Essilor SL550L User manual

SLIT LAMP - SL550L
Installation manual
www.essilor-instruments.com

INSTALLATION MANUAL > CONTENTS
CONTENTS
I. INSTALLATION 5
1. Equipment installation 7
a. Fix the slit lamp to the pedestal 8
b. Set the objective 11
c. Position the eyepiece 13
2. Electrical connection 14

INSTALLATION MANUAL > CONTENTS

I. INSTALLATION

INSTALLATION MANUAL > INSTALLATION
6Slit lamp - SL550L > v1.0 -03.16

INSTALLATION MANUAL > INSTALLATION
Slit lamp - SL550L > v1.0 -03.16 7
1. Equipment installation
This section describes the system equipment installation stages.
Prerequisites
Before starting the installation, you’ll need:
A size 5 Allen wrench
A flat screwdriver
The 6 provided screws:
4 to fix the plate on the stand (if Essilor table)
2 to fix the chinrest
4 wood screws (not provided)

INSTALLATION MANUAL > INSTALLATION
8Slit lamp - SL550L > v1.0 -03.16
4
3
2
1
4
3
2
1
4
3
2
1
a. Fix the slit lamp to the pedestal
Using the size 5 Allen wrench and the 4 provided screws, fix the plate to the stand.
If the plate used is other than the Retina412 then use the installation pattern provided with the SL550L, which is also
downloadable on M’eyeDocs.
Fix the power supply unit on the slit lamp SL550L under the table using the 4 wood screws (not provided).
Take the chinrest and screw the handles onto it on both sides.
Using the size 5 Allen wrench and 2 of the screws and washers, fix the chinrest to the table.

INSTALLATION MANUAL > INSTALLATION
Slit lamp - SL550L > v1.0 -03.16 9
7
6
5
7
6
5
7
6
5Remove the rubber cap located under the lifting beam of the slit lamp.
Put the base unit of the slit lamp on the rails then clip the 2 rail covers onto each rail.
Use the screw which is under the main part of the lamp.

INSTALLATION MANUAL > INSTALLATION
10 Slit lamp - SL550L > v1.0 -03.16
9
8
9
8
9
8Place this screw in its proper place on the base unit of the slit lamp to assemble the bottom and upper parts.
Tighten with the Allen wrench.
The upper part is now fixed to the pedestal.>

INSTALLATION MANUAL > INSTALLATION
Slit lamp - SL550L > v1.0 -03.16 11
3
2
1
3
2
1
3
2
1
b. Set the objective
Fit the objective onto the support.
Slide the objective on until it reaches the end.
Screw on the side knob then, using the flat screwdriver, screw on the flathead screw.
The objective is positioned.>

INSTALLATION MANUAL > INSTALLATION
12 Slit lamp - SL550L > v1.0 -03.16
The system is blocked.>

INSTALLATION MANUAL > INSTALLATION
Slit lamp - SL550L > v1.0 -03.16 13
111
c. Position the eyepiece
Using the screw located above the slit lamp microscope, fit on and then screw tight the eyepiece.
The system is assembled.>
You can now connect the system.>

INSTALLATION MANUAL > INSTALLATION
14 Slit lamp - SL550L > v1.0 -03.16
1.
2.
3.
2. Electrical connection
The slit lamp is delivered with:
A power supply unit,
A power supply cable
Drawing of the complete connection of the slit lamp
Chinrest
Upper part of the slit lamp
Pedestal of the slit lamp

INSTALLATION MANUAL > INSTALLATION
Slit lamp - SL550L > v1.0 -03.16 15
3
2
1Connect the power supply cable located on top of the chinrest to the upper part of the slit lamp to bring power to the LED.
Connect the power supply cable located on the bottom of the chinrest to the power supply unit.
Then connect the LED power supply cable to the “ ” port on the pedestal of the SL550L.LED

INSTALLATION MANUAL > INSTALLATION
16 Slit lamp - SL550L > v1.0 -03.16
6
5
4Plug the bent end of the power supply cable into the “ ” port of the slit lamp.Power In
Then, plug the other end of the power supply cable into the power supply unit.
Turn on the product by pressing on button 0/1 on the power supply unit.
The light turns green.>
The attachment point turns on.>
