Extech Instruments HDV-WTX2L User manual

HDV‐WTX2L‐en‐GB_V1.12/16
Productsheet

ModelHDV‐WTX2L
WirelessArticulatingSemi‐RigidProbe
ForusewiththeHDV600Borescopeonly

Thankyouforpurchasingthisprofessionalcameraprobe.Thissheetcoversthewarningand
specificationsfortheprobeonly.InstructionsregardingtheusageoftheHDV600Borescopeare
providedintheBorescopeUserGuide.

Note:ThecameraLEDsbecomewarmwhensettomaximumintensity

CAUTION:FortheArticulatingProbe,donotoperatethearticulationknobwiththe
probeinacoiledconfiguration.Thiswilldamagethearticulationcontrols!
CAUTION:Alwaysreturnthearticulationandtensionknobstotheneutralposition
beforeremovingtheprobefromtheinspectionarea.

ThelabelontheprobeprovidestheSerialNumberandPartNumberintheformat
shownbelow.Pleasedonotremovethislabel;otherwisethewarrantywillbeinvalid.

PartNo.WTX2LF/M/R(flex/macro/rigid)SerialNo:HDV110001

Warnings

Donotbendtoasmallerdiameterthan10cm(4”)
Warrantyisinvalidifstickers,tags,orlabelsareremoved


ArticulatingProbeDescription
1. Articulationknob
2. Articulationtensionknob
3. Articulatingcamera
4. Lightintensitybuttons
5. Powerbutton
6. ACAdaptorjack,chargingLED,&extensioncablesocket
7. Carryingstrap


12 345
6
7
www.calcert.com [e-mail]1.888.610.7664 0
5
10
15
20
25
30

HDV‐WTX2L‐en‐GB_V1.12/16
ArticulationSetupandOrientation

Thearticulationdirectionandorientationmaychangeiftheprobeistwistedandcoiledduring
useorwhenstored.Tore‐orienttheprobe:
1. Placetheextendedprobeonaflatsurface
2. Setthetension“F”knobtotheleftorreleasedposition.
3. SetthearticulationknobtothecenterpositionwiththeRΔandΔL
labelsinthehorizontalposition.
4. Manuallyadjusttheprobeandcameratothezerodegreeposition.
5. Rotatethearticulationknobclockwisefora90°bend.
6. Ifnecessary,manuallyadjusttheprobesothatthecameralaysflaton
thesurfacewitha90°articulation
7. Rotatethearticulationknobcounter‐clockwiseandconfirmproper
orientation.

ChargingtheProbeBattery
Theprobebatterycanbechargedintwoways:
1. Chargetheprobewithitsownchargingcable.TheACchargerportandchargingstatusLED
arelocatedinthebottomaccesscompartment.Connectthechargertotheprobeand
observethecoloroftheLED:Redindicatescharging;Greenindicatesfullycharged.
2. Chargetheprobethroughthecamera.Connectthecameratotheprobeviatheextension
cable(bottomaccesscompartmentjack).Makesurethatthechargingcableisdisconnected
fromtheprobeandthenconnectachargingcabletothecamera.Nowwhilethecamerais
charging,theprobewillchargeatthesametime.
Note:Therechargeablebatteryisnotuserreplaceable.

Specifications

Resolution640x480pixels
Length2m(6.6’)
Outerdiameter(O.D.)6mm(0.24”)
Battery3.7VrechargeableLi‐Polymer
Focusdistance6cmto∞(2.36”to∞)
HousingStainlessSteel
FieldofView60º
NumberofLEDs4
LampOutput3500Luxat20mm(0.8”)
OperatingTemperature‐20to70°C(‐4to158°F)
StorageTemperature‐20to70°C(‐4to158°F)
Warranty1year

Copyright©2013‐2016FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
ISO‐9001Certified
www.extech.com
RΔ ΔL
