Exibel DAB X45 User manual

DAB+/FM-radio med Bluetooth ·DAB+/UKW-Radio mit Bluetooth
Ver. 20181107
English 3
Svenska 16
Norsk 29
Deutsch 42
DAB+/FM Radio with Bluetooth
Art.no. Model
38-9155 DAB X45 / NE-6105

2

3
English
DAB+/FM Radio with Bluetooth
Art. no 38-9155 Model DAB X45 / NE-6105
Please read theentire instruction manual before using theproduct and then save it for future reference.
We reserve theright for any errors in text or images and any necessary changes made to technical
data. In theevent of technical problems or other queries, please contact our Customer Services
(see address details on theback).
Safety
This product is intended for indoor use only.
Important:
• Theproduct must not be taken apart or modified. Certain unshielded components inside
thehousing carry dangerous voltages. Contact with these can lead to fire or electric shock.
• Never subject theproduct to high temperature, dust, heavy vibration, impacts, humidity
or moisture.
• Do not place theproduct where it could fall into water or other liquid. Do not place any
objects containing liquid on theproduct, e.g. flower vases or drinks.
• Do not cover theproduct. Adequate ventilation with adistance of at least 10 cm between
theproduct and thesurrounding area is necessary to prevent theappliance from becoming
too warm.
• Disconnect theproduct from thepower supply by unplugging it from thewall socket.
Make sure that thewall socket and plug are easily accessible.
• Theon/off button does not disconnect theproduct from theelectricity mains.
• Protect your hearing. Listening on high volume for prolonged periods can lead to permanent
hearing loss.
• Repairs and service should only be performed by qualified tradesmen, and only with original
spare parts.

4
English
3
15 14 13 12 11
16
20 19 18 17
10 9
4 5 6 7 8
21
Buttons and functions
1. Speaker
2. Display
3. [VOLUME] Increase/
decrease thevolume
4. [SCAN/►||] Play/pause,
automatic search for radio
channels.
5. [DIMMER] Press repeatedly
to change thebrightness of
thedisplay.
6. [PRESET/RECALL/STORE]
Saved channel list: Hold
in to save, quick-press to
select achannel.
7. [SELECT] Select, open
amenu, confirm selection.
8. [SCROLL] Scroll through
themenu, change values.
Previous track/next track.
9. [SNOOZE] Snooze function
10. [ALARM] Alarm function
11. [INFO] Display radio station
info
12. [MENU] Display themenu
13. [SLEEP] Sleep timer
14. [MODE] Select audio
source: FM radio, DAB
radio, Bluetooth or Auxiliary
Input
15. [ ] On/off
16. Aerial
17. DC IN: Mains adapter socket
18. USB port (1 A) for charging e.g. mobile phones
19. AUX IN: 3.5 mm external audio source input socket
20. 3.5 mm headphones socket

5
English
Installation
Aerial
Extend theaerial (16) fully for thebest signal reception. Theoptimum radio signal reception is
usually achieved when theaerial is in anupright, vertical position.
Connecting the mains adapter
Connect themains adapter to theDC IN socket (17) and to a230V wall socket. Thedisplay will
first show “Welcome to Digital Radio”, thereafter thetime will be shown.
Remember to unplug theproduct from thewall socket during heavy thunder storms to protect it.
External audio source input socket
If you wish to connect anexternal audio source to theradio such as amobile phone or MP3 player,
you can do this by plugging it into theAUX IN socket (19) on theback of theradio.
Listening with headphones
1. Connect headphones to the3.5 mm headphones socket (20). Thesound from
thespeakers in theradio will be automatically cut off once headphones are connected.
2. Turn thevolume down completely.
3. Put theheadphones on and carefully increase thevolume to acomfortable level.
Instructions for use
Switching the radio on/off
Switch theradio on or off by pressing [ ].
Thefirst time theradio is switched on it will automatically
search for DAB channels. Whilst theradio is scanning,
“Scanning…” will appear on thedisplay along with aprogress
bar indicator and anumber showing how many channels
have been found. Once thescan has finished, theradio will
select thechannel that was found first.
Information
• If no DAB channels are found “No DAB Station” will appear on thedisplay. Thereafter
theradio will revert to showing theDAB menu.
• Make sure that DAB broadcasts are available in your geographical area.
• If reception is poor, try to change theposition of theaerial or move theradio to improve reception.
• Refer to theDAB menu section to carry out anew channel search.

6
English
Audio setting
Adjust thevolume by turning thevolume dial (3).
Information
It is possible to customise thesound by selecting from achoice of pre-installed equaliser settings.
Refer to theDAB/FM menu section.
Display backlight
Adjust thedisplay backlight by repeatedly pressing the [DIMMER] button. There are four settings
to choose from: Low, Medium, High and Off.
Setting the time and date
Thetime and date are set automatically with thehelp of DAB or FM radio signals (thetime is
set approximately 2 minutes after theradio is switched on). Thetime and date can also be set
manually if theradio signal is too weak:
Note: No more than 5 seconds must elapse between menu selections otherwise theradio will
return to theprevious display mode.
• Press [MENU] to display themenu.
• Turn the [SCROLL] dial to scroll through themenu and change theselected data.
• Press [SELECT] to select or confirm thechosen menu/function.
1. Select System →Time →Set Time/Date.
2. Set thehours, minutes, day, month and year. Confirm each step by pressing [SELECT].
3. When each step has been performed thesettings will be saved and “Time Saved” will appear
on thedisplay.
DAB radio
Selecting anaudio source: Press [MODE] repeatedly until “DAB” appears on thedisplay.
Thecurrent radio channel will then be shown on thedisplay. If no channels are stored in theradio
anautomatic search for DAB channels will be initiated.
Choosing radio channels
Turn the [SCROLL] dial to choose achannel from thelist of stations. Thedisplay will then show
“Station list” and thechannel name. Press [SELECT] to confirm.
Up to 10 channels can be saved as preset channels on alist so that you can choose your
favourite stations more quickly. Refer to thePreset channels section below.
Information
If theradio is moved to anew location or if radio stations change frequencies, some preset
channels might become unavailable. If theradio does not find theselected channel, “Service not
available” will appear on thedisplay. Refer to theDAB menu section to carry out anew search
and to delete any unavailable channels from thechannel list.

7
English
DAB menu
In DAB mode, press [MENU] repeatedly to enter theDAB menu.
1. Turn the [SCROLL] dial to scroll through themenu.
2. Press [SELECT] to select or confirm thechosen menu/function.
Thesettings marked with anasterisk (*) are thecurrent settings.
Thefollowing menus will appear:
• Full scan: Automatic scan for DAB radio channels.
- Press [SELECT] to confirm. Theradio automatically starts scanning for DAB radio channels.
• Manual tune: Manual scan for DAB radio channels. Thecurrent channel number and
frequency will be displayed.
- Turn the [SCROLL] dial to select afrequency manually. Press [SELECT] to confirm.
• Prune: Clear thechannel list of unavailable radio channels.
- Turn the [SCROLL] dial to select Yes or No. Press [SELECT ] to confirm. “Yes” clears
thechannel list and “No” aborts theclearance.
• System: Choose from thefollowing list of sub-menus:
- Equaliser: Audio characteristics settings.
- Time: Time and date settings.
- Factory Reset: Resets theradio to thefactory settings.
- SW version: Shows thecurrent software version.
Full scan
Manual tune
Prune
System
Equaliser
Time
Set Time/Date
Auto update
Update from Any
Update from DAB
Update from FM
No update
Set 12/24 hour
Set date format
Factory Reset
SW version

8
English
• Equaliser: Customise thesound by selecting from achoice of pre-installed equaliser settings.
- Selection options: Normal, Rock, Classic, Pop and Jazz. Press [SELECT] to confirm.
• Time:
- Set Time/Date: refer to theSetting thetime and date section above.
- Auto update: has four sub-menus:
- Update from Any (update time using DAB or FM radio signals).
- Update from DAB (update time using DAB radio signals).
- Update from FM (update time using FM radio signals).
- No update (no automatic update, set time manually).
- Set 12/24 hour: select to display thetime on a12-hour or 24-hour clock.
- Set date format: set date format (day-month-year/month-day-year).
• Factory Reset: Reset to factory default settings. Select No (no reset) or Yes (reset).
Press [SELECT] to confirm. Note: Afactory reset will erase all your preset channels.
• SW version: Press [SELECT] to display theversion info.
Display options (DAB mode)
Press [INFO] repeatedly to display information about thecurrent radio channel.
Thedisplay will appear as follows:
• Radio Text: Shows text messages from theradio channel.
• Signal Strength: Shows thesignal strength of thechannel.
• Programme Type: Shows thecurrent programme type (genre).
• Ensemble Name: Shows thegroup name of thechannels transmitted on thesame frequency.
• Channel Number/Frequency: Shows thechannel number and frequency of theradio channel.
• Signal Error: Shows thesignal quality of thechannel.
• Audio Bit Rate: Shows thebit rate of theaudio stream.
• Time/Date: Displays time or date.
Signal Error Audio Bit Rate Time Date
Radio Text Signal Strength Programme Type Ensemble
Name
Channel Number/
Frequency

9
English
FM radio
Selecting anaudio source: Press [MODE] repeatedly until “FM” appears on thedisplay.
Thereafter thedisplay will show thechosen radio channel/frequency.
Tuning into a radio station
• Manual tuning: Turn the [SCROLL] dial to change to alower or higher frequency.
• Automatic search: Press [SCAN/►||] to automatically search for thenext detectable radio
channel. Thesearch stops when achannel has been found.
Up to 10 channels can be saved as preset channels on alist so that you can choose your
favourite stations more quickly. Refer to thePreset channels section below.
If theselected channel transmits RDS information (Radio Data System), thename of channel will
be shown on thedisplay.
FM menu
In FM mode, press [MENU] to enter theFM menu.
1. Turn the [SCROLL] dial to scroll through through themenu.
2. Press [SELECT] to select or confirm thechosen menu/function.
Thesettings marked with anasterisk (*) are thecurrent settings.
Thefollowing menus will appear:
Scan setting
Strong stations
only
All stations
Audio setting
Stereo allowed
Forced mono
System
Equaliser
Time
Set Time/Date
Auto update
Update from Any
Update from DAB
Update from FM
No update
Set 12/24 hour
Set date format
Factory Reset
SW version

10
English
• Scan setting: Choose thesensitivity for scanning for FM channels. Turn the [SCROLL]
dial to select either Strong stations only (low sensitivity) or All stations (high sensitivity).
Press [SELECT] to confirm.
• Audio setting: Select whether you wish to receive stereo audio or if you want to receive
transmissions in mono. In poor reception conditions, mono can improve thesound quality.
Turn the [SCROLL] dial to select Stereo allowed or Forced mono. Press [SELECT] to confirm.
• System: Choose from thefollowing list of sub-menus:
- Equaliser: Audio characteristics settings.
- Time: Setting thetime and date
- Factory Reset: Reset theradio to thefactory settings.
- SW version: Shows thecurrent software version.
• Equaliser: Adjust thesound by selecting from achoice of pre-installed equaliser settings.
Selection options: Normal, Rock, Classic, Pop and Jazz. Press [SELECT] to confirm.
• Time
- Set Time/Date: refer to theSetting thetime and date section above.
- Auto update: has four sub-menus:
- Update from Any (update time using DAB or FM radio signals).
- Update from DAB (update time using DAB radio signals).
- Update from FM (update time using FM radio signals).
- No update (no automatic update, set time manually).
- Set 12/24 hour: select to display thetime on a12-hour or 24-hour clock.
- Set date format: set date format (day-month-year/month-day-year).
• Factory Reset: Reset to factory default settings. Select No (no reset) or Yes (reset).
Press [SELECT] to confirm. Note: Afactory reset will erase all your preset channels.
• SW version: Press [SELECT] to display theversion info.
Display options (FM mode)
Press [INFO] repeatedly to display information about thecurrent radio channel. Note: Information
about thecurrent radio channel is only shown if theFM channel sends out RDS data.
Thefollowing information can be displayed:
Radio Text Programme
Type Frequency Audio Type Time Date
• Radio Text: Shows text information transmitted on thechannel.
• Programme Type: Shows thecurrent programme type (genre).
• Frequency: Shows thefrequency of thechannel.
• Audio Type: Shows whether thetransmission is received in stereo or mono.
• Time/Date: Displays time or date.

11
English
Preset channels
Up to 10 stations can be preset in both DAB and FM mode, this will enable you to access your
favourite stations more quickly.
Note: No more than 5 seconds must elapse between menu selections otherwise theradio will
return to theprevious display mode.
Saving a radio channel as a preset channel
1. Choose thechannel that you wish to save.
2. Press and hold in [PRESET/RECALL/STORE] until “Save to...” appears on thedisplay.
3. Select achannel slot by turning the [SCROLL] dial.
4. Save by pressing [SELECT]. “Preset # stored” will appear on thedisplay.
Selecting a channel from the preset channels
1. Press [PRESET/RECALL/STORE] . “Preset Recall” will appear on thedisplay.
2. Turn the [SCROLL] dial to scroll through through thelist of preset channels.
3. Select achannel slot and confirm by pressing [SELECT].
If you choose achannel slot which has no preset radio channel on it, “Preset Empty” will be
shown on thedisplay.
Note:
Disconnecting theradio from thepower supply will erase any saved/preset radio channels.
External devices
Bluetooth
1. Select anaudio source: Press [MODE] repeatedly until “Bluetooth” appears on thedisplay.
2. Make sure that no other Bluetooth device is connected to theradio. “Disconnected” will
appear on thedisplay.
3. Activate Bluetooth on thedevice that you want to connect.
4. Look for theradio on thelist of detected devices on theBluetooth device (refer to theinstruction
manual of thedevice). Theradio will appear on theBluetooth device as “DAB X45”.
5. Select DAB X45 from thelist. You might need to enter thePIN-code 0000.
Certain devices may also require you to approve theconnection.
6. Once theconnection has been successful “Connected” will appear on thedisplay of theradio.
7. Start playback on your Bluetooth device.
8. Adjust thevolume both on theBluetooth device and theradio.
To disconnect aconnected Bluetooth device: Press and hold in [SCAN/►||].
Thedisplay will show “Disconnected”.

12
English
Audio source input (AUX IN)
1. Connect anexternal audio source to the3.5mm input socket (19) on theback of theradio.
2. Selecting anaudio source: Press [MODE] repeatedly until “Auxiliary Input” appears on thedisplay.
3. Start playback on theexternal audio source.
4. Adjust thevolume to adesired level.
Information
If theradio is set to “Auxiliary Input” for over four hours, thedevice shuts down automatically.
1. 10 minutes after thedevice shuts down “Press MENU/INFO to cancel auto off” will appear
on thedisplay.
2. Press [MENU]/[INFO] to interrupt theautomatic shut down.
Charging external devices
Connect theexternal device that you wish to charge to theUSB charge port (18) using aUSB
cable (sold separately).
Sleep timer
Set how long theradio is to be left on before it automatically shuts off. Press [SLEEP]
therequired number of times to choose between: Off , 10, 20, 30, 60, 70, 80 or 90 min.
Alarm
Information
• Thealarm works whether theradio is switched on or off.
• If you try to set thealarm when thetime and date have not been set, theradio automatically
enters time set mode. Refer to point 2 under the Setting the time and date section.
• When theradio is in standby mode, is shown on thedisplay to indicate that thealarm is activated.
Setting alarm 1
1. Switch theradio on by pressing [ ].
2. Press [ALARM] once. “Alarm 1 Setup” will appear on thedisplay.
3. Press [SELECT]. “Alarm 1 Wizard” will appear on thedisplay.
4. Set thealarm by turning the [SCROLL] dial and confirming every step using [SELECT].
5. Make thesettings in thefollowing order:
- On time (alarm time): hour/min.
- Duration (alarm duration): 15, 30, 45, 60, 90 or 120 min.
- Source (alarm signal): buzzer, DAB or FM (if DAB or FM radio is chosen, you will be
prompted to select aradio station).
- Choose when thealarm is to sound: Daily , Once, Weekends, Weekdays. If Once is chosen,
you will be prompted to select adate.
- Volume (alarm volume): Set thevolume you wish thealarm to reach. Thealarm signal
starts on low volume and gradually increases in volume to theset level.
- Alarm On/Off: activate/deactivate thealarm.

13
English
Setting alarm 2
1. Switch theradio on by pressing [ ].
2. Press [ALARM] twice. “Alarm 2 Setup” will appear on thedisplay.
3. Then follow thesame steps as those used for setting alarm 1 as described above.
Activating/Deactivating a programmed alarm
When theradio is switched on:
1. Select which alarm is to be activated/deactivated by pressing [ALARM] repeatedly.
2. Turn the [SCROLL] dial to choose On (activate) or Off (deactivate). Confirm by pressing [SELECT].
In standby mode:
Press [ALARM] therequired number of times to activate/deactivate either of therespective alarms.
Confirm by pressing [SELECT].
Snooze
Press [SNOOZE] when thealarm sounds. Press the [SNOOZE] button therequired number of
times to select thedesired snooze duration: 5, 10, 15 or 30 minutes. Thechosen snooze time will
countdown on thedisplay.
Switching the alarm off
Press [ ] to switch thealarm off. “Alarm off” will appear on thedisplay. Thealarm will sound at
theset time thefollowing day.
Care and maintenance
Clean theradio by wiping it with adamp cloth. Use only mild cleaning agents, never solvents or
corrosive chemicals.

14
English
Troubleshooting guide
Theradio won’t turn on. • Make sure that themains adapter and lead are intact and undamaged.
• Make sure that themains adapter and its lead are properly
connected to awall socket and theradio.
• Is thewall socket energised?
No sound from
thespeakers or
connected headphones.
• Check thevolume.
• Make sure that there are no headphones connected
to the3.5mm headphone socket. When you connect
theheadphones, thespeaker turns off.
• Make sure that theheadphones and cord are intact and properly
connected to theradio.
No sound from
connected external
device.
• Make sure that thecorrect audio source has been chosen.
• Check thevolume level on both theradio and theconnected device.
If using Bluetooth:
• Make sure that theBluetooth connection has been properly
established.
• Test theplayback from theBluetooth device without it being
connected to theradio to ensure that it is working.
Things to consider:
• Other wireless equipment can negatively impact
thetransmission range.
• Therange can also be affected by thetype of obstacles located
between thetransmitter and thereceiver (e.g. aconcrete wall
will interfere with thesignal more than aplasterboard wall).
If using theAUX IN socket:
• Check that thecable connected to thedevice and theAUX IN
(19) socket on theradio is undamaged and properly connected.
• Check that thecorrect audio source has been chosen (Auxiliary
Input).
Poor or non-existent radio
reception. Theauto-
matic FM scan doesn’t
work.
• Make sure that theaerial is fully extended.
• Try moving theaerial.
• Move theradio to another location.
Thetime and date are
cleared when theradio
is switched off.
• Theradio only stores thetime and date during mains operation.
Upon reception of aDAB or RDS signal, thetime is set
automatically.
If theradio is operating
abnormally in some
other way.
• Perform afactory reset. Refer to theDAB/FM menu section.

15
English
Responsible disposal
This symbol indicates that this product should not be disposed of with general
household waste. This applies throughout theentire EU. In order to prevent
any harm to theenvironment or health hazards caused by incorrect waste
disposal, theproduct must be handed in for recycling so that thematerial can
be disposed of in aresponsible manner. When recycling your product, take it to
your local collection facility or contact theplace of purchase. They will ensure that
theproduct is disposed of in anenvironmentally sound manner.
Specifications
Radio
Frequency range FM 87.5–108MHz
DAB 174–240 MHz
Power consumption 27W
Speaker power 2×5 W RMS
Size 300×160×120 mm
Weight 1.65 kg
Mains adapter
Input 100–240 V AC, 50/60 Hz
Output 9 V, 3 A

16
Svenska
DAB+/FM-radio med Bluetooth
Art.nr 38-9155 Modell DAB X45 / NE-6105
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska problem
eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
Produkten är endast avsedd för inomhusbruk.
Viktigt:
• Produkten får inte demonteras eller ändras. Farlig spänning finns oskyddad på komponenter
under produktens hölje. Kontakt med dessa kan leda till brand eller ge elektriska stötar.
• Utsätt aldrig produkten för höga temperaturer, dammig miljö, starka vibrationer, stötar, fukt
eller väta.
• Placera inte produkten så att den kan falla ner ivatten eller annan vätska. Ställ inte några
föremål som innehåller vätska på produkten, t.ex. enblomvas eller dryck.
• Täck inte över produkten. Tillräcklig ventilation, med ettminsta avstånd på ca 10 cm mellan
produkten och omgivande ytor, är nödvändig för att förhindra att produkten blir för varm.
• Bryt strömmen till produkten genom att dra ut stickproppen ur vägguttaget. Stickproppen
måste vara lättåtkomlig.
• Produktens på/av-knapp bryter inte strömmen från elnätet.
• Skydda din hörsel. Lyssning med hög volym under lång tid kan leda till bestående hörselskador.
• Låt behörig personal utföra service och reparationer och endast med originalreservdelar.

17
Svenska
3
15 14 13 12 11
16
20 19 18 17
10 9
4 5 6 7 8
21
Knappar och funktioner
1. Högtalare
2. Display
3. [VOLUME] Öka/minska
volymen
4. [SCAN/►||] Automatisk
sökning efter radiokanaler,
play/pause.
5. [DIMMER] Tryck upprepade
ggr för att ändra displayens
ljusstyrka
6. [PRESET/RECALL/STORE]
Favoritlista: Håll in för att
spara, tryck kort för att
välja kanaler.
7. [SELECT] Välj, öppna
meny, bekräfta
8. [SCROLL] Stega genom
menyn, ändra värde.
Föregående/nästa spår.
9. [SNOOZE] Snoozefunktion
10. [ALARM] Alarmfunktion
11. [INFO] Visa radiokanal-info
12. [MENU] Visa meny
13. [SLEEP] Insomningstimer
14. [MODE] Val av ljudkälla:
FM-radio, DAB-radio,
Bluetooth eller Auxiliary
Input (ljudingång)
15. [ ] På/av
16. Antenn
17. DC IN: Anslutning för nätadapter
18. USB-uttag (1 A) för laddning av t.ex. mobiltelefoner
19. AUX IN: 3,5 mm-ljudingång för externa enheter
20. 3,5 mm-uttag för hörlurar

18
Svenska
Installation
Antenn
Sträck ut antennen (16) till sin fulla längd för bästa möjliga mottagning. Optimal mottagning
brukar uppnås när antennen är iupprätt, vertikalt läge.
Anslut nätadaptern
Anslut nätadaptern till DC IN (17) och till ett230 V-vägguttag. Displayen visar ”Welcome to Digital Radio”,
därefter visas klockan.
Kom ihåg att dra ut nätadaptern ur vägguttaget vid kraftiga åskväder för att skydda produkten.
Ljudingång för externa enheter
Vill du ansluta enextern ljudkälla som t.ex. mobiltelefon, MP3-spelare kan du göra det genom att
ansluta dessa till ljudingången (AUX IN) (19) på radions baksida.
Lyssning med hörlurar
1. Anslut hörlurarna till 3,5 mm-uttaget (20). Radions högtalare stängs automatiskt av.
2. Justera ner volymen helt.
3. Sätt på dig hörlurarna och justera försiktigt upp volymen.
Användning
På/av
Slå på eller av enheten genom att trycka [ ].
Första gången radion slås på startas enautomatisk sökning
av DAB-kanaler. Under sökningen visas ”Scanning…”
tillsammans med enindikator samt ensiffra för hur många
radiokanaler som hittats. När sökningen är klar väljer radion
den först hittade kanalen.
Information
• Om inga radiokanaler hittas under sökningen visas ”No DAB Station” idisplayen.
Därefter återgår radion till att visa DAB-menyn.
• Kontrollera att DAB-utsändningar finns iditt geografiska område.
• Prova att rikta om antennen eller flytta enheten till enannan plats.
• Se avsnitt DAB-meny för att göra enny sökning.

19
Svenska
Ljudinställning
Justera volymen genom att vrida på radions volymratt (3).
Information
Det finns möjlighet att justera ljudet genom att välja mellan olika förinställda equaliserinställningar.
Se avsnitt DAB-/FM-meny.
Displaybelysning
Justera displayens bakgrundsbelysning genom att trycka upprepade gånger på [DIMMER].
Välj mellan Low, Medium, High och Off.
Tidsinställning
Radion ställer automatiskt in tid och datum med hjälp av DAB- eller FM-radiosignalen (tiden ställs
in ca 2 min efter att radion slagits på). Om radiosignalen är för svag kan tid och datum behöva
ställas in manuellt:
Obs! Det får inte gå längre än 5 sek mellan följande menyval eftersom radion annars återgår till
föregående visningsläge.
• Tryck [MENU] för att komma till menyn.
• Vrid på [SCROLL] för att stega genom menyn samt ändra valt värde.
• Tryck [SELECT] för att välja eller bekräfta vald meny/funktion.
1. Välj System →Time → Set Time/Date.
2. Ställ in timmar, minuter, dag, månad och år. Bekräfta varje steg med [SELECT].
3. När alla steg är genomförda sparas inställningarna och displayen visar ”Time Saved”.
DAB-radio
Välj ljudkälla: Tryck upprepade gånger på [MODE] tills ”DAB” visas idisplayen. Displayen visar
därefter aktuell radiokanal.
Finns det inga radiokanaler lagrade iradion startas enautomatisk sökning av DAB-kanaler.
Välja radiokanal
Vrid på [SCROLL] för att välja enradiokanal ikanallistan. Displayen visar ”Station list” och kanalnamn.
Tryck [SELECT] för att bekräfta.
Det finns möjlighet att spara upp till 10 favoritkanaler till enfavoritlista för att snabbt kunna välja kanal.
Se avsnitt Favoritlista nedan.
Information
Om radion flyttas till enny plats eller om radiokanaler byter frekvens etc. kan vissa lagrade kanaler bli
otillgängliga. När radion inte hittar vald kanal visas ”Service not available” idisplayen. Se avsnitt
DAB-meny för att göra enny sökning och för att rensa kanallistan från otillgängliga radiokanaler.

20
Svenska
DAB-meny
IDAB-läge, tryck [MENU] upprepade gånger för att komma till DAB-menyn.
1. Vrid på [SCROLL] för att stega genom menyn.
2. Tryck [SELECT] för att välja eller bekräfta vald meny/funktion.
De inställningar som markeras med enasterisk (*) visar aktuell inställning.
Följande menyer visas:
• Full scan: Automatisk sökning efter DAB-radiokanaler.
- Tryck [SELECT] för att bekräfta. Radion startar enautomatisk sökning av DAB-kanaler.
• Manual tune: Manuell sökning av DAB-radiokanaler. Displayen visar aktuellt kanalnummer
och frekvens.
- Vrid på [SCROLL] för att manuellt välja frekvens. Tryck [SELECT] för att bekräfta.
• Prune: Rensa kanallistan från otillgängliga radiokanaler.
- Vrid på [SCROLL] för att välja Yes eller No. Tryck [SELECT] för att bekräfta.
”Yes” rensar kanallistan och ”No” avbryter rensningen.
• System: Välj mellan följande undermenyer:
- Equaliser: Inställning av ljudkaraktär.
- Time: Inställning av tid och datum.
- Factory Reset: Återställer radion till fabriksinställningar.
- SW version: Visar aktuell mjukvara.
Full scan
Manual tune
Prune
System
Equaliser
Time
Set Time/Date
Auto update
Update from Any
Update from DAB
Update from FM
No update
Set 12/24 hour
Set date format
Factory Reset
SW version
