Ethnicraft Torsion 50011 User manual

SYMBOLS
ASSEMBLY INSTRUCTION FOR TABLE INSTALLATION
50011 - 50013 OAK TORSION DINING TABLE
X2
S MB NSE LYINSTRUCTIO
NOTICE
DIRECTION NUMBER OF
PERSONS NEEDED
USE L KEY
TO TIGHTEN
A
TOOL
HARDWARE ENCLOSED
JCBC SCREW
M8x50
(3X)
L KEY
(included in package)
2
3
1
JCBC SCREW
M8x16
(9X)
IN YOUR PACKAGE :
ASSEMBLY INSTRUCTION
HARDWARES (AS LISTED ABOVE)
PARTS TO BE INSTALLED
1. TABLE TOP 1 pc
2. CENTER LEG 1 pc
3. LEG BASE 1pc
METAL PLATE
(SMALL)
(1X)
METAL PLATE
(LARGE)
(1X)
X
RUBBER PAD
(6X)
1/3

INSTALLING METAL PLATE TO THE CENTER LEG
A
INSTALLING CENTER LEG TO TOP TABLE
B
1
ASSEMBLY INSTRUCTION FOR TABLE INSTALLATION
2
1
2
2
UP
1
2
- ALWAYS REFER THE STICKER
- USE THE SCREW M8x16
TIGHTEN FULLY
TIGHTEN FULLY
50011 - 50013 OAK TORSION DINING TABLE
- MAKE SURE “UP” SIGN IS ON TOP / ABOVE
- USE THE SCREW M8x16
2/3

INSTALLING LEG BASE
C
ASSEMBLY INSTRUCTION FOR TABLE INSTALLATION
USE THE SCREW M8x50
50011 - 50013 OAK TORSION DINING TABLE
ADJUST LEVELER
D
TIGHTEN FULLY
2
4
1
3
65
Make sure the holes of leg base
and center leg inline
Make sure the holes of
metal plate and center leg inline
3
NOTE :
THIS IS A COMPULSORY ACTION TO MAKE SURE
ALL OF THE RUBBER PADS TOUCH THE GROUND!
RUBBER PADS POSITION
STABLE UNSTABLE
X
3/3
