Eurotherm TE300 Series User manual

TE300 User manual HA175437ENG - Issue 2.0 - 09/2000 i
Digital Power Controllers
TE300 Series
Three-phase load control
User Manual
©Copyright Eurotherm Automation 1996
All rights reserved. All reproduction or transmission in any form or using any procedure (electronic or mechanical, including
photocopying or recording) without written authorisation from EUROTHERM AUTOMATION is strictly prohibited.
EUROTHERM AUTOMATION has made every effort to ensure that the specification given in this manual is as accurate and
up to the minute as possible. However, in order to maintain our 'leading edge', it may be necessary to make certain changes or
omissions to our specification. We cannot be held responsible for any damage to persons or property or for any financial loss
or costs arising.

TE300
USER MANUAL
CONTENTS
EUROPEAN DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
CE MARKING AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
ELECTROMAGNETIC COMPATIBILITY (EMC) . . . . . . . . . . . . . . . . . . .iv
DECLARATION OF CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . .v
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
Chapter 1 IDENTIFYING THE CONTROLLERS . . . . . . . . . . . . . . . . . . . . . . . .1-2
GENERAL INTRODUCTION TO THE TE300 SERIES . . . . . . . . . . . . .1-2
TECHNICAL SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
PRODUCT CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
EXAMPLE OF PRODUCT CODE . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
SERIAL NUMBER LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Chapter 2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
INSTALLATION - SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
DIMENSIONAL DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
MOUNTING DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Chapter 3 WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
WIRING - SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
POWER WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
USER TERMINAL BLOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
TE300 User manualii

TE300 User manual iii
Chapter 4 CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
CONFIGURATION - SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
DRIVER BOARD CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . .4-3
Chapter5 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
THYRISTOR FIRING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
CONTROL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Chapter 6 COMMISSIONING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
COMMISSIONING PROCEDURE - SAFETY . . . . . . . . . . . . . . . . . .6-2
CHECKING THE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . .6-3
POWERING UP THE CONTROLLER . . . . . . . . . . . . . . . . . . . . . . . .6-4
Chapter 7 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
FUSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
SERVICING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4
TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4

TE300 User manualiv
EUROPEAN DIRECTIVES
CE MARKING AND SAFETY
TE300 products carry the CE mark in compliance with the essential
requirements of the European Low Voltage Directive 73/23/EC of 19/2/73
(amended by the Directive 93/68/EC of 22/7/93).
For safety reasons, TE300 products installed and used in compliance with this
User Manual meet the essential requirements of the European Low Voltage
Directive.
ELECTROMAGNETIC COMPATIBILITY (EMC)
For an industrial environment only, must not be used in domestic environments
Eurotherm certifies that TE300 products, installed and used in compliance with this User Manual,
meet the following EMC test standards and enable the system which incorporates them to comply
with the EMC Directive, as far as the TE300 products are concerned.
EMC test standards
Immunity Standards : EN 50082-2, EN 61000-4-2, EN 61000-4-3,
EN 61000-4-4, EN 61000-4-6, ENV 50204
Emission Standards : EN 50081-2, EN 55011 class A, EN61800-3 (second
environment)
Internal EMC filters
EMC filters are incorporated in the TE300 to reduce conducted emission in accordance with the
test standard.
EMC Guide
In order to help you reduce the effects of electromagnetic interference depending on the product
installation, Eurotherm can supply you with the 'Electromagnetic Compatibility' Installation
Guide (ref: HA025464).
This guide lists the rules generally applicable for EMC.

DECLARATION OF CE CONFORMITY
Availability
A declaration of CE conformity is available on request.
Validation by Competent Body
Eurotherm has validated the compliance of TE300 products with the European Low Voltage
Directive and EMC test standards through product design and laboratory testing.
The tests carried out on TE300 products are listed in a Technical Construction File validated by
the LCIE (Central Laboratory for the Electrical Industries), a Recognised Competent Body.
Further information
For any further information, or if in doubt, please contact Eurotherm Controls where qualified
staff are available to advise or assist you with the commissioning of your installation.
TE300 User manual v

PRECAUTIONS
Safety symbols
Important safety precautions and special information are indicated in the text of the manual by
two symbols:
This symbol means that failure to take note of the information given in this
manual may have serious consequences for the safety of personnel and may
even result in electrocution.
DANGER
This symbol means that failure to take note of the information may
· have serious consequences for the installation or
· lead to the incorrect operation of the power unit
ATTENTION
These symbols must be observed for particular points.
However the whole of the manual remains applicable.
Personnel
The installation, configuration, commissioning and maintenance of the power unit should only be
carried out by personnel qualified and trained to work with low voltage electrical equipment in
an industrial environment.
Independent alarm
Given the value of the equipment controlled by TE300 products it is the responsibility of the user,
and it is highly recommended, that an independent safety device (alarm) should be installed. This
alarm must be tested regularly.
Eurotherm can supply suitable equipment.
TE300 User manualvi
!

Chapter 1
IDENTIFYING THE CONTROLLERS
Contents
GENERAL INTRODUCTION TO THE TE300 SERIES . . . . . . . .1-2
TECHNICAL SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . .1-5
PRODUCT CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
EXAMPLE OF PRODUCT CODE . . . . . . . . . . . . . . . . . . . . . .1-8
SERIAL NUMBER LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
TE300 User manual 1-1

Chapter 1 IDENTIFYING THE CONTROLLERS
GENERAL INTRODUCTION TO THE TE300 SERIES
The TE300 series of controllers are thyristor units designed to control the electrical power of
industrial three-phase loads.
ATE300 series controller is made up of three channels, each comprising a pair of thyristors
connected in anti-parallel.
The TE300 series is designed to control three-phase resistive loads:
· elements with a low temperature coefficient
· short-wave infrared elements
Three-phase loads can be connected:
· in star with or without neutral
· in open or closed delta
The wiring of the controller is indifferent to the order of the supply phase rotation.
The nominal line-to-line voltage can be selected from 230V to 500V.
The nominal currents of the TE300 series controllers are between 16A and 63A, per phase,
defined at an ambient temperature of 45°C.
Figure 1-1 Current derating per phase as a function of ambient temperature
(dotted line: current limit for recommended fuse)
Attention!
In order to allow for variations in load resistance, the calculated current should not
exceed 0.8 times the maximum rated current of the unit. The load current is
calculated from the supply voltage and the load power (or resistance).
TE300 User manual1-2
20 353025 40 45 50 60
0
10
20
30
40
50
55
Ieff(A)
60
70
Ambient temperature (°C)
IN = 40 A
IN = 25 A
70
IN = 16 A
IN = 63 A (fan-cooled)
IN = 50 A
(fan-cooled)
!

Figure 1-2 Overview of the TE300 series controller
TE300 User manual 1-3
C1
L1
ε
Load terminal block
UR
ETE
HR
OM
ON
9
78
-
+
5V
C3
C2
L3
L2
E3
T00
Supply terminal block
Control connector
Auxiliary power
supply connector
(option)
Thyristor firing
Heatsink

The unit is controlled by analogue or logic signals.
The input analogue signals have two possible voltage ranges: 0 to 5V or 0 to 10V and a current
range of: 4 to 20mA.
The input logic signals have the following nominal values: 5V, 10V or 20mA.
Local control is possible via a potentiometer or external contacts. (The input must be configured
as 0 to 5V code 0V5)
The 5V,0.5mA user-voltage output on terminal 7 and 9 is intended for this purpose.
The electronics of the TE300 controllers are self-supplied from the power voltage and do not
require external connections.
The control method of the TE300 series includes line voltage squared (V2) compensation for
line variations in the range +10% to -15% of the nominal voltage of the controller.
TE300 series controllers have several thyristor firing modes:
- Logic ON-OFF
- Cycle time modulation (Burst-firing with four possible cycle times)
- Advanced Single-cycle (firing by complete cycles separated by a complete number of
half-cycles of non-firing).
Thyristor firing ensures the absence of any DC component in load currents when connected in
open delta or in star with neutral configurations. .
ATE300 series controller is equipped with:
·A‘driver board’ which generates thyristor firing pulses, implements control and
provides power for the electronics. This board is also used for the signal and
operating mode configurations
·A‘filter board’ to ensure Electromagnetic Compatibility in accordance with the test
standard and to protect the controller from transient interference.
The filters which provide immunity against electromagnetic interference are located:
· Between the power phases
· Between the phases and the safety earth connector
The user terminal block below the controller is used for the control signal connection without
having to open the front door of the unit.
A green LED indicating thyristor firing (‘ON’) is located on the front facia.
TE300 power controllers are designed to be bulkhead or DIN rail mounted.
The 63A rated limit must be permanently fan-cooled.
The fan power supply of either 115V or 230V should be specified when ordering the controller.
TE300 User manual1-4

TECHNICAL SPECIFICATION
The TE300 series of controllers is intended for thyristor regulation and control of an
industrial three-phase load.
Power
Nominal current (per phase) 16A, 25A, 40A, 50A or 63A (at 45°C)
Line-to-line voltage 230V to 500V (+10%, -15%)
Supply frequency 50Hz and 60Hz (±2Hz) automatic selection
Dissipated power 1.3W (approx.) per amp, per phase. Fuses are external to
TE300 and will produce 0.7W (approx) per amp per phase.
Insulation (1 min test) 2000Vac between power and earth and 3600Vac between
power and control
Cooling Natural convection for 16A, 25A, 40A ratings Permanent
fan-cooling for 50A and 63A rating
Fan power supply (63 amp unit) 115V or 230V (to be specified) 13VA
Load Resistive three-phase load with a low temperature coefficient
or short-wave infrared elements
Supply phases Wiring independent of the phase rotation order
Load configuration Closed delta (3-wire) or open (6-wire)
Star without neutral (3-wire) or with neutral (4-wire)
Load configuration set by ‘coffee beans’
CE Marking
Electrical safety TE300 controllers carry the CE mark in compliance with the
essential requirements of the European Low Voltage
Directive 73/23/EC (amended by the Directive 93/68/EC)
Electromagnetic compatibility
Immunity and Emissions TE300 products comply with Electromagnetic Compatibility
test standards (see page iv).
Control
External control signal Analogue (in Burst-firing and Single-cycle modes):
voltage 0 to 5V or 0 to 10V; current 4 to 20mA
Logic (ON/OFF mode), nominal levels:
voltage 5V or 10V; current 20mA
On state ≥50% and off state ≤25% of the nominal level
Input impedance Voltage input: ≥100kΩ, current input: 250Ω
Configuration ‘Coffee beans’on driver board
Local control 10kΩpotentiometer supplied by the user-voltage
‘Dry’contact for logic operation
Input configured as 0 to 5V
TE300 User manual 1-5

Thyristor firing
Firing modes ON/OFF (Logic)
Burst-firing mode
Number of firing cycles at 50% of configurable power:
1, 8, 16 or 128 cycles
Advanced Single-cycle (load in star with neutral or open
delta)
Firing by complete cycles separated by half-cycles of non-
firing without DC component
One cycle of firing and one cycle of non-firing at 50% power
Switching Conduction starts and ends at zero voltage
Indication Thyristor firing is signalled by a green LED
Control performance
Control type The power controlled in the load (simulated by voltage
squared V2) is proportional to the setpoint
Linearity Better than ±2% of the full scale
Stability With variations:
· Of the supply voltage +10%, -15%
· Of the temperature from 0 to 40°C
stability is better than ±2% of full scale
Options
Auxiliary power supply Possibility of operation for non-standard three-phase mains
by supplying the electronics separately from the power at
115V or 230V
Environment
Operating temperature 0°C to +45°C at maximum altitude of 2000m
Storage temperature -10°C to +70°C
Thyristor protection High-speed external fuses (except for short-wave infrared
application)
Internal MOVs (varistors) and RC snubbers
Protection IP20 on the front facia (in compliance with Standard IEC529)
External wiring To be carried out in compliance with standard IEC 364
Operating atmosphere Non-explosive, non-corrosive, non-conductive
Humidity RH: 5% to 95%, non-condensing
Pollution Pollution degree 2permissible, defined by IEC 664
In order to maintain its 'leading edge', Eurotherm may have to make changes to its specifications without advance notice.
For any further information, or if in doubt, please contact Eurotherm Controls.
TE300 User manual1-6

PRODUCT CODE
TE300/Current/Voltage/Cooling/Signal/Firing/Configuration/Mounting/Language/Options/00
Nominal current Code
16 amps 16A
25 amps 25A
40 amps 40A
50 amps* 50A
63 amps* 63A
* Fan cooled
Mains voltage*
(line-to-line) Code
230 volts 230V
240 volts 240V
277 volts 277V
380 volts 380V
400 volts 400V
415 volts 415V
440 volts 440V
480 volts 480V
500 volts 500V
Fan supply Code
Without fan-cooling (16A to 40A) 000
With fan-cooling (50A & 63A):
115V 115V
230V 230V
Input signal Code
0 to 5 volts 0V5
0 to 10 volts 0V10
4 to 20 milliamps 4mA20
* Non-standard mains: use the coding
for the voltage immediately above and
choose option of power supply separated
Bulkhead mounting
TE300 controllers may be bulkhead mounted.
TE300 User manual 1-7
Thyristor firing mode Code
Logic ON/OFF LGC
Burst-firing: 1 cycle FC1
8 cycles FC8
16 cycles C16
128 cycles 128
Advanced Single-cycle
(4- or 6-wire configuration) SCA
Load configuration Code
Delta (3-wire) 3D
Star without neutral (3-wire) 3S
Star with neutral (4-wire) 4S
Open delta (6-wire) 6D
Mounting Code
Bulkhead BKD
DIN rail DIN
Manual language Code
French FRA
English ENG
German GER
Italian ITA
Options Code
Power supply separate from
electronics 115V
(non-standard power supply) 230V

EXAMPLE OF PRODUCT CODE
Controller and installation parameters
Nominal load current 35 amps
Nominal supply voltage 415 volts line-to-line
Input signal 0 to 5 volts
Firing mode Advanced Single-cycle
Load configuration Star with neutral
DIN rail mounting DIN
User manual In English
Controller code:
TE300 / 40A / 415V / 000 / 0V5 / SCA / 4S / DIN / ENG / 00
SERIAL NUMBER LABELS
An identification label provides all the information relating to the factory settings of the controller.
The identification label is located externally on the right side of the unit.
EI EUROTHERM 2.20
WORTHING, ENGLAND : 01903 268500
MODEL : TE300/40A/415V/000/0V5/SCA/4S/DIN/ENG/00
SERIAL No. : INT100/002/001/03/99 0F222935
RANGE : 40A 415V AUX. POWER SUPPLY : SELF-SUPPLIED
INPUT : 0-5V FAN POWER SUPPLY : NONE
FIRING : ADVANCED SINGLE-CYCLE WIRING : STAR WITH NEUTRAL
ANY NON-SPECIFIED FUSE INVALIDATES GUARANTEE : FERRAZ B093910
Figure 1.3 Example of identification label for a TE300 controller
The information corresponds to the product code example
Attention!
Following any re-configuration on the part of the user, there is no guarantee that the
controller will corespond to the label information.
TE300 User manual1-8
!

TE300 series controllers may be mounted:
MOUNTING DETAILS
Fan-cooled controllers
63A rating TE300 controllers have permanent fan-cooling
Weight of fan-cooled TE300 controller: 3.5kg
The overall dimensions of the fan-cooled TE300 controller are given in Figure 2-2.
Figure 2-2 Dimensions of fan-cooled TE300 controller (63A rating)
TE300 User manual 1-9

TE300 User manual 2-1
Chapter 2
INSTALLATION
Contents
INSTALLATION - SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
DIMENSIONAL DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
NON FAN-COOLED CONTROLLERS . . . . . . . . . . . . . . . . .2-3
FAN-COOLED CONTROLLERS . . . . . . . . . . . . . . . . . . . . . .2-4
MOUNTING DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
DIN RAIL MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
BULKHEAD MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

Chapter 2 INSTALLATION
INSTALLATION - SAFETY
DANGER!
TE300 units must be installed by personnel qualified and trained to work with
low voltage electrical equipment in an industrial environment.
Units must be installed in electrical cabinets correctly fan-cooled to ensure that
condensation and pollution are excluded.
The cabinet must be closed and bonded to the safety earth in accordance with
Standards NFC 15-100, IEC 364 or current national Standards.
For installations which are fan-cooled, it is recommended that a fan-failure detection device or a
thermal safety cut-out should be fitted in the cabinet.
TE300 units may be bulkhead or DIN rail mounted.
The units must be mounted with the heatsink positioned vertically, with no obstructions above or
below which could inhibit or impede airflow.
If several units are mounted in the same cabinet, they should be arranged in such a way that air
expelled from one cannot be drawn into the unit located above it.
Attention!
The units are designed to be used at an ambient temperature less than or equal to
45°C.
Leave a minimum gap of 5cm between two units placed side by side.
Excessive overheating of the controller may lead to incorrect operation of the unit.
This may in turn cause damage to the components.
TE300 User manual2-2
!

TE300 User manual 2-3
Protective cover
186
215
141
EUROTHERM ε
TE300
L1
C1
L3
C3
L2
C2
ON
7 8 9
12
100
Power terminal block
Power terminal block Safety earth terminal
57
22
22
40
Control terminal block
DIMENSIONAL DETAILS
Non fan-cooled controllers
The overall dimensions of non fan-cooled TE300 controllers (16A to 40A ratings) are given in
Figure 2-1.
Figure 2-1 Dimensions of non fan-cooled TE300 controllers
Weight of non fan-cooled TE300 controller: 3.1kg

Fan-cooled controllers
50A and 63A rating TE300 controllers have permanent fan-cooling
Weight of fan-cooled TE300 controller: 3.5kg
The overall dimensions of the fan-cooled TE300 controller are given in Figure 2-2.
Figure 2-2 Dimensions of fan-cooled TE300 controller (50A and 63A rating)
TE300 User manual2-4
Protective cover
186
233
141
EUROTHERM ε
TE300
L1
C1
L3
C3
L2
C2
ON
7 8 9
12
100
Power terminal block
Power
terminal
block
Safety earth
terminal
57
22
22
92
40
92
Fan supply
Fan
Power
terminal
block
Control
terminal
block
Fan

MOUNTING DETAILS
TE300 series controllers may be mounted:
· On DIN rails (code DIN)
· On a bulkhead (code BKD)
DIN rail mounting
TE300 controllers are designed to be mounted on two DIN rails EN 50022.
Figure 2-3 DIN rail mounting for TE300 controller
To mount the TE300 controller on DIN rails (see Figure 2-3).
1. Offer up the unit by first engaging the two lips on the upper part of the fixing plate (back
plate of controller) on to the upper DIN rail.
2. Clip the controller (by spring clips) on to the lower DIN rail, making sure that the clip is
properly engaged.
TE300 User manual 2-5
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
A
A
125 ±0·5
mm
Fixing clip
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAA
AAAA
TE300
Lip
AAA
AAA
Fixing
plate
AAA
AAA
Upper
DIN rail
AAA
A
A
A
AAA
Lower
DIN rail
AA
AA
1
AA
AA
2
