Product information
An Exodraft RSHT chimney fan is designed with horizontal discharge.
The fan must be installed on top of a chimney and creates a negative pressure (suction) along the full
length of the ue.
The fan can be used in connection with all types of fuel burning appliances and is especially well-suited to
appliances burning solid fuel, such as wood-burning replaces and stoves and biomass or solid-fuel boilers.
The fan is part of an Exodraft system and should be connected to an Exodraft controller for optimal effect.
Incorrect ring may result in problems with soot, chimney res, etc. which might damage the product.
Please check out this site for advice about lighting and maintaining a re:
www.exodraft.com
Scope of supply
• Exodraft RSHT chimney fan
• Mineral wool mat for vibration-free mounting
• Packet with location brackets, safety wire, bolts and nuts
(wing screws included - to be used where allowed)
• Armoured hose
• Installation manual and user instructions
Accessories and spare parts
The table below shows the accessories and spare parts available for the RSHT-models.
Accessories* Spare parts
Flanges (for steel chimneys) Motors
Cover Plates (for steel and brick chimneys) Impellers and axial vanes
RSD - Dilution bolts (for brick chimneys) Mineral wool mats
Rainshield SVD-RS - Vibrations dampers (for anges on steel chimneys)
Capacitors
*This manual does not describe the specic use of accessories. We refer to the separate manuals for such components.
For more details contact your Exodraft dealer.

8|UK
Your energy. Optimized.
Warranty
All Exodraft products are covered by a 2-year guarantee as per European consumer rights legislation. For
some countries an extended period of guarantee may apply depending on either national legislation or
other clearly stipulated conditions. Customer complaints must be handled by a specialised dealer or
wholesaler (preferably where the Exodraft product has been bought originally). An updated list of Exodraft
specialised dealers can be found on our website for the country in question.
Exodraft products must always be installed by properly qualied personnel. Exodraft reserves the right to
change these guidelines without prior notice.
The warranty and liability does not cover instances regarding personal injury or damage to property or the
product that can be ascribed to one or more of the following causes:
• Failure to follow this installation and operation manual
• Incorrect installation, start-up, maintenance or servicing
• Improper repairs
• Unauthorised structural modications made to the product
• Installation of additional components that have not been tested/approved with the product
• Any damage resulting from continued use of the product despite an evident defect
• Failure to use original spareparts and accessories
• Failure to use the product as intended
• Exceeding or failure to meet the limit values in the technical data
• Force majeure
Technical specications
The RSHT fan is designed for horizontal discharge. It is available in four sizes.
The body and casing are manufactured in cast aluminium and equipped with a stainless steel axial vane.
Chimney fan Axial vane/Impeller
RSHT009-41
RSHT012-41
RSHT014-41
RSHT016-41
Stainless steel axial vane
All models can be opened for service and cleaning purposes.
The sound level is below 60 dB (measured at a distance greater than one metre away from the fan) if
installed correctly. Further information about sound levels available in our technical brochure.

UK |9
3112003_RSHT_UK
Model Motor specications Weight Dimension [mm]
rpm V Amp kW* kg A B x B C [Ø] DE [Ø]
RSHT009-41 130 1 x 230 0.26 0.06 12 298 296 275 75 220
RSHT012-41 1350 1 x 230 0.55 0.09 15 325 364 344 85 280
RSHT014-41 1350 1 x 230 1.00 0.19 19.0 372 422 395 100 330
RSHT016-41 1350 1 x230 1.90 0.31 22 400 478 441 100 380
*Power consumption at ambient temperature of 20 °C
• The RPM of the above fan models are innitely adjustable
• Motor protection IP rating IP54
• Insulation class F
A
C
D
E
B
The RSHT fan has been designed to tolerate ue gas temperatures up to 500°C. Should the temperature be
higher (though maximum 700°C), the mineral wool mat should be removed and replaced with optional
dilution bolts (type RSD) or vibration dampers (type SVD-RS) at the ange to create extra cooling air under
the fan. For more information about these parts see under accessories.
All RSHT models has a motor capacitor. The capacitor is considered a wear part that will be worn out over
time (depending on usage). If the capacitor is worn out, the motor will have difculties starting up. Then it is
time to replace the capacitor. Please ask a qualied electrician to carry out this job.
Technical data

10 |UK
Your energy. Optimized.
Construction and components
1 Top section
2 Bottom section
3Motor
4 Motor plate
5 Cooling plate
6 Axial vane
7 Safety hinge
8Safety mesh
9 Armoured cable and connecting cable
10 Mineral wool mat
11 Safety wire
12 Location brackets, bolts and nuts etc.
3
5
6
1
8
7
4
2
10
12
11
9

UK |11
3112003_RSHT_UK
Precautions and user instructions
These instructions, applicable standards and relevant safety procedures from the manufacturer must be
followed and at the same time the ofcial provisions in force in the country, where the product is installed,
must be observed.
Support system
Prior to installation of a chimney fan, it must be determined if the chimney can safely carry the weight of the
chimney fan.
A steel chimney should be well supported at the roof penetration point. If the chimney extends high above
the roof, the chimney and the fan should be secured. The manufacturer’s instructions must be followed.
Brick chimneys do not usually need any kind of support to carry the weight of the chimney fan.
System type
Fireplaces and wood stoves used in private dwellings normally operate in a relatively stable environment,
where no major pressure uctuations occur. However, to secure an optimal use of the Exodraft system
speed adjustments and adjustment of air intakes are required depending on the weather outside and on the
stage of the ring process.
Fireplaces used in restaurants are exposed to major pressure changes due to factors like the constant
opening/closing of doors, kitchen exhaust fans pulling out air, etc. In an environment like this spillage of
smoke can easily occur.
Precautions
Be aware that it
• must be installed on top of the chimney
• can be mounted on steel as well as brick chimneys
• must be mounted with the approved Exodraft accessories
• must be accessible for service and maintenance from the roof or from a ladder/cherry picker
• the distance to ammable materials must be at least 500 mm
• the isolation switch must be easily accessible
ATTENTION! It is always recommended to install a
smoke alarm in connection with a wood red installation.

12 |UK
Your energy. Optimized.
Mechanical installation
Exodraft products must always be installed by properly qualied personnel and according to the
manufacturer’s instructions.
Transportation safety bracket
Do not forget to remove the transport safety bracket located near the axial vane and check that the axial
vane turns freely, before mounting the fan on the chimney.
Models:
RSHT009-41
RSHT012-41
RSHT014-41
RSHT016-41

UK |13
3112003_RSHT_UK
Positioning of the chimney fan
The chimney fan can only be mounted vertically. Be aware of national law and building regulations!
Minimum distance
The minimum distance to ammable materials must be at least 500 mm (national legislation must be
observed)!
Min. distance according
to national legislation!

14 |UK
Your energy. Optimized.
Installation onto a brick chimney
If the fan is to be tted on a brick chimney, please use the location brackets. See the installation guide
below.
Step Action Illustration
1 Measure the inside diameter of the brick chimney.
2
Then cut a hole in the mineral wool mat that
matches.
Note that there must always be a minimum of
20 mm of mat surface at any point around the
circumference of the hole. 20 mm
20 mm
3
Mount and fasten the location brackets to the
underside of the base plate by means of the bolts
and nuts supplied.
Please note that the bolts must be inserted from
beneath.
4
Adjust the distance between the location brackets
to t the inside diameter of the chimney, and then
tighten the nuts.
Note that there should be a 2-4 mm gap between
the brackets and the chimney in order to avoid
transmitting vibrations from the fan to the
chimney.

UK |15
3112003_RSHT_UK
5
Place the mineral wool mat on top of the chimney.
It can be used with either of the sides facing
the fan. The chimney fan can now be lowered
into place (on top of the mat) with the location
brackets into the chimney.
IMPORTANT! Do not screw or bolt the brackets into
the ue pipe!
6
Use the safety wire to secure the fan to the chim-
ney. Apply the supplied screw and rawlplug into
the brick chimney. Then mount the wire through
the designated hole in the base plate and into the
wire lock.
Tighten the safety wire slightly and then tighten
the wire lock, so that the chimney fan is secured
when opened for service and cleaning purposes.
The isolation switch should be tted on the side
of the chimney, so it is easily accessible when
servicing the fan.
The armoured cable should be connected into the
underside of the isolator and up into the switch
via the cable gland.
7
Before taking the fan into operation, please make
sure that:
• the nuts in the location brackets have been
tightened.
• the safety wire has been fastened to the fan
and chimney.
• the safety wire and the wire lock have been
tightened.
• the connection on the armoured cable has
been fastened. The armoured cable must hang
straight down from the fan.
• the chimney fan is securely closed.
• when opening/closing the fan, support the
upper part with your hand.
NOTICE! The end-user should be made aware of
the fact that the chimney fan must always remain
switched on when the replace/boiler is in use.
8To avoid rainwater from entering the chimney fan
the slots and holes must be sealed with silicone.

16 |UK
Your energy. Optimized.
Installation onto a steel chimney
If the fan is to be tted on a steel chimney, the chimney fan must be installed with an approved ange.
See the installation guide below.
Step Action Illustration
1
The ange must be placed so that the spigot goes
into the chimney!
Measure the diameter of the hole in the ange.
2
Then cut a hole in the mineral wool mat that
matches.
Note that there must always be a minimum of
20 mm of mat surface at any point around the
circumference of the hole.
20 mm
20 mm
3
Cut the corners off the mineral wool mat, so there
is room to t the vibration dampers.
If a temperature sensor is to be installed with the
chimney fan, cut a groove in the mineral wool mat
that is big enough for the sensor.
Now place the mineral wool mat on the ange
(between the ange and the fan).

UK |17
3112003_RSHT_UK
4Fixate the ange to the chimney fan with the use
of the vibration dampers supplied with the ange.
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
5The fan assembly can now be tted onto the steel
chimney.
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG

18 |UK
Your energy. Optimized.
6
Use the safety wire to secure the fan to the
chimney. Apply the supplied self-cutting screw
in steel chimney. Then mount the wire through
the designated hole in the base plate and into the
wire lock.
Tighten the safety wire slightly and then tighten
the wire lock, so that the chimney fan is secured
when opened for service and cleaning purposes.
The isolation switch should be tted on the side
of the chimney, so it is easily accessible when
servicing the fan.
The armoured cable should be connected into the
underside of the isolator and up into the switch
via the cable gland.
7
Before taking the fan into operation, please make
sure that:
• the nuts in the location brackets have been
tightened.
• the safety wire has been fastened to the fan
and chimney.
• the safety wire and the wire lock have been
tightened.
• the connection on the armoured cable has
been fastened. The armoured cable must hang
straight down from the fan.
• the chimney fan is securely closed.
• when opening/closing the fan, support the
upper part with your hand.
NOTICE! The end-user should be made aware of
the fact that the chimney fan must always remain
switched on when the replace/boiler is in use.
8To avoid rainwater from entering the chimney fan
the slots and holes must be sealed with silicone.

UK |19
3112003_RSHT_UK
Multiple fans on chimney
If two or more chimney fans are required to create sufcient draft, installation procedures are almost the
same as for single fan installation. See the installation guide below.
Multiple fans on a brick chimney
1
If two or more fans are required to create suf-
cient draft, a special adapter plate is required
(not an Exodraft part). The two holes in the plate
should match the throat diameter of the fan
model used and the distance from center to center
should be at least equal to the fan width. Exodraft
recommends that a partition is mounted between
the fans.
The adapter should be sealed with silicone and
bolted onto the top.
When installing multiple fans, it is extremely
important that the fans are of the same model
and size, and they must be controlled in tandem
by one motor speed control.
A similar approach should be taken if the ue size
exceeds the fan base dimensions. The adapter
plate should be sized so it covers the ue and
secured. A hole should be cut in the center of the
plate and the fan mounted centered over the hole.
Multiple fans on a steel chimney
1
If two or more chimney fans are required to create
sufcient draft, the installation procedures are
basically the same as for single fan installation
on a steel chimney. However, as the fans will be
placed next to each other, a special plenum box
will be required (not an Exodraft part).
Exodraft recommends that a partition is mounted
between the fans.
When installing multiple fans, it is extremely
important that the fans are of the same model
and size, and they must be controlled in tandem
by one motor speed control.

20 |UK
Your energy. Optimized.
Electrical installation
The fan and motor specications are provided on the fan’s type plate. All the single-phased fan models are
adjustable in speed.
Wires are to be connected in accordance the wiring diagram. For further details, please see guidelines for
the Exodraft control units.
Any lightning conductor connected to the fan must respect current applicable national legislation.
Exodraft motor Grundfos motor
L
Z2 U1 T2
Z1 U2 T1 4 x 1,0
Power supply
1 x 230V ~ 50Hz
Main
Aux.
Black
Grey
Brown
Yellow / Green
N
Cap.
8765 4 321
L1
N4 x 1,0
Power supply
1 x 230V ~ 50Hz
YEGN
Cap. Brown
Black
Grey
Aux
Main
Wiring
Wiring in the capacitor and repair switch box.
All wiring is done at delivery except for the power supply from the mains or Exodraft control.
For fastening the wires to the terminals use a slotted screwdriver, max. 3 mm wide. Push it hard, straight
down into the marked slot to release the terminal. The wire can now be pushed into the terminal and by
releasing the screwdriver again the wire is secured.
Project:
Material:
Date:
Rev.:
Title:
Rev. No.: Ref.:
Format: A3
Weight:
Approved:
Draw. No.:
Sheet:
PR-0011
Klemblok
25-06-2013
100427
PMN
DS/EN 22768 m
Unless otherwise specified tolerances are after
0,000 kg
RSHT
1 of 2
Max. 3 mm
