movadogroup.com,
clicking on repair and service in the
menu bar, then selecting ESQ by Movado.
ESQ BY MOVADO WA CHES
The finest watches in the world are made in
Switzerland, where time-keeping technology
was developed and perfected, and where
watchmaking techniques grew into an art.
Manufactured by Movado and crafted to the
highest standards of Swiss quality and
design, water-resistant ESQ by Movado
watches feature precise Swiss-engineered
movements, scratch-resistant sapphire or
mineral crystals and exceptional details usu-
ally reserved for timepieces costing far
more.
Congratulations on your ESQ by Movado
watch purchase.

Shock
All ESQ by Movado watches have shock-
resistant movements, and are tested to
meet international standards for shock
resistance.
Magnetism
The exposure of your ESQ by Movado quartz
watch to a strong magnetic field will affect
its time-keeping and may cause it to stop.
However, it should resume working with
original accuracy when removed from the
magnetic field.
Leather Straps
ESQ by Movado watch straps are fashioned
from high quality natural and embossed
leathers. While the life-span of a leather
watch strap will depend on your care, wear-
ing habits, and the climate in which you live,
proper care will extend it.
Keep your leather watch strap dry. Exposure
to water may cause a strap to become brittle
8 9
CARE AND MAIN ENANCE
Like any finely crafted mechanism, your
ESQ by Movado watch requires periodic
maintenance for optimal performance.
Maintenance includes complete disassem-
bly, cleaning, reassembly and lubrication of
the movement. A maintenance interval of 3
to 5 years is recommended, in addition to
any required battery replacement.
Never open the watch yourself: dust or mois-
ture could enter the case and affect the func-
tioning of the movement. If your watch needs
repair or adjustment, return it directly to ESQ
by Movado or one of its authorized service
centers. See the back pages of this booklet
or visit www.esqbymovado.com for a
complete list.
NOTE: ESQ by Movado assumes responsibility
only for service performed at its Authorized
Service Centers.

10 11
Your ESQ by Movado watch is fitted with a
series of gaskets and a specially designed
crown which seal the watch and prevent
moisture from entering the case. Because
the gaskets and crown are subject to wear
and deterioration under normal use, these
parts should be inspected, and replaced as
needed, each time the watch is opened for
service, including battery changes.
The case must also be tested with specialized
equipment to insure that the proper seal has
been reestablished. We recommend that you
take or send the watch to an ESQ by Movado
Authorized Service Center to have this rou-
tine, periodic maintenance performed. See
the end of this booklet for a complete list.
CAUTION: Manufacturer will not be responsi-
ble for any damage caused by or related to
leakage which originated from improper han-
dling or damage to the case, crown, gaskets
or crystal.
and eventually break.
To preserve the finish of the leather, contact
with perfumes should be avoided.
NOTE: ESQ by Movado watch straps are not
covered by the ESQ by Movado watch warranty.
Water Resistance
All ESQ by Movado watches are tested to meet
international standards for water resistance.
Most models are water resistant to 3 ATM, so
faucet spray or rain won’t hurt them as long as
the case, crown and crystal remain intact.
Certain sport models are water resistant to
even greater depths, as indicated on their dials.
You may wear models that are water resistant
to 5 ATM while showering, swimming or
snorkeling. Equipped with screw-down crowns,
ESQ by Movado sport watches that are water
resistant to 30 ATM may be worn while
snorkeling or shallow water scuba diving, but
not for deep sea diving.

13
OPERA ING INS RUC IONS
BASIC MODELS
Figure 1
Crown Positions:
Position 1 - Normal position. Crown pushed
against case.
Position 2 - To set TIME: Rotate crown in
either direction.
SWISS QUARTZ
12
BA ERY INFORMA ION
Your ESQ by Movado watch has a 1.55 volt
silver oxide watch battery that will last
approximately 24 to 36 months. It is important
to use only the replacement battery recom-
mended by ESQ by Movado. Many so-called
“interchangeable” batteries may not work
properly in your watch or might damage it.
End-of-life Feature
The seconds hand on some ESQ by Movado
watches will start to advance haltingly in
4-second increments when the battery is
almost exhausted, signaling the need to
replace it within a week or two. Do not
attempt to change the battery yourself. Take
or send your watch to an ESQ by Movado
Authorized Service Center. See the end of
this booklet, or visit www.esqbymovado.com
for a complete listing.

14 15
AUTOMATIC MODELS
Figure 3
Crown Positions:
Position 1 - Normal position. Crown pushed
against case.
Position 2 - To set DATE: Rotate crown
clockwise.
NOTE: For models with DAY/DATE display(s):
Rotate crown clockwise to set DATE, and
counterclockwise to set DAY.
Position 3 - To set TIME: Rotate crown in
either direction.
CALENDAR MODELS
Figure 2
Crown Positions:
Position 1 - Normal position. Crown pushed
against case.
Position 2 - To set DATE: Rotate crown
clockwise.
NOTE: For models with DAY/DATE display(s):
Rotate crown clockwise to set DATE, and
counterclockwise to set DAY.
Position 3 - To set TIME: Rotate crown in either
direction.
5
1 2
11
10
0 9
08
07
05
04
0 3
02
01

16 17
BIG DATE 3-HAND MODELS
Figure 4
Crown Positions:
Position 1 - Normal position. Crown pushed
against case. (Watch runs)
Position 2 - Position for QUICK CHANGE of
BIG DATE. Rotate crown clock-
wise. (Watch continues to run)
Position 3 - To set TIME: Rotate crown in
either direction. (Watch stops)
To manually wind an automatic
movement:
The motion of your arm during normal daily
activities should be sufficient to keep the
movement of your automatic timepiece
wound. However, if you have not worn your
watch for several days, and the movement
has stopped, you will need to wind it by
hand before resetting the time:
1. With crown in position 1, flush against the
case, turn crown clockwise, completing
approximately 20 revolutions.
2. Reset time and date following instructions
above.
3. Push crown back in to position 1, flush
against case.

18 19
BIG DATE CHRONOGRAPH
Figure 5
Legend:
H- Hour hand
M- Minute hand
S- Seconds hand
C- Chronograph seconds counter
E- Chronograph minutes counter
G- Chronograph tenths-of-a-second counter
D- Big Date display
1,2,3- Crown positions
A,B- Push-buttons for operation of
chronograph
S
W
I
S
S
This watch features an oversized date win-
dow with two single-digit disks that rotate
independently of one another.
Each day, during the calendar “jump phase”
– the hours between 10:00 pm and 12:00
midnight – the date will change automatically.
NOTE: The date may be adjusted manually
during these hours; however it must be set
to the following day: the date will not auto-
matically change at midnight if it has been
manually adjusted during the jump phase.
To manually adjust Big Date display:
(see Figure 4)
1. Pull crown out to position 2. (Watch will
continue to run)
2. Turn crown clockwise until correct digit
appears in each of the two Big Date windows.
3. Push crown back in to position 1, flush
against case.

20 21
To synchronize hands on Big Date
Chronograph:
After changing the battery, or in the event of
an error, the chronograph hands can be
realigned to zero if needed. A single push
(quick press and release) of button Awill
advance the selected hand by one increment.
To advance hand rapidly, depress and hold
push button Afor longer than one second.
1. Pull crown out to position 3.
2. Press and hold buttons Aand Bsimulta-
neously for at least 2 seconds to enter cor-
rective mode: Center-mounted chronograph
hand Cwill rotate 360º, indicating mode has
been activated.
3. Adjust chronograph seconds hand Cusing
button A.
4. Press button B.
5. Adjust tenths-of-a-second counter Gusing
button A.
NOTE: On ESQ by Movado Big Date
Chronograph models, tenths-of-a-second
counter Gwill run continuously for the first
30 seconds after the chronograph feature is
engaged, then return to 0 and remain on 0
until chronograph is stopped. When chrono-
graph is stopped, hand Gwill advance to
indicate elapsed tenths-of-a-second like any
standard quartz chronograph. If the chrono-
graph runs for more than 30 minutes, then
tenths-of-a-second hand Gwill become an
hour-recorder, measuring 10 hours per one
complete rotation.
To operate Big Date Chronograph:
For Chronograph function overview, Simple
chronograph functions, Accumulated time
functions, Split-time or intermediate time
functions, and First-place and runner-up
results, please see instructions for Analog
Chronographs 1/10 Second.

22 23
ANALOG CHRONOGRAPHS 1/10 SECOND
Legend:
H- Hour hand
M- Minute hand
S- Seconds hand
C- Chronograph seconds counter
E- Chronograph minutes counter
G- Chronograph tenths-of-a-second counter
D- Date window
1,2,3- Crown positions
A,B- Push-buttons for operation of
chronograph
Figure 6
6. Press button B.
7. Adjust Chronograph minutes counter E
using button A.
8. Press button B.
9. When done synchronizing hands, return
crown to position 1. (Can be done at any
time.)

24 25
Correcting time zone and date:
1. Pull crown out to position 2.
2. Turn crown to move hour hand Hahead or
back after crossing into another zone, or to cor-
rect for daylight savings/standard time change.
3. To change date D, advance hour hand H
by two complete revolutions, otherwise date
will change at noon.
These adjustments will not stop the watch
and do not affect the time indicated by the
minute and seconds hands.
4. Once adjustments have been made,
immediately return crown to position 1.
Chronograph Function Overview
Use buttons Aand Bto operate the chrono-
graph. Pressing button Athe first time will
start the chronograph. While the chrono-
graph is running, once the chronograph sec-
onds counter hand Chas completed one turn,
A chronograph combines two time-keeping
functions. It incorporates a device to meas-
ure intervals of time independent of the reg-
ular time shown on the dial.
Adjusting the time:
1. As soon as small seconds hand Sreaches
<<60>> position, pull crown out to position 3.
The watch will stop.
2. Turn crown to move hands and set time,
making sure date changes at midnight, not
noon.
3. Move hands slightly ahead of exact time,
then slowly turn crown counterclockwise to
align minute hand with correct minute marker.
4. Take an accurate time signal (from a radio
news station, for example). When audible
tone signals exact time, immediately push
crown back in to position 1. Watch will
restart, now set to the exact time.

26 27
Simple chronograph functions:
To measure the duration of a single, non-stop
event:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop
chronograph, and read the 3 chronograph
hands to determine elapsed time, for example:
14 minutes, 37 seconds, 5/10 of a second.
3. Press button Bto reset chronograph to
zero.
Accumulated time functions:
To measure the combined time of a series of
shorter events, for example the actual play-
ing time of a football game, where play is
repeatedly interrupted:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop
chronograph.
3. Press button Aagain to resume
measurement.
minute-counter hand Ewill jump ahead one
minute. Tenths-of-a-second hand Gdoes not
move when the chronograph is running.
Pressing button Aa second time will stop the
chronograph and move hand Gto the relevant
tenth-of-a-second mark. Pressing button Bwill
reset hands G,Eand Cto zero. Adjusting the
time does not stop the chronograph, but it
does block buttons Aand Bfor as long as the
crown is pulled out.
IMPORTANT: Crown must be in position 1 and
hands must be at zero before chronograph is
started. Press button Bto reset hands to zero.
Do not push button Aor Bwhile crown is
pulled to position 2 or 3. If button Aor Bis
accidentally activated while crown is not flush
against case, one or more of the chronograph
hands will become desynchronized. Should
this occur, see directions for synchronizing
hands at end of following instructions.

28 29
5. To read a second split time, press button
Bagain.
Repeat steps 2 through 4 to take any addi-
tional split times.
6. Press button Ato stop chronograph.
7. Take a reading of the final time, for exam-
ple: 57 minutes, 3 seconds, 7/10 seconds.
8. Press button Bto reset chronograph to
zero.
First place and runner-up results:
To measure both a winning time and runner-
up results:
1. Start chronograph by pressing button A.
2. As soon as winner crosses finish line,
press button B. Chronograph will stop.
3. When second runner crosses finish line,
press button A.
4. Note time for the winner as shown on
the dial.
4. Press button Aa fourth time to stop chrono-
graph again.
NOTE: Each time you stop chronograph,
chronograph hands will indicate total accumu-
lated time.
5. Repeat steps 1 and 2 to add each additional
interval of time.
6. After you have taken your final accumulated
time reading, press button Bto reset chrono-
graph hands to zero.
Split-time or intermediate time functions:
To take intermediate time readings as a race
progresses:
1. Press button Ato start chronograph.
2. Press button Bto momentarily stop
chronograph.
3. Read off the intermediate time, for example:
20 minutes, 26 seconds, 3/10 of a second.
4. Press button Bto resume chronograph func-
tion. Hands will catch up with ongoing event.

30 31
ROTATING BEZEL
Some ESQ by Movado sport models feature
an engraved, unidirectional bezel for measuring
elapsed time. The bezel turns counterclock-
wise only. It can be used, for example, to
monitor the number of minutes left on a
parking meter:
1. Align the marker (triangle or dot) on the
bezel with the current position of the minute
hand.
2. As the minute hand advances around the
dial, the engraved number which it points to
on the bezel indicates exactly how many
minutes (1 to 59) have passed since you
began the timing.
3. When not in use, turn bezel counterclock-
wise until marker is aligned at 12 o’clock.
5. Press button B; hands will move up to
indicate time for the runner-up.
6. Press button Bagain to return all hands
to zero.
To synchronize hands on Analog
Chronograph 1/10 Second:
After changing the battery, or in the event
of an error, the chronograph hands can be
realigned to zero if needed. A single push
(quick press and release) will advance hands
by one increment. To advance hands rapidly,
depress and hold push buttons for longer
than one second.
Crown position 2:
Adjust minute-counter hand Eusing button B.
Crown position 3:
Adjust chronograph seconds hand Cusing
button A.
Adjust tenths-of-a-second hand Gusing
button B.

32 33
WO-YEAR LIMI ED WARRAN Y
ESQ by Movado will, within two years from date
of purchase, repair or replace, at ESQ by Movado’s
option, the movement of your timepiece free of
charge if such movement proves to be defective
in material or workmanship under normal use.
This warranty does not cover damage or defects
arising from accidents, misuse or neglect, or from
any alterations, service or repair performed by any
party other than ESQ by Movado or an authorized
ESQ by Movado service center. This warranty does
not cover batteries, leather straps, bracelets, crystals,
or cases; and is void if the timepiece was not pur-
chased from an authorized ESQ by Movado dealer.
Any other warranty provided by the retailer, is
entirely their responsibility. No person or com-
pany is authorized to change the terms of this
warranty. This warranty gives the consumer
specific legal rights. He/she may also have
other statutory rights which may vary from
state to state, and country to country.
SCREW-DOWN CROWN
Some ESQ sport watches are equipped with
a special screw-down crown that helps seal
the case against water and moisture. Before
attempting to set the time or date, you must
first unlock the screw-down crown by turn-
ing it counterclockwise until it loosens
(approximately six rotations).
After your watch has been set to the correct
time and date (following instructions for
Calendar Models, Figure 2), the crown must
be screwed back down into the case to
ensure water resistance:
1. Return the crown to position 1, flush
against case.
2. Turn the crown clockwise while gently
pressing in on it.
3. Continue to turn the crown until you feel
resistance. Do not over-tighten.

34 35
Tracking Service Online
When you send your watch directly to MGI
for service, we will send you a written
acknowledgement that includes a personal
User ID and Password. With them, you may
authorize and track the status of your watch
service online via our secure internet site:
www.mgiservice.com
Service Under Warranty
Your ESQ by Movado timepiece is protected
from the date of purchase by a two-year lim-
ited warranty. To obtain service under the
warranty, you must present a valid warranty
card and dated receipt of purchase.
NOTE: ESQ by Movado is not to be held
liable for any incidental or consequential
damages occurring from the failure or
malfunction of its product.
OB AINING SERVICE
Should your ESQ by Movado watch require
service or repair, it should be returned direct-
ly to ESQ by Movado or one of its authorized
service centers. See end of this booklet or
www.esqbymovado.com for a complete listing.
Be sure to include your complete return
address and phone number along with a
brief note describing the problem with your
watch and/or service needed.
Packing Instructions
When mailing your watch, it should be
packed securely in padded wrapping materi-
als (for protection against shock) in a sturdy
box sealed with tape.
We recommend that you use registered mail
and insure your watch for its full replace-
ment value.

36 37
ÍNDICE
Instrucciones disponibles en línea ............ 38
Acerca los relojes ESQ by Movado............ 40
Cuidado y mantenimiento .......................... 41
Información sobre las baterias .................. 46
Instrucciones de operación
Modelos básicos .................................... 47
Modelos con calendario ........................ 48
Modelos automáticos ............................ 50
Modelos “Big Date” de 3 agujas .......... 52
Modelos “Big Date” cronógrafo ............ 55
Cronógrafos analógicos 1/10
de segundo........................................ 59
Bisel giratorio .......................................... 68
Corona enroscada .................................. 69
Información sobre la garantía .................... 70
Cómo obtener servicio .............................. 72
Centros autorizados de servicio .............. 113
INSTRUCCIONES DE OPERACIÓN
Y GUÍA DE SERVICIO

38 39
INS RUCCIONES DE OPERACIÓN
DISPONIBLES EN LÍNEA
Este folleto ofrece información sobre el
cuidado y mantenimiento e instrucciones
detalladas de operación para todos los modelos
estándar de los relojes ESQ by Movado.
Las instrucciones adicionales de operación
para los relojes ESQ con funciones y
características adicionales ahora se ofrecen
como archivos PDF, junto con este folleto, que
se puede ver o bajar desde nuestro sitio Web.
Para accederlas, visítenos en línea en
http://www.esqbymovado.com. Haga clic
en la pestaña GET SUPPORT (CONSEGUIR
APOYO) arriba de la página inicial o el botón
GET SUPPORT (CONSEGUIR APOYO) más
pequeño al final de cualquiera de las páginas.
De la lista “Select” (Seleccionar) de temas,
haga clic en “Operating Instructions
and Service Guides” (Instrucciones de
funcionamiento y guías de servicio), luego
elija el folleto de las instrucciones del reloj
específico que desea de la lista de opciones
disponibles.
Si no tiene acceso a Internet o prefiere
recibir instrucciones de operación impresas
para un modelo con características o
funciones adicionales, por favor comuníquese
con Servicio al Cliente en EE.UU. de ESQ by
Movado llamando al 1 800 810 2311 o su
centro de servicio autorizado más cercano
de ESQ by Movado. Encontrará una lista de
centros de todo el mundo al final de este fol-
leto.
También puede buscar la ubicación de los
centros de servicio en línea si visita
http://service.movadogroup.com, haciendo
clic en “Repair and service” (Reparación y
servicio) en la barra del menú y luego
seleccionando ESQ by Movado.
