Ethnicraft CIRCLE DINING TABLE User manual

IN YOUR PACKAGE :
ASSEMBLY INSTRUCTION
HARDWARE ( AS LISTED ABOVE)
CIRCLE DINING TABLE
ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
PARTS TO BE INSTALLED
1. TOP PANEL 1pc
2. LEG 1 set
L KEY
( included in package )
SYMBOLS
HARDWARES
NOTICE
X2
SMB NA SELYINSTRUC T IO
X
DIRECTION NUMBER OF
PERSONS NEEDED
USE L KEY
TO TIGHTEN
(1X)
Ø 6 x 10 cm
JCBC SCREW
TOOLS
RUBBER HAMMER
( Not included in package )
USE RUBBER
HAMMER
USE HAND
(6X)
Ø 6 x 7 cm
JCBC SCREW
2
2
3
3
1
1
321
- ALWAYS REFER TO HOLE POSITION & STICKER
1/3

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
CIRCLE DINING TABLE
- ALWAYS REFER TO HOLE POSITION & STICKER
MAKE SURE THE 2 SURFACES
ARE FLUSH
STICKER IS ON THE BACK SIDE
FACING UPWARD
A.
CONNECTING LEG #1&2
B.
CONNECTING LEG #3
C.
LOCKING
2/3

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
D.
INSTALLING THE LEG TO TABLE TOP
1
CIRCLE DINING TABLE
E.
FINISH
DO NOT FULLY TIGHTEN WHEN ASSEMBLY THE SCREW
TIGHTEN WHEN ALL SCREWS ARE IN ITS POSITION
3
3
1
1
2
2
2
1
3/3
