Ethnicraft Light Frame User manual

SYMBOLS
DIRECTION NUMBER OF
PERSON NEEDED
USE HAND USE L KEY
TO TIGHTEN
ASSEMBLY INSTRUCTION FOR MIRROR INSTALLATION
HARDWARES
SMB NASELYINSTRUCTIO
X2
NOTICE
WALL SCREW
(2X)
(not included in package)
WALL PLUG
(2X)
(not included in package)
(Not included in package)
TOOLS
SCREW DRIVERDRILL MACHINE PENCIL
Hanging hardware
Hanging hardware
1/2

ASSEMBLY INSTRUCTION FOR MIRROR INSTALLATION
INSTALLING WALL PLUG
A.
INSTALLING MIRROR TO THE WALL
B.
x
x
X cm
Ycm
(Y = desired height)
X cm
X = DRILLING MARKX = DRILLING MARK
Ø 8 mm
X
X
1
2
3
Horizontal Position Vertical Position
2/2

ASSEMBLY INSTRUCTION FOR ANTI-TIPPING INSTALLATION
(1X)
BELT
ANTI-TIPPING
HARDWARE ENCLOSED
(1X)
WALL SCREW
M5x50mm
A B
(1X)
SCREW
M5x30mm
C
(1X)
WASHER
Ø6
(1X)
WALL PLUG
M8x40mm
D E
INSTRUCTION
1. Install anti-tipping belt (A),washer (D) with M5x30mm screw (C) into the pre-drilled hole on the top back
frame of the mirror.
2. Using a 1/4” diameter drill bit, drill the wall at the same level as the anti-tipping belt (A) on the mirror.
Install the wall plug (E) into the hole.
3. Connect the anti-tipping belt (A) with wall screw (B) into the wall plug (E).
TOOLS
SCREWDRIVER
(not included in package)
DRILLING MACHINE
(not included in package)
INSTALLING ANTI-TIPPING SYSTEM
A
D
C
E
B
PENCIL
(not included in package)
12
3
4
5
AS WALL MATERIALS VARY,
THE SCREW INCLUDED ARE FOR BRICK WALL.
FOR ADVICE ON SUITABLE SCREW SYSTEMS,
CONTACT YOUR LOCAL SPECIALISED DEALER.
X1
NOTICE
PRE-DRILLED HOLE
FOR SCREW
