Eurolux F24C User manual

30cm Desk Fan
ILLUSTRATIONS
F24C / F24SC
PRODUCT CODE
Cape Town - 9 Racecourse Road, Milnerton, 7441
Johannesburg - 10 Milkyway Avenue, Linbro Business Park, Sandton, 2065
www.eurolux.co.za
Please read instructions before commencing installation and retain for future reference.
Screws
Plastic Screw Nut
Fan Blades
Cap
ENVIRONMENTAL PROTECTION
Waste electrical & Electronic equipment regulations requires that any of our products
showing this marking must not be disposed of with other household or commercial
waste. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate any such products from other waste types and recycle
it responsibly at your local facilities.

• Fitting material: Steel.
• Motor: 35W.
• Voltage: 220 - 240V~ 50/60Hz.
• Protection against electric shock: Class 1. Requires earth connection.
• IP: 20. Protected against solid foreign objects of 12.5mm Ø and greater. Not protected against water.
• Not for outdoor use.
• Dimensions: (H)420mm x (W)335mm x (D)260mm.
• Features: 3 Speeds.
Lockable direction.
Adjustable tilt.
Including: cable & plug.
Fan Assembly:
1. Ensure that the power is disconnected.
2. Remove any protective plastic.
3. Position the rear grill guard over the motor shaft, ensuring that the notches are correctly aligned and
then x into place with the screw / plastic nut provided.
4. Align the fan blade with the at part on the motor shaft and secure into position with the plastic cap.
5. Position the front grill guard and secure into place with the clips / screw provided.
Ensure the fan is in the off position when plugged in.
• Adjust the fan speed by moving the rotary switch from:
0: Off
I: Low
II: Medium
III: High
• To oscillate, press down the control knob at the top of the motor housing. To lock position, pull up on
the same knob.
• To adjust the angle of the fan, loosen large tilt control knob and smaller locking screw, then adjust the
fan head to the desired position and retighten.
SPECIFICATIONS INSTALLATION
OPERATION
CLEANING
• Before cleaning always ensure the power supply is turned off and that the fan has been unplugged.
• Do not immerse the fan in water.
• No abrasive products, solvents, detergent may be used to clean this fan.
• Ensure that the fan does not come in contact with corrosive chemicals, etc.
• Remove the front grill guard, blades and rear grill guard and wipe down parts with a damp cloth to
remove any dust.
• Ensure all parts are dry before reassembling your fan.
• The motor bearings are permanently sealed and do not require additional lubrication.
F24C / F24SC - attachments:
If the external exible cable or cord of this fan is damaged, it should be exclusively replaced by the
manufacturer or his service agent or a similar qualied person in order to avoid a hazard.
To ensure that you get maximum longevity and maximum use out of your fan, please observe the
following safety instructions.
Electrical products can cause death, injury, or damage to property.
Installation of the fan must be carried out by a qualied electrician, in accordance with SANS 10142.
On completion of installation, ensure that the Certicate of Compliance is updated.
• Before connecting this fan, ensure that voltage indicated on the rating label corresponds with the mains
voltage in your home.
• When cleaning, ensure that the power is turned off.
• This fan is checked in full for conformity to the quality standards and safety requirements.
• The manufacturer / supplier is not responsible for any damage of properties and persons, caused by
the incorrect use or installation of the fan.
• Should you be unsure of how to install this fan correctly, please consult a qualied electrician or your
supplier for assistance.
• Ensure all items / components, threads and screws are tightly secured.
IMPORTANT:
• Tampering with this fan, i.e. using silicon sealers or incorrect cabling, will invalidate your warranty.
• Please check whether the connection of the power cord is safe and reliable before installation.
• Always ensure that the mains supply voltage is correct.
• Do not use the fan outdoors, in wet conditions or areas of high humidity.
• Do not insert objects or ngers through the bars of the grill.
• This appliance is not intended for use by young children or inrm persons unless they have been
adequately supervised by a responsible person.
• Always unplug the fan when cleaning or moving from one location to another.
• Always ensure that the fan is on an even, stable surface.
• To disconnect the appliance, unplug by rst turning off the mains power then unplugging the fan.
Do NOT pull on the cord, always grasp the plug.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance
IMPORTANT SAFEGUARDS
