evertz 8083XDS-AD User manual

8083XDS-AD
Analog and SD-SDI XDS Encoder
Instruction Manual
© Copyright 2005-2007
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive, Burlington, Ontario, Canada, L7L 5Z9
Phone: [phone]
Fax: [phone]
Internet: Sales: [email protected]
Tech Support: [email protected]
Web Page: http://www.evertz.com
Revision 1.0.2, August 2006
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 8083XDS-AD Analog and SD-SDI XDS Encoder. Evertz
Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the XDS
encoder.
All rights reserved. No part of this publication may be reproduced without the express written permission of
Evertz Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
• Read these instructions
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC – SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE
NOTE
This equipment with the CE marking complies with bother the EMC Directive (89/336/EEC) and the
Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European standards:
• EN60065 Product Safety
• EN55103-1 Electromagnetic Interference Class A (Emission)
• EN55103-2 Electromagnetic Susceptibility (Immunity)
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to the European Union EMC directive. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.

8083XDS-AD Analog and SD-SDI XDS Encoder
Revision 1.0.2
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Edition Apr 05
1.0.1 Added information on changing the battery Aug 06
1.0.2 Removed references to Field Mode Aug 07
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor
for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only
warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation
form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty
is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order
confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you
encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in
equipment design or specifications.

8083XDS-AD Analog and SD-SDI XDS Encoder
Revision 1.0.2
This page left intentionally blank

8083XDS-AD Analog and SD-SDI XDS Encoder
CONTENTS Revision 1.0.2 Page i
TABLE OF CONTENTS
1 OVERVIEW..................................................................................................................................1-1
1.1 THE CLOSED CAPTION and XDS SYSTEM.............................................................................1-1
1.2 FEATURES..................................................................................................................................1-3
1.2.1 Hardware System Features: ............................................................................................1-3
1.2.2 Serial Digital Video Path Features:..................................................................................1-3
1.2.3 Component Analog Video Path Features.........................................................................1-3
1.2.4 Data Encoding Features: .................................................................................................1-4
1.2.5 Communications Features:..............................................................................................1-4
1.3 DAYLIGHT SAVING TIME ADJUSTMENT.................................................................................1-4
1.4 HOW TO USE THIS MANUAL.................................................................................................... 1-5
1.5 GLOSSARY OF STANDARDS ................................................................................................... 1-5
1.6 GLOSSARY OF TERMS .............................................................................................................1-7
2 INSTALLATION...........................................................................................................................2-1
2.1 REAR PANEL..............................................................................................................................2-1
2.1.1 Program Video Connections............................................................................................2-1
2.1.2 Preview Video Connections.............................................................................................2-2
2.1.3 Serial Port Connections ...................................................................................................2-2
2.1.4 Parallel Remote Control Connections..............................................................................2-3
2.1.5 Power Connections..........................................................................................................2-3
2.2 MOUNTING .................................................................................................................................2-3
2.3 POWER REQUIREMENTS .........................................................................................................2-4
2.4 CONNECTING THE DIGITAL VIDEO.........................................................................................2-4
2.4.1 SDI Video Input................................................................................................................2-4
2.4.2 SDI Video Output.............................................................................................................2-4
2.5 CONNECTING THE ANALOG VIDEO........................................................................................2-5
2.5.1 Decoder Outputs (from SDI video path)........................................................................... 2-5
2.5.2 Composite Analog Video Input.........................................................................................2-5
2.5.3 Composite Analog Video Output......................................................................................2-5
2.6 CONNECTING THE ENCODER TO AN XDS COMPUTER........................................................2-5
3 HOW TO OPERATE THE XDS ENCODER ................................................................................ 3-1
3.1 AN OVERVIEW OF KEY AND DISPLAY FUNCTIONS..............................................................3-1

8083XDS-AD Analog and SD-SDI XDS Encoder
Page ii Revision 1.0.2 CONTENTS
3.1.1 Navigating the Front Panel Menus -- The Setup Group...................................................3-1
3.1.2 Caption Keyer Control Group...........................................................................................3-5
3.1.2.1 Keyer Control on the 8083XDS-AD......................................................................3-5
3.1.3 Status Indicator Lights......................................................................................................3-6
3.1.4 Front Panel Operating Messages ....................................................................................3-6
3.2 SETUP MENU ITEMS................................................................................................................3-10
3.2.1 Selecting The Type Of Video Being Used......................................................................3-10
3.2.2 Selecting the Line Caption Data Will be Encoded On....................................................3-10
3.2.3 Operating the Manual Bypass Relay..............................................................................3-10
3.2.4 Selecting the Upstream Caption Source........................................................................3-11
3.2.5 Inserting “V-Chip” Ratings Locally..................................................................................3-11
3.3 ENGINEERING SETUP MENU ITEMS .....................................................................................3-12
3.3.1 Setting the Serial Port Baud Rate and Data Format ......................................................3-13
3.3.2 Setting the Serial Port Access Permission.....................................................................3-13
3.3.3 Special Functions of Port B............................................................................................3-14
3.3.4 Vertical Shift of the Caption Line Data ...........................................................................3-16
3.3.5 Configuring Whether Upstream Captions and XDS will be Passed or Blocked.............3-17
3.3.6 SETTING THE ENCODER CLOCK...............................................................................3-18
3.3.6.1 Setting the Time .................................................................................................3-18
3.3.6.2 Setting the Date..................................................................................................3-18
3.3.6.3 Setting the Time Zone........................................................................................3-18
3.3.6.4 Setting the Daylight Saving Time Observance...................................................3-19
3.3.7 Encoding a Test Message.............................................................................................3-19
3.3.8 Using the 16 Second Erase Timer .................................................................................3-19
3.3.9 CLEARING XDS PACKETS FROM MEMORY..............................................................3-20
3.3.10 Monitoring the Status of the Parallel Remote Control Inputs .........................................3-20
3.3.11 Resetting the XDS Encoder to Factory Defaults............................................................3-20
3.3.12 Performing a Front Panel Reset to its Power-On State..................................................3-20
3.4 MONITORING THE INCOMING DATA ..................................................................................... 3-21
3.4.1 Monitoring the Data in ‘Stream Mode’............................................................................3-21
3.5 PARALLEL REMOTE CONTROL CONNECTIONS ................................................................. 3-22
3.5.1 Disabling the Caption Keyer using the Parallel Remote Control....................................3-22
3.5.2 Enabling the Bypass Relay using the Parallel Remote Control .....................................3-22
3.5.3 Disabling the Serial Ports using the Parallel Remote Control........................................3-22
3.5.4 Shifting Caption Text Up using the Parallel Remote Control .........................................3-23
4 SERIAL COMMAND PROTOCOL ..............................................................................................4-1
4.1 COMMAND CROSS REFERENCE.............................................................................................4-1
4.2 COMMAND SYNTAX DESCRIPTION.........................................................................................4-2
4.2.1 Special Characters...........................................................................................................4-2
4.2.2 Parameters.......................................................................................................................4-2
4.2.3 Flow Control Handshaking...............................................................................................4-5
4.2.4 Break Handling.................................................................................................................4-5
4.2.5 Command Responses and Error Messages ....................................................................4-5

8083XDS-AD Analog and SD-SDI XDS Encoder
CONTENTS Revision 1.0.2 Page iii
4.2.6 Command Differences Between Operating Modes (Legacy Operation)..........................4-6
4.3 COMMANDS COMMON TO OPERATING MODES ...................................................................4-6
4.3.1 Set Baud Rate..................................................................................................................4-6
4.3.2 Reset Encoder .................................................................................................................4-7
4.3.3 Set Output Line................................................................................................................4-8
4.3.4 Monitoring the Line 21 Data on the Serial Port................................................................4-8
4.3.5 Controlling the Caption Decoder...................................................................................... 4-8
4.3.6 Report Firmware Version .................................................................................................4-9
4.3.7 Command Help ................................................................................................................4-9
4.3.8 Set Stream Mode .............................................................................................................4-9
4.3.9 Report Bypass Switch Mode..........................................................................................4-10
4.3.10 Report Battery Status.....................................................................................................4-10
4.3.11 Set / Report Time of Day Clock......................................................................................4-10
4.3.12 Set / Report Calendar Date............................................................................................4-11
4.4 COMMANDS SUPPORTED IN STREAM OPERATING MODE ............................................... 4-12
4.4.1 Transparent State ..........................................................................................................4-12
4.4.2 Null State........................................................................................................................4-12
4.4.3 Direct Control State........................................................................................................4-13
4.4.4 Display System Status ...................................................................................................4-14
4.5 TEXT ARTICLES (STREAM MODE ONLY).............................................................................. 4-14
4.5.1 Input Article....................................................................................................................4-15
4.5.2 Output Article .................................................................................................................4-16
4.5.3 Delete Article..................................................................................................................4-17
4.5.4 Queue Articles................................................................................................................4-17
4.5.5 Display Article Status.....................................................................................................4-17
4.5.6 Display Output Queue....................................................................................................4-18
4.6 EXTENDED DATA SERVICES (STREAM MODE ONLY)........................................................4-18
4.6.1 Input XDS.......................................................................................................................4-19
4.6.2 Blocking Upstream XDS Packets...................................................................................4-20
4.6.3 Queue XDS Packets......................................................................................................4-21
4.6.4 Delete XDS Packet ........................................................................................................4-21
4.7 COMM PORT CONTROL COMMANDS (STREAM MODE)..................................................... 4-22
4.7.1 Show Port Permission Maps..........................................................................................4-22
4.7.2 Alter Port Permission Maps............................................................................................4-23
4.7.3 Show Port Active Maps..................................................................................................4-24
4.7.4 Alter Port Active Maps....................................................................................................4-24
4.7.5 Reset Port......................................................................................................................4-25
5 TECHNICAL DESCRIPTION.......................................................................................................5-1
5.1 OVERVIEW..................................................................................................................................5-1
5.2 SPECIFICATIONS.......................................................................................................................5-1
5.2.1 Serial Digital Video Input..................................................................................................5-1
5.2.2 Serial Digital Video Outputs.............................................................................................5-1

8083XDS-AD Analog and SD-SDI XDS Encoder
Page iv Revision 1.0.2 CONTENTS
5.2.3 Composite Analog Video Input.........................................................................................5-1
5.2.4 Composite Analog Video Outputs....................................................................................5-1
5.2.5 Electrical...........................................................................................................................5-2
5.3 SERVICING INSTRUCTIONS .....................................................................................................5-2
5.3.1 Changing The Fuses........................................................................................................5-3
5.3.2 REPLACING THE BATTERY...........................................................................................5-3
5.3.2.1 Safety Guidelines and Precautions concerning the Use of 3V Lithium Batteries.5-4
5.3.2.2 Procedure for Replacing the Battery ....................................................................5-4
5.3.3 DIP Switch Functions.......................................................................................................5-4
5.3.4 Configuring Serial Port A..................................................................................................5-5
5.3.5 Configuring Serial Ports B and C .....................................................................................5-6
5.4 CIRCUIT DESCRIPTION.............................................................................................................5-8
5.4.1 Front Panel Display and Pushbuttons..............................................................................5-8
5.4.2 Analog Composite Monitor 9000CME..............................................................................5-8
5.5 UPGRADING THE FIRMWARE..................................................................................................5-9
5.5.1 Overview..........................................................................................................................5-9
5.5.2 Procedure for Firmware Upgrades...................................................................................5-9
5.5.3 Viewing Firmware and PLD Revision Levels..................................................................5-11
6 TROUBLESHOOTING.................................................................................................................6-1
6.1 ANSWERS TO FREQUENTLY ASKED QUESTIONS................................................................6-1
6.1.1 Which serial port should I connect to?.............................................................................6-1
6.1.2 There is no SDI video being output from the unit.............................................................6-1
6.1.3 There is valid input video but the front panel shows “VIDEO MISSING”..........................6-1
6.1.4 What baud rate and port settings should I use?...............................................................6-1
6.1.5 I see “BUFFER OVERFLOW” or “PARITY BAD” messages on the front panel...............6-2
6.1.6 How do I check the logic levels and pinouts of the serial ports?......................................6-2
6.1.7 How do I check the status of my power supplies? ...........................................................6-2
6.1.8 Captions are not being encoded at all..............................................................................6-2
6.1.9 The Caption Shift Up GPI is not working properly............................................................6-3
6.1.10 How can I block upstream captions? ...............................................................................6-3
6.1.11 How can I pass upstream captions?................................................................................6-3
6.1.12 How can I encode XDS / V-Chip “Content Advisory” or “Program Rating” packets?.......6-3
6.1.13 When the caption decoder is set to XDS, the text sometimes disappears momentarily..6-5
6.1.14 Captioning waveform is at the wrong voltage level when converted to analog video. .....6-6
6.1.15 When should I use “Reset to Factory Defaults”? .............................................................6-6
6.2 BEFORE YOU CALL EVERTZ TECHNICAL SUPPORT…........................................................6-6
6.3 CREATING A CAPTURE FILE....................................................................................................6-6
Application Notes:
Application Note 3: Transmitting Time of Day using XDS Packets..................................AN3-1

8083XDS-AD Analog and SD-SDI XDS Encoder
CONTENTS Revision 1.0.2 Page v
Figures:
Figure 1-1: Typical Line 21 Closed Caption Signal...................................................................... 1-2
Figure 2-1: 8083XDS-AD Rear Panel..........................................................................................2-1
Figure 2-2: Parallel GPI Port Pinout.............................................................................................2-3
Figure 2-3: Typical Connections to the 8083XDS-AD XDS Encoder...........................................2-6
Figure 2-4: Wiring RS-232 DTE Serial Port to Computer ............................................................2-6
Figure 2-5: Wiring RS-422 Tributary Serial Port to RS-422 Master............................................. 2-7
Figure 3-1: 8083XDS-AD Front Panel Layout..............................................................................3-1
Figure 3-2: Overview of the Setup Menu System........................................................................3-3
Figure 3-3: Overview of the Engineering Menu System ..............................................................3-4
Figure 3-4: Front Panel Time Indicators ......................................................................................3-8
Figure 3-5: Connections for Port Echo Mode.............................................................................3-15
Figure 3-6: Connections to Copy XDS data between Video Feeds...........................................3-16
Figure 3-7: Reinserting XDS after Video Processing.................................................................3-16
Figure 5-1: Jumper Settings for Port A Configurations................................................................5-6
Figure 5-2: Port B or Port C Ribbon Cable Positions...................................................................5-7
Figure 5-3: Jumper Settings for Ports B and C............................................................................5-7
Tables:
Table 1-1: XDS Encoder Feature Summary................................................................................1-1
Table 3-1: Front Panel Data Monitoring in Stream Mode ..........................................................3-21
Table 5-1: DIP Switch Functions..................................................................................................5-4
Table 5-2: Keyboard Scan Codes................................................................................................5-8

8083XDS-AD Analog and SD-SDI XDS Encoder
Page vi Revision 1.0.2 CONTENTS
This page left intentionally blank

8083XDS-AD Analog and SD-SDI XDS Encoder
OVERVIEW Revision 1.0.2
CHAPTER 1: OVERVIEW
1 OVERVIEW..................................................................................................................................1-1
1.1 THE CLOSED CAPTION and XDS SYSTEM.............................................................................1-1
1.2 FEATURES..................................................................................................................................1-3
1.2.1 Hardware System Features: ............................................................................................1-3
1.2.2 Serial Digital Video Path Features:..................................................................................1-3
1.2.3 Component Analog Video Path Features.........................................................................1-3
1.2.4 Data Encoding Features: .................................................................................................1-4
1.2.5 Communications Features:..............................................................................................1-4
1.3 DAYLIGHT SAVING TIME ADJUSTMENT.................................................................................1-4
1.4 HOW TO USE THIS MANUAL.................................................................................................... 1-5
1.5 GLOSSARY OF STANDARDS ................................................................................................... 1-5
1.6 GLOSSARY OF TERMS .............................................................................................................1-7
Figures
Figure 1-1: Typical Line 21 Closed Caption Signal...................................................................... 1-2
TablesTable 1-1: XDS Encoder Feature Summary ................................................................................1-1

8083XDS-AD Analog and SD-SDI XDS Encoder
Revision 1.0.2 OVERVIEW
This page left intentionally blank

8083XDS-AD Analog and SD-SDI XDS Encoder
OVERVIEW Revision 1.0.2 Page 1-1
1 OVERVIEW
This manual describes the operation of the 8083XDS-AD Analog and SD-
SDI XDS Encoder.
The Model 8083XDS-AD provides a cost-effective method of encoding
eXtended Data Service (XDS) into Field 2 of the analog and digital video
bitstream. It has been designed to meet the needs of both television
broadcast and post-production facilities.
The following table summarizes the major features of the 8083XDS-AD.
Feature 8083XDS-AD
Front Panel 10 buttons
SDI Video 4:2:2
Analog Video composite
Serial Ports 3
RS-232 / RS-422 all ports
Modems (14.4kbps) 0
Bypass Relay Yes - both feeds
Power Supplies 1 or 2
Monitoring Decoder Yes - both feeds
VBI Bridge Yes
ATSC Comm. No
XDS Insertion Yes
WebTV URL Insertion No
Text Article Insertion No
Local Default V-Chip Yes
LTC Reader No
Table 1-1: XDS Encoder Feature Summary
1.1 THE CLOSED CAPTION and XDS SYSTEM
The Closed Caption System provides for the transmission of data on line
21 of the NTSC composite signal, or Line 22 of the PAL composite video
signal. The EIA-608-B standard specifies nine data channels or “streams”
for line 21 data services. In each video field there are two caption streams
and two text streams. Field two also contains the Extended Data Service
(XDS) data stream. These are summarized in the following chart:

8083XDS-AD Analog and SD-SDI XDS Encoder
Page 1-2 Revision 1.0.2 OVERVIEW
Field 1 Field 2
CC1 Primary Synchronous Caption Service CC3 Secondary Synchronous Caption Service
CC2 Special Non-synchronous Use Captions CC4 Special Non-synchronous Use Captions
T1 First Text Service T3 Third Text Service
T2 Second Text Service T4 Fourth Text Service
XDS Extended Data Services
The separate data streams are independent of each other in content.
Within each field, the streams are time-multiplexed. Control codes are
transmitted to announce the transition to a different stream. Home viewers
may generally select which data stream to display with their caption
decoders.
The primary Synchronous Caption Service (CC1) is primary language
captioning data that must be in sync with the sound. The Secondary
Synchronous Caption Service (CC3) is an alternate captioning data
channel in sync with the sound, usually used for a second language.
The special Non-Synchronous channels (CC2, CC4) carry data that is
intended to augment information carried in the program and is not
necessarily in sync with the sound.
The four text services are used to carry general text information that may
not be related to the program content. Text stream T2 is often reserved to
carry URL data for WebTV applications.
Extended Data Service stream contains information about the program
such as program title, length, and V-Chip-compatible program rating
information.
IRE
-4
0
0
25
50
H Sync Color Burst Clock Run-In Start Bits
S1 S3S2 b0 b1 b2 b3
Character One
b4 b5 b6 P1 b0 b1 b2 b3 b4 b5 b6
Character Two
P2
Figure 1-1: Typical Line 21 Closed Caption Signal

8083XDS-AD Analog and SD-SDI XDS Encoder
OVERVIEW Revision 1.0.2 Page 1-3
Figure 1-1 shows the typical waveform of the signal. The line 21 data
signal consists of a 7 cycle sine wave clock burst, a start bit, and two data
characters. Each character consists of seven data bits with odd parity.
The clock rate is 32 times the horizontal line frequency or 503.4 KHz. The
signal amplitude is 50 IRE units peak to peak. There is no setup on the
line when the caption signal is present. When caption data is encoded into
field 2, there must at least be null characters encoded into field 1. The full
specification for the caption data waveform and data content is given in the
EIA-608-B standard.
1.2 FEATURES
1.2.1 Hardware System Features:
• 3 RS-232 serial ports can be configured for direct connection to
captioning computer.
• Rack mountable chassis.
• 16 digit alphanumeric display, with 8 push buttons.
• Parallel remote port for GPI control of six important 8083 functions.
• Real-time clock and calendar with battery backup.
• Flash ROM program memory for easy in-system-programmable
firmware upgrades.
• Optional redundant power supply.
1.2.2 Serial Digital Video Path Features:
• Keys directly into 4:2:2 (525 or 625 line) digital video bitstream.
• 8 or 10 bit SDI video resolution supported.
• Serial digital video input provides automatic cable equalization on cable
lengths up to 200 meters of low loss coax such as Belden 8281.
• Two separate serial digital video outputs.
• Serial Digital Video bypass relay activates automatically on power
failure to maintain the integrity of the program video path.
• Analog composite monitor output with caption decoder provides a
means of verifying the caption information that is being encoded.
1.2.3 Component Analog Video Path Features
• Keys directly into 1Vp-p component analog (525 or 625 line) video
signal.
• User may select either analog or SDI video path as upstream data
source for data bridging applications.
• XDS may be encoded onto both video feeds simultaneously when the
feeds are frame-locked.
• Studio-quality video output with bypass relay protection.
• Monitor output with caption and XDS decoder that provides a means of
verifying the information that is being encoded.
• Video bypass relay activates automatically on power failure to maintain
the integrity of the program video path.

8083XDS-AD Analog and SD-SDI XDS Encoder
Page 1-4 Revision 1.0.2 OVERVIEW
1.2.4 Data Encoding Features:
• Supports encoding of Extended Data Service (XDS) data packets
including V-Chip-compatible program ratings into Field 2
• EDH packet checksum correction.
• Keyer bypass mode allows video to pass through without keying any
signal in
• Data encoding line is selectable – 11 to 25 in NTSC, 6 to 25 in PAL.
1.2.5 Communications Features:
• Serial communications protocol emulates EEG 270, EEG 370 and EEG
470 Encoders.
1.3 DAYLIGHT SAVING TIME ADJUSTMENT
Daylight Saving Time (DST) was instituted to take advantage of the later
hours of daylight between April and October. In 1966, the U.S. Congress
passed the Uniform Time Act that standardized the length of Daylight
Saving Time. For those parts of the United States that observe Daylight
Saving Time, it begins at 2 a.m. local time on the first Sunday of April.
Time reverts to standard time at 2 a.m. local time on the last Sunday of
October. In the spring clocks spring forward by 1 hour to 3 a.m.; in the fall
clocks fall back by 1 hour to 1 a.m. Arizona, Hawaii and most of Indiana
have chosen not to observe Daylight Saving Time.
People often consider daylight saving time to be an “event” that happens
twice a year, setting their clocks ahead or back by one hour. In reality,
DST is in effect (ON) for six months of the year and not in effect (OFF) for
the other six months, in regions that observe DST.
The Caption Encoders will automatically switch their local time to Daylight
Saving time at 2 a.m. local time on the first Sunday of April, and back to
standard time at 2 a.m. local time on the last Sunday of October. The DST
Observed control allows the user to enable or disable the DST adjustment
of the local encoder time (the DSO flag). For regions that observe Daylight
saving time, the DST Observed setting must be set to On, and for regions
that do not observe Daylight saving time, the DST Observed setting must
be set to Off. Regardless of whether DST is observed in a region, DST will
be In effect between the first Sunday of April and the last Sunday of
October. (The DST flag) The front panel time display shows the status of
the DST and DSO flags as shown in Figure 3-4.
There are two XDS packets defined by EIA-608-B for encoding time and
date information. The Time of Day packet (0701) encodes the UTC time
and contains a flag bit (DST Flag) that is to be set when Daylight Saving
Time is in effect (i.e. between the first Sunday of April and the Last Sunday
of October). The Time of Day packet must be inserted locally at each
affiliate station so that the correct time is encoded when programs are aired
at different times across the network.

8083XDS-AD Analog and SD-SDI XDS Encoder
OVERVIEW Revision 1.0.2 Page 1-5
The Time Zone packet (0704) encodes the time zone offset from UTC time
and contains a flag bit (DSO Flag) that is to be set when the entire area
served by the signal observes Daylight Saving Time. When the DSO Flag
bit is set to Off, it means that the VCR will ignore the DST Flag bit in the
Time of Day packet. The Time Zone packet must be inserted locally at
each affiliate in order to encode the correct time zone offset for the region.
See application note AN3 at the back of this manual for more information
about encoding time in XDS packets.
1.4 HOW TO USE THIS MANUAL
This manual is organized into 6 chapters: Overview, Installation, Operation,
Serial Command Protocol, Technical Description, and Troubleshooting.
There are also two application notes in the rear of the manual.
If you are confused by any terminology used throughout the manual,
please refer to the Glossary of Terms in Chapter 1.
"Items of special note are indicated with a double box like this
1.5 GLOSSARY OF STANDARDS
EIA (Electronic Industries Alliance): An association of trade
associations representing various facets of the electronics industry. Each
of these EIA Sector Associations manages its own standards-setting
programs under EIA, the umbrella organization.
EIA-608-B: This EIA standard serves as a technical guide for those
providing encoding equipment and/or decoding equipment to produce
material with encoded data embedded in Line 21 of the vertical blanking
interval of the NTSC video signal. It is also a usage guide for those who will
produce material using such equipment.
EIA-708-B defines the coding of DTV closed captions (DTVCC) as they
are delivered in an ATSC signal, and also defines the Caption Distribution
Packet (CDP). This structure contains fields that can hold: EIA-608-B data
for use if the video is converted to standard definition analog; DTV captions
for use in an ATSC program; Caption Descriptors; and Time Code. The
CDP is the basic unit of data that is transported through the professional
portion of a DTV plant. As such, it is central to the methods discussed in
this document.

8083XDS-AD Analog and SD-SDI XDS Encoder
Page 1-6 Revision 1.0.2 OVERVIEW
EIA-744-A: The EIA standard that defines the formatting of content
advisory information accommodating either U.S. or Canadian systems, as
well as the movie industry’s MPAA rating system using the vertical blanking
interval. EIA 744-A redefines the XDS Program Rating (content advisory)
packet, 05h, currently contained in EIA-608-B, Current Class.
EIA-746-A: This document is a proposed amendment to EIA-608-A to
insert Internet Uniform Resource. Locators (URLs) within the line-21 data
system using the Text-2 (T-2) service. These URLs may be used by
receiving devices in a variety of ways to associate Internet content with
related television broadcast content.
SMPTE (Society of Motion Picture and Television Engineers): A
professional organization that recommends standards for the film and
television industries.
SMPTE 12M: The SMPTE standard for linear time code.
SMPTE 125M: The SMPTE standard for bit parallel digital interface
for component video signals. SMPTE 125M defines the parameters
required to generate and distribute component video signals on a parallel
interface.
SMPTE 244M: The SMPTE standard for bit parallel digital interface
for composite video signals. SMPTE 244M defines the parameters
required to generate and distribute composite video signals on a parallel
interface.
SMPTE 259M: The SMPTE standard for 525 line serial digital
component and composite interfaces.
SMPTE 269M: This SMPTE standard defines an opto-isolated fault
tally output signal for connecting to user-defined equipment such as
warning indicators.
SMPTE 291M: Defines the method of multiplexing ancillary data such as
audio and captions to 292M and 259M signals.
SMPTE 292M: Defines the serial interface that is used for carriage of
HDTV video signals. It and its standard definition equivalent 259M provide
a standard transport mechanism, not only for the video signal, but also for
digitized audio and data such as captions.
SMPTE 309M: The SMPTE standard for encoding date information
into the user bits of linear time code.
SMPTE 333M: The SMPTE standard for serially interfacing
captioning equipment with ATSC XDS encoders
