ExpertDAQ EX-9543G-MM User manual

EX-9543G-MM/SM
User’s Manual
10/100/1000Base-T to 1000Base SX/LX
Fiber Optic Media Converter
fully compliant with the IEEE
802.3ab 1000Base-T /802.3az
1000Base SX/LX
Standard
10/100/1000TX / 1000FX Fiber Optic
Converter
It is a Gigabit Ethernet 10/100/1000Base-T to Fiber
1000Base-SX/LX Media converter, which is fully compliant
with the IEEE 802.3ab / IEEE 802.3az standard, features
one fiber port using SC / LC connector and one STP RJ-45
10/100/1000Base-T port. It supports conversion of Gigabit
Ethernet port to fiber optic cabling. It is automatic for either
full or half duplex mode. Full-duplex cabling provides
bandwidth of up to 2Gbps and allows for transmission
distance up to 550m over multi-mode fiber or up to 80 km
over single-mode fiber.
EX-9543G-MM/SM supports Link Loss Carry Forward
(LLCF) bi-direction Function, The Converter can detect and
indicate the remote-side copper port or fiber port Link fails,
and force TP and Fiber links down on both side, and when
the Linkage was resumed, it will link again automatically.
EX-9543G-MM/SM also supports upto 9KBytes Jumbo
frame packet to enhance network performance, and
supports Green Ethernet power saving mode for copper
port, It will detect Link status and cable length (for gigabit
links only) and adjust power usage automatically.
Specifications
yIEEE802.3 10Base-T / IEEE802.3u 100Base-TX /
IEEE802.3ab1000Base-T/IEEE802.3z
1000Base-SX/LX IEEE802.3x Flow Control standards
yFeatures STP and Fiber connector
….. RJ45 and SC connector (multi-mode)
….. RJ45 and SC connector (single-mode)
yData Transfer Rate: 10/100Mbps(halfduplex),
20/200Mbps(Full duplex)
1000/2000Mbps (Full duplex)
yAuto-MDIX for 10/100/1000 STP port
ySupport Store-and-Forward and Smart Pass-Through
forward mode.
ySupport upto 9K bytes Jumbo packet size.
ySupport High-performance QoS functions
Four Priority Queues per port
Port-based, 802.1Q-based, DSCP-based
IP-based, ACL-based priority
Weighted round robin service
ySupport 802.1x and 802.31D.
yTX Duplex Mode: Full or Half duplex mode ( default :
Auto-Negotiation )
yLED: Power, speed, FX Link/Act, TX Link/Act and,
LLCF.
yPower Requirement: Max. 2.5 Watt (external switching
power adapter DC5V / 1.5A)

yAmbient Temperature:
0℃to 40℃
yHumidity: 5% to 90% RH(operating)
yDimension: 22(H) x 125(W) x 75 mm (L)
yCable:
UTP: Cat. 5 / Cat. 5e / Cat. 6 UTP/STP cable
Fiber: 1000Base-SX : 50/125um Multi-mode Fiber
optic cable, upto 220M , 62.5/125um multi-mode
Fiber optic cable, upto 550M.
1000Base-LX : 9/125um Single Mode Fiber
Optic cable . upto 120Km , It depends on the
Fiber transceiver.
10/100/1000TX / 1000FX Fiber Optic
Media Converter
Package Contents
Before going any further, please make sure that you have
the following parts in this package.
•One EX-9543G-MM/SM Fiber Optic converter
•One External AC to DC power adapter ( 5V DC 1.5A )
•One user’s manual
NOTE: Please DO NOT use any other power adapter for
EX-9543G-MM/SM.
Panel Contents :
EX-9543G-MM/SM Front Panel
LED Indicator
LED Mark State Description
POWER PWR ON Powerisreceived
OFF Powerisnotreceived
100Mbps 100M ON TP port work on 10M or 100M
speed
1000Mbps 1000M ON TP port work on 1000M speed
TX Link/Act TX ON A TX port good Link status has
been established.
Blinking During Data Transfer or Receiving
FX Link/Act FX ON A FX port good Link status has
been established.
Blinking During Data Transfer or Receiving
LLCF LLCF ON Remote Link Fails was detected
Port Description:
PORT Mark Description
Copper port 10/100/1000TX It is connected to LAN card
or connected to Switch
hub.
Fiber port 1000SX/LX It is connected to other end
of Fiber Optic Transceiver.
**Note : The TX port support Auto-negotiation for
10/100/1000M and Auto-MDI/MDIX capability.
EX-9543G-MM/SM Real Panel
DIP Switches Setting :
DIP 1 ON Enable Jumbo packet 9k bytes Function
DIP 2 ON Enable Gigabit Green Function
DIP 3 ON Set Fiber port work on 100Base-FX mode
( depends on Fiber Transceiver)
DIP 4 ON Enable Link Loss Carry Forward LLCF Function
DIP 5 ON Enable Smart Pass Through Mode
DIP 6 ON Disable Fiber port Auto-Negotiation
( All DIP Switches Default setting are OFF )
Warning : When the setting of DIP switches is changed,
the power gas to be turned OFF and new setting will be
effective after turned power ON again.
Ordering Information:
EX-9543G-MM : 10/100/1000TX to 1000Base-SX/LX
MediaConverter
SC connector, Multi-mode 550M
EX-9543G-SM : 10/100/1000TX to 1000Base-SX/LX
MediaConverter.
SC connector, Single-mode
10/40/60/80Km(optional)
