Extech Instruments HDV-TX2L Dimensions

HDV‐TX2L‐en‐GB_V1.12/16
Productsheet


ModelHDV‐TX2L
ArticulatingSemi‐RigidProbe
ForusewiththeHDV600Borescopeonly

Thankyouforpurchasingthisprofessionalcameraprobe.Thissheetcoversthewarningand
specificationsfortheprobeonly.InstructionsregardingtheusageoftheHDV600Borescopeare
providedintheBorescopeUserGuide.

Note:ThecameraLEDsbecomewarmwhensettomaximumintensity

CAUTION:FortheArticulatingProbe,donotoperatethearticulationknobwiththe
probeinacoiledconfiguration.Thiswilldamagethearticulationcontrols!
CAUTION:Alwaysreturnthearticulationandtensionknobstotheneutralposition
beforeremovingtheprobefromtheinspectionarea.

ThelabelontheprobeprovidestheSerialNumberandPartNumberintheformat
shownbelow.Pleasedonotremovethislabel;otherwisethewarrantywillbeinvalid.

PartNo.TX2LF/M/R(flex/macro/rigid)SerialNo:HDV110001



Warnings

Donotbendtoasmallerdiameterthan10cm(4”)
Warrantyisinvalidifstickers,tags,orlabelsareremoved



ArticulatingProbeDescription
1. Articulationknob
2. Articulationtensionknob
3. Articulatingcamera
4. Extensioncablesocket


12 3
4

HDV‐TX2L‐en‐GB_V1.12/16
ArticulationSetupandOrientation

Thearticulationdirectionandorientationmaychangeiftheprobeistwistedandcoiledduring
useorwhenstored.Tore‐orienttheprobe:
1. Placetheextendedprobeonaflatsurface
2. Setthetension“F”knobtotheleftorreleasedposition.
3. SetthearticulationknobtothecenterpositionwiththeRΔandΔL
labelsinthehorizontalposition.
4. Manuallyadjusttheprobeandcameratothezerodegreeposition.
5. Rotatethearticulationknobclockwisefora90°bend.
6. Ifnecessary,manuallyadjusttheprobesothatthecameralaysflaton
thesurfacewitha90°articulation
7. Rotatethearticulationknobcounter‐clockwiseandconfirmproper
orientation.







Specifications

Resolution640x480pixels
Length2m(6.6’)
Outerdiameter(O.D.)6mm(0.24”)
Focusdistance(depthoffield)6cmto∞(2.36”to∞)
HousingStainlessSteel
FieldofView60º
NumberofLEDs4
LampOutput3500Luxat20mm(0.8”)
OperatingTemperature‐20to70°C(‐4to158°F)
StorageTemperature‐20to70°C(‐4to158°F)
WarrantyOneyear




Copyright©2013‐2016FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
ISO‐9001Certified
www.extech.com


RΔ ΔL
