ETC Source Four LED Series User manual

ETC Quick Guide
Source Four LED™ Profile
Source Four LED Profile Page 1 of 8 Electronic Theatre Controls, Inc.
Corporate Headquarters  Middleton, WI, USA  Tel [phone]  Service: (Americas) [email protected]
London, UK
 Tel [phone]  Service: (UK) [email protected]
Rome, IT
 Tel [phone]  Service: (UK) [email protected]
Holzkirchen, DE
 Tel [phone]  Service: (DE) [email protected]
Hong Kong
 Tel [phone]  Service: (Asia) [email protected]
Web: www.etcconnect.com
 © 2015 ETC. All Rights Reserved.  Product information and specifications subject to change.
7460M1300-1.8.0
 Rev A  Released 2015-11  ETC intends this document to be provided in its entirety.
Overview
For complete information and step-by-step instructions, see the Source Four LED Profile User Manual. ETC
documentation can be downloaded at www.etcconnect.com.
Accessory
holder
Yoke
Accessory
retainer
Yoke
locking
knob
Safety
cable loop
LCD
DMX Thru
DMX In
Keypad
Power In
Power Thru
Status
indicator
Light Bulb
Home
Back
Up
Enter
Down
Power – Indicates AC power is On.
DMX – Indicates control signal is Active.
Error – Indicates data error, high temperature, or other
unusual status.

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 2 of 8 Electronic Theatre Controls, Inc.
Install
Lens Tube
Step 1: Slide the lens tube into the shutter barrel.
Step 2: Tighten the lens zoom knob.
Step 3: Tighten the Phillips screw at the top of the lens barrel.
Install Fixture
Step 1: Hang or mount the fixture.
Step 2: Attach a safety cable.
Step 3: Insert additional accessories such as a top hat, etc.
WARNING:
Use only hardware rated for total weight of fixture and accessories.
A safety cable (or other approved safety device) must be securely attached to
the safety cable loop before loosening the clamp.
Disconnect the unit from power and DMX and allow the fixture to cool before
removing or installing the shutter barrel or other adapters, and all cleaning and
maintenance.
Low clearance position
General use

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 3 of 8 Electronic Theatre Controls, Inc.
Connect
Step 1: Attach the power cable to the Power In connector.
Step 2: Attach the 5-pin XLR cable to the DMX In connector (if using external control).
Step 3: Connect the power cable to AC power.
Step 4: Plug the XLR cable (if using) into the data source.
Step 5: Link additional fixtures via Power Thru and DMX Thru connectors.
Focus
Step 1: Supply power and wait for the fixture to boot up.
Step 2: Press []to open the Presets & Sequences menu.
Step 3: Select Focus and press []to turn on the LED array.
Step 4: Adjust the fixture to the desired position.
Step 5: Once focus is set, press []to turn off the LED array and then []to return to home
screen.
WARNING:
No more than nine total Source Four LED (four total Series 2 Lustr) fixtures on
Power Thru (non-dimming, 100 to 240 VAC, 50/60 Hz).
Up to 32 device loads can be on one DMX daisy-chain.
WARNING:
The fixture must be connected to a non-dimmable power source in order to
avoid damage to its internal power supply and other electrical components.
Dimming will damage the fixture and void the warranty.
Power In
Power Thru
DMX In
DMX Thru

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 4 of 8 Electronic Theatre Controls, Inc.
Soft Focus Diffuser
Step 1:Install the diffuser into an A-Sized Pattern holder.
Step 2:Install a pattern in front of the diffuser, if needed.
Step 3:Insert the pattern holder with diffuser into the Pattern holder slot, making sure the writing
on the diffuser faces the front of the fixture.
Address
Step 1: From the home screen, press []to open the Main Menu.
Step 2: In the Main Menu, scroll to DMX Start Address, press [].
Step 3: Use []or []to scroll to the desired fixture address.
Step 4: Press []to select the address number.
Step 5: Press []to return to the home screen.
* DMX address is not needed if using standalone or master/slave control.
Features
Quick Color
(Lustr+ and Series 2: Lustr, Daylight HD, Tungsten HD, and Studio HD)
Quick Color allows you to easily select a color and its intensity from a predefined menu. This
feature overrides any presets or sequences previously selected and is only available when there is
no external DMX signal to the fixture.
To select a Quick Color:
Step 1: Within the Presets and Sequences screen, scroll to Quick Color and press [].
Step 2: Scroll to Color and press [].
Step 3: Scroll to the desired color and press [].
Step 4: Scroll to Intensity and press [].
Step 5: Scroll to adjust the fixture’s intensity and press []to commit the selection.
Note:
Exiting the Quick Color menu will return the fixture to the state it was in prior to
entering the menu.

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 5 of 8 Electronic Theatre Controls, Inc.
Step 6: To exit the Quick Color menu, press [].
Quick Setup
Step 1: On the Main Menu, scroll to Quick Setups and press [].
Step 2: Scroll to the desired setup and then press [].
An asterisk (*) indicates which setup is active.
Step 3: Press []to return to the home screen.
The top line of the home screen displays the name of the active setup.
Individual features and settings are adjustable under the Advanced menu. Consult the User Manual
for more information on advanced features of Source Four LED fixtures.
Lustr+ and Series 2: Lustr, Daylight HD, Tungsten HD, and Studio HD
Tungsten and Daylight
Quick
Setup Profile Features Recommended For:
General Direct
Standard dimming curve,
regulated output for color
consistency.
Factory default: for general purpose use,
including interior architectural
applications.
Stage HSI
Plus 7 enabled
Incandescent dimming curve,
regulated output for color
consistency, 3200K white point
setting.
Theatrical lighting: duplicates the color
and dimming behavior of tungsten and
stage lighting fixtures.
High
Impact RGB
Quick dimming curve, boost
mode for maximum intensity,
5600K white point setting.
Event lighting: enables quick response,
simple RGB control and strobe channel
for maximum effect usage.
Studio Studio
Linear dimming curve,
regulated output mode for
color consistency.
Studio factory default: enables three-
parameter control of white light
(intensity, white point, and tint) via DMX
from a console or console-free fixture
display.
Quick
Setup Profile Features Recommended For:
Studio Studio Linear dimming curve, regulated
output for intensity stability.
Enables control of intensity from luminaire’s
user interface; no console required.
Single
Channel Direct
Standard dimming curve,
regulated output for color
consistency.
For general purpose architectural use.
Stage Direct Incandescent dimming curve,
regulated output.
Matches conventional luminaire
performance.

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 6 of 8 Electronic Theatre Controls, Inc.
DMX Profiles
Lustr+ and Series 2: Lustr, Daylight HD, Tungsten HD, and Studio HD
DMX
Profile
DMX
Channels Channel Assignments Notes
Direct 10 See Channel assignments in
direct mode chart below.
Direct control of each individual color with a
separate master intensity channel. Color
calibration of LEDs is not active in this mode. The
ten-channel profile will produce the highest
quality color cross fades.
RGB
6
(Ch. 4 not
used)
1-Red
Effectively addresses all seven colors via three
channels of control. RGB profile will produce
medium quality color cross-fades.
2-Green
3-Blue
4 - n/a
5 - Strobe
6-Fan Control
HSI 6
1 – Hue (coarse)
High resolution hue (two channels), saturation,
and intensity control.
HSI mode will produce color cross-fades around
the color space.
2 – Hue (fine)
3 - Saturation
4 - Intensity
5- Strobe
6 - Fan Control
HSIC 7
1 – Hue (coarse)
High-resolution hue, saturation, and intensity
control as above, with the addition of a color
point channel to adjust the color temperature of
the fixture in both white light and color. Color
cross-fade performance is the same as HSI.
2 – Hue (fine)
3 - Saturation
4 - Intensity
5 - Strobe
6 - Fan Control
7-Color Point (CCT)
Studio
6
(Ch. 4 not
used)
1 – Intensity
Controls fixture as a white light unit. If no DMX is
present, (i.e. console input), a fixture can be
adjusted for these three parameters on the U/I at
the back of the unit.
2 – Color Point (CCT)
3 - Tint
4 - n/a
5 - Strobe
6 - Fan Control
Additional profile options (on following page)
Plus 7
Seven additional precision color-control override channels are available for use
with RGB, HSI, and HSIC input profile settings. For example HSI with ‘Plus 7’
enabled becomes an 15-channel profile:
See Plus7 profile options
chart below
The desired color and intensity are achieved by
using the HSI or RGB channels.
Placing the Plus7 channel at a value over 51% gives
the fixture additional channels in its profile.
Channels 9-15 represent the native colors of the
fixture and allow the operator to adjust individual
color channels to fine tune the color output.
Strobe Variable strobe control: 0% is no strobe. The fixture output will strobe more
rapidly as the strobe channel value approaches 100%.

ETC Quick Guide
Source Four LED Profile
Source Four LED Profile Page 7 of 8 Electronic Theatre Controls, Inc.
Channel assignments in direct mode
Plus7 profile options
Tungsten and Daylight
Channel
Number
Series 1
Studio HD
Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Red Red Red Red Red
2 Red Orange White Lime (not used) Red Orange
3 Mint Amber Amber Mint Mint
4 Blue Green Green Blue Blue
5 Indigo Cyan Cyan Indigo Indigo
6 n/a Blue Blue n/a n/a
7 n/a Indigo Indigo n/a n/a
8 Intensity Intensity Intensity Intensity Intensity
9 Strobe Strobe Strobe Strobe Strobe
10 Fan Control Fan Control Fan Control Fan Control Fan Control
Channel
Number
Series 1
Studio HD Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Hue (course) Hue (course) Hue (course) Intensity Intensity
2 Hue (fine) Hue (fine) Hue (fine) White Point White Point
3 Saturation Saturation Saturation Tint Tint
4 Intensity Intensity Intensity (not used) (not used)
5 Strobe Strobe Strobe Strobe Strobe
6 Fan Control Fan Control Fan Control Fan Control Fan Control
7 (not used) (not used) (not used) (not used) (not used)
8Plus7 Control on/
off
Plus7 Control on/
off
Plus7 Control on/
off
Plus7 Control on/
off
Plus7 Control on/
off
9 Red Red Red Red Red
10 Red Orange White Lime (not used) Red Orange
11 Mint Amber Amber Mint Mint
12 Blue Green Green Blue Blue
13 Indigo Cyan Cyan Indigo Indigo
14 (not used) Blue Blue (not used) (not used)
15 (not used) Indigo Indigo (not used) (not used)
DMX
Profile
DMX
Channels
Channel
Assignments Notes
Studio 3
1 - Intensity Control of parameters is also enabled from the luminaire's
user interface. No console is required.
2 - Strobe
3 - Fan Control
Direct 3
1 - Intensity
2 - Strobe
3 - Fan Control

ETC Quick Guide
Source Four LED Prole
.cnI,slortnoCertaehTcinortcelE8fo8egaPeliforPDELruoFecruoS
Typical Power Consumption
Lustr+
Series 2 Lustr
Studio HD
Daylight
Tungsten
Series 2 Daylight HD
Series 2 Tungsten HD
90V 120V 240V
Idle Power / Current4.27W / 0.084A 4.38W / 0.079A4.2W / 0.068A
100% Boost Power / Current 130.8W / 1.48A 129.9W / 1.11A126.4W / 0.576A
90V 120V 240V
Idle Power / Current6.77W / 0.144A 6.9W / 0.149A 6.5W / 0.155A
100% Boost Power / Current 173.0W / 1.94A 171.0W / 1.44A168.0W / 0.783A
100V 120V 240V
Idle Power / Current 5.69W / 0.096A5.71W / 0.091A 5.35W / 0.073A
100% Boost Power / Current 129.2W / 1.3A 127.1W / 1.07A 126.2W / 0.564A
90V 120V 240V
Idle Power / Current4.3W / 0.083A4.35W / 0.077A 4.04W / 0.066A
100% Boost Power / Current 165.2W / 1.87A 163.3W / 1.39A160.3W / 0.718A
100V 120V 240V
Idle Power / Current4.3W / 0.085A4.35W / 0.078A4.0W / 0.065A
100% Boost Power / Current 159.8W / 1.81A 157.4W / 1.35A154.8W / 0.695A
100V 120V 240V
Idle Power / Current5.58W/0.093A 5.69W/0.088A 4.9W/0.06A
100% Boost Power / Current 246.6W/2.481A 245.2W/2.58A 242.3W/1.111A
100V 120V 240V
Idle Power / Current5.64W/0 .095A 5.71W/0.091A 4.9W/0.061A
100% Boost Power / Current 210.1W/2.115A 208.5W/1.752A 205.4W/0.963A
Supplied by:
