EUCHIPS CT420 User manual

Page 1 of 4CT420 SPEC V1.0
LED RF-2.4Ghz RGBW Controller
Model: CT420
Thank you for using RF2.4G Series led controller. With advanced micro-computer control
technology and the 2.4G transmission, Led 2.4Ghz RGBW Controller and remote/Wi-Fi
gateway provide higher-performance light control functions. The controller is designed to
control RGBW color change of full color LED light. The remote support 4 groups control
individually, with touch sensitive key and color ring, it is fashionable and easy to use.
FEATURE
4 constant voltage output (R/G/B/W), each channel can drive 5A max.
Using 2.4G RF remote control. Long distance transmission.
4 groups remote control individually.
Touch sensitive buttons and colorful color-ring.
Pre-loaded with 17 modes (scenes).
Remote is stylish and easy to use.
Compatible with Led strip light or constant voltage panel light, etc.
TECHNICAL PARAMETER
Channels
4 channels
Input Voltage
12-24V DC
Output Voltage
12-24V DC
Output Current Max 5A * 4CH
Color modes 17 modes
Protection Short-circuit protect, Over current protect, Over temper
protect.
Dimension
168*51*22 mm
N.G 105g

Page 2 of 4CT420 SPEC V1.0
Wiring Diagram
REMOTE INSTRUCTION
Remote model：RC16
ALL ON/ALL OFF: Press the button to turn on or turn off all led controller which be
matched to this remote.
Color ring: Touch the color ring to enter static color mode, in this mode, slide your
finger on the color ring, choose the color you need optionally, and the color ring is only
effective for the body finger.
Brightness-/Brightness+: Adjust the led lights brightness.
Speed-/Speed+:Increase or decrease the speed of light color flashing.
Group ON/Group OFF: Press the button to turn on or turn off the lights which be

Page 3 of 4CT420 SPEC V1.0
matched to this group.
Modes:Change the pre-loaded modes.
1. Matching code and grouping：
The remote control can be used after the remote match the code with the LED RGBW
controller, the method is as following:
Choose the led controller that you want to match, then turn off the power for 10 seconds,
then turn on the power, within 5 seconds when you turn on the power, press the button
"Group ON" of the group you want to assign, the lights connecting to the led controller will
flick for 3 times, then this group is match successfully. The other groups can also be set by
the same method.
Remark：One led controller can only match one group in the same remote, but one remote
group can match countless led controllers, and one led controller can match 10 remotes.
2. Clear the code and regroup:
if the room layout are changed, or you want to make a little adjustment upon your fond, then
you may want to change the previous groups, before you change the groups, you need to
clear the code, the method is as following:
Choose the led controller you want to clear the code, turn off the power for 10 seconds,
then turn on the power again, within 5 seconds when you turn on the power of the led
controller, press the button "ALL ON" for 6 times, the lights connecting to the led controller
will flick for 6 times very quickly then the code is cleared successfully.
After the code is cleared, the method of setting the group is totally the same as the principle
of "matching the code and grouping"
If you want to dim all lights controlled by remote at once, press the button “ALL ON” firstly; if
you want to do this with individual light, press the associated button “Group on” firstly, then
choose the mode, color or brightness.
Attention:When install the batteries, please don’t touch the color ring or any key, and use
the remote 5 seconds later after batteries installed. If the touch key or ring is low-sensitive,
please reinstall the batteries in the right way.
MODE LIST
1 Red Fade 10 Green Strobe
2 Green Fade 11 Blue Strobe
3 Blue Fade 12 White Strobe
4 RG Fade 13 RG Strobe

Page 4 of 4CT420 SPEC V1.0
5 RB Fade 14 GB Strobe
6 GB Fade 15 RB Strobe
7 RGB Fade 16 RGB Strobe
8 Rainbow changing 17 7 colors Strobe
9 Red Strobe
Wi-Fi Gateway Control
The LED RGBW controller can also connect with Wi-Fi Gateway（Model：WiFi-203）， so you
can use your mobile smart phone or iPad to control the lightings. More information about
the smart lighting system, please see the WiFi-203 specification.
