evertz 7707IFTA Series User manual

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - i
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 5
2. INSTALLATION................................................................................................................................... 8
2.1. 7707IFTA CONNECTIONS......................................................................................................... 9
2.2. 7707IFRA CONNECTIONS........................................................................................................ 9
2.3. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 9
2.3.1. Safety.............................................................................................................................. 9
2.3.2. Handling and Connecting Fibers..................................................................................... 9
3. SPECIFICATIONS............................................................................................................................. 10
3.1. 7707 IFTA SPECIFICATIONS.................................................................................................. 10
3.1.1. IF Input.......................................................................................................................... 10
3.1.2. IF Monitoring Output...................................................................................................... 10
3.1.3. Optical Output ............................................................................................................... 10
3.1.4. Electrical........................................................................................................................ 10
3.1.5. Physical......................................................................................................................... 11
3.2. 7707IFRA SPECIFICATIONS................................................................................................... 11
3.2.1. IF Output ....................................................................................................................... 11
3.2.2. Optical Input.................................................................................................................. 11
3.2.3. Electrical........................................................................................................................ 11
3.2.4. Physical......................................................................................................................... 11
4. STATUS INDICATORS AND DISPLAYS ......................................................................................... 12
4.1. 7707IFTA STATUS INDICATORS ........................................................................................... 12
4.2. 7707IFRA STATUS INDICATORS........................................................................................... 13
5. DIP SWITCH CONTROLS................................................................................................................. 14
5.1. IFTA DIP SWITCH CONTROLS............................................................................................... 14
5.1.1. Configuring IFTA for AGC or Manual mode.................................................................. 14
5.2. IFRA DIP SWITCH CONTROLS .............................................................................................. 14
5.2.1. Configuring IFRA for AGC or Manual mode.................................................................. 15
6. JUMPERS.......................................................................................................................................... 16
6.1.1. Selecting Whether Local Faults Will Be Monitored
By the Global Frame Status.......................................................................................... 17
6.1.2. Selecting Whether Module Will Be Controlled From the Local Controls or Through
the VistaLINK
®
Interface................................................................................................ 17
6.1.3. Configuring the Module for Firmware Upgrades ........................................................... 17
7. DOT-MATRIX DISPLAY.................................................................................................................... 18
7.1. CARD EDGE MENU SYSTEM ................................................................................................. 18
7.1.1. Navigating the Menu System ........................................................................................ 18
7.2. IFTA MENUS............................................................................................................................ 19

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - ii Revision 4.1
7.2.1. User Menu / Set ............................................................................................................ 19
7.2.2. User Menu / Mon........................................................................................................... 19
7.2.3. IFTA User Menu-Set ..................................................................................................... 19
7.2.3.1. Setting the IF Threshold................................................................................... 19
7.2.3.2. Adjusting the Gain............................................................................................ 20
7.2.3.3. Changing the display orientation...................................................................... 20
7.2.3.4. Restoring Factory Defaults............................................................................... 20
7.2.4. IFTA User Menu – Mon................................................................................................. 20
7.2.4.1. IF-In Threshold................................................................................................. 20
7.2.4.2. IF In Power....................................................................................................... 20
7.2.4.3. Gain.................................................................................................................. 20
7.2.4.4. Software Version.............................................................................................. 20
7.3. IFRA MENUS............................................................................................................................ 21
7.3.1. User Menu / Set ............................................................................................................ 21
7.3.2. User Menu / Mon........................................................................................................... 21
7.3.3. IFRA User Menu-Set..................................................................................................... 21
7.3.3.1. Setting the IF Output Threshold....................................................................... 21
7.3.3.2. Optical Threshold............................................................................................. 22
7.3.3.3. Adjusting the Gain............................................................................................ 22
7.3.3.4. Changing the Display Orientation .................................................................... 22
7.3.3.5. Restoring Factory Defaults............................................................................... 22
7.3.4. IFRA User Menu – Mon................................................................................................. 22
7.3.4.1. IF-Out Threshold.............................................................................................. 22
7.3.4.2. IF Out Power.................................................................................................... 22
7.3.4.3. Optical Threshold............................................................................................. 23
7.3.4.4. Optical Power................................................................................................... 23
7.3.4.5. Gain.................................................................................................................. 23
7.3.4.6. Transmitter Power............................................................................................ 23
7.3.4.7. Software Version.............................................................................................. 23
8. CARD EDGE CONTROLS ................................................................................................................ 24
8.1. CONFIGURING GAIN LEVELS OF THE 7707IFTA AND 7707IFRA IN MANUAL MODE...... 24
9. VISTALINK
®
REMOTE MONITORING/CONTROL ........................................................................... 26
9.1. WHAT IS VISTALINK
®
?............................................................................................................. 26
9.2. IFTA VISTALINK
®
PARAMETERS............................................................................................ 26
9.2.1. IFTA MONITORED PARAMETERS.............................................................................. 26
9.2.2. IFTA CONTROLLED PARAMETERS ........................................................................... 27
9.2.3. IFTA Traps .................................................................................................................... 27
9.3. IFRA VISTALINK
®
PARAMETERS.......................................................................................... 27
9.3.1. IFRA MONITORED PARAMETERS.............................................................................. 27
9.3.2. IFRA CONTROLLED PARAMETERS........................................................................... 28
9.3.3. IFRA Traps.................................................................................................................... 28

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - iii
Figures
Figure 1-1: 7707IFTA Block Diagram....................................................................................................................6
Figure 1-2: 7707IFRA Block Diagram ...................................................................................................................7
Figure 2-1: 7707IFTA / 7707IFRA Rear Panels....................................................................................................8
Figure 6-1: Location of 7707IFTA Jumpers and LEDs........................................................................................16
Figure 6-2: Location of 7707IFRA Jumpers and LEDs .......................................................................................16
Figure 8-1: 7707IFRA Block Diagram .................................................................................................................25
Tables
Table 5-1: Front DIP Switch Functions................................................................................................................14
Table 5-2: Front DIP Switch Functions................................................................................................................14
Table 9-1: 7707IFTA VistaLINK
®
Monitored Parameters....................................................................................26
Table 9-2: 7707IFTA VistaLINK
®
Controlled Parameters ...................................................................................27
Table 9-3: 7707IFTA VistaLINK
®
Traps ..............................................................................................................27
Table 9-4: 7707IFRA VistaLINK
®
Monitored Parameters ..................................................................................27
Table 9-5: 7707IFRA VistaLINK
®
Controlled Parameters..................................................................................28
Table 9-6: 7707IFRA VistaLINK
®
Traps..............................................................................................................28

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - iv Revision 4.1
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Release Oct 03
2.0 Second release Jul 04
3.0 Updated safety and added assembly and labeling section July 05
4.0 Updated from 7707IFT/IFR to new part numbers Jan 06
4.1 Updated features, specs & VistaLINK
®
section, fixed format Nov 08
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof, nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 5
1. OVERVIEW
The 7707IFTA and 7707IFRA IF Transmitter/Receiver modules are used for transmitting IF satellite
signals over fiber optic cable. The 7707IFTA accepts one IF coaxial input and provides a fiber optic output
signal. An additional BNC IF output is also available for monitoring or further signal distribution. The
7707IFRA accepts a fiber optic input from the 7707IFTA and provides two IF output signals via BNCs.
Monitoring and control of card status and parameters is provided locally via card edge and remotely via
VistaLINK
®
capability.
The 7707IFTA and 7707IFRA modules each occupy one card slot and can be housed in either a 1RU
frame, which will hold up to three modules, or a 3RU frame which will hold up to 15 modules.
Features:
•Broadband operation - 70 or 140MHz
•Protocol transparent - handles all video, audio and data modulation formats
•Fully hot swappable from front of frame
•Available with BNC or F type connector options
•Available in SC/PC, ST/PC, FC/PC and APC connector options
•Supports muIti-mode and single-mode fiber optic cable
•Comprehensive signal and card status monitoring via four digit card-edge display or remotely
through SNMP and VistaLINK
®
capability
7707IFTA Features
•30-200MHz bandwidth
•Wide dynamic range RF input (-5 to -65dBm)
•Protocol transparent - transmits all video, audio and data modulation formats
•Supports manual and automatic gain control on IF input
•Wide AGC hold range (45dB) using 7707IFTA + 7707IFRA
•Additional IF BNC output for monitoring or distribution
•Available with BNC or F-Type connector options
•Available with output wavelengths of 1310nm, 1550nm, CWDM (ITU-T G.694.2 compliant) and
DWDM (ITU-T G.694.1 compliant)
•Supports single-mode and multi-mode fiber optic cable
•Available in SC/PC, ST/PC, FC/PC and APC connector options
•Fully hot-swappable from front of frame
•Comprehensive signal and card status monitoring via four digit card edge display or remotely
through SNMP and VistaLINK
®
•VistaLINK
®
capability is available when modules are used with the 3RU 7700FR-C or 350FR
portable frame and a 7700FC VistaLINK
®
Frame Controller module in slot 1 of the frame

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 6 Revision 4.1
Amplifier Optical
Transmitter
Buffer
CPU
VistaLINK
®
Interface
Local
Control
Local
Indication
IF Input
IF
Output
Fiber
Output
AGC
AMP
Auto
Manual
Figure 1-1: 7707IFTA Block Diagram
7707IFRA Features
•30-200MHz bandwidth
•Protocol transparent - receives all video, audio and data modulation formats
•Supports manual and automatic gain control (AGC)
•Wide AGC hold range (45dB) using 7707IFTA + 7707IFRA
•Two IF outputs for extra signal distribution or monitoring functions
•IF output power independent of optical loss (within AGC range)
•Available with BNC or F-Type connector options
•Wide range optical input (1270nm to 1610nm)
•Supports single-mode and multi-mode fiber optic cable
•Available in SC/PC, ST/PC, FC/PC and APC connector options
•Fully hot-swappable from front of frame
•Comprehensive signal and card status monitoring via four digit card edge display or remotely through
SNMP and VistaLINK
®
•VistaLINK
®
capability is available when modules are used with the 3RU 7700FR-C or 350FR portable
frame and a 7700FC VistaLINK
®
Frame Controller module in slot 1 of the frame

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 7
Optical
Receiver
CPU
VistaLINK
®
Interface
Local
Control
Local
Indication
Splitter
IF
Output
Fiber
Input
IF
Output
AGC
AMP
RF
AMP
Auto
Manual
Figure 1-2: 7707IFRA Block Diagram

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 8 Revision 4.1
2. INSTALLATION
Each of the modules in the 7707IFA series comes standard with a companion +3RU rear plate. The rear
plate must be specified during the time of order. SC/PC, ST/PC or FC/PC optical connector are available
for these modules and must be specified during the time of order. For information on mounting the rear
plate and inserting the module into the frame, see the 7700FR manual for detailed instructions.
Figure 2-1: 7707IFTA / 7707IFRA Rear Panels

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 9
2.1. 7707IFTA CONNECTIONS
IF IN: Input BNC connector for IF satellite signals
IF OUT: Output BNC is an IF output for monitoring or further signal distribution of your IF
satellite signals.
FIBER OUTPUT: SC/PC, ST/PC or FC/PC female connector with the optical output from the
7707IFTA as shown in section 3.1.3. This connector should be connected to the
FIBER IN connector of a 7707IFRA module at the destination end with a suitable
fiber optic cable. The 7707IFTA transmits on the wavelength marked on the rear
panel.
2.2. 7707IFRA CONNECTIONS
FIBER INPUT: SC/PC, ST/PC or FC/PC female connector with the optical input to the 7707IFRA as
shown in section 2.7.2. This connector should be connected to the FIBER OUT
connector of a 7707IFTA module at the origination end with a suitable fiber optic
cable.
IF OUT: Two output BNC connectors for distributing IF satellite signals. The BNC nearest
the bottom of the rear panel is the primary output and will provide slightly better
performance than the secondary output located directly under the fiber optic input.
2.3. CARE AND HANDLING OF OPTICAL FIBER
2.3.1. Safety
!
Never look directly into an optical fiber. Non-reversible damage to the eye can occur
in a matter of milliseconds.
The laser modules used in the Evertz IF fiber optic modules are Class I, II, and III depending on the
required output wavelength.
2.3.2. Handling and Connecting Fibers
" Never touch the end face of an optical fiber.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that the user maintains a minimum bending radius of 3 cm to avoid fiber-bending loss that
will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come
with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in
the frame that does not have a suitable I/O module.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 10 Revision 4.1
3. SPECIFICATIONS
3.1. 7707 IFTA SPECIFICATIONS
3.1.1. IF Input
Connector: 1 BNC per IEC 61169-8 Annex A (F-type optional)
I/O Impedance: 75 Ω(50 Ωoptional)
Input Frequency Range: 30-200MHz
Input Signal Range: -5 to -65dBm
AGC Hold Range: -10 to –35dBm
Return Loss: > 18dB
3.1.2. IF Monitoring Output
Number of outputs: 1
Connector: 1 BNC per IEC 61169-8 Annex A (F-type optional)
I/O Impedance: 75 Ω(50 Ωoptional)
Return Loss: > 18dB
Flatness: ±1 dB @ 30 – 200MHz
±0.2dB @ 36MHz BW
Output Signal Level AGC Mode: -20dBm ±0.5dBm (Within AGC Range)
Output Signal Level Manual Mode:(Input signal) + (Manual Gain setting) ±1dB
Intermodulation Products: -50dBc ( -10dBm RF in, AGC mode )
Carrier to Noise: 37dB @ 36MHz BW ( -30dBm RF at IFTA input, AGC on
IFTA/IFRA and 0dBm optical power to IFRA )
3.1.3. Optical Output
Number of outputs: 1
Connector: Female SC/PC, ST/PC, FC/PC
Operating Wavelength:
Standard: 1310nm, 1550nm (nominal)
CWDM: 1270nm to 1610nm
DWDM: C-Band/L-Band Wavelengths (ITUG.694.1)
Optical Power:
1310nm FP: 0dBm ±1dBm
1310nm, 1550nm &
CWDM DFB: +2dBm ±1dBm
DWDM DFB: +7dBm ± 1dBm
Fiber Size: 9 µm core / 125 µm overall
3.1.4. Electrical
VoItage: +12VDC
Power: 6 Watts (Non-DWDM), 9 Watts (DWDM)
EMI/IFI: Complies with FCC Part 15, Class A
EU EMC Directive

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 11
3.1.5. Physical
7700 or 7701 frame mounting:
Number of slots: 1
3.2. 7707IFRA SPECIFICATIONS
3.2.1. IF Output
Number of outputs: 2
Connector: 2 BNC per IEC 61169-8 Annex A
I/O Impedance: 75 Ω(50 Ωoptional)
Return Loss: 18dB (30 to 200MHz)
Output
AGC mode: -10dBm (within AGC range)
Manual mode: -5 to –65dBm (dependent on RF input level, optical loss & gain setting)
Intermodulation Products: -50dBc max ( -10dBm RF at IFTA input, AGC on IFTA/IFRA and 3dB optical
loss )
Flatness: ± 1.5dB (30MHz to 200MHz)
± 0.2dB ( any 36MHz bandwidth )
Carrier to Noise: 37dB @ 36MHz BW ( -30dBm RF at IFTA input, AGC on IFTA/IFRA and
0dBm optical power to IFRA )
3.2.2. Optical Input
Number of inputs: 1
Connector: Female SC/PC, ST/PC, FC/PC
Operating Wavelength: 1270nm - 1610nm
Maximum Input Power:
Standard: +3dBm
-H Version: -7dBm
Optical Sensitivity:
Standard: -14dBm @ 35dB C/N @ 36MHz BW
-H Version: -23dBm @ 35dB C/N @ 36MHz BW
-29dBm @ 25dB C/N @ 36MHz BW
3.2.3. Electrical
Voltage: +12VDC
Power: 5 Watts
EMI/IFI: Complies with FCC Part 15, Class A
EU EMC Directive
3.2.4. Physical
7700 or 7701 frame mounting:
Number of slots: 1

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 12 Revision 4.1
4. STATUS INDICATORS AND DISPLAYS
4.1. 7707IFTA STATUS INDICATORS
The 7707IFTA module has 9 LED Status indicators on the front card edge to show operational status of
the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module.
LOCAL FAULT: This Red LED indicates poor module health and will be illuminated if a board power
fault exists (i.e.: a blown fuse) or if the laser is nearing the end of the life cycle. The
LOCAL FAULT indication can also be reported to the frame through the FRAME
STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when the board power
is good.
There are 7 small LEDs on the card edge. Six of which indicate the status of the incoming IF signal, laser
status, and AGC/manual operation.
IF HIGH: This red LED (LED1) will be On when the incoming IF signal is higher than the set
upper IF Threshold trip point.
IF OK: This green LED (LED2) will be On when the incoming IF signal is within the set
upper and lower IF Threshold trip points.
IF LOW: This yellow LED (LED3) will be On when the incoming IF signal is lower than the set
lower IF Threshold trip point.
LASER FAIL: This red LED (LED4) will be On when the laser is at the end of its life. This is a sign
that the laser should be replaced immediately.
LASER OK: This green LED (LED5) will be On when the output laser is operating with its normal
output power.
LED 6: The LED (LED6) is not used on this product.
AGC ON: This Green Led (LED 7) is On when AGC Mode is enabled and Off when Manual
mode is enabled. To enable AGC mode, set DIP switch 4 to the OFF position (away
from PCB). To disable AGC and set to manual mode, set DIP switch 4 to the ON
position (towards PCB).

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 13
4.2. 7707IFRA STATUS INDICATORS
The 7707IFRA modules have 9 LED Status indicators on the front card edge to show operational status of
the card at a glance.
Two large LEDs on the front of the board indicate the general health of the module.
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid optical input signal, or if a local input power fault exists (i.e. a blown fuse). The
LOCAL FAULT indication can also be reported to the frame through the FRAME
STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid optical
input signal is present, and the board power is good.
There are 7 small LEDs that indicate the status of the output IF signal and optical input signal.
IF HIGH: This red LED (LED1) will be On when the output IF signal is higher than the set
upper IF output threshold trip level.
IF OK: This green LED (LED2) will be On when the output IF signal is within the set upper
and lower threshold trip levels.
IF LOW: This yellow LED (LED3) will be On when the output IF signal is lower than the set
lower IF output threshold trip level.
OPTICAL INPUT HIGH: This red LED (LED4) will be On when the input optical power is to high.
OPTICAL INPUT OK: This green LED (LED 5) will be On when the input optical power is within the
rated input range.
OPTICAL INPUT LOW: This yellow LED (LED6) will be On when the optical power is lower than the
rated input range.
AGC ON: This green (LED7) is on when AGC mode is enabled and Off when manual mode is
enabled. To enable AGC mode, set DIP switch 4 to the OFF position (away from
PCB). To disable AGC and set to manual mode, set DIP switch 4 to the ON
position (towards PCB).

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 14 Revision 4.1
5. DIP SWITCH CONTROLS
5.1. IFTA DIP SWITCH CONTROLS
The 7707IFTA modules are equipped with a 4 position DIP switch at the front card edge. All positions are
assigned sequentially such that switch 1 is located at the top of the DIP switch (farthest from the card
ejector). Table 5-1 gives an overview of the front DIP switch functions and section 2.6.1 describes the
front DIP switch function in more detail. The On (closed) position is down, or closest to the printed circuit
board. The Off (open) position is up, or farthest from the printed circuit board.
DIP Switch Function
1
2
3
4 AGC Disable
Table 5-1: Front DIP Switch Functions
5.1.1. Configuring IFTA for AGC or Manual mode
The 7707IFTA input IF stage has an automatic gain control (AGC) that adjusts to varying input IF levels.
If the input IF level differs from –20dBm the AGC will adjust the level so that the level presented to the
optical link is maintained at –20dBm. To set the unit in AGC (Automatic Gain Control) mode, set Dip 4 to
the Off (away from PCB) position, conversely, to set the unit in Manual mode, set Dip 4 to the On (towards
PCB) position. Once the card has been set to Manual mode, the user can adjust the IF gain values
manually via the card edge menu system. See section 7.2.3.2. In AGC mode the monitor port will be
constant at –20dBm ±2dBm with input levels between –20 and –40dBm.
" NOTE: In order to conduct a frequency response sweep, the 7707IFA cards must
be set and configured to Manual Mode and not AGC mode.
5.2. IFRA DIP SWITCH CONTROLS
The 7707IFRA modules are equipped with a 4 position DIP switch at the front card edge. All positions are
assigned sequentially such that switch 1 is located at the top of the DIP switch (farthest from the card
ejector). The On (closed) position is down, or closest to the printed circuit board. The Off (open) position
is up, or farthest from the printed circuit board.
DIP Switch Function
1
2
3
4 AGC Disable
Table 5-2: Front DIP Switch Functions

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 15
5.2.1. Configuring IFRA for AGC or Manual mode
The DIP switches control the gain of the IF output section of the 7707IFRA and can be used to adjust for
losses in varying lengths of fiber optic cable in the system. The 7707IFRA output IF stage has an
automatic gain control (AGC) that adjusts to varying input optical levels. To set the unit in AGC (Automatic
Gain Control) mode, set Dip 4 to the Off (away from PCB) position. To set the unit in Manual mode, set
Dip 4 to the On (towards PCB) position. Once the card has been set to Manual mode, the user can adjust
the gain values manually via the card edge menu system.
" In order to conduct a frequency response sweep, the 7707IFA cards must be set
and configured to Manual Mode and not AGC mode.
" Output IF power measurements are made with 1 m of fiber optic cable between the
transmitting module and the receiving module.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 16 Revision 4.1
6. JUMPERS
/ MODULE OK
LOCAL FAULT
MASTER/SLAVE
COM
RUN/UPGRADE
FRAME STATUS
FACTORY
IF High
IF OK
IF Low
Laser Fail
Laser OK
AGC ON
1
2
3
4
DOT MATRIX DISPLAY
Figure 6-1: Location of 7707IFTA Jumpers and LEDs
/ MODULE OK
LOCAL FAULT
MASTER/SLAVE
COM
RUN/UPGRADE
FRAME STATUS
FACTORY
IF High
IF OK
IF Low
Optical Input High
Optical Input OK
AGC ON
1
2
3
4
DOT MATRIX DISPLAY
Figure 6-2: Location of 7707IFRA Jumpers and LEDs

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 17
6.1.1. Selecting Whether Local Faults Will Be Monitored
By the Global Frame Status
The FRAME STATUS jumper J3 determines whether local faults (as shown by the Local Fault indicator)
will be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this
jumper in the On position. (Default)
When this jumper is installed in the Off position local faults on this module will not
be monitored.
6.1.2. Selecting Whether Module Will Be Controlled From the Local Controls or Through the
VistaLINK
®
Interface
The MASTER jumper J38 selects whether the module will be controlled from the local user controls or
through the VistaLINK
®
interface.
MASTER: When this jumper is installed in the MASTER position, the card functions are
controlled through the local controls.
SLAVE: When this jumper is installed in the SLAVE position, the card functions are
controlled through the VistaLINK
®
interface.
6.1.3. Configuring the Module for Firmware Upgrades
UPGRADE: The UPGRADE jumper J43 is used when firmware upgrades are being done to the
module. For normal operation it should be installed in the RUN position. See the
Upgrading Firmware section of this manual for more information.
To upgrade the firmware in the module unit pull it out of the frame. Move the
UPGRADE jumper into the UPGD position. Install the Upgrade cable provided
(located in the vinyl pouch in the front of this manual) onto the SERIAL header at
the card edge. Re-install the module into the frame. Run the upgrade as described
in the Upgrading Firmware section of this manual. Once the upgrade is completed,
remove the module from the frame, move the UPGRADE jumper into the RUN
position, remove the upgrade cable and re-install the module. The module is now
ready for normal operation.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 18 Revision 4.1
7. DOT-MATRIX DISPLAY
Additional signal and card status monitoring and control over the card’s parameters are provided via the 4-
digit alphanumeric display located on the card edge. The card edge toggle switch is used to select
whether the user is displaying status from the card (monitoring mode) or setting control parameters for the
card (control mode). To select one of the display modes, press the pushbutton one or more times to exit
the current display mode and return to the mode select menu item (the display will show MON or SET).
Press the toggle switch to select monitor mode (MON) or control mode (SET). Once the desired mode is
selected, press the pushbutton to enter that mode.
While in monitor mode, the toggle switch determines what data is being displayed on the alphanumeric
display. Each time the toggle switch is pressed up/down, the display advances to the next/previous
display. A message indicating what display mode is active is shown for one second. After one second
without the toggle switch being pressed, the selected display data is shown. The card edge pushbutton is
used to select sub-items where applicable.
7.1. CARD EDGE MENU SYSTEM
" When changes are made in the menu system, the user must exit the menu system
and wait 30 seconds before the new menu settings are stored in the flash memory.
7.1.1. Navigating the Menu System
While in control mode, the toggle switch and pushbutton are used to navigate through a menu system to
set various parameters for the module. To enter the menu system, press the pushbutton one or more
times to exit the current display mode and return to the mode select menu item. The display will show MON
or SET. Press the toggle switch to select control mode (SET) and then press the pushbutton to enter the
control mode main setup menu. Use the toggle switch to move up and down the list of available sub
menus. Once the desired submenu name is displayed, press the pushbutton to select the next menu
level.
In the sub menu there will be a list of parameters to adjust. To adjust any parameter, use the toggle
switch to move up or down to the desired parameter and press the pushbutton. Using the toggle switch,
adjust the parameter to its desired value. If the parameter is a numerical value, the number will increase if
toggle switch is pushed upward and the number will decrease if the toggle switch is pressed downward. If
the parameter contains a list of choices, the user can cycle through the list by pressing the toggle switch in
either direction.
When desired value is reached, depress the pushbutton. This will update the parameter to the selected
value and return to the mode select menu item (the display shows SET). To change another parameter,
press the pushbutton to enter the main menu system again and continue selecting and adjusting other
parameters.
Each time the toggle switch is pressed up/down, the display advances to the next/previous display. A
message indicating what display mode is active is shown for one second. After one second without the
toggle switch being pressed, the selected display data is shown. The card edge pushbutton is used to
select sub-items where applicable.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
Revision 4.1 7707IFTA/IFRA - 19
7.2. IFTA MENUS
The following is a brief description of the top level of the menu tree that appears when the user enters the
Control menu. Selecting one of these items will take you down into the next menu level.
7.2.1. User Menu / Set
RFTH Allows the user to configure the Upper and Lower Input alarm Threshold.
GAIN Allows the user to set the Gain levels of the 7707IFTA in manual mode.
DISP Allows the user to set the orientation of the front panel display.
FDEF Allows the user to resets the module to its factory default values.
7.2.2. User Menu / Mon
RFTH Allows the user to monitor the upper and lower Input alarm Threshold
PWR Allows the user to monitor the IF Input power
GAIN Allows the user to monitor the Gain
SFTV Allows the user to check the software version
7.2.3. IFTA User Menu-Set
7.2.3.1. Setting the IF Threshold
RFTH
UPPR
LWR
AGC (Automatic Gain Control) Mode Operation
Manual Mode Operation -7707IFTA
IF Gain Setting
Default IF Warning Thresholds
AGC
0dBm to -35dBm
0dB
0dBm to -35dBm
+10dB
-10dBm to -45dBm
+15dB
-25dBm to -50dBm
The RF threshold setting enables the user to set both the upper and lower
threshold.

7700 Multiframe Manual
7707IFTA/IFRA Series IF Fiber Transmitter / Receiver
7707IFTA/IFRA - 20 Revision 4.1
7.2.3.2. Adjusting the Gain
GAIN
AUTO (AGC only)
0 dB (manual only)
10 dB (manual only)
15 dB (manual only)
The gain control allows the user to control the gain of the 7707IFTA card. To
manually set the Gain control, first set the 7707IFTA to manual mode dip
switch. Please refer to section 5.1.1 for further details. Once the unit is in
manual mode, the gain values can be adjusted to 0dB, 10dB, or 15dB. If
the 7707IFTA card is in AGC mode, the display will say AGC, and no
changes can be made with this menu item.
7.2.3.3. Changing the display orientation
DISP
VERT
HOR The DISP control allows the user to select a horizontal or vertical orientation
for the displays to accommodate mounting the module in the 3RU or 1RU
frames.
7.2.3.4. Restoring Factory Defaults
FDEF
YES
NO To restore the factory defaults, enter the FDEF control and choose yes to
restore all factory settings to the 7707I. All configurations previously made
to the card will be lost.
7.2.4. IFTA User Menu – Mon
The MON (monitoring) menu allows the user to check the status and values of the settings for the
7707IFTA card. To make changes to the settings, please refer to the User Set menu outlined in section
7.2.3.
7.2.4.1. IF-In Threshold
RFTH
UPPR
LWR The RFTH control allows the user to monitor the upper and lower IF-Input
threshold alarm set points.
7.2.4.2. IF In Power
PWR The PWR control allows the user to monitor the power levels of the IF-IN. If
the power level goes outside of the upper and lower thresholds, the display
will indicate high or low respectively.
7.2.4.3. Gain
GAIN
Auto (AGC Only)
0 dB
10 dB
15 dB
The gain control allows the user to monitor the gain of the 7707IFTA card.
To make changes to the gain, please refer to section 5.1.1.
7.2.4.4. Software Version
S/W The S/W function allows the user to check the version of software in the
card.
